Wiring - Yada Backup Camera User Manual

See Below. you can also visit our faQ's at www.letsyada.com for more information
Caution: this unit is designed to operate on a 12V/24V DC neGatIVe GrOUnD electrical system. Connecting
to other types of electrical systems will cause damage to your vehicle. Please contact the manufacturer if
you are unaware of the system type in your vehicle.
1. Locate the reverse taillights wiring behind your reverse light. you may need to remove the interior panel
in order to locate. you only need to attach the signal booster power wire to One of the reverse lights,
not both. If you cannot manually locate the tail light cables, please contact the vehicle manufacturer or
reference a wiring diagram for your vehicle.
2. at your taillight, remove the light bulb socket from the reverse light housing.
3. Determine the reverse light power wires for your car, designating the positive and negative wires. If you
are not sure of which are the power wires, then please contact your vehicle manufacturer or reference a
wiring diagram for your vehicle.
4. Connecting the Power Cables:
a. take the open wire end of this cable, and connect it to the power wires of your car (as determined in
step 3). Using the Scotchlok Connectors, connect the Camera's red wire to reverse light's Positive wire.
Connect the camera's Black Wire to reverse light's negative wire.
b. Use pliers to squeeze the metal tabs of the Scotchlok Connectors and ensure a solid connection, then
snap the plastic cover closed.
c. Place the fixed adapter from the Wireless Digital transmitter Power Cable into the Wireless Digital
transmitter.
d. Determine the best place to mount the transmitter. the transmitter is not waterproof and needs to be
protected. If mounting on a pickup truck you may want to mount behind the tail light and wrap in plastic
or you can purchase extension cables if you wish to mount in the cab of your truck. now it is time to
install the camera.
5. remove your license plate
6. Determine the best route for the Camera Cable from the top of your license plate to the transmitter. you
may need to drill a small hole in the panel behind where the license plate is situated.
7. take the Camera and run the attached cable through the rubber ring Grommet, then from the outside
of your car to the inside where the transmitter is. Pull the cable through so that there is a small amount
of slack and you can still move the Camera around the license plate.
8. Plug the attached wire from the Camera into the Wireless transmitter. ensure that the wires are not
tangled. you are now ready to test the camera.
5
