Page 1: User Manual
VSP 628PRO User Manual Manual #: RGB-RD-UM-V628PRO E001 Revision:V1.0 This User Manual Applies to VSP 628PRO Series! VSP 628PRO User Manual... - Page 2 No part may be copied, reproduced or translated without permission. Notice RGBlink provides this manual ―as is‖ without warranty of any kind, either expressed or implied, including but not limited to the implied warranties or merchantability and fitness for a particular purpose. RGBlink may make improvements and/or changes to the product(s) and/or the program(s) described in this publication at any time without notice.
- Page 3 30 days after the transfer of risks. In the event of justified notice of compliant, RGBlink can repair the fault or provide a replacement at its own discretion within an appropriate period.
- Page 4 Company Address Xiamen RGBlink Science & Technology Co., Ltd. S603~604 Weiye Building Torch Hi-Tech Industrial Headquarter: Development Zone Xiamen, Fujian Province, P.R.C Shenzhen office: Floor 11, A1 Building, Baiwang R&D Building, Shahe West Road, Xili Town, Nanshan District, Shenzhen, Guangdong Province, P.R.C...
-
Page 5: Power Source
To avoid fire hazard, use only the fuse having identical type, voltage rating, and current rating characteristics. Refer fuse replacement to qualified service personnel. Do Not Operate in Explosive Atmospheres To avoid explosion, do not operate this product in an explosive atmosphere. VSP 628PRO User Manual... - Page 6 Highlights an essential operating procedure, condition or statement. CAUTION The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. VSP 628PRO User Manual...
-
Page 7: Change History
Change History The table below lists the changes to the Video Processor User Manual. Format Time ECO# Description Principal V1.0 2014-12-02 0000# Release Vira VSP 628PRO User Manual... -
Page 8: Table Of Contents
System Overview ..................23 Application Questions .................. 24 2. Hardware Orientation ..............25 In This Chapter .................... 25 VSP 628PRO Back Panel ................26 CONT Interface ...................... 26 1. 10/100M UDP Interface ..................26 2. USB Interface ....................26 INPUT Interface ..................... 27 3：Genlock Input .................... - Page 9 Optional Module ....................29 9: S. V. D. H. U Optional Module ................29 10: F Optional Module/Sending Card Interface ........... 29 VSP 628PRO Front Panel ................31 OLED Panel ......................32 Menu Buttons ....................... 32 Signal keys ......................32 Function ........................
- Page 10 Tech Support ......................45 Factory Reset ......................45 5. Communication Software Guideline ..........46 In This Chapter .................... 46 Software Installation ..................47 Software Operation ..................51 Set up Communication ..................51 Use ........................51 Image Toolbar ....................... 51 VSP 628PRO User Manual...
- Page 11 Single Image Switching ..................62 PIP Setting ......................62 Scale Setting ......................63 Image Size Adjust ....................63 Dimmer and Effects Setting .................. 63 Dual 2K Setting ...................... 64 Mapping of Single VSP 628PRO ................64 VSP 628PRO User Manual...
- Page 12 Signal need to scale ....................78 No Display in the Second Half Part of LED Display ........78 Resolution is Insufficient ..................78 A. Specification .................. 79 B. Contact Information ............... 85 C. Upgrading Software ............... 86 VSP 628PRO User Manual...
- Page 13 USB Upgrade Guideline ................86 WEB SERVER Cross-platform Control Operation Interface ......87 VSP 628PRO User Manual...
-
Page 14: Introduction
Introduction This chapter is designed to introduce you to the VSP 628PRO User Manual. Areas to be covered are: Chapter Structure How to Use This Manual Terms and Definitions System Overview Application Questions VSP 628PRO... -
Page 15: Chapter Structure
1. Introduction Chapter Structure Chapter Structure The following chapters provide instructions for all aspects of VSP 628PRO operations. Chapter 1 Introduction Chapter 2 Hardware Orientation Chapter 3 Hardware Installation Chapter 4 Menu Orientation Chapter 5 Communication Software Guideline Chapter 6... -
Page 16: How To Use This Manual
For system setup and operations, refer to Chapter 6, ―System Setup and Operations‖ on page 59. Should you have any questions regarding the installation or operation of VSP 628PRO, please consult with the factory. Refer to Appendix B, ―Contact information‖ on page 85. VSP 628PRO... -
Page 17: Terms And Definitions
Telecommunications Wiring Standard. “Color bars”: A standard test pattern of several basic colors (white, yellow, cyan, green, magenta, red, blue, and black) as a reference for system alignment and testing. In NTSC video, the most commonly VSP 628PRO User Manual... - Page 18 “Frame”: In interlaced video, a frame is one complete picture. A video frame is made up of two fields, or two sets of interlaced lines. In a film, a frame is one still picture of a series that makes up a motion picture. VSP 628PRO User Manual...
