Enviro C34 Instruction Manual

C series cool surface system side vent (50-3455)
Hide thumbs Also See for C34:

Advertisement

Table of Contents

PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
C Series
Cool Surface System
S I D E V E N T [ 5 0 - 3 4 5 5 ]
INSTRUCTION MANUAL
This Cool Surface System has been tested for compliance to Standards:
ANSI Z21.88-2014 and CSA Z2.33-2014.
This Cool Surface System has been approved for use on the ENVIRO C34/44/60 Direct Vent
fireplaces only and must be installed at the time of fireplace installation.
The following instructions must be followed in conjunction with the fireplace installation
instructions to comply with the standards and allow safe operation of the installed fireplace.
4001609
1
50-3455
Version Française: www.enviro.com/fr.html

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C34 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Enviro C34

Summary of Contents for Enviro C34

  • Page 1 This Cool Surface System has been tested for compliance to Standards: ANSI Z21.88-2014 and CSA Z2.33-2014. This Cool Surface System has been approved for use on the ENVIRO C34/44/60 Direct Vent fireplaces only and must be installed at the time of fireplace installation.

  • Page 2: General Information

    Please refer to Figure 1 to ensure that all CSS parts are accounted for and have not been damaged. Item Description Item Description Item Description Top Standoff C34 Main Wall C44 Extension Main Body C60 Extension Bag of Screws Trimable Deflector Vent Collars Figure 1. Cool Surface System Side Vent - Parts Diagram...
  • Page 3 Dimensions 12.18 1.39 14.92 13.64 8.00 0.50 8.00 7.47 11.74 Figure 2. Cool Surface System Side Vent- Overall Dimensions 36.00 0.49 36.00 26.00 2.00 9.95 0.50 0.50 Figure 3. Combustible Facing Kit - Overall Dimensions...

  • Page 4: Framing And Clearances

    & r ront raming ough pening Min Framing and rough opening for C-Series. C44 Shown. C34 = 45” (114cm) C44 = 55” (140cm) C60 = 71” (180cm) Min. Height 51-3/8” ( 130cm) Figure 4. C-Series - CSS Front Framing & Rough Opening...
  • Page 5 Framing & Clearances QUALIFIED INSTALLERS ONLY inimum learanCes orizontal nstalation minimum vent The CSS has been designed to allow for installations where a vertical run of vent is required without having to jog the vent pipe around the CSS. The horizontal vent shield supplied with the fireplace is not required (see Owner’s Manual) when vertically venting and the vent pipe can simply be run straight up between the side vents of the CSS.
  • Page 6 Framing & Clearances QUALIFIED INSTALLERS ONLY inimum learanCes vertiCal vent minimum vent The CSS has been designed to allow for installations where a vertical run of vent is required without having to jog the vent pipe around the CSS. The horizontal vent shield supplied with the fireplace is not required (see Owner’s Manual) when vertically venting and the vent pipe can simply be run straight up between the side vents of the CSS.

  • Page 7: Initial Installation

    Initial Installation QUALIFIED INSTALLERS ONLY evised antel equirements Refer to Figure 7, 8 for a combustible mantel installation, measurement is from bottom of the unit to the bottom of the mantel. If you are planning on installing a TV above the fireplace refer to page 9 to see the options available. Note: Minimum height of mantle if you intend on using a surround is 31”...
  • Page 8 Initial Installation QUALIFIED INSTALLERS ONLY Min. Height to Ceiling 55-1/16” (1399cm) 12” (305mm) 8” (203mm) 4” (102mm) 33“ 2-1/16” (84cm) (75cm) 31 “ (79cm) Min. Height For Surround 29 “ (74cm) Figure 8. Mantle Instalation...

  • Page 9: Installation

    Installation Installation and service must be performed by a qualified installer, service agency or the gas supplier. tv i nstallation onsiderations If you are planning to mount a TV above your fireplace some considerations must be made to ensure it is protected from the heat. During testing temperatures did not exceed 121°F (49°C) midway up the front wall (Figure 9 &...
  • Page 10 It comes in the length required to fit a C60 and must be trimmed to fit either the C44 or the C34. Notches on the top and bottom of the trimable deflector show where to cut it. The first notch on the far left will size it for a C44 and the second notch will size it for a C34.
  • Page 11 Step 2: All the Units use the C34 panel as a base. If installing a C44, use both the C34 and C44 panels. If installing a C60, use both the C34 and C60 panels. Once you have your required panels locate the flanges in the figure 14 below.
  • Page 12 Step 4: Make sure all your hand bend flanges are bent prior to assembly and that you have the correct length deflector before instalation to the unit. Step 5: If installing a C44 or C60, attach your extension piece to the C34 main panel. Step 6: Attach your deflector to your panel configuration as shown below.
  • Page 13 Installation QUALIFIED INSTALLERS ONLY ombustible aCing ptional Before installing your chosen facing material, a 1/2” base layer must be placed over the framing up to the Combustible Facing Kit assembly as shown below. Up to a 1” thick material may be placed on top of the base layer and the combustible facing kit assembly afterwards.
  • Page 14 Installation QUALIFIED INSTALLERS ONLY Prior to installing your Cool Surface System Side Vents you will need to set up your Side Vents in the configuration required for your instalation. A T20 screwdriver is required for assembly and dissaembly. Step 1: Pop off your front bezel from the side vent. Its retained by clips on both sides. Step 2: Remove the the grill by removing the 4 T20 screws.
  • Page 15 Installation QUALIFIED INSTALLERS ONLY Step 6: Fasten the top standoff to the Side Vent body using your T20 screwdriver and T20 screws provided. Step 7: Place your block off plates on the sides of the side vent body not in use. NOTE: The Cool Surface Systme will not fucntion properly if the block of plates are not installed.
  • Page 16 Installation QUALIFIED INSTALLERS ONLY Step 8: Connect the required lengths of 5” dia. stainless steel or aluminium flex vent (not supplied) to the duct collar registers. Secure the venting to the collars using either sheet metal screws or band clamps. Both side vents of the CSS must be connected to the fireplace via 5” dia. flex vent. Feed the flex vent through the CSS Side vent body.

  • Page 17: Replacement Parts

    Replacement Parts Item Description Part Number Side Vent Duct Collar 50-3483 Side Vent Grill 50-3484 Side Vent Front Bezel 50-3485 Vent Collars (Set of 2) 50-3309 CSS Side Vent Instruction Manual 50-3482...
  • Page 18 Notes...
  • Page 19 Learn more about our products at ƒ Detailed Product Lineup ƒ Model Photo Galleries ƒ Downloadable Manual PDF’s ƒ Unit Comparison Charts ƒ Youtube Burn Example Videos ƒ Online Brochures ƒ Dealer Locator Tool...
  • Page 20 MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.enviro.com October 10, 2017 C-15196...
