Cherokee

2 0 1 4

O W N E R ' S M A N U A L

Table of Contents

Advertisement

Chapters

Table of Contents

Need help?

Need help?

Do you have a question about the 2014 Cherokee and is the answer not in the manual?

Questions and answers

Summary of Contents for Jeep 2014 Cherokee

Page 1 Cherokee 2 0 1 4 O W N E R ’ S M A N U A L...
Page 2 VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name This manual illustrates and describes the operation of Chrysler Group LLC shall be deemed to be deleted and features and equipment that are either standard or the name Chrysler Canada Inc.
Page 3: Introduction 3
TABLE OF CONTENTS SECTION PAGE INTRODUCTION ............. 3 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE .
Page 5: Table Of Contents
INTRODUCTION CONTENTS INTRODUCTION ......4 WARNINGS AND CAUTIONS ....7 ROLLOVER WARNING .
Page 6: Introduction
4 INTRODUCTION INTRODUCTION When it comes to service, remember that your authorized dealer knows your vehicle best, has factory-trained tech- Congratulations on selecting your new Chrysler Group nicians and genuine parts, and cares about your satisfac- LLC vehicle. Be assured that it represents precision tion.
Page 7: How To Use This Manual
INTRODUCTION 5 in a collision, rollover of the vehicle, and severe or fatal more each year and could reduce disabling injuries by injury. Drive carefully. two million annually. In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
Page 8 6 INTRODUCTION...
Page 9: Warnings And Cautions
INTRODUCTION 7 WARNINGS AND CAUTIONS This Owners Manual contains WARNINGS against op- erating procedures that could result in a collision or bodily injury. It also contains CAUTIONS against pro- cedures that could result in damage to your vehicle. If you do not read this entire Owners Manual, you may miss important information.
Page 10: Vehicle Modifications/Alterations
8 INTRODUCTION VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death. Right Front Body VIN Location NOTE: It is illegal to remove or alter the VIN.
Page 11: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A WORD ABOUT YOUR KEYS ... . .12 VEHICLE SECURITY ALARM — IF EQUIPPED . . .19 ▫ Wireless Ignition Node (WIN) ... . .12 ▫...
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ▫ Using The Panic Alarm ....25 WINDOWS ......44 ▫...
Page 13 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 ▫ Enhanced Seat Belt Use Reminder System ENGINE BREAK-IN RECOMMENDATIONS . . .114 (BeltAlert®) ......64 SAFETY TIPS .
Page 14: A Word About Your Keys
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Your vehicle uses either a key start ignition system or keyless ignition system. The key start ignition system consists of a either a Key Fob with Remote Keyless Entry (RKE) transmitter and an Ignition Node Module (IGNM).
Page 15: Keyless Ignition Node (Kin)
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Keyless Ignition Node (KIN) This feature allows the driver to operate the ignition switch with the press of a button, as long as the Remote Keyless Entry (RKE) transmitter is in the passenger compartment.
Page 16: Key Fob - If Equipped
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Key Fob — If Equipped The Key Fob also contains the Remote Keyless Entry (RKE) transmitter and an emergency key, which stores in the rear of the Key Fob. The emergency key allows for entry into the vehicle should the battery in the vehicle or the Key Fob go dead.
Page 17: Ignition Or Accessory On Message
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 Ignition Or Accessory On Message Opening the driver’s door when the ignition is in ACC or ON (engine not running), a chime will sound to remind you to place the ignition in the OFF position. In addition to the chime, the ignition or accessory on message will display in the cluster.
Page 18: Sentry Key
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • Do not leave children or animals inside parked • When leaving the vehicle, always remove the Key vehicles in hot weather. Interior heat build-up may Fob from the vehicle and lock your vehicle. cause serious injury or death.
Page 19 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 The system uses a Key Fob with a factory-mated Remote Should this occur, have the vehicle serviced as soon as Keyless Entry (RKE) transmitter, a Keyless Ignition Node possible by an authorized dealer. (KIN) and a RF receiver to prevent unauthorized vehicle operation.
Page 20: Replacement Keys
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Replacement Keys Duplication of Key Fobs may be performed at an autho- rized dealer. This procedure consists of programming a NOTE: Only Key Fobs that are programmed to the blank Key Fob to the vehicle electronics. A blank Key Fob vehicle electronics can be used to start and operate the is one that has never been programmed.
Page 21: Vehicle Security Alarm - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 • This device must accept any interference that may be Rearming Of The System received, including interference that may cause unde- If something triggers the alarm, and no action is taken to sired operation.
Page 22: To Disarm The System
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Perform one of the following methods to lock the To Disarm The System vehicle: The Vehicle Security Alarm can be disarmed using any of • Push LOCK on the interior power door lock switch the following methods: with the driver and/or passenger door open.
Page 23: Security System Manual Override
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 • For vehicles not equipped with Keyless Enter-N- The Vehicle Security Alarm is designed to protect your Go™ , insert a valid key into the ignition switch and vehicle; however, you can create conditions where the turn the key to the ON position.
Page 24: Illuminated Entry
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The Illuminated Entry system will not operate if the ILLUMINATED ENTRY dimmer control is in the “Dome defeat” position The courtesy lights will turn on when you use the (extreme bottom position). Remote Keyless Entry (RKE) transmitter to unlock the doors or open any door.
Page 25 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 Emergency Key Removal (KIN) Emergency Key Removal (IGNM)
Page 26: To Unlock The Doors And Liftgate
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Unlock The Doors And Liftgate Flash Lights With Remote Key Push and release the UNLOCK button on the RKE This feature will cause the turn signal lights to flash when transmitter once to unlock the driver’s door or twice the doors are locked or unlocked with the RKE transmitter.
Page 27: Using The Panic Alarm
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 If the vehicle is equipped with Passive Entry, refer to The Panic Alarm will stay on for three minutes unless “Keyless Enter-N-Go™” in “Things To Know Before you turn it off by either pushing the PANIC button a Starting Your Vehicle”...
Page 28: Transmitter Battery Replacement
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Transmitter Battery Replacement The recommended replacement battery is one CR2032 battery. NOTE: • Perchlorate Material — special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate • Do not touch the battery terminals that are on the back housing or the printed circuit board.
Page 29 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 Emergency Key Removal (KIN) Remove Screw From Transmitter Case 2. Separating RKE halves requires screw removal and gently prying the two halves of the RKE transmitter apart. Make sure not to damage the seal during removal.
Page 30 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Separating Ignition Node Module (IGNM) Separating Keyless Ignition Node (KIN) Transmitter Case Transmitter Case 3. Remove the battery by turning the back cover over (battery facing downward) and tapping it lightly on a solid surface such as a table or similar, then replace the battery.
Page 31: General Information
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 clip, located on the back cover. Avoid touching the NOTE: Changes or modifications not expressly approved new battery with your fingers. Skin oils may cause by the party responsible for compliance could void the battery deterioration.
Page 32: Remote Starting System - If Equipped
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE REMOTE STARTING SYSTEM — IF EQUIPPED How To Use Remote Start All of the following conditions must be met before the This system uses the Remote Keyless Entry engine will remote start: (RKE) transmitter to start the engine conve- •...
Page 33 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 • Vehicle alarm system not active Remote Start Abort Message On Electronic Vehicle Information Center (EVIC) — If Equipped • Ignition in Off position for Keyless Enter-N-Go™ vehicle The following messages will display in the EVIC if the •...
Page 34 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The engine can be started two consecutive times with To Enter Remote Start Mode the RKE transmitter. However, the ignition must be cycled by pushing the START/STOP button twice (or Push and release the REMOTE START button the ignition switch must be cycled to the ON/RUN on the RKE transmitter twice within five sec- position) before you can repeat the start sequence for a...
Page 35 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 • For vehicles equipped with the Keyless Enter-N-Go™ doors and disarm the Vehicle Security Alarm (if equipped). Then, prior to the end of the 15-minute cycle, feature, the message “Remote Start Active — Push press and release the START/STOP button.
Page 36: Door Locks
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE DOOR LOCKS WARNING! Manual Door Locks • For personal security and safety in the event of a To lock each door, rotate the door lock knob on each door collision, lock the vehicle doors before you drive as trim panel forward.
Page 37: Power Door Locks
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 WARNING! (Continued) • Do not leave the Key Fob in or near the vehicle, or in a location accessible to children, and do not leave the ignition of a vehicle equipped with Keyless Enter-N-Go™...
Page 38 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If you press the power door lock switch while the Automatic Unlock Doors On Exit ignition is in the ACC or ON/RUN position, and any The doors will unlock automatically on vehicles with front door is open, the power locks will not operate.
Page 39: Child-Protection Door Lock System - Rear Doors
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 Child-Protection Door Lock System — Rear Doors To provide a safer environment for small children riding in the rear seats, the rear doors are equipped with a Child-Protection Door Lock system. To use the system, open each rear door, use a flat blade screwdriver (or ignition key) and rotate the dial to the LOCK or UNLOCK position.
