Enviro ACCENT 25BV Owner's Manual

Enviro ACCENT 25BV Owner's Manual

Gas fired vented room heater
Hide thumbs
Table of Contents

Advertisement

Quick Links

SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY
THIS MANUAL IS PRINTED ON RECYCLED PAPER
O W N E R S M A N U A L
WHAT TO DO IF YOU SMELL GAS
• Open windows/Extinguish any open flame
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire
department.
Do not store or use gasoline or other Flammable vapors and liquids
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
A C C E N T 2 5
FOR YOUR SAFETY
in the vicinity of this or any other appliance.
B y S H E R W O O D I N D U S T R I E S L T D .
WARNING
If the information in this
manual is not followed exactly,
a fire or explosion may result
causing property damage,
personal injury or loss of life.
Installation and service must
be performed by a qualified
installer, service agency or the
gas supplier.
B V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACCENT 25BV and is the answer not in the manual?

Questions and answers

Related Manuals for Enviro ACCENT 25BV

Summary of Contents for Enviro ACCENT 25BV

  • Page 1 SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY THIS MANUAL IS PRINTED ON RECYCLED PAPER A C C E N T 2 5 B y S H E R W O O D I N D U S T R I E S L T D . O W N E R S M A N U A L WARNING WHAT TO DO IF YOU SMELL GAS...

  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS FOR SAFE INSTALLATION AND OPERATION OF YOUR "ENVIROGAS" HEATER, PLEASE, CAREFULLY READ THE FOLLOWING INFORMATION: • All "ENVIROGAS" gas-fired appliances must be • installed in accordance with these instructions. To prevent injury do not allow anyone who is Carefully read all the instructions in this manual first.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SECTION PAGE Code Approvals Dimensions and Clearances to Combustibles Venting Assembly and Installation Instructions Electrical Requirements Gas Line Connection and Testing Installation of Log Sets and Embers and Brick Panels Operating Instructions Routine Maintenance and Service Fuel Conversion Trouble Shooting Parts and Accessories Warranty...
  • Page 4 CODES AND APPROVALS CONTINUED RE: CONVERSION OF ZERO CLEARANCE FACTORY BUILT FIREPLACES The following instructions cover Sherwood Industries Ltd. policy for Gas-Fired Appliances (inserts) to be retofitted into existing factory built fireplaces with replacement parts removed. GENERAL REQUIREMENTS Background A gas fired insert is approved for use in an existing masonry or a listed factory built fireplace without any alterations.

  • Page 5: Dimensions And Clearances To Combustibles

    2. DIMENSIONS AND CLEARANCES TO COMBUSTIBLES DISTANCE TO COMBUSTIBLES: Mantel pillar to surround panel 2" / 5.08 cm Floor to 8" wide mantel 40" / 101 cm Minimum non-combustible surface in front of unit 8" / 20.8 cm OTHER DIMENSIONS A.
  • Page 6 3.VENTING FIREPLACE INSERTS WARNING: Operation of this heater when not connected to a properly installed and maintained venting system can result in carbon monoxide (CO) poisoning and possible death. The Envirogas ACCENT 25 may be installed and vented into any solid fuel fireplace that has been installed in accordance with the National, Provincial/State and local building codes and has been constructed of non-combustible materials.

  • Page 7: Assembly And Installation Instructions

    4. ASSEMBLY AND INSTALLATION INSTRUCTIONS ASSEMBLING AND INSTALLING YOUR ENVIROGAS ACCENT 25 1. Remove the unit from it’s box DRAFT HOOD 2. Open the door, by first removing the cover with the nameplate ADJUSTMEN attached (open valve door and pull nameplate cover SCREWS side tab to release catch), undo the two bolts at the bottom of the door.

  • Page 8: Electrical Requirements

    5. ELECTRICAL REQUIREMENTS The ACCENT 25 will operate without electrical power. This model has a Millivolt gas control which uses the pilot flame to generate enough electricity to operate the main burners. The appliance when equipped with blower must be electrically connected and grounded in accordance with local codes or in the absence of local codes, with the current CSA C22.1 CANADIAN ELECTRICAL CODE Part 1, SAFETY STANDARDS FOR ELECTRICAL INSTALLATIONS, OR THE NATIONAL ELECTRICAL CODE ANSI / NFPA 70 in the U.S.

