1080 P ROADCAM
BT58186
User Manual
Important, retain for future reference:
Read carefully

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BT58186 and is the answer not in the manual?

Questions and answers

Summary of Contents for Yada BT58186

  • Page 1 1080 P ROADCAM BT58186 User Manual Important, retain for future reference: Read carefully...
  • Page 2 QUICK INSTALLATION GUIDE Before you begin... Gather these items. TF Card 4 GB 1. Mount the Roadcam Mount the Roadcam on the windshield.
  • Page 3 2. Insert the MicroSD Card 3. Connect to Power...
  • Page 4 Consult an experienced technician if you are not comfortable installing the product. You can also contact YADA at 1.866.294.9244 to speak to one of our installation specialists if you have any specific questions regarding the 1080P Roadcam.
  • Page 5: Package Contents

    PACKAGE CONTENTS 1. 1 x 1080P Roadcam 2. 1 x Windshield Mount 3. 1 x 12V/24V Power Adapter 4. 1 x 4GB MicroSD Card TF Card 4 GB...
  • Page 6: Product Specifications

    PRODUCT SPECIFICATIONS Display: 2.2 inch display Lens: 120 degrees diagonal Video Resolution: 1080P / 30 FPS Circular Video: Seamless loop recording Memory Card: MicroSD (maximum support 32GB) Microphone: Supported Built-in Audio: Supported Operating Temperature: 14°F~140°F (-10°C~60°C) Operating Voltage: Cigarette Charger - DC 12/24V / DC 5V (Micro USB) Battery: Built-in 180 mAh li-ion battery CAMERA DIMENSIONS...
  • Page 7: Product Overview

    PRODUCT OVERVIEW 1. LCD Screen 5. Menu / Back Button 9. Mounting Socket 2. Power / OK / Record Button 6. Camera Lens 10. Speaker 3. Up Navigation Button 7. Micro USB Power Port 11. MicroSD Card Slot 4. Down Navigation Button 8.
  • Page 8: Installation

    INSTALLATION Insert the windshield mount to the socket on the top of the Roadcam. Peel off the protective sticker from the LCD screen and insert the MicroSD card. Plug the Micro USB power cable into the DC input port. Note: Power on and test camera before mounting.
  • Page 9 INSTALLATION Route and hide the power cable in the headliner and pillars in your vehicle. Plug the cigarette charger cable into your vehicle’s 12/24V DC outlet. Mount the Roadcam on the windshield. You can turn on the Roadcam and check the live screen to determine the most suitable mounting position. Push the locking lever while pressing the windshield mount onto the glass to secure the camera on the windshield.
  • Page 10: Configuration & Menu Settings

    CONFIGURATION & MENU SETTINGS Initial Setup Set the date & time before installing and using the Roadcam. This date & time is the time stamp for all recorded media files and digital clock. Switching Modes Press and hold the button to cycle through the following modes: video mode > camera mode >...
  • Page 11 General Settings Page Recording must be paused manually to access the general settings page. Next, press the M button on video mode or camera mode to open the general settings page. Press the button to cycle through all the settings. Video Resolution FHD 1920 x 1080, HD 1280 x 720 or VGA 640 x 480.
  • Page 12: Additional Features

    ADDITIONAL FEATURES Automatic ON / OFF When the Roadcam is connected to the vehicle’s power, it will power on and start recording when the vehicle engine starts. When the engine is off, the Roadcam will stop recording and turn off automatically. Gravity Induction Recording Protection System In a vehicle collision, the Roadcam will lock the video of the accident and save it as a special image.
  • Page 13 Battery Indications: Please refer to the diagram below for the battery indication. Fully charged Battery low Battery is empty Charging Note: The Roadcam is designed to be powered on while the vehicle is running. The built-in battery is only designed for storing documents when the vehicle’s engine is off.
  • Page 14 Help / FAQs 1) Problem: The Roadcam is unable to take pictures and record videos. Solution: Check if the MicroSD card has enough space and lock it. 2) Problem: The Roadcam stops automatically when it is recording a video. Solution: Because HD video data takes a lot of space, please use a high-speed MicroSD card compatible with SDHC, high-speed MicroSD cards will have a C10 logo.
  • Page 15: Safety Information

    1. SAVE THESE INSTRUCTIONS – This manual contains important safety and operating instructions of the 12V/24V cigarette lighter adapter for Model BT58186. 2. Before using the product, read all instructions and cautionary markings. 3. Do not expose cigarette lighter adapter to rain, moisture, or snow.
  • Page 16 WARNING: A failure to read and follow these warnings and instructions may result in a serious accident, including damaged property or a serious injury, including loss of life. • The 1080P Roadcam is designed as an aid to the driver in detecting large stationary objects to help avoid damaging the vehicle.
  • Page 17 • There is a plastic cover over the 1080P Roadcam. Do not scratch the cover when cleaning dirt or snow from it. • If the temperature changes rapidly, the system may not operate normally. • When strong light directly enters a camera, objects may not be displayed clearly.
  • Page 18: Maintenance And Warranty

    YADA warrants, to the original purchaser, that its products are free from defects in material and workmanship for 1 year from the date of original purchase. Where permitted by law, YADA’s liability shall be limited to that set forth in this limited express warranty. This limited express warranty shall be the exclusive remedy of the purchaser and YADA makes no other warranty of any kind aside from the limited express warranty stated above.
  • Page 19 4. The replacement of parts is excluded from the warranty when replacement is necessary due to normal wear and tear. 5. Repair or replacement parts supplied by YADA under this warranty are protected only for the unexpired portion of the original warranty.
  • Page 20 Return Authorization and instruct on how to get a new unit. YADA makes no other warranty of any kind aside from the limited express warranty stated herein. DISCLAIMER OF WARRANTIES, INCLUDING WARRANTY OF...
  • Page 21: General Information

    Neither shall YADA and/or its affiliates have any liability for any decision, action or inaction taken by any person in reliance on the 1080P Roadcam, or for any delays, inaccuracies and /or errors in connection with the 1080P Roadcam and its functioning.
  • Page 22 (DEHP) and Diisononyl Phthalate (DINP), which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. 1080P Roadcam BT58186 Responsible Party: YADA 2975 Red Hill Ave., Ste. 100, Costa Mesa, CA 92626...
  • Page 23 Product code / Code de produit / Código del producto : BT58186 Register this product within 30 days of purchase to receive one (1) additional year of warranty coverage (beyond the standard 1-year warranty), along with special product offers and announcements.
  • Page 24 CONNECT @letsyada WITH US 2975 Red Hill Ave., Ste. 100, Costa Mesa, CA 92626 1.866.294.9244 | customercare@horizon-brands.com © 2021 ADC Solutions Auto, LLC. www.letsyada.com ML-58186_V1...