Page 40: Keyless Enter-N-Go
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: WARNING! • When the child lock system is engaged, the door can Avoid trapping anyone in a vehicle in a collision. be opened only by using the outside door handle even Remember that the rear doors can only be opened though the inside door lock is in the unlocked position.
Page 41 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 NOTE: • Passive Entry may be programmed ON/OFF; refer to “Uconnect® Settings” in “Understanding Your Instru- ment Panel” for further information. • If wearing gloves on your hands, or if it has been raining on the Passive Entry door handle, the unlock sensitivity can be affected, resulting in a slower re- sponse time.
Page 42 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Unlock From The Passenger Side FOBIK-Safe only executes in vehicles with passive entry. There are three situations that trigger a FOBIK-Safe With a valid Passive Entry RKE transmitter within 5 ft search in any passive entry vehicle.
Page 43 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 NOTE: The vehicle will only unlock the doors when a equipped with Power Liftgate. Press the electronic lift- valid Passive Entry RKE transmitter is detected inside the gate release and lift for Manual Liftgate vehicles. vehicle, and no valid Passive Entry RKE transmitter is NOTE: If the vehicle is unlocked then the liftgate will open detected outside the vehicle.
Page 44 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: If “Unlock All Doors 1st Press” is programmed in Uconnect® Settings, all doors will unlock when you push the electronic liftgate release. If Unlock Driver Door 1st press is programmed in Uconnect® Settings, only the liftgate will unlock when you press the electronic liftgate release.
Page 45 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 NOTE: • After pressing the door handle LOCK button, you must wait two seconds before you can lock or unlock the doors, using either Passive Entry door handle. This is done to allow you to check if the vehicle is locked by pulling the door handle, without the vehicle reacting and unlocking.
Page 46: Windows
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WINDOWS There are single window controls on each passenger door trim panel, which operate the passenger door windows. Power Windows The window controls will operate only when the ignition The window controls on the driver’s door control all the is in the ACC or ON/RUN position.
Page 47 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 To open the window part way, press the window switch WARNING! (Continued) to the first detent and release it when you want the ignition of a vehicle equipped with Keyless Enter-N- window to stop. Go™...
Page 48 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Reset Auto-Up • If the window runs into any obstacle during auto- Should the Auto Up feature stop working, the window probably needs to be reset. To reset Auto Up: closure, it will reverse direction and then go back down.
Page 49: Wind Buffeting
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 the DOWN position). To enable the window controls, Wind Buffeting press and release the window lockout button again Wind buffeting can be described as the perception of (setting it in the UP position). pressure on the ears or a helicopter-type sound in the ears.
Page 50 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: If “Unlock All Doors 1st Press” is programmed in EVIC/DID if equipped, all doors will unlock when you push the electronic release on the liftgate. If Unlock Driver Door 1st press is programmed in Uconnect®, the liftgate will unlock when you press the electronic release on the liftgate For further information, refer to “Uconnect®”...
Page 51: Power Liftgate - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 The power liftgate may also be opened or closed by WARNING! pressing the LIFTGATE button located on the left side of the steering wheel on the instrument panel, or closed by Driving with the liftgate open can allow poisonous pressing the LIFTGATE button located on left rear trim exhaust gases into your vehicle.
Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: NOTE: • In the event of a power malfunction to the liftgate, an • The power liftgate buttons will not operate if the emergency liftgate latch release can be used to open vehicle is in gear or the vehicle speed is above 0 mph the liftgate.
Page 53 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 • The power liftgate must be in the full open position for • If your liftgate is power closing and you put the rear liftgate close button on the left rear trim, near the vehicle in gear, the liftgate will continue to power liftgate opening to operate.
Page 54: Occupant Restraints
52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Front seat belts incorporate pretensioners that may OCCUPANT RESTRAINTS enhance occupant protection by managing occupant Some of the most important safety features in your energy during an impact event vehicle are the restraint systems: •...
Page 55 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 NOTE: The Advanced Front Air Bags have a multistage Children that are not big enough to wear the vehicle seat inflator design. This allows the air bag to have different belt properly (see section on Child Restraints) should be rates of inflation based on several factors, including the secured in the rear seat in child restraints or belt- severity and type of collision.
Page 56 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. All occupants should always wear their lap and WARNING! shoulder belts properly. • Relying on the air bags alone could lead to more 3. The driver and front passenger seats should be severe injuries in a collision.
Page 57: Lap/Shoulder Belts
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 Research has shown that seat belts save lives, and they WARNING! (Continued) can reduce the seriousness of injuries in a collision. Some • In a collision, you and your passengers can suffer of the worst injuries happen when people are thrown much greater injuries if you are not properly buck- from the vehicle.
Page 58 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • It is dangerous to ride in a cargo area, inside or • Wearing a seat belt incorrectly is dangerous. Seat outside of a vehicle. In a collision, people riding in belts are designed to go around the large bones of these areas are more likely to be seriously injured your body.
Page 59 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 Pulling Out The Lap/Shoulder Belt Latch Plate Inserting Latch Plate Into Buckle 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click”.
Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • A shoulder belt placed behind you will not protect • A belt that is buckled into the wrong buckle will you from injury during a collision. You are more not protect you properly.
Page 61 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 WARNING! • A lap belt worn too high can increase the risk of internal injury in a collision. The belt forces won’t be at the strong hip and pelvic bones, but across your abdomen.
Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. To release the belt, push the red button on the buckle. Adjustable Upper Shoulder Belt Anchorage The belt will automatically retract to its stowed posi- In the front seating positions, the shoulder belt can be tion.
Page 63: Lap/Shoulder Belt Untwisting Procedure
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 Lap/Shoulder Belt Untwisting Procedure Use the following procedure to untwist a twisted lap/ shoulder belt. 1. Position the latch plate as close as possible to the anchor point. 2. At about 6 to 12 in (15 to 30 cm) above the latch plate, grasp and twist the belt webbing 180 degrees to create a fold that begins immediately above the latch plate.
Page 64: Seat Belts In Passenger Seating Positions
62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belts In Passenger Seating Positions If the passenger seating position is equipped with an ALR and is being used for normal usage: The seat belts in the passenger seating positions are equipped with Automatic Locking Retractors (ALR) Only pull the belt webbing out far enough to comfortably which are used to secure a child restraint system.
Page 65: Energy Management Feature
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 Mode anytime a child safety seat is installed in a seating WARNING! position that has a belt with this feature. Children 12 • The belt and retractor assembly must be replaced if years old and under should always be properly re- the seat belt assembly Automatic Locking Retractor strained in a vehicle with a rear seat.
Page 66: Seat Belt Pretensioning
64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belt Pretensioning Enhanced Seat Belt Use Reminder System (BeltAlert®) The seat belts for both front seating positions are equipped with pretensioning devices that are designed to BeltAlert® is a feature intended to remind the driver and remove slack from the seat belt in the event of a collision.
Page 67: Seat Belts And Pregnant Women
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 unbuckled while traveling at speeds greater than 5 mph Seat Belts And Pregnant Women (8 km/h), BeltAlert® will provide both audio and visual We recommend that pregnant women use the seat belts notification.
Page 68: Supplemental Restraint System (Srs) - Air Bags
66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE panel below the steering column and a Supplemental WARNING! Passenger Side Knee Air Bag mounted in the instrument panel below the glove compartment. Using a seat belt extender when not needed can in- crease the risk of injury in a collision.
Page 69 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 NOTE: The Driver and Front Passenger Advanced Front and rear passengers sitting next to a window. The SABIC Air Bags are certified to the new Federal regulations for air bags, are located above the side windows and their Advanced Air Bags.
Page 70: Advanced Front Air Bag Features
68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Supplemental Passenger Side Knee Air Bag Air Bag System Components • Front and Side Impact Sensors Your vehicle may be equipped with the following air bag system components: • Front Seat Belt Pretensioners, Seat Belt Buckle Switch, •...
Page 71 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 Supplemental Seat-Mounted Side Air Bags (SAB) WARNING! Supplemental Seat-Mounted Side Air Bags (SAB) may • No objects should be placed over or near the air bag provide enhanced protection to help protect an occupant on the instrument panel, because any such objects during a side impact.
Page 72 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE When the air bag deploys, it opens the seam on the side of the seat’s trim cover (front seats) and between the side seat’s cushion trim cover. Each air bag deploys indepen- dently;...
Page 73 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 NOTE: WARNING! • Air Bag covers may not be obvious in the interior trim, • Your vehicle is equipped with left and right but they will open during air bag deployment. SABIC, do not stack luggage or other cargo up high •...
Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Always sit upright as possible with your back against the Along with seat belts and pretensioners, Advanced Front seat back, use the seat belts properly, and use the Air Bags work with the Supplemental Driver and Pas- appropriate sized child restraint, infant restraint or senger Side Knee Air Bags and the knee bolsters to booster seat recommended for the size and weight of the...