- Page 19 For this reason, the hue control is not needed on a PAL TV set. PAL, in many transmission forms, is widely used in Western Europe, Australia, Africa, the Middle East, and Micronesia. PAL uses 625-line, VSP 628PRO User Manual...
- Page 20 This is a 10-bit, scrambled, polarity independent interface with common scrambling for both component ITU-R 601 and composite digital video and four channels of (embedded) digital audio. “Seamless Switching”: A feature found on many video switchers. This VSP 628PRO User Manual...
- Page 21 31.5 kHz and vertical frequency of 70 Hz (Mode 1, 2) and 60 Hz (Mode 3). The signal is non-interlaced in modes 1, 2, and 3 and interlaced when using the 8514/A card (35.5 kHz, 86 Hz) in mode 4. It VSP 628PRO User Manual...
- Page 22 640×480 with a color palette of 16 bits and 256,000 colors. “YCrCb”: Used to describe the color space for interlaced component video. “YPbPr”: Used to describe the color space for progressive-scan (non-interlaced) component video. VSP 628PRO User Manual...
-
Page 23: System Overview
LOGO capture and standard test pattern built in, 3D processing, HDCP and EDID management, Web page control interface seamless switching between the inputs, VSP 628PRO is one of the most advanced and flexible signal processor in the industry. -
Page 24: Application Questions
1. Introduction Application Question Application Questions RGBlink offers solutions to demanding technical problems. Any application questions, or required further information, please contact with our Customer Support Engineers. Refer to Appendix B for contact details. VSP 628PRO User Manual... -
Page 25: Hardware Orientation
Hardware Orientation In This Chapter This chapter provides detailed information about the VSP 628PRO hardware. The following topics are discussed: VSP 628PRO Back Panel VSP 628PRO Front Panel VSP 628PRO User Manual... -
Page 26: Vsp 628Pro Back Panel
2. Hardware Orientation VSP 628PRO Back Panel VSP 628PRO Back Panel The figure below illustrates the professional interface and control signals of VSP 628PRO back panel. INTERFACE INTERFACE 10/100M Interface HDMI Input USB Interface HDMI Loop Out Genlock Input Displayport Input... -
Page 27: Input Interface
Genlock loop out, connect to the Genlock input of the next VSP 628PRO or the device with Genlock input. 6.8：SDI Loop Out SDI loop out, connect to the SDI input of the next VSP 628PRO or the VSP 628PRO User Manual... -
Page 28: Dvi Loop Out
VSP 628PRO Back Panel device with SDI input. 12：DVI Loop Out DVI loop out, connect to the DVI input of the next VSP 628PRO or the device with DVI input. 14：HDMI Loop Out HDMI loop out, connect to the HDMI input of the next VSP 628PRO or the device with HDMI input. -
Page 29: Optional Module
Computer, etc. input signal via the DB15 interface. DVI Input (D Optional Module): Input the video signal from computer, DVI signal generator. Connect to the same DVI interface on VSP 628PRO. (This Connection does not support hot-plugging). HDMI Input (U Optional Module): Input the image signal from computer. - Page 30 2. Hardware Orientation VSP 628PRO Back Panel SDI Output: Connect to the device with SDI input. HDBaseT Output: RJ45 interface. Connect one end of the CAT5e or CAT6 cable to RJ45 interface, and the other end to HDBaseT input interface of MSP 215 extender or other device.
