Figure 9. Mounting the moving portion of the slide and mounting brackets to the switch
4. Optional step: If desired, install the right rack mount bracket 2 (see Figure 7
5. Attach all four of the 3-hole rack mounting brackets 4 in Figure 10 on page
16
SAN32B-E4 Installation, Service, and User Guide
Front
c. Repeat step 3a on page 15 and step 3b on page 15 for the second inner rail
on the other side of the switch chassis.
on page 14) and the left rack mount bracket 3 on the switch chassis. Use
these brackets to secure the switch to the rack as shown in Figure 9.
Attention: Do not use screws longer than 3/16 in.; they can damage the
switch.
a. Position the left rack mount bracket at the left front corner of the switch
chassis. Align the two holes in the bracket with the two threaded holes in
the switch chassis.
b. Attach the bracket by using two of the 8-32 x 3/16 in. zinc screws (see 6
in Figure 7 on page 14)
c. Repeat step 4a and step 4b for the right rack mount bracket on the right
front corner of the switch chassis.
17.
a. Position a 3-hole rack mounting bracket 4 at the end of one of the outer
slides.
b. Attach the bracket by using the 8-32 x 3/8 in. zinc screws 9 . Ensure that
the screw heads are inside the slides.
c. Place one each of the following items on the outer end of the screw in the
order listed (see Detail A in Figure 7 on page 14):
1) Washer, flat No. 8 10
2) Washer, lock No. 8 11
3) Nut, hex, 8-32 12
d. Repeat steps 5a through 5c for the three remaining rail ends.
1
SJ000047
