Features at a Glance
2
3
Your Range includes:
1.
Electronic oven control with kitchen timer.
2.
Left front burner valve and knob.
3.
Left rear bridge burner valve and knob.
4.
Warmer drawer control.
5.
Center rear burner valve and knob.
6.
Right rear burner valve and knob.
7.
Right front burner valve and knob.
8.
Self-clean door latch.
9.
Oven vent.
10. Broil element.
11. Self-cleaning convection oven interior.
12. Dual convection bake cooking system.
13. Adjustable interior porcelain oven rack(s).
14. Large 1-piece oven door handle.
15. Full width oven door with window.
16. Warmer drawer.
17. Cast iron grates.
18. 21 000 BTU bridge burner.
19. 9 500 BTU regular burner.
20. 5 000 BTU simmer burner.
21. 600 to 18 000 BTU dual burner.
22. Deep drawn cooktop.
17
18
NOTE: The features of your range may vary according to
model type & color.
4
20
19
21
1
8
11
14
14
16
22
7
5
6
9
10
12
13
7
15
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the Elite and is the answer not in the manual?
Questions and answers
How to remove the oven door?
To remove the oven door on a Kenmore Elite:
1. Open the oven door completely until it is horizontal with the floor.
2. Pull the hinge locks on both the left and right door hinges down toward the oven door. Use a small flat-blade screwdriver if needed.
3. Firmly grasp both sides of the oven door along the door sides and lift to remove.
This answer is automatically generated
How do I start the self-cleaning option on my Kenmire Elite stove?
To start the self-cleaning option on your Kenmore Elite stove:
1. Make sure the oven is empty, the oven door is closed, and the clock is set to the correct time.
2. Press the CLEAN button.
3. The default self-cleaning time is 3 hours. To change this, press 2 0 0 for 2 hours or 4 0 0 for 4 hours based on the amount of soil.
4. The oven will begin the cleaning cycle automatically.
Note: A smoke eliminator in the oven vent helps reduce visible smoke.
This answer is automatically generated