-
Page 31: Vsp 628Pro Front Panel
VSP 628PRO Front Panel Insert power cord and push power to ON position. OLED module on the front panel will show RGBLINK and go into self verification before it load last setting config and send processed image to the target monitor. For the first setup, DVI1 input is default source. -
Page 32: Oled Panel
2. Hardware Orientation VSP 628PRO Front Panel VSP 628PRO front panel as following: OLED Panel Used to show button menu and menus for interactive communication. Menu Buttons Used to adjust OLED menu and information interaction and with the same function with enter to confirm current options. -
Page 33: Function
2. Hardware Orientation VSP 628PRO Front Panel VGA input selection button, its LED light turns on, output will be switched to this channel. Optional module input selection button 7, push the button, its LED light is on, output will be switched to optional module channel 1. - Page 34 2. Hardware Orientation VSP 628PRO Front Panel Dimmer adjust button, push the button, its LED light turns on, and enable the dimmer function, the adjustment range is among 0~100. User can also choose effects and set the brightness, contrast and so on. User can also choose CHA or CHB by pushing [DIMMER] button.
-
Page 35: Hardware Installation
Hardware Installation In This Chapter This chapter provides comprehensive installation instruction for VSP 628PRO hardware: Following is the size of VSP 628PRO for your reference. VSP 628PRO User Manual... -
Page 36: Safety Precautions
If there is damage, notify the shipping carrier immediately for all claims adjustments. Site Preparation The environment in which you install your VSP 628PRO should be clean, properly lit, free from static, and have adequate power, ventilation, and space for all components. -
Page 37: Menu Orientation
Menu Orientation In This Chapter This chapter describes all VSP 628PRO processor menus, including how they are accessed, the functions that are available, and descriptions of each menu tree (in block diagram format). The following topics are discussed: • MENU ... -
Page 38: Menu
Push the [MENU] button to enter the menu items, shown as below: Turn the knob to select menu items. -> before the menu means it is in selected state. Push the knob to enter corresponding setting or view the menu. VSP 628PRO User Manual... -
Page 39: Input
Aspect Ratio: User can set the mode and choose the ratio. Sizing Adjust: Settings including as follows: H Size: Zoom the width V Size: Zoom the height. H Pos: Horizontal phase setting. V Pos: Vertical phase setting. VSP 628PRO User Manual... -
Page 40: Output
Reset Mask: If image quality distorts by improper operation, it can be recover by reset mask. VGA Adjust: Adjust VGA input signal, VSP 628PRO support auto adjust VGA input signal include H POS, V POS, CLOCK, PHASE, auto adjust to display in full screen image. - Page 41 And system default as 10 bit, user can also choose 8 bit or 12 bit. Data range: DVI out range adjustment can choose RGB or YCBCR; among them the RGB adjusting range is between 0~255, YCBCR adjusting range VSP 628PRO User Manual...
-
Page 42: Custom Formats
Genlock: User can enable or disable the genlock function. Custom Formats The special display project or LED display application would like to require special resolution settings to meet the requirement. Details please refer to the instructions in the manual: How to customized output resolution. VSP 628PRO User Manual... -
Page 43: Views
SAVE TO: Push the [LEFT/RIGHT] button to choose the save channel. Recall: Turn the knob to choose the recall the save mode. Save: Turn the knob to choose the save channel, VSP 628PRO supports 23 kinds of save modes. Delete: Delete the save mode. -
Page 44: Logo
<Display Setup>, push the knob to confirm, show level 2 menu as follows: Display Brightness: Display brightness setting, including: Brightness: Brightness setting, the adjustment range is 0~10. Calibration: Calibrate the brightness, the adjustment range is 0~10. VSP 628PRO User Manual... -
Page 45: Test Pattern
628PRO is reset to its factory settings. After 5 seconds, it completes factory settings and is ready for more operations. Note All the items marked <N/A> is the functions not avail, we will complement it with the functional improvement. VSP 628PRO User Manual... -
Page 46: Communication Software Guideline
Communication Software Guideline In This Chapter This chapter provides detailed information about the control communication software. The following topics are discussed: Software Installation Software Operation VSP 628PRO User Manual... -
Page 47: Software Installation
Also it can be customized with schedule function. Double click to install, English version default for use, click ―Next‖ to next dialog: And in next dialog is the user agreement of the software, click Agree to go VSP 628PRO User Manual... - Page 48 5. Communication Software Guideline Software Installation User can select ―Change‖ to choose the VSP 628PRO install software: VSP 628PRO User Manual...
- Page 49 5. Communication Software Guideline Software Installation Click ―Next‖ to go on: Click ―Next‖ to go on: VSP 628PRO User Manual...
