CM7200 Master Guide

Installation Basics

If you are new to installing Firstech Series Remote Starts and/or Alarms, we highly recommended that you
thoroughly review this manual to installing your first unit.

Remote Programming:

You must code remotes to this system before anything will function. Begin by cycling the ignition ON and
OFF five times within 10 seconds and press and release button 1 (half second) on the first remote, and then
press and release button 1 (half second) on the second remote.
DAS Sensor (Required for Manual Transmission Installs):
The DAS sensor monitors forward movement for remote starting manual transmissions, dual stage impact,
and auto adjusting tilt sensor. See the DAS Sensor section of this manual for details.
Internal green/white loop must be cut for AUTOMATIC transmission vehicles.
By default, the units come in MANUAL transmission mode. You will need to cut the green/white loop inside
the control module if you are installing the unit in a AUTOMATIC transmission.
High Current 2nd Ignition Output (CN1 Blue Wire) (Jumper Programmable)
High Current Parking Light Output (CN1 Green/White Wire) (Jumper Programmable)
High Current Accessory Output (CN1 White Wire) (Jumper Programmable)
Optional Low Current Outputs Available (CN3 Pin 1 - 3 Amp (+) In) Harness Included.
When Using Connector, CN1 (High Current Connector) Not Required.
2nd RS232 Data Port (Grey CN6) Default DroneMobile Protocol w/Fortin Protocol
Optional.
Lock connector functions added to Connector 5 - 20 Pin Grey Harness
Lock connector functions are now available via POC 3, 4 and 7. There is also a lock connector for FT-
DM600/FT-DM700 on rear of Control Module. (CN11)
Built-In Blade Removal Tool
(Located on bottom of Control Module) - Turn screw to eject Blade Module.
Tach learning procedure:
Learn tach by: (1.) Starting the vehicle with the key, (2.) Press and hold the foot brake, then (3.) Activate the
remote start sequence - one chirp and parking light flash indicates that the vehicle tach signal has been
successfully learned. Three chirps and three parking light flashes indicate that the control module failed to
see a proper tach signal. (These units have the option for Tachless and 3 second assume cranking).