Page 75: Air Bag Deployment Sensors And Controls
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 Air Bag Deployment Sensors And Controls including the severity and type of collision. Advanced Front Air Bags and Supplemental Driver and Front Occupant Restraint Controller (ORC) Passenger Knee Air Bags are not expected to reduce the The ORC is part of a Federally regulated safety system risk of injury in rear, side, or rollover collisions.
Page 76 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Because air bag sensors measure vehicle deceleration Also, the ORC turns on the Air Bag Warning over time, vehicle speed and damage by themselves are Light in the instrument panel for approxi- not good indicators of whether or not an air bag should mately four to eight seconds for a self-check have deployed.
Page 77 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 • OCS Sensor located in the front passenger seat WARNING! (Continued) • Air Bag Warning Light to protect you in a collision. If the light does not come on as a bulb check when the ignition is first turned The OCS will NOT prevent deployment of the passenger on, stays on after you start the vehicle, or if it comes Advanced Front Air Bag.
Page 78 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Front Passenger Seat Front Passenger Air WARNING! Occupant Status Bag Classification • Never place a rear facing infant seat in front of an Rearward-facing Reduced-power air bag. A deploying Passenger Advanced Front infant seat* deployment Air Bag can cause death or serious injury to a child...
Page 79 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 In order for the OCS to operate as designed, it is important for the front passenger to be seated properly and properly wearing the seat belt. Properly seated passengers are: • Sitting upright •...
Page 80 78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The front passenger seatback is not in the full upright WARNING! (Continued) position injury or death in a collision. Always wear your seat • The front passenger carries or holds an object while belt and sit properly, with the seat back in an upright seated (e.g., backpack, box, etc.) position, your back against the seat back, sitting...
Page 81 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 Not Seated Properly Not Seated Properly...
Page 82 80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Not Seated Properly Not Seated Properly WARNING! Placing an object on the floor under the front pas- senger seat may prevent the OCS from working properly, which may result in serious injury or death (Continued)
Page 83 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 Front Passenger Seat Storage bin do not interfere with the WARNING! (Continued) latch before closing the seat. In addition, after closing the in a collision. Do not place any objects on the floor Front Passenger Seat Storage bin make sure the front under the front passenger.
Page 84 82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the specific model being repaired. Always use the WARNING! correct seat cover and cushion specified for the vehicle. Make sure that objects inside the Flip ’n Stow™ • Do not replace the seat cover or cushion with an Front Passenger Seat Storage bin do not interfere aftermarket seat cover or cushion.
Page 85 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 83 collision type and severity. The steering wheel hub trim WARNING! (Continued) cover and the upper right side of the instrument panel could result in death or serious injury to the front separate and fold out of the way as the air bags inflate to passenger if the vehicle is involved in a collision.
Page 86 84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Air Bag deploys down and around the knee blocker/ you if you are not seated properly, or if items are glove box surface allowing the air bags to inflate to the positioned in the area where the side air bag inflates. This full size.
Page 87 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 85 where the SABIC inflates. This especially applies to event the ORC will determine whether to have the children. The SABIC is only about 3-1/2 in (9 cm) thick Enhanced Accident Response System perform the follow- when it is inflated.
Page 88 86 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE In order to reset the Enhanced Accident Response System you might get sliding along a carpet or gymnasium functions after an event, the ignition switch must be floor. They are not caused by contact with chemicals. changed from IGN ON to IGN OFF.
Page 89 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 87 Do not drive your vehicle after the air bags have de- Maintaining Your Air Bag System ployed. If you are involved in another collision, the air bags will not be in place to protect you. WARNING! •...
Page 90 88 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Air Bag Warning Light WARNING! (Continued) You will want to have the air bags ready to • Do not attempt to modify any part of your air bag inflate for your protection in a collision. The system.
Page 91: Event Data Recorder (Edr)
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 89 NOTE: If the speedometer, tachometer, or any engine vehicle dynamics and safety systems for a short period of related gauges are not working, the Occupant Restraint time, typically 30 seconds or less. The EDR in this vehicle Controller (ORC) may also be disabled.
Page 92: Child Restraints
90 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE personal data (e.g., name, gender, age, and crash loca- Children 12 years or younger should ride properly tion) are recorded. However, other parties, such as law buckled up in a rear seat, if available. According to crash enforcement, could combine the EDR data with the type statistics, children are safer when properly restrained in of personally identifying data routinely acquired during...
Page 93 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 91 NOTE: • For additional information, refer to www.seatcheck.org or call 1–866–SEATCHECK. Canadian residents should refer to Transport Canada’s website for additional information: • http://www.tc.gc.ca/eng/roadsafety/safedrivers- childsafety-index-53.htm WARNING! In a collision, an unrestrained child can become a projectile inside the vehicle.
Page 94 92 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Summary Of Recommendations For Restraining Children In Vehicles Child Size, Height, Weight Or Age Recommended Type Of Child Restraint Infants and Toddlers Children who are two years old or Either an Infant Carrier or a Convertible younger and who have not reached the Child Restraint, facing rearward in the height or weight limits of their child...
Page 95 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 93 Infants And Child Restraints their infant carrier but are still less than at least two years old. Children should remain rearward-facing until they Safety experts recommend that children ride rearward- reach the highest weight or height allowed by their facing in the vehicle until they are two years old or until convertible child seat.
Page 96 94 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Older Children And Child Restraints seat. The child and belt-positioning booster seat are held in the vehicle by the seat belt. Children who are two years old or who have outgrown their rear-facing convertible child seat can ride forward- WARNING! facing in the vehicle.
Page 97 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 95 To position a child into the Integrated Child Booster Seat WARNING! (Continued) follow these steps: • When your child restraint is not in use, secure it in 1. Slide the second row seat to the full rear position to the vehicle with the seat belt or LATCH anchor- use the Integrated Child Booster Seat.
Page 98 96 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. Slide the latch plate up the webbing as far as necessary WARNING! (Continued) to allow the seat belt to go around the child’s lap. An improperly latched seat cushion could cause NOTE: The lap portion of the seat belt should be low on serious injury.
Page 99 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 97 3. Does the shoulder belt cross the child’s shoulder WARNING! between their neck and arm? Never allow a child to put the shoulder belt under an 4. Is the lap part of the belt as low as possible, touching arm or behind their back.
Page 100 98 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Recommendations For Attaching Child Restraints Use any attachment method shown with an “X” Below Combined LATCH – Weight of the LATCH – Restraint Type Lower Anchors Seat Belt + Top Child + Child Lower Anchors Seat Belt Only + Top Tether...
Page 101 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 99 Lower Anchors And Tethers For Children (LATCH) Your vehicle is equipped with the child restraint anchor- Restraint System age system called LATCH, which stands for Lower Anchors and Tethers for CHildren. The LATCH system has three vehicle anchor points for installing LATCH- equipped child seats.
Page 102 100 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE LATCH Positions For Installing Child Restraints In This Vehicle • Lower Anchorage Symbol 2 anchorages per seating position • Top Tether Anchorage Symbol...
Page 103 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 101 What is the weight limit (child’s weight 65 lbs (29.5 kg) Use the LATCH anchorage system until the + weight of the child restraint) for combined weight of the child and the child using the LATCH anchorage system to restraint is 65 lbs (29.5 kg).
Page 104 102 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Can the rear-facing child restraint touch The child seat may touch the back of the front the back of the front passenger seat? passenger seat if the child restraint manufac- turer also allows contact. See your child restraint owner’s manual for more information.
Page 105 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 103 Locating The Upper Tether Anchorages Center Seat LATCH This vehicle has 5 lower LATCH anchorages in the rear There are tether strap anchorages behind each seat. Anchorages A and B are used for the right outboard rear seating position located on the back of the position behind the front passenger (1).
Page 106 104 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If the child seats do not block the center seat belt webbing and buckle, the center seat belt can be used to restraint an occupant or child restraint in the center seating position. 2.
Page 107 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 105 WARNING! WARNING! (Continued) • If you are installing three child restraints next to • Use anchorages C and D to install a LATCH- each other, you must use the seat belt and the center compatible child restraint in the center seating tether anchor for the center position.
Page 108 106 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Install A LATCH-Compatible Child Restraint 3. Attach the lower hooks or connectors of the child restraint to the lower anchorages in the selected seat- If the selected seating position has a Switchable Auto- ing position.
Page 109 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 107 How To Stow An Unused ALR Seatbelt WARNING! When using the LATCH attaching system to install a • Improper installation of a child restraint to the child restraint, stow all ALR seat belts that are not being LATCH anchorages can lead to failure of an infant used by other occupants or being used to secure child or child restraint.
Page 110 108 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Installing Child Restraints Using The Vehicle Seat Lap/Shoulder Belt Systems For Installing Child Belt Restraints In This Vehicle The seat belts in the passenger seating positions are equipped with a Switchable Automatic Locking Retractor (ALR) that is designed to keep the lap portion of the seat belt tight around the child restraint so that it is not necessary to use a locking clip.
