Option Menu Descriptions - Firstech CM7200 Master Manual

CM7200 Master Guide
Feature
Programmable
Output Connector
1 POC #1
2 POC #2
3 POC #3
4 POC #4
5 POC #5
6 POC #6
7 POC #7
8 POC #8

Option Menu Descriptions

FO = Feature Option
1-01 Unlock before, Lock after:
FO1 - Off
FO2 - On: Sends an unlock command as soon as the remote start sequence is triggered then send a
relock command as soon as the CM7 has confirmed remote start success.
FO3 - Lock after start only: Sends a lock command after the CM7 has confirmed remote start
success.
FO4 - Lock after shutdown only: will send a lock command only after the CM7 has successfully
shut down. Note: It will not provide an output if the CM7 is shut down with an
emergency override input. (i.e. hood pin, or foot brake input)
Copyright 2014 Firstech, LLC. Copyright 2014 Firstech, LLC. Copyright 2014 Firstech, LLC.
Special Option Group 2
0 - Default Setting
(-) Starter Kill (Blue/White)
(-) Horn (White)
(-) Lock (Blue/Light Green)
(-) Unlock (Blue)
(-) Disarm (Orange/White)
(-) Rearm (Orange)
(-) Trunk (Violet/White)
(-) Status (Black)
Setting and OP500 Value
1~28 – Optional Settings
2nd Light - [1] 2nd Start - [2]
2nd Acc - [4] Status Out - [5] Rearm Out - [6]
Disarm Out - [7] Horn Out - [8] Dome Light - [9]
Aux 1 Out - [10] Aux 2 Out - [11] Aux 3 - [12]
Aux 4 Out - [13] Aux 5 Out - [14] Aux 6 Out - [15]
Aux 7 Out – [16] Defrost - [17] GWA - [18]
Status 2 For Manual Trans. - [19] Siren 2 - [20]
Defrost 2 - [21] VAC - [22]
Aux 3 (EZGO Unlock) - [24] Lock - [25] Unlock - [26]
2nd Unlock (Driver's Priority) - [27] Trunk Release - [28]
Starter System
techfeed.compustar.com
2nd IG1 - [3]
Page 28 Page 2 Page 2
