Figure 1. Port side view
The Fibre Channel ports are numbered from left to right on the faceplate; 0-15 on
the top row, and 16-31 on the bottom row (see Figure 2).
Figure 2. Port numbering
Nonport side of the switch
Figure 3 on page 4 shows the nonport side of the switch, which contain the
combined power supplies and fans.
1
2
3
4
5
5
6
1
System status LED
2
System power LED
3
RJ45 GE ports (for
clustering and
re-keying)
4
Smart Card reader
7
8
5
RJ45 GE management port
6
RJ45 serial console port
7
USB port
8
Fibre Channel ports (0 - 31)
0
1
2
3
4
5
6
7
8
16 17 18 19
20 21 22 23
24 25 26 27
9
10
11
12 13 14 15
28 29 30 31
Chapter 1. Introducing the SAN32B-E4
3