Page 111 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 109 What is the weight limit (child’s weight + Weight limit of the Always use the tether anchor when using weight of the child restraint) for using the Child Restraint the seat belt to install a forward facing Tether Anchor with the seat belt to attach child restraint, up to the recommended a forward facing child restraint?
Page 112 110 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Installing A Child Restraint With A Switchable 4. Pull on the webbing to make the lap portion tight Automatic Locking Retractor (ALR) against the child seat. 1. Place the child seat in the center of the seating 5.
Page 113 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 111 8. If the child restraint has a top tether strap and the Installing A Child Restraint With A Cinching seating position has a top tether anchorage, connect Latch Plate (CINCH) — If Equipped the tether strap to the anchorage and tighten the tether 1.
Page 114 112 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Finally, pull up on any excess webbing to tighten the If the buckle or the cinching latch plate is too close to the lap portion around the child restraint while you push belt path opening of the child restraint, you may have the child restraint rearward and downward into the trouble tightening the seat belt.
Page 115 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 113 Installing Child Restraints Using The Top Tether 3. Attach the tether strap hook of the child restraint to Anchorage the top tether anchorage as shown in the diagram. 1. Look behind the seating position where you plan to install the child restraint to find the tether anchorage.
Page 116: Engine Break-In Recommendations
114 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ENGINE BREAK-IN RECOMMENDATIONS WARNING! A long break-in period is not required for the engine and • An incorrectly anchored tether strap could lead to drivetrain (transmission and axle) in your vehicle. increased head motion and possible injury to the child.
Page 117: Safety Tips
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 115 CAUTION! WARNING! • Do not leave children or animals inside parked Never use Non-Detergent Oil or Straight Mineral Oil in the engine or damage may result. vehicles in hot weather. Interior heat build-up may cause serious injury or death.
Page 118: Exhaust Gas
116 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Exhaust Gas WARNING! (Continued) • If it is necessary to sit in a parked vehicle with the WARNING! engine running, adjust your heating or cooling Exhaust gases can injure or kill. They contain carbon controls to force outside air into the vehicle.
Page 119: Safety Checks You Should Make Inside The Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 117 Safety Checks You Should Make Inside The Vehicle not lit during starting, see your authorized dealer. If the light stays on, flickers, or comes on while driving, have Seat Belts the system checked by an authorized dealer. Inspect the seat belt system periodically, checking for Defroster cuts, frays, and loose parts.
Page 120 118 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • Check mounting of mats on a regular basis. Always Pedals that cannot move freely can cause loss of properly reinstall and secure floor mats that have vehicle control and increase the risk of serious per- been removed for cleaning.
Page 121: Periodic Safety Checks You Should Make Outside The Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 119 Periodic Safety Checks You Should Make Outside Door Latches The Vehicle Check for positive closing, latching, and locking. Tires Fluid Leaks Examine tires for excessive tread wear and uneven wear Check area under vehicle after overnight parking for fuel, patterns.
Page 123: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS ▫ Sun Visor “Slide-On-Rod” Feature — MIRRORS ......128 If Equipped .
Page 124 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ Front Heated Seats — If Equipped ..152 ▫ Automatic Headlights — If Equipped ..167 ▫ Front Ventilated Seats — If Equipped ..154 ▫...
Page 125 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 ▫ Front Map/Reading Lights ....173 ELECTRONIC SPEED CONTROL — IF EQUIPPED ......185 ▫...
Page 126 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ To Set A Desired ACC Speed ... . .195 FORWARD COLLISION WARNING (FCW) WITH MITIGATION — IF EQUIPPED ..216 ▫...
Page 127 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 ▫ Enabling And Disabling ParkSense® ..238 PARKSENSE® ACTIVE PARK ASSIST SYSTEM — IF EQUIPPED ......259 ▫...
Page 128 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ Using HomeLink® ....292 ▫ Closing Power Shade — Express ...298 ▫...
Page 129 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 ▫ Console Storage Compartment ... .310 ▫ Retractable Cargo Area Cover — If Equipped . .315 ▫ Flip ’n Stow™ Front Passenger Seat Storage — ▫...
Page 130: Mirrors
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE MIRRORS Inside Day/Night Mirror — If Equipped A single ball joint mirror is provided in the vehicle. It is a twist on mirror that has a fixed position at the wind- shield. The mirror installs on the windshield button with a counterclockwise rotation and requires no tools for mounting.
Page 131 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 mounting. The mirror head can be adjusted up, down, NOTE: The ASSIST and 9–1–1 features operate through the Uconnect® Access service. These buttons will only left, and right for various drivers. The mirror should be operate as long as your Uconnect®...
Page 132 130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 9-1-1 Call 3. Once a connection between the vehicle and a 9-1-1 operator is made, the 9-1-1 Call system may transmit 1. Press the 9-1-1 Call button on the Rearview Mirror. the following important vehicle information to a 9-1-1 NOTE: In case the 9-1-1 Call button is pushed in error, operator: there will be a 10 second delay before the 9-1-1 Call...
Page 133 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 operator opens a voice connection with the vehicle’s 9-1-1 WARNING! (Continued) Call system, the operator should be able to speak with you • The 9-1-1 Call system is embedded into the vehi- or other vehicle occupants and hear sounds occurring in cle’s electrical system.
Page 134 132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 9-1-1 Call System Limitations WARNING! Vehicles sold in Canada and Mexico DO NOT have 9-1-1 • Ignoring the Rearview Mirror light could mean you Call system capabilities. will not have 9-1-1 Call services. If the Rearview 9-1-1 or other emergency line operators in Canada and Mirror light is illuminated, have an authorized Mexico may not answer or respond to 9-1-1 system calls.
Page 135 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 • The vehicle’s electrical systems are not intact. from placing an emergency call. Wireless and GPS signal reception is required for the 9-1-1 Call system to function • The 9-1-1 Call system software and/or hardware are properly.
Page 136: Outside Mirrors
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Outside Mirrors Power Mirrors To receive maximum benefit, adjust the outside mirror(s) The power mirror switches are located on the driver’s to center on the adjacent lane of traffic and a slight door trim panel. overlap of the view obtained from the inside mirror.
Page 137: Power Folding Mirrors - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 Models With Express Window Feature Power Folding Mirrors — If Equipped Press and release the mirror select button marked L (left) The switch for the power folding mirrors is located or R (right) and then press one of the four arrow buttons between the power mirror switches L (left) and R (right).
Page 138: Heated Mirrors - If Equipped
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: If the vehicle speed is greater than 10 mph To reset the power folding mirrors: Fold and unfold them (16 km/h) the folding feature will be disabled. by pressing the button. (This may require multiple button pushes).
Page 139: Sun Visor "Slide-On-Rod" Feature - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 Sun Visor “Slide-On-Rod” Feature — If Equipped The sun visor “Slide-On-Rod” feature allows for addi- tional flexibility in positioning the sun visor to block out the sun. 1. Fold down the sun visor. 2.
Page 140: Blind Spot Monitoring (Bsm) - If Equipped
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE BLIND SPOT MONITORING (BSM) — IF EQUIPPED When the vehicle is started, the BSM warning light will momentarily illuminate in both outside rear view mirrors The Blind Spot Monitoring (BSM) system uses two radar- to let the driver know that the system is operational.
Page 141 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 NOTE: The area on the rear fascia where the radar sensors are located must remain free of snow, ice, and dirt/road • The BSM system does NOT alert the driver about contamination so that the BSM system can function rapidly approaching vehicles that are outside the de- properly.
Page 142 140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Entering From The Side Vehicles that move into your adjacent lanes from either side of the vehicle. Warning Light Location The BSM system monitors the detection zone from three different entry points (side, rear, front) while driving to see if an alert is necessary.
Page 143 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 Entering From The Rear Overtaking Traffic If you pass another vehicle slowly (with a relative speed Vehicles that come up from behind your vehicle on either less than 15 mph (24 km/h) and the vehicle remains in side and enter the rear detection zone with a relative the blind spot for approximately 1.5 seconds, the warning speed of less than 30 mph (48 km/h).
Page 144 142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The BSM system is designed not to issue an alert on stationary objects such as guardrails, posts, walls, foliage, berms, etc. However, occasionally the system may alert on such objects. This is normal operation and your vehicle does not require service.
Page 145 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 The BSM system will not alert you of objects that are WARNING! traveling in the opposite direction of the vehicle in adjacent lanes. The Blind Spot Monitoring system is only an aid to help detect objects in the blind spot zones.
Page 146: Rear Cross Path
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Cross Path The Rear Cross Path (RCP) feature is intended to aid the driver when backing out of parking spaces where their vision of oncoming vehicles may be blocked. Proceed slowly and cautiously out of the parking space until the rear end of the vehicle is exposed.
