When Using the Reversing Automatic Document Feeder

When the originals are placed on the Reversing Automatic Document Feeder, the uppermost page is first
scanned and sent.
1
After aligning the edges of originals, place
them with their face up and slide the
guides to the width of the originals.
- You cannot mix A series format (A3, A4, A5) and B series format
(B4, B5) or LT series and COMP.
- LT/A4 size originals are rotated 90º so that they are sent as LT-R/
A4-R originals.
- If a mixture of LD and LG, A3 and A4, or B4 and B5 originals are
placed, they are sent in their original sizes.
- When LD, LG, LT-R, COMP, A3 and B4, A4-R, B5 originals are
placed as shown in the figure on the right, the pre-entered sender
information is printed in the shaded position shown (A) in the
figure and sent to the remote Fax.
- Entering the sender information "2.REGISTERING THE
TERMINAL ID"
- When LT, ST-R, A4, A5-R or B5-R originals are placed as shown
in the figure on the right, the pre-entered sender information is
printed in the shaded position shown (B) in the figure and sent to
the remote Fax.
Page 130
( A )
2
( B )
