Management
Table 13 lists the management specifications for the switch. Refer to Fabric OS
Administration Guide for more information regarding management of the switch.
50
SAN32B-E4 Installation, Service, and User Guide
Table 12. General specifications (continued)
Specification
ISL trunking
Aggregate bandwidth
Maximum frame size
Classes of service
Data traffic types
USB
Fabric services
Table 13. Management specifications
Specification
Management
Security and management
Management access
Description
Frame-based trunking with up to eight 8
Gbps ports per ISL trunk; up to 64 Gbps per
ISL trunk
512 Gbps per switch for non-encrypted
traffic
2112-byte payload for FC
Class 2 (non-encrypted traffic), Class 3, Class
F (inter-switch frames)
Fabric switches supporting unicast, multicast
(255 groups), and broadcast
One USB port for system uploads and
downloads, and firmware upgrades
(supportsave, configUploads,
configDownloads)
Simple Name Server (SNS), Registered State
Change Notification (RSCN), NTP v3, RCS
(Reliable Commit Service), Dynamic Path
Selection (DPS), Advance Zoning (default
zoning), Port/WWN zoning, broadcast
zoning, NPIV, FDML, Management Server,
FSPF, Fabric Watch, Extended Fabrics, ISL
Trunking, Advanced Performance
Monitoring (APM), Adaptive Networking,
Per data flow QoS, Ingress port rate limiting,
Traffic Isolation, Group Management,
Integrated Routing, and IPFC.
Description
Telnet, HTTP, LDAP, Syslog, SCP, Auditing,
IP Filtering, SNMP v1/v3 (FE MIB, FC
Management MIB), Advanced WEB Tools,
DCFM, SMI-S compliant, SMI-S scripting
toolkit
SSL, SSH v2, HTTPS, RADIUS, RBAC
(Role-Based Access Control), DH-CHAP
(between switches and end devices), port
binding, switch binding, Secure RPC,
Trusted Switch, change tracking
Serial port (RJ-45) and one USB port.
Call-home integration enabled through
DCFM