Page 147: Modes Of Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145 NOTE: In a parking lot situation, oncoming vehicles can Modes Of Operation be obscured by vehicles parked on either side. If the Three selectable modes of operation are available in the sensors are blocked by other structures or vehicles, the Uconnect®...
Page 148 146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Blind Spot Alert Lights/Chime When the system is in RCP, the system shall respond with both visual and audible alerts when a detected object is When operating in Blind Spot Alert Lights/Chime mode, present.
Page 149: General Information
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 General Information SEATS This vehicle has systems that operate on radio frequency Seats are a part of the Occupant Restraint System of the that comply with Part 15 of the Federal Communications vehicle. Commission (FCC) rules and with Industry Canada Standards RSS- GEN/210/220/310.
Page 150: Power Seats - If Equipped
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Seats — If Equipped Reclining The Seatback Forward Or Rearward Some models may be equipped with a power driver’s The seatback can be reclined both forward and rearward. seat. The power seat switch is located on the outboard Push the seat recliner switch forward or rearward, the side of the seat near the floor.
Page 151 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 WARNING! Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt, which could result in serious injury or death. Power Lumbar —...
Page 152: Manual Seats - If Equipped
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual Seats — If Equipped While sitting in the seat, lift up on the bar and move the seat forward or rearward. Release the bar once you have Manual Front Seat Forward/Rearward Adjustment reached the desired position.
Page 153 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 Manual Front Seat Recline Adjustment WARNING! To adjust the seatback, lift the lever located on the Do not ride with the seatback reclined so that the outboard side of the seat, lean back to the desired shoulder belt is no longer resting against your chest.
Page 154: Front Heated Seats - If Equipped
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual Seat Height Adjustment — If Equipped Front Heated Seats — If Equipped The driver’s seat height can be raised or lowered by The front heated seats control buttons are located within using a lever, located on the outboard side of the seat. the climate or controls screen of the touchscreen.
Page 155 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 time, the display will change from HI to LO, indicating WARNING! the change. The LO-level setting will turn OFF automati- • Persons who are unable to feel pain to the skin cally after a maximum of 45 minutes. because of advanced age, chronic illness, diabetes, NOTE: The engine must be running for the heated seats spinal cord injury, medication, alcohol use, exhaus-...
Page 156: Front Ventilated Seats - If Equipped
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Front Ventilated Seats — If Equipped Vehicles Equipped With Remote Start Located in the seat cushion are small fans that draw the On models that are equipped with remote start, the air from the passenger compartment and pull air through ventilated seats can be programed to come on during a fine perforations in the seat cover to help keep the driver remote start.
Page 157 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 To raise the head restraint, pull upward on the head WARNING! restraint. To lower the head restraint, press the push The head restraints for all occupants must be properly button, located at the base of the head restraint, and push adjusted prior to operating the vehicle or occupying a downward on the head restraint.
Page 158 156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The head restraints should only be removed by To raise the head restraint, pull upward on the head qualified technicians, for service purposes only. If either restraint. To lower the head restraint, press the push of the head restraints require removal, see your autho- button, located at the base of the head restraint, and push rized dealer.
Page 159: 60/40 Split Folding Rear Seat With Fold-Flat Feature
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 60/40 Split Folding Rear Seat With Fold-Flat WARNING! (Continued) Feature • Do not allow people to ride in any area of your To provide additional storage area, each rear seat can be vehicle that is not equipped with seats and seat folded flat.
Page 160 158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Lower The Rear Seat To Raise The Rear Seat 1. Lift the seatback release lever located on the upper NOTE: If interference from the cargo area prevents the outer edge of the seat or pull the pull strap located on seatback from fully locking, you will have difficulty the middle outer edge of the seat.
Page 161: Driver Memory Seat - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 Recliner Adjustment WARNING! The rear seatback also reclines for additional passenger Do not ride with the seatback reclined so that the comfort. Pull on the pull strap while sitting in the rear shoulder belt is no longer resting against your chest. seat to recline the seatback.
Page 162: Programming The Memory Feature
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The memory switch is located on the driver’s side door Programming The Memory Feature panel. The switch contains 3 buttons, a S (SET) button to To create a new memory profile, perform the following: activate the memory save function, the number (1) memory button and the number (2) memory button.
Page 163 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 • For vehicles equipped with a manual transmission, the If desired, a second memory profile can be stored into memory as follows: vehicle speed must be at 0 mph (0 km/h) to recall a memory profile.
Page 164: Linking And Unlinking The Remote Keyless Entry Transmitter To Memory
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Linking And Unlinking The Remote Keyless Entry 3. Press and release the SET button on the memory Transmitter To Memory switch, then within five seconds press and release the button labeled 1 or 2 accordingly. “Memory Profile Your Remote Keyless Entry (RKE) transmitters can be Set”...
Page 165: Easy Entry/Exit Seat
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 • For vehicles equipped with a manual transmission, the Easy Entry/Exit Seat vehicle speed must be at 0 mph (0 km/h) to recall This feature provides automatic driver seat positioning to memory positions. If a recall is attempted with the enhance driver mobility when entering and exiting the vehicle speed above 0 mph (0 km/h), a message will vehicle.
Page 166: To Open And Close The Hood
164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The Easy Entry/Easy Exit feature is disabled when TO OPEN AND CLOSE THE HOOD the driver seat position is less than 0.9 in (22.7 mm) Two latches must be released to open the hood. forward of the rear stop.
Page 167 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165 2. Move to the outside of the vehicle and pull the safety CAUTION! latch release lever forward (toward you). The safety latch release lever is located behind the center front To prevent possible damage, do not slam the hood to edge of the hood.
Page 168: Lights
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE LIGHTS Headlight Switch The headlight switch is located on the left side of the instrument panel. This switch controls the operation of the headlights, parking lights, auto- matic headlights — if equipped, instrument panel lights, instrument panel light dimming, interior lights and fog lights —...
Page 169: Automatic Headlights - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167 Automatic Headlights — If Equipped In addition, the headlights will turn off when the wipers are turned off if they were turned on by this feature. This system automatically turns the headlights on or off according to ambient light levels.
Page 170: Automatic High Beam Headlamp Control - If Equipped
168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If you turn the headlights or parking lights on, or place Automatic High Beam Headlamp Control — the ignition in ACC or RUN, the system will cancel the If Equipped delay. The Automatic High Beam Headlamp Control system If you turn the headlights off before the ignition, they will provides increased forward lighting at night by automat- turn off in the normal manner.
Page 171 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169 • Broken, muddy, or obstructed headlights and taillights To Activate of vehicles in the field of view will cause headlights to 1. Turn the headlight switch to the AUTO headlight remain on longer (closer to the vehicle). Also, dirt, film, position.
Page 172: Daytime Running Lights (Drl)
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Daytime Running Lights (DRL) Fog Lights — If Equipped The LED Daytime Running Lights will come on when- The front fog light switch is built into the headlight switch. ever the ignition is placed in the RUN position, the headlights are off, the transmission is moved out of “Park”...
Page 173: Multifunction Lever
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171 To activate the front fog lights, turn on the parking Multifunction Lever lights or the low beam headlights and press the The multifunction lever controls the operation of the turn headlight switch. To turn off the front fog lights, either signals, headlight beam selection and passing lights.
Page 174: Turn Signals
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When the Daytime Running Lights are on and a turn Turn Signals signal is activated, the Daytime Running Lamp will Move the multifunction lever up or down and the arrows turn off on the side of the vehicle in which the turn on each side of the instrument cluster flash to show signal is flashing.
Page 175: Flash-To-Pass
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173 Flash-To-Pass You can signal another vehicle with your headlights by lightly pulling the multifunction lever toward you. This will turn on the high beams headlights until the lever is released. Front Map/Reading Lights The front map/reading lights are mounted in the over- head console.
Page 176: Interior Lights
174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Interior Lights With the parking lights or headlights on, rotating the instrument panel dimmer control upward will increase The interior lights come on when a door is opened. the brightness of the instrument panel lights and lighted To protect the battery, the interior lights will turn off cupholders —...
Page 177 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175 Ambient Light Control — If Equipped Dome Light Position Rotate the ambient dimmer control upward or down- Rotate the instrument panel dimmer control completely ward to increase or decrease the brightness of the ambi- upward to the second detent to turn on the interior lights.
Page 178: Battery Saver Feature
176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Battery Saver Feature To protect the battery, the interior lights will turn off automatically 10 minutes after the ignition switch is moved to the LOCK position. This will occur if the interior lights were switched on manually or are on because a door is open.
Page 179: Windshield Wiper Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177 Windshield Wiper Operation CAUTION! Rotate the end of the lever to one of the first four detent Always remove any buildup of snow that prevents positions for intermittent settings, the fifth detent for low the windshield wiper blades from returning to the wiper operation and the sixth detent for high wiper “park”...
