CipherLab 8000 Reference Manual page 80

8000 Series Mobile Computer
SETTINGS
Interface
Options
Cradle-IR (Serial IR)
IrDA
Bluetooth
Baud Rate
Options
115200 (bps)
76800 (bps)
57600 (bps)
38400 (bps)
19200 (bps)
9600 (bps)
4800 (bps)
2400 (bps)
Note: If you select to use Serial IR of the Modem Cradle, any value other than 57600
bps (default) must be configured through the DIP switch on the IR control board.
LOAD PROGRAM VIA BLUETOOTH
1) Go to Kernel Menu | 5. Bluetooth Menu | 3. Security, and configure the following
Bluetooth settings first.
Authentication
PIN code
2) Go to Kernel Menu | 2. Load Program and select Bluetooth.
3) Start the pairing procedure from your computer, for example, click [Pair Device]
and/or [Connect Bluetooth Serial Port].
4) Run the download utility: ProgLoad.exe
- Select interface RS-232/IrDA for using Bluetooth SPP.
- Select COM port properties that match with the serial port settings used on your
computer.
Note: The interface option "Bluetooth" is only available on 8062.
70
Reference Manual
Description
Proceed to configure baud rate settings on your computer and the
mobile computer.
Point to the target IrDA device.
Approach the target Bluetooth enabled device.
Supported by CipherLab software, including download utilities
Yes
Yes
Yes
Yes
Yes
No
No
No
