Size and weight

Table 14 lists the dimensions and weight of the switch.

Environmental requirements

Table 15 lists the acceptable environmental ranges for both operating and
non-operating (such as during transportation or storage) conditions.
Table 13. Management specifications (continued)
Specification
Diagnostics and supportability
Key management
Table 14. Switch dimensions
Dimension
Height
Depth
Width
Weight (with two power supplies and no
SFPs installed)
Table 15. Environmental requirements
Condition Acceptable range during operation
Ambient 0° to +40°C (32° to 104°F)
temperature
Humidity 10% to 85% RH non-condensing, at 40°C
(104°F), with maximum gradient of 10%
per hour
Altitude 0 to 3 km (9,842 ft) above sea level
Shock 20 G, 6 ms, half-sine wave
Vibration 0.5 G sine, sine, 0.4 grms random, 5-500
Hz
Air flow 129.1 cubic meters per hour (76 CFM)
Maximum; 90.1 cubic meters per hour (53
CFM) Nominal
Heat 1183 BTU/hr
dissipation
Description
POST and embedded online/offline
diagnostics, including RAStrace logging,
environmental monitoring, non-disruptive
daemon restart, RCping and Pathinfo (FC
traceroute), port mirroring (SPAN port),
automatic trace dump transfers in support of
FFDC (first--failure data capture),
supportsave utility
Compatible with industry-leading key
management systems, including IBM Tivoli
Key Lifecycle Manager (TLKM).
Value
2U = 86 mm (3.34 in)
635 mm (25 in)
429 mm (16.88 in)
22.4 kg (49.4 lb)
Acceptable range during
non-operation
-25° to 70°C (-13° to 158°F)
10% to 90% RH non-condensing,
at 70°C (158°F)
0 to 12 km (39,370 ft) above sea
level
Half sine, 33 G 11ms, 3/eg Axis
2.0 G sine, 1.1 grms random
5-500 Hz
NA
NA
Appendix. Product specifications
®