Page 180: Intermittent Wiper System
178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Intermittent Wiper System Use one of the four intermittent wiper settings when weather conditions make a single wiping cycle, with a variable delay between cycles, desirable. At driving speeds above 10 mph (16 km/h), the delay can be regulated from a maximum of approximately 18 seconds between cycles (first detent), to a cycle every one second (fourth detent).
Page 181: Windshield Washer Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179 Windshield Washer Operation To use the washer, pull the lever rearward toward you and hold while spray is desired. If the lever is pulled while in the intermittent setting, the wipers will turn on and operate for several wipe cycles after the lever is released, and then resume the intermittent interval pre- viously selected.
Page 182: Mist
180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The mist feature does not activate the washer WARNING! pump; therefore, no washer fluid will be sprayed on the windshield. The wash function must be used in order to Sudden loss of visibility through the windshield spray the windshield with washer fluid.
Page 183: Windshield Wiper De-Icer - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181 • Activation By Remote Start Operation — When re- Windshield Wiper De-Icer — If Equipped mote start is active and the outside ambient tempera- Your vehicle may be equipped with a Windshield Wiper ture is less than 40°...
Page 184 182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The Rain Sensing feature can be turned on and off The sensitivity of the system can be adjusted with the multifunction lever. Wiper delay position one is the least using the Uconnect® System, refer to “Uconnect® sensitive, and wiper delay position four is the most Settings”...
Page 185: Tilt/Telescoping Steering Column
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 183 Remote Start Mode Inhibit — On vehicles equipped with Remote Starting system, Rain Sensing wipers are not operational when the vehicle is in the remote start mode. Once the operator is in the vehicle and has placed the ignition switch in the RUN position, rain sensing wiper operation can resume, if it has been selected, and no other inhibit conditions (mentioned previously) exist.
Page 186: Heated Steering Wheel - If Equipped
184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To lock the steering column in position, push the control The heated steering wheel can shut off early or may not handle upward until fully engaged. turn on when the steering wheel is already warm. The heated steering wheel control button is located WARNING! within the climate or controls screen of the touchscreen.
Page 187: Electronic Speed Control - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 185 The Electronic Speed Control buttons are located on the WARNING! right side of the steering wheel. • Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaus- tion, or other physical conditions must exercise care when using the steering wheel heater.
Page 188: To Activate
186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: In order to ensure proper operation, the Elec- WARNING! tronic Speed Control System has been designed to shut down if multiple Speed Control functions are operated at Leaving the Electronic Speed Control system on the same time.
Page 189: To Deactivate
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 187 To Deactivate The speed increment shown is dependant on the chosen speed unit of U.S. (mph) or Metric (km/h): A soft tap on the brake pedal, pushing the CANCEL button, or normal brake pressure while slowing the U.S.
Page 190: To Accelerate For Passing
188 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Decrease Speed Metric Speed (km/h) • Pressing the SET - button once will result in a 1 km/h When the Electronic Speed Control is set, you can de- decrease in set speed. Each subsequent tap of the crease speed by pushing the SET - button.
Page 191: Adaptive Cruise Control (Acc) - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 189 Using Electronic Speed Control On Hills WARNING! The transmission may downshift on hills to maintain the Electronic Speed Control can be dangerous where the vehicle set speed. system cannot maintain a constant speed. Your ve- NOTE: The Electronic Speed Control system maintains hicle could go too fast for the conditions, and you speed up and down hills.
Page 192 190 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ACC will allow you to keep cruise control engaged in WARNING! light to moderate traffic conditions without the constant • Adaptive Cruise Control (ACC) is a convenience need to reset your cruise control. ACC utilizes a radar system.
Page 193 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 191 WARNING! (Continued) WARNING! (Continued) • Cannot take street, traffic, and weather condi- You should switch off the ACC system: • When driving in fog, heavy rain, heavy snow, sleet, tions into account, and may be limited upon adverse sight distance conditions.
Page 194: Adaptive Cruise Control (Acc) Operation
192 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The Cruise Control system has two control modes: • Adaptive Cruise Control mode for maintaining an appropriate distance between vehicles. • Normal (fixed speed) electronic speed control mode for cruising at a constant preset speed. For additional information, refer to “Normal (Fixed Speed) Cruise Control Mode”...
Page 195: Activating Adaptive Cruise Control (Acc)
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 193 NOTE: Any chassis/suspension or tire size modifications NOTE: You cannot enable ACC under the following to the vehicle will effect the performance of the Adaptive conditions: Cruise Control. • When in Four-Wheel Drive Low. Activating Adaptive Cruise Control (ACC) •...
Page 196: To Activate/Deactivate
194 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Activate/Deactivate To turn the system OFF, push and release the Adaptive Cruise Control (ACC) ON/OFF button again. At this Push and release the Adaptive Cruise Control (ACC) time, the system will turn off and the EVIC will display ON/OFF button.
Page 197: To Set A Desired Acc Speed
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 195 If the system is Set when the vehicle speed is below WARNING! 20 mph (32 km/h), the Set Speed shall be defaulted to 20 mph (32 km/h). If the system is Set when the vehicle Leaving the Adaptive Cruise Control (ACC) system speed is above 20 mph (32 km/h), the Set Speed shall be on when not in use is dangerous.
Page 198: To Cancel
196 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Cancel To Turn Off The following conditions cancel the system: The system will turn off and clear the set speed in memory if: • The brake pedal is applied. • The Adaptive Cruise Control (ACC) ON/OFF button •...
Page 199: To Vary The Speed Setting
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 197 NOTE: To Vary The Speed Setting • If your vehicle stays at standstill for longer than two To Increase Speed seconds, then the driver will either have to press the While ACC is set, you can increase the set speed by RES (resume) button, or apply the accelerator pedal to pressing the SET + button.
Page 200 198 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • If the button is continually pressed, the set speed will Metric Speed (km/h) continue to decrease in 5 mph increments until the • Pressing the SET + button once will result in a 1 km/h button is released.
Page 201: Setting The Following Distance In Acc
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 199 • When you use the SET - button to decelerate, if the Setting The Following Distance In ACC engine’s braking power does not slow the vehicle The specified following distance for ACC can be set by sufficiently to reach the set speed, the brake system varying the distance setting between four bars (longest), will automatically slow the vehicle.
Page 202 200 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Distance Setting 3 Bars (Long) Distance Setting 2 Bars (Medium)
Page 203 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 201 If there is no vehicle ahead, the vehicle will maintain the set speed. If a slower moving vehicle is detected in the same lane, the EVIC displays the “Sensed Vehicle Indi- cator” icon, and the system adjusts vehicle speed auto- matically to maintain the distance setting, regardless of the set speed.
Page 204 202 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The maximum braking applied by ACC is limited; how- ever, the driver can always apply the brakes manually, if necessary. NOTE: The brake lights will illuminate whenever the ACC system applies the brakes. A Proximity Warning will alert the driver if ACC predicts that its maximum braking level is not sufficient to maintain the set distance.
Page 205: Overtake Aid
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 203 Overtake Aid ACC Operation At Stop When driving with ACC engaged and following a target If the ACC system brings your vehicle to a standstill vehicle, the system will provide an additional accelera- while following a target vehicle, if the target vehicle starts tion to assist in passing vehicles in front.
Page 206: Adaptive Cruise Control (Acc) Menu
204 UNDERSTANDING THE FEATURES OF YOUR VEHICLE While ACC is holding your vehicle at a standstill, if the Press the ADAPTIVE CRUISE CONTROL (ACC) ON/ driver seatbelt is unbuckled or the driver door is opened, OFF button (located on the steering wheel) until one of the parking brake will be activated, and the ACC system the following displays in the EVIC: will be cancelled.
Page 207: Display Warnings And Maintenance
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 205 The ACC screen may display once again if any ACC Display Warnings And Maintenance activity occurs, which may include any of the following: “Wipe Front Radar Sensor In Front Of Vehicle” • Distance Setting Change Warning •...
Page 208 206 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Do not remove any screws from the sensor. Doing so vehicle has left these areas. Under rare conditions, when the radar is not tracking any vehicles or objects in its path could cause an ACC system malfunction or failure and this warning may temporarily occur.
Page 209 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 207 NOTE: system may also become temporarily blinded due to obstructions, such as mud, dirt, or ice on windshield and • If the “ACC/FCW Unavailable Wipe Front Radar fog on the inside of glass. In these cases, the EVIC will Sensor”...
Page 210: Precautions While Driving With Acc
208 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When the condition that created limited functionality is no Precautions While Driving With ACC longer present, the system will return to full functionality. In certain driving situations, ACC may have detection issues. In these cases, ACC may brake late or unexpect- NOTE: If the “ACC/FCW Limited Functionality Clean edly.
Page 211 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 209 the vehicle is out of the curve the system will resume your original Set Speed. This is a part of normal ACC system functionality. NOTE: On tight turns ACC performance may be limited. Offset Driving Condition Example Turns And Bends When driving on a curve with ACC engaged, the system...
