OWNER'S MANUAL
WHAT TO DO IF YOU SMELL GAS
• Open windows/extinguish any open flame.
• Do not try to light any appliance.
• Do not touch any electrical switch or use any phone
in your building.
• Immediately call your gas supplier from a neighbour's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
Massachusetts installations (Warning): This product must be installed by a licensed
plumber or gas fitter when installed within the Commonwealth of Massachusetts.
Other Massachusetts code requirements: Flexible connector must not be longer than
36in, shut off valve must be a "T" handle gas cock; only direct vent sealed combustion
products are approved for bedrooms/bathrooms; fireplace dampers must be removed
or welded in the open position prior to the installation of a fireplace insert or gas log.
Accent 20 BV
B Y : S H E R W O O D I N D U S T R I E S L T D
This appliance is only for use
with the type of gas indicated
on the rating plate. This
appliance is not convertible for
use with other gases, unless a
certified kit is used.
FOR YOUR SAFETY
Do not store or use gasoline
or other flammable vapours
and liquids in the vicinity of
this or any other appliance.
WARNING
If the information in this manual
is not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of
life. Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
50-304