- Page 50 5. Communication Software Guideline Software Installation Click ―Next‖ to go on: Click ―Finish‖ and ready to run VSP 628PRO console: VSP 628PRO User Manual...
-
Page 51: Software Operation
5. Communication Software Guideline Software Operation Software Operation Install communication which comes with the package of VSP 628PRO device. Double click icon from home screen and choose to run the software. VSP 628PRO communication software interface as shown: Set up Communication Connect the computer and windows control program with the network cable or USB cable, it will automatically connect without setting. -
Page 52: Basic
Set the X, Y, Width and Height of Screen Parameter B according to actual need. Click ―Set‖ after finish. Choose the window mode by selecting from scrolling down list. VSP 628PRO support standard mode, dual 2K and Switcher. VSP 628PRO User Manual... -
Page 53: Image
Enable or disable the H Mirror or V Mirror function. Set the hue of the image according to actual need. Click ―Set‖ after finish. Set the chroma of the image according to actual need. Click ―Set‖ after finish. VSP 628PRO User Manual... - Page 54 Click ―Take‖, the image will be switched to the LED display with seamless effect. Enable the gamma function and set the gamma value by selecting from scrolling down list. Set the ratio mode by selecting from scrolling down list. VSP 628PRO User Manual...
-
Page 55: Input
Image 2: The operation is same with image 1. Input Interface is as follows: Set the input format by selecting from scrolling down list. Scale the image according to actual need, click ―Set‖ after finish.. VSP 628PRO User Manual... -
Page 56: Output
DVI setting, including output type, color range and bits. HDM setting, including output type, color range and bits. User Mode Interface is as follows: Choose the save mode by selecting from scrolling down list. VSP 628PRO supports 23 kinds of save modes. VSP 628PRO User Manual... -
Page 57: Control
5. Communication Software Guideline Software Operation Choose the load mode by selecting from scrolling down list. VSP 628PRO supports 23 kinds of save modes. Control Synchronization: Refresh the current page. Device Update Factory Setup: Click ―Factory Setup‖, previously saved user mode will be cleared. -
Page 58: Help
Version Explain: Show the content of software update history. About: Show software version and company information. Information Toolbar It shows the VSP 628PRO connection state, software version and serial number in the bottom of the software interface. VSP 628PRO User Manual... -
Page 59: System Setup And Operations
How to Realize the Test Pattern Setting How to Realize LAN Remote Control Setting How to Realize WEB SERVER Cross-platform Setting How to Save the parameter How to Load the Saved Parameter VSP 628PRO User Manual... -
Page 60: Interface And Input Signal Option
4.6.8.12.14. Loop output interface of the signal source, it can output the input signal without any treatment and change. This is the advantage of VSP 628PRO. Any input signal can be realized without changing its format, and output the original image. - Page 61 Interface and Input Signal Option In addition to CONT part and the sending cards and the power and the interface above-mentioned, the other interfaces are video signal input interface, including Genlock, 3G-SDI, DVI, HDMI, Displayport and VGA. VSP 628PRO User Manual...
-
Page 62: How To Realize The System Mode Setting
VSP 628PRO supports seamless switch in single image and double images. Push the [PIP] button, the button light is on, and enable the PIP function. Choose the signal in PIP: VSP 628PRO can output two same or different signals to the LED display, the settings are as follows: VSP 628PRO... -
Page 63: Scale Setting
Dimmer and Effects Setting Push the [DIMMER] button, and enter to the menu items, user can set the dimmer and effects. The adjustment value range of dimmer is 0~100. The setting for effects include brightness, contrast, chroma, hue, color VSP 628PRO User Manual... -
Page 64: Dual 2K Setting
<Channel select>, turn the knob to choose CHB. Then choose the signal, CHB will switch to the selected signal. In addition, dual 2K can realize max 4K×1K mapping of single VSP 628PRO and Multiple synchronization mapping, the operations are as follows:... -
Page 65: Multiple Synchronization Mapping
All the settings above are for preview, push [TAKE] button after setting, and the preview image will be cut or fade in fade out to the program. VSP 628PRO User Manual... -
Page 66: How To Do Customized Output Resolution
× is the refresh rate. Only digital 50 or digital 60 supports for the refresh rate. For example, input 60 as following. Use the digital buttons to finish the settings. Custom Formats —>1536×1536×60.0 VSP 628PRO User Manual... - Page 67 6. System Setup and Operations How to Do Customized Output Resolution 4. After input all the values, push the knob to enable VSP 628PRO to output output this resolution. VSP 628PRO will take 5~10 seconds to enable this output resolution.
