Item Symbol
1
2
3
4
5
6
7
8
9
10
11
12
099-005320-EW501
22.05.2014
Machine description – quick overview
Description 0
Key button, Automatic cutout
Wire feed motor supply voltage fuse
(press to reset a triggered fuse)
Connection socket, 7-pole
Connection for peripheral devices with digital interface
7-pole connection socket (digital)
Wire feed unit connection
Connection socket, "+" welding current
•
Standard MIG/MAG welding (intermediate hose package)
Connection socket, "-" welding current
Connection for welding current plug from intermediate hose package
•
MIG/MAG flux cored wire welding
•
TIG welding
Stirrup
Intermediate hose package strain relief
Cooling air outlet
8-pole connection socket
Cooling unit control lead
4-pole connection socket
Cooling unit voltage supply
Mains connection cable
PC interface, serial (D-Sub connection socket, 9-pole)
19-pole mechanised welding interface (analogue)
(See chapter entitled "Design and function > interfaces".)
Rear view