Page 212 210 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Using ACC On Hills Lane Changing When driving on hills, ACC may not detect a vehicle in ACC may not detect a vehicle until it is completely in the your lane. Depending on the speed, vehicle load, traffic lane in which you are traveling.
Page 213 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 211 Narrow Vehicles Some narrow vehicles traveling near the outer edges of the lane or edging into the lane are not detected until they have moved fully into the lane. There may not be sufficient distance to the vehicle ahead.
Page 214: General Information
212 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Stationary Objects And Vehicles General Information ACC does not react to stationary objects and stationary FCC Requirements For Vehicular Radar Systems vehicles. For example, ACC will not react in situations Classification Specifications: where the vehicle you are following exits your lane and 47 C.F.R.
Page 215 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 213 To change between the different control modes, press the To Set A Desired Speed ADAPTIVE CRUISE CONTROL (ACC) ON/OFF button which turns the ACC and the NORMAL (Fixed Speed) Turn the Normal (Fixed Speed) Electronic ELECTRONIC SPEED CONTROL OFF.
Page 216 214 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • If the button is continually pressed, the set speed will The speed increment shown is dependant on the speed of U.S. (mph) or Metric (km/h) units: continue to increase in 10 km/h increments until the button is released.
Page 217 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 215 • If the button is continually pressed, the set speed will To Cancel continue to decrease in 5 mph increments until the The following conditions will cancel the Normal (Fixed button is released. The decrease in set speed is re- Speed) Electronic Speed Control without clearing the flected in the EVIC display.
Page 218: Forward Collision Warning (Fcw) With Mitigation - If Equipped
216 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Resume Speed FORWARD COLLISION WARNING (FCW) WITH MITIGATION — IF EQUIPPED To resume a previously set speed, push the RES button and release. Resume can be used at any speed above Forward Collision Warning (FCW) With Mitigation 20 mph (32 km/h).
Page 219 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 217 NOTE: FCW monitors the information from the forward looking sensors as well as the Electronic Brake Controller (EBC), to calculate the probability of a forward collision. When the system determines that a forward collision is probable, the driver will be provided with audible and visual warnings and may provide a brake jerk warning.
Page 220 218 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: WARNING! • The minimum speed for FCW activation is 5 mph Forward Collision Warning (FCW) is not intended to (10 km/h). avoid a collision on its own, nor can FCW detect • The FCW alerts may be triggered on objects other than every type of potential collision.
Page 221 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 219 • Changing the FCW status to “Off” prevents the system from warning you of a possible collision with the vehicle in front of you. • Changing the FCW sensitivity - Near vs. Far. Far warns the driver of a possible collision earlier and Near warns the driver later.
Page 222 220 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Changing FCW And Active Braking Status NOTE: • The system will retain the last setting selected by the The FCW Sensitivity And Active Braking Settings are programmable through the Uconnect® System. Refer to driver after ignition shut down.
Page 223: Lanesense - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 221 Although the vehicle is still drivable under normal LANESENSE — IF EQUIPPED conditions, the active braking may not be fully available. LaneSense Operation Once the condition that limited the system performance The LaneSense system is operational at speeds above is no longer present, the system will return to its full 37 mph (60 km/h) and below 112 mph (180 km/h).
Page 224: Turning Lanesense On Or Off
222 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The driver may manually override the haptic warning by Turning LaneSense ON Or OFF applying torque into the steering wheel at any time. The default status of LaneSense is “OFF”. When only a single lane marking is detected and the The LaneSense button is located on the switch panel driver unintentionally drifts across the lane marking (no below the Uconnect®...
Page 225: Lanesense Warning Message
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 223 To turn the LaneSense system ON, press the LaneSense To turn the LaneSense system OFF, press the LaneSense button to turn the system ON (LED turns off). A “Lane button once to turn the system OFF (LED turns on). Sense On”...
Page 226 224 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3.5 EVIC Screen — If Equipped Left Lane Departure — Only Left Lane Detected • When the LaneSense system is ON, the LaneSense When the LaneSense system is ON; the lane lines are gray when both of the lane boundaries have not been detected indicator is solid white when only the left lane mark- and the LaneSense indicator is solid white.
Page 227 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 225 Left Lane Departure — Both Lanes Detected • When the LaneSense system is ON, the lane lines turn from gray to white to indicate that both of the lane markings have been detected. The LaneSense indicator is solid green when both lane markings have been detected and the system is “armed”...
Page 228 226 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • For example: If approaching the left side of the lane the steering wheel will turn to the right. Lanes Sensed (White Lines/Green Indicator) • When the LaneSense system senses a lane drift situa- tion, the left thick lane line and the left thin line turn Lane Sensed (Solid White Thick Line, Solid White Thin solid white.
Page 229 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 227 • When the LaneSense system senses the lane has been approached and is in a lane departure situation, the left thick lane line flashes from white to gray, the left thin line remains solid white and the LaneSense indi- cator changes from solid yellow to flashing yellow.
Page 230 228 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 7.0 EVIC Screen — If Equipped Left Lane Departure — Only Left Lane Detected • When the LaneSense system is ON, the LaneSense When the LaneSense system is ON; the lane lines are gray when both of the lane boundaries have not been detected indicator is solid white when only the left lane mark- and the LaneSense indicator is solid white.
Page 231 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 229 Left Lane Departure — Both Lanes Detected • When the LaneSense system is ON, the lane lines turn from gray to white to indicate that both of the lane markings have been detected. The LaneSense indicator is solid green when both lane markings have been detected and the system is “armed”...
Page 232 230 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • For example: If approaching the left side of the lane the steering wheel will turn to the right. Lanes Sensed (White Lines/Green Indicator) • When the LaneSense system senses a lane drift situa- tion, the left thick lane line and left thin line turn solid Lane Sensed (Solid Yellow Thick Line, Solid Yellow yellow.
Page 233 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 231 • When the LaneSense system senses the lane has been approached and is in a lane departure situation, the left thick lane line flashes yellow (on/off) and the left thin line remains solid yellow. The LaneSense indicator changes from solid yellow to flashing yellow.
Page 234: Changing Lanesense Status
232 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Changing LaneSense Status PARKSENSE® REAR PARK ASSIST — IF EQUIPPED The LaneSense system has settings that you can config- ure the intensity of the torque warning and the warning The ParkSense® Rear Park Assist system provides visual zone sensitivity (early/late) through the Uconnect®...
Page 235: Parksense® Sensors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 233 and above the system’s operating speed, a warning will ParkSense® Warning Display appear in the EVIC indicating the vehicle speed is too The ParkSense® Warning screen will only be displayed if fast. The system will become active again if the vehicle Sound and Display is selected from the Customer - speed is decreased to speeds less than approximately Programmable Features section of the Uconnect®...
Page 236: Parksense® Display
234 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ParkSense® Display sound tone. As the vehicle moves closer to the obstacle, the display will show the single arc moving closer to the When the vehicle is in REVERSE, the EVIC will display vehicle and the tone will change from fast to continuous.
Page 237 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 235 Slow Tone/Solid Arc Slow Tone/Solid Arc...
Page 238 236 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Fast Tone/Flashing Arc Continuous Tone/Flashing Arc The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert opera- tion when the system is detecting an obstacle:...
Page 239 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 237 WARNING ALERTS Rear Greater than 79-59 in 59-47 in 47-39 in 39-25 in 25-12 in Less than Distance 79 in (200 cm) (200-150 cm) (150-120 cm) (120-100 cm) (100-65 cm) (65-30 cm) 12 in (30 cm) (in/cm) Arcs —...
Page 240: Enabling And Disabling Parksense
238 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Enabling And Disabling ParkSense® When the ParkSense® switch is pressed to disable the system, the instrument cluster will display the ParkSense® can be enabled and disabled with the “PARKSENSE OFF” message for approximately five sec- ParkSense®...
Page 241: Service The Parksense® Rear Park Assist System
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 239 Service The ParkSense® Rear Park Assist If “PARKSENSE UNAVAILABLE WIPE REAR SEN- System SORS” appears in the Electronic Vehicle Information Center (EVIC) make sure the outer surface and the During vehicle start up, when the ParkSense® Rear Park underside of the rear fascia/bumper is clean and clear of Assist System has detected a faulted condition, the instru- snow, ice, mud, dirt or other obstruction and then cycle...
Page 242: Parksense® System Usage Precautions
240 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • ParkSense®, when on, will reduce the volume of the ParkSense® System Usage Precautions radio when it is sounding a tone. NOTE: • Clean the ParkSense® sensors regularly, taking care • Ensure that the rear bumper is free of snow, ice, mud, not to scratch or damage them.
Page 243 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 241 • On vehicles equipped with a tailgate, ParkSense® WARNING! should be disabled when the tailgate is in the lowered • Drivers must be careful when backing up even or open position and the vehicle is in REVERSE. A lowered tailgate could provide a false indication that when using ParkSense®.