-
Page 68: How To Realize The Test Pattern Setting
AOI Raster Box: User can choose enable or disable the AOI raster box function. If choose ―ON‖, user can choose the types including Box X, Box Y, Box Width and Box Height. If image quality distorts by improper operation, it can be recover by reset. VSP 628PRO User Manual... -
Page 69: How To Realize Lan Remote Control Setting
No limitation for router’s model and brand, such as VPN router model: Netcore 255 or 266; Volans VE 760W or 982W). ③One VSP 628PRO processor (as long as the router’s network ports can connect to, user can place multi pieces of VSP 628PRO). - Page 70 Push the [MENU] button on front panel and go into items as below picture shows. Change processor’s IP to be 192.168.1.100, confirm and restart the processor, then user can directly control on VSP 628PRO via windows control software. Method two: Change router’s gateway.
- Page 71 Go to router setting part and find out ―LAN port setting‖, change the default value ―192.168.1.1‖ to be ―192.168.0.1‖. Save the setting and restart the router, then user can directly control on VSP 628PRO via windows control software. VSP 628PRO...
-
Page 72: How To Realize Web Server Cross-Platform Setting
First, the formation of LAN Remote Control Platform: one Ipad or one Iphone, one router (with wireless functions, for example with a wireless-enabled VPN router models: Netcore 255 and 266. Volans VE760W, 982W.), one VSP 628PRO processor (can be more processors, as long as the network interface can be connected to the router) - Page 73 6. System Setup and Operations How to Realize WEB SERVER Cross-platform Setting After connection successfully, Web page appears as VSP 628PRO system control interface. Click on the toolbar below the control interface, then accesses setup menu, now WEB control on VSP 628PRO is available.
-
Page 74: How To Save The Parameter
How to Save the Parameter How to Save the Parameter VSP 628PRO provides 23 kinds of save modes, the settings are as follows: 1. Push the [MENU] button to enter to the menu items, turn the knob, choose <View>, push the knob to confirm. -
Page 75: How To Load The Saved Parameter
How to Load the Saved Parameter How to Load the Saved Parameter VSP 628PRO provides 23 kinds of save modes, the settings are as follows: 1. Push the [MENU] button to enter to the menu items, turn the knob, choose <View>, push the knob to confirm. -
Page 76: Common Questions And Solution
The following topics are provided: No Output in LED Display Flash Point in LED Display Output LED Display only Shows Part of the Image No Display in the Second Half Part of LED Display VSP 628PRO User Manual... -
Page 77: No Output In Led Display
If display normally shows and no flash point, please check whether DVI outlets put tight or replace to DVI line of sending card. If display flashes point, please judge if input signal, wire, and interface are normal. VSP 628PRO User Manual... -
Page 78: Led Display Only Displays Part Of The Image
Resolution is Insufficient Please make sure the points of the screen width and height, choose the resolution to be bigger than screen width via push [MENU] button to find [OUTPUT FORMAT], and push SEL button to confirm. VSP 628PRO User Manual... -
Page 79: Specification
Number of Inputs Connector Standard DVI-I socket Supported SMPTE: 625/25/50 PAL, 525/29.97/59.94 NTSC, Resolution 1080P50,1080P59.94/60,1080i50,1080i59.94/60, 720p50,720p59.94/60 VESA: 800×600@60Hz, 1024×768@60Hz, 1280×768@60Hz, 1280×1024@60Hz, 1600×1200@60Hz, 1920×1080@60Hz Signal Level TMDS pwl, single pixel input,165MHz bandwidth Format Standard HDMI 1.3 DP (Displayport) Input VSP 628PRO User Manual... - Page 80 Belden 1694A cable: 150m at 2.97Gb/s Balance 250m at 1.485Gb/s 480m at 270Mb/s HDMI Loop Out Number of Loop Out Connector HDMI standard type A interface Supported SMPTE: 625/25 PAL, 525/29.97 NTSC, 625/50p PAL, Resolution 525/59.94p NTSC VSP 628PRO User Manual...
