CM7200 Master Guide

Knock Panel Sensitivity

To change knock sensitivity, disarm the system and adjust the switch on the rear of the RPS. The larger the
circle, the more sensitive the knock sensor is.

FT-DAS (Digital Adjustable Sensor) (Not Programmable with OEM Remotes)

The DAS sensor monitors sudden movement forward or backward during the remote start process when
starting a manual transmission vehicle. It also includes a dual stage impact sensor, and auto adjusting
tilt sensor. Follow the steps below to properly setup your DAS sensor. You can view our programming/
demonstration video located in our video library at techfeed.compustar.com.

Installing Your DAS

STEP 1: Make sure Option 4-12 is set to the DAS option. (Default is DAS option 1)
STEP 2: Set switch 1 and 2 on the side of the DAS. *See below for explanation of switches.
STEP 3: Connect cable to the red 4 pin port on the CM7 Series module.
STEP 4: Mount DAS securely using zip ties or included hardware. Can be mounted in any orientation.
Tilt will set 30 seconds after arming.
Switch 1:

Adjusting DAS Shock Sensitivity (CM7000, *CM7200, CM6300)

STEP 1: Turn the ignition to the 'on' position. *(CM7200: Feature 3-06, FO2 must be selected)
STEP 2: 2 Way remotes-hold buttons 1 and 2 (Lock and Unlock) for 2.5 seconds. You will get two
parking light flashes. 1 Way remotes-hold Lock and Unlock for 2.5 seconds. You will get two
parking light flashes.
STEP 3: To set the Warn Away Zone 1, (2way LCD) tap lock or button I. (1 Way) tap Lock. After you get
one parking light flash, proceed with impact testing on the vehicle. Note: please be careful
as not to damage the vehicle during the sensitivity adjustments. You will get
siren chirps 1-most sensitive (lightest impact to the vehicle requiring the least amount of force
to trigger warn away) through 10-least sensitive (heaviest impact to the vehicle requiring more
force to trigger warn away). This sets the impact sensitivity of Warn Away Zone 1. Setting
Zone 1 will automatically set Zone 2. If you would like to manually set Zone 2
proceed:
a. To set Instant Trigger Zone 2, tap button 2. (1 Way: Unlock) After you get two parking light
flashes, tap the vehicle. You will get siren chirps 1-most sensitive through 10-least sensitive. This
sets the impact sensitivity of Instant Trigger Zone 2.
STEP 4: Once you get two parking light flashes, you are ready to test your DAS.
Copyright 2014 Firstech, LLC. Copyright 2014 Firstech, LLC. Copyright 2014 Firstech, LLC.
ON - 3 Degree Tilt
OFF - 1.5 Degree Tilt
Switch 2: ON - 4 Inch Movement
OFF - 3 Inch Movement
Starter System
techfeed.compustar.com
