8000 Series Mobile Computer
Ethernet Cradle
Refer to the Ethernet Cradle manual for more information.
No. Description
1 LED Indicators (from left to right):
Power
Tx/Rx
LAN
3 Ethernet Port (RJ-45)
5 Power Jack
The cradle provides three LED indicators on the front panel to indicate connection status.
Indicator
Power (Line status)
TX/RX (Transmission status)
LAN (Network status)
20
Reference Manual
No.
2
4
Status
Off
Red, solid
Red, flashing
Off
Red, flashing
Off
Green, flashing
Red, flashing
Description
IP Reset Switch
Cable Connector (RS-232)
Description
Power off
Waiting to connect to network
Connected to network
No activity
Data transmission
Network unavailable
10 Mbps network available
100 Mbps network available