  • Page 9: Gas Line Connection And Testing

    6. GAS LINE CONNECTIONS and TESTING WARNING: Only persons licensed to work with gas piping may make the necessary gas connections to this appliance. GAS LINE CONNECTION • This stove is equipped with a 3/8 x 3 inch black iron nipple located on the right side of the unit terminating in a 3/8" male NPT fitting.
  • Page 10 7. INSTALLATION OF LOGS, EMBERS and BRICK PANELS REMOVING AND INSTALLING THE BRICK PANELS INSTALLING THE GLOWING EMBERS and LOGSET A bag of ceramic fiber embers is provided for use on the burner PAN. Open the door. Remove the log set. CAUTION: Use only the type of ember material supplied Optional ceramic panels: Remove burners.

  • Page 11: Operating Instructions

    8.OPERATING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE OPERATING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. • If you cannot reach your gas supplier, call the A) This appliance is equipped with a pilot, which must be lit by hand by following these instructions exactly.

  • Page 12: Routine Maintenance And Service

    9. ROUTINE MAINTENANCE and SERVICE Periodically check to ensure that your system is clean. After carefully replacing the log and embers in their correct positions, and the door has been resealed, re-light the Periodically check the pilot and burner. Check to see that pilot, following the instructions on the attached label.

  • Page 13: Fuel Conversion

    10.FUEL CONVERSION “Warning” This conversion kit shall be installed by a qualified service technician in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instructions is not followed exactly, a fire, explosion or CO poisoning may result.

  • Page 14: Trouble Shooting

    11. TROUBLE SHOOTING Problem Possible Cause Solution Spark will not arc to the pilot after Defective piezo ignitor Check connections to ignitor repeated pressing of spark ignitor -If ignitor connections are good but there is no spark-replace ignitor Broken spark electrode -Check for broken ceramic insulation replace, electrode if broken Miss-aligned spark electrode...

  • Page 15: Parts And Accessories

    12. PARTS AND ACCESSORIES Service Parts available from your local Envirogas Dealer. PART # DESCRIPTION EG25-001 Convection Blower EG25-002 Heyco Strain Relief EG25-003 Fan Controller with Knob EG25-004 Hi-Temperature Electrical Cord EG25-008 Burner Switch EG25-014 120°F Ceramic Auto Reset n/o Temp Sensor (big foot) EG25-015 300°F Temp Sensor n/c Ceramic (spill switch) EG25-018...
  • Page 16 120° F (49° C) DRAFT HOOD TEMPERATURE FULLY SLIDER SENSOR ASSEMBLED EC-001 PILOT EC-015 NG EC-016 LP THERMOPILE BRICK CLIPS 300° F EC-012 AND BACK CERAMIC (149° C) LEDGE THERMOCOUPLE BRICK SPILL EC-009 PAN BURNER LINERS SWITCH SPARK POST APR 2000 EG25-074 EC-003 ELECTRODE...
  • Page 17 ON / OFF / THERMOSTAT SWITCH BURNER SWITCH BRASS TRIM CORNER EC-026 BRACKETS (NOT SHOWN) EC053 CONTROLLER EC-039 ACCENT 25 OVERSIZE FPI WIRING SURROUND WITH HARNESS PART (A) PAINTED TRIM 50-108 EC-034 ACCENT 25 BRASS TRIM (NOT SHOWN) 50-013 REGULAR NICKEL TRIM SURROUND WITH 50-014...

  • Page 18: Warranty

    13. WARRANTY Sherwood Industries Ltd. offers a *Lifetime Warranty on this gas product. The lifetime warranty covers the appliance for a period of seven years from the date of installation. This warranty applies only to the original owner in the original location Covered under the lifetime warranty are Cabinet Sides, Tops, Pedestals, Surround Panels and Chassis and Heat Exchanger.

  • Page 19: Installation Data Sheet

    14. INSTALLATION DATA SHEET The following information must be recorded by the installer for warranty purposes and future reference. Envirogas Model: ACCENT 25 BV Name of Dealer: Name of Owner: ___________________________________________ __________________________________________ Address: Address: ___________________________________________ __________________________________________ ___________________________________________ __________________________________________ ___________________________________________ __________________________________________ Phone: ___________________________________ Phone:_____________________________________...