- Page 81 625/25 PAL, 525/29.97 NTSC, Resolution 720p50/59.94/60, 1080i50/59.94/60, 1080p23.98/24/25/29.97/30, 1080P50/59.94/60 Format Standard HDMI 1.3 VGA Output Number of Outputs Connector Standard DB15 Socket Supported VESA: Resolution 800×600@60, 1024×768@60, 1024×768@75, 1024×768@85, 1280×720@60, 1280×768@60, 1280×800@60, 1280×1024@60, 1360×768@60, 1366×768@60, 1400×1050@60, 1440×900@60, 1600×1200@60, VSP 628PRO User Manual...
- Page 82 Number of Inputs Connector Standard DVI-I socket SMPTE：625/25/50 PAL, 525/29.97/59.94 NTSC, Supported Resolution 1080P50,1080P59.94/60,1080i50,1080i59.94/60, 720p50,720p59.94/60 VESA：800×600@60Hz, 1024×768@60Hz, 1280×768@60Hz, 1280×1024@60Hz, 1600×1200×60Hz, 1920×1080×60Hz Signal Level TMDS pwl, single pixel input,165MHz bandwidth Format Standard HDMI 1.3 SDI Input (Optional Module) VSP 628PRO User Manual...
- Page 83 Choose 1 in 2 Channels Format Standard HDMI 1.3 Function Input channel Support each input channel signal programming configuration configuration Support PIP、PBP for any two inputs Transition effects Fade in and fade out switching between any two inputs VSP 628PRO User Manual...
- Page 84 Extras Communication USB TCP/IP Power Supply 85-264V IEC-3 Working 0° C~45° C Environment Stored Environment 10% to 90% Product Warranty 3-year parts and labor warranty VSP 628PRO User Manual...
-
Page 85: Contact Information
All video products are designed and tested to the highest quality standard and backed by a full 3-year parts and labor warranty. Warranties are effective upon delivery date to customer and are non-transferable. RGBlink warranties are only valid to the original purchase/owner. Warranty related... -
Page 86: Upgrading Software
, shown as below: 5. User need not to install the driver, after the windows control program auto identification the VSP 628PRO, the interface will show ―Down Load‖ button. 6. If the windows control program can not auto identification, the button is gray. - Page 87 If users use Ipad or Iphone, they can input the website 192.168.0.100 (default) or 192.168.0.231 in Safari browsers to operate. If users need to modify VSP 628PRO IP address, they can input corresponding modified IP address. If users use other device, they need to install webkit kernel browser, such as: apple Safari, Google Chrome or Maxthon.
- Page 88 Step 4: Select "Image" icon in title bar to scale the image, user can modify digital setting parameters and image size and position easily through "-+" icon. Click "Set" after modify the digital, VSP 628PRO image will display the latest Settings.
- Page 89 User can preset the image mode that switch the current single picture mode to double-picture mode and the position of the two images in the mode. Drag the slider rolling ball, when the slide block is green, pip starts. VSP 628PRO User Manual...
- Page 90 , the selected image with blue stripes, tick, as shown below: image2 is selected, all settings will for image 2. For example, you can switch "Input" icon in title bar to choose image 2 input source. VSP 628PRO User Manual...
- Page 91 Nonprofessional isn’t recommend to the above operations, if distortion of image quality as of improper operation errors, you can reset to the factory initialization. VSP 628PRO User Manual...
- Page 92 Step 8: Save and Call function. User can save the parameters to UserMode1 and UserMode2, and can also load UserMode1 and UserMode2 that saved before. VSP 628PRO User Manual...
- Page 93 Click "Set" after select the language (such as select Chinese), pay attention to system prompt "Language will effect after the next time and after reboot IP will affect" (at green box); Now you need to refresh the page to complete the setting. VSP 628PRO User Manual...
- Page 94 ->Ethernet->IP, it will take effect after restart the device. Reset: If appear wrong operation, click "Reset" to factory default. Key Lock: If slide block is gray, it is unlock, and VSP 628PRO keys can normally operate. And if slide block is green, the VSP 628PRO keys locked, and user can't operate any button.
- Page 95 VSP 628PRO User Manual...
