Hobbico Ominus User Manual

Radio controlled quadcopter
Hide thumbs
1
2
3
4
Table of Contents

Advertisement

Quick Links

Download this manual

CHARGING

Plug the charger into a USB port or AC adapter (not included) as shown and connect the battery.
The charger LED is steady on when charging. The LED flashes when charge is complete.
• NEVER leave the battery unattended while charging.
• DO NOT allow the USB port to power down while the
charger is connected to the battery.
• ALWAYS unplug the charger from the USB port and
the battery when charging is complete.

INSTALL BATTERIES INTO RADIO

Remove the screw on the cover for the battery compartment. Slide the cover down and insert 4 AAA batteries.

LINKING

1
1. Turn on the radio with the throttle
at its lowest position.
Spare Blades
(2 black, 2 color)
AAA Batteries (4)
USB Charger
Ominus Quadcopter
Flight Battery
2. Connect the battery to the Ominus and place it on a
level surface. The LED on the quad will flash rapidly
when the quad is linked to the radio and ready to fly.
™
Radio Controlled
Quadcopter
Radio
ALWAYS unplug the
battery after flying!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ominus and is the answer not in the manual?

Questions and answers

Related Manuals for Hobbico Ominus

Summary of Contents for Hobbico Ominus

  • Page 1 ALWAYS unplug the battery after flying! 1. Turn on the radio with the throttle 2. Connect the battery to the Ominus and place it on a at its lowest position. level surface. The LED on the quad will flash rapidly...
  • Page 2 LOW BATTERY INDICATOR The LEDs on the Ominus will flash slowly when the battery voltage is low. The Ominus should land as soon as possible to avoid damaging the battery. Always unplug the battery after flight. The battery needs to be charged before the quadcopter is stored.
  • Page 3 BLADE REPLACEMENT 1. Remove screw that secures the rotor blade to the gear shaft. 2. Pull prop off the gear shaft. FRONT 3. Install new rotor blade and secure with screw. Color Blades, Note: The rotor blades have arrows that indicate which direction they rotate. Please Color LEDs refer to this diagram to verify that the correct replacement rotor blade is installed.

  • Page 4: Replacement Parts

    LED Cover GREEN/CLEAR DIDP1120 USB 1S LiPo Charger 4 DIDE1115 Gear Set 11 DIDE1136 LED Cover RED/CLEAR 5 DIDE1116 Main Gear Shaft 11 DIDE1137 LED Cover BLUE/CLEAR 11 DIDE1138 LED Cover YELLOW/CLEAR dromida.com DIDE01xx Mnl v1.0 © 2014 DROMIDA, A HOBBICO COMPANY...