Page 244: Parksense® Front And Rear Park Assist - If Equipped
242 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: WARNING! (Continued) • The driver can override the automatic braking func- could detect the ball mount and hitch ball assem- tion by pressing the gas pedal, turning ParkSense® off bly, depending on its size and shape, giving a false via ParkSense®...
Page 245 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 243 • The automatic braking function can be enabled/ NOTE: disabled from the Customer-Programmable Features • The driver is always responsible for controlling the section of the Uconnect® System. vehicle. • ParkSense® will retain its last known configuration •...
Page 246: Parksense® Sensors
244 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ParkSense® can be active only when the shift lever is in NOTE: If your vehicle is equipped with the ParkSense® REVERSE or DRIVE (NON-REVERSE for manual trans- Active Park Assist system, six sensors will be located in mission).
Page 247: Parksense® Display
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 245 The ParkSense® Warning screen is located within the If an obstacle is detected in the center rear region, the Electronic Vehicle Information Center (EVIC). It provides display will show a single solid arc in the center rear visual warnings to indicate the distance between the rear region and will produce a one-half second tone.
Page 248 246 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Single 1/2 Second Tone/Solid Arc Slow Tone/Solid Arc...
Page 249 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 247 Slow Tone/Solid Arc Fast Tone/Flashing Arc...
Page 250 248 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Fast Tone/Flashing Arc Continuous Tone/Flashing Arc The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert opera- tion when the system is detecting an obstacle:...
Page 251 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 249 WARNING ALERTS Rear Distance Greater than 79-59 in 59-47 in 47-39 in 39-25 in 25-12 in Less than (in/cm) 79 in (200 cm) (200-150 cm) (150-120 cm) (120-100 cm) (100-65 cm) (65-30 cm) 12 in (30 cm) Arcs —...
Page 252 250 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Front Park Assist A fast sound tone will be produced when reaching the 2nd flashing arc and will change to a continuous sound When the vehicle is in DRIVE or NON-REVERSE for tone when the 1st flashing arc appears. manual transmission, the ParkSense®...
Page 253 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 251 No Tone/Solid Arc No Tone/Flashing Arc...
Page 254 252 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Fast Tone/Flashing Arc Continuous Tone/Flashing Arc The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert opera- tion when the system is detecting an obstacle:...
Page 255 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 253 WARNING ALERTS Front Distance Greater than 47-39 in 39-25 in 25-12 in Less than (in/cm) 47 in (120 cm) (120-100 cm) (100-65 cm) (65-30 cm) 12 in (30 cm) Arcs — Left None None None 2nd Flashing...
Page 256: Enabling And Disabling Parksense
254 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Front Park Assist Audible Alerts Enabling And Disabling ParkSense® ParkSense® will turn off the Front Park Assist audible ParkSense® can be enabled and disabled with the alert (chime) after approximately three seconds when an ParkSense®...
Page 257: Service The Parksense® Park Assist System
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 255 When the ParkSense® switch is pressed to disable the Service The ParkSense® Park Assist System system, the instrument cluster will display the During vehicle start up, when the ParkSense® System “PARKSENSE OFF” message for approximately five sec- has detected a faulted condition, the instrument cluster onds.
Page 258: Cleaning The Parksense® System
256 UNDERSTANDING THE FEATURES OF YOUR VEHICLE arc alerts will interrupt the PARKSENSE UNAVAIL- Cleaning The ParkSense® System ABLE WIPE REAR SENSORS , PARKSENSE UNAVAIL- Clean the ParkSense® sensors with water, car wash soap ABLE WIPE FRONT SENSORS , or PARKSENSE UN- and a soft cloth.
Page 259 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 257 • When you move the shift lever to the REVERSE • Use the ParkSense® switch to turn the ParkSense® position and ParkSense® is turned off, the instrument system off if objects such as bicycle carriers, trailer cluster will display “PARKSENSE OFF”...
Page 260 258 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! WARNING! • ParkSense® is only a parking aid and it is unable to • Drivers must be careful when backing up even recognize every obstacle, including small obstacles. when using ParkSense®. Always check carefully Parking curbs might be temporarily detected or not behind your vehicle, look behind you, and be sure detected at all.
Page 261: Parksense® Active Park Assist System - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 259 PARKSENSE® ACTIVE PARK ASSIST SYSTEM — WARNING! (Continued) IF EQUIPPED • Before using ParkSense®, it is strongly recom- The ParkSense® Active Park Assist system is intended to mended that the ball mount and hitch ball assem- assist the driver during parallel and perpendicular park- bly is disconnected from the vehicle when the ing maneuvers by identifying a proper parking space,...
Page 262: Enabling And Disabling The Parksense® Active Park Assist System
260 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Enabling And Disabling The ParkSense® Active Park Assist System • The driver is always responsible for controlling the The ParkSense® Active Park Assist system can be enabled vehicle, responsible for any surrounding objects, and and disabled with the ParkSense®...
Page 263 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 261 • Touching the steering wheel during active steering To enable the ParkSense® Active Park Assist system, press the ParkSense® Active Park Assist switch once guidance into the parking space. (LED turns on). • Pressing the ParkSense® Front and Rear Park Assist To disable the ParkSense®...
Page 264 262 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The ParkSense® Active Park Assist system will only NOTE: If the vehicle is driven above approximately operate and search for a parking space when the follow- 15 mph (25 km/h), the EVIC will instruct the driver to ing conditions are present: slow down.
Page 265: Parallel Parking Space Assistance Operation/Display
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 263 • The driver needs to make sure that the selected Parallel Parking Space Assistance Operation/ Display parking space for the maneuver remains free and clear of any obstructions (e.g. pedestrians, bicycles, etc.). When the ParkSense® Active Park Assist system is •...
Page 266 264 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The feature will only indicate the last detected parking When an available parking space has been found, and the space (example: if passing multiple available parking vehicle is not in position, you will be instructed to move spaces, the system will only indicate the last detected forward to position the vehicle for a parallel parking parking space for the maneuver).
Page 267 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 265 Once the vehicle is in position, you will be instructed to Once the vehicle is at a standstill with your hands stop the vehicle’s movement and remove your hands removed from the steering wheel, you will be instructed from the steering wheel.
Page 268 266 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When the driver places the shift lever into the REVERSE The system will then instruct the driver to check their position, the system may instruct the driver to wait for surroundings and move backward. steering to complete.
Page 269 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 267 • The system will cancel the maneuver if the vehicle NOTE: speed exceeds 5 mph (7 km/h) during active steering • It is the drivers responsibility to use the brake and guidance into the parking space. The system will accelerator during the semi-automatic parking maneu- provide a warning to the driver at 3 mph (5 km/h) that ver.
Page 270 268 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When the vehicle has reached the end of its backward roundings and be prepared to stop the vehicle either when movement, the system will instruct the driver to check instructed to, or when driver intervention is required. their surroundings and stop the vehicle’s movement.
Page 271 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 269 When the driver places the shift lever into the DRIVE The system will then instruct the driver to check their position, the system may instruct the driver to wait for surroundings and move forward. steering to complete.
Page 272 270 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When the vehicle has reached the end of its forward when instructed to, or when driver intervention is re- movement, the system will instruct the driver to check quired. their surroundings and stop the vehicle’s movement. Once the vehicle is in a standstill condition, the driver will be instructed to place the shift lever into the RE- VERSE position.
Page 273 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 271 When the driver places the shift lever into the REVERSE The system will then instruct the driver to check their position, the system may instruct the driver to wait for surroundings and move backward. steering to complete.
Page 274: Perpendicular Parking Space Assistance Operation/Display
272 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Your vehicle is now in the parallel park position. When Perpendicular Parking Space Assistance the maneuver is complete, the driver will be instructed to Operation/Display check the vehicle’s parking position. If the driver is When the ParkSense®...
Page 275 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 273 NOTE: • When searching for a parking space, use the turn signal indicator to select which side of the vehicle you want to perform the parking maneuver. The ParkSense® Active Park Assist system will automatically search for a park- ing space on the passenger’s side of the vehicle if the turn signal is not activated.
Page 276 274 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When seeking for a parking space, the driver should drive as parallel or perpendicular (depending on the type of maneuver) to other vehicles as possible. • The feature will only indicate the last detected parking space (example: if passing multiple available parking spaces, the system will only indicate the last detected parking space for the maneuver).
Page 277 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 275 Once the vehicle is in position, you will be instructed to Once the vehicle is at a standstill with your hands stop the vehicle’s movement and remove your hands removed from the steering wheel, you will be instructed from the steering wheel.
Page 278 276 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When the driver places the shift lever into the REVERSE The system will then instruct the driver to check their position, the system may instruct the driver to wait for surroundings and move backward. steering to complete.
Page 279 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 277 • The system will cancel the maneuver if the vehicle NOTE: speed exceeds 5 mph (7 km/h) during active steering • It is the drivers responsibility to use the brake and guidance into the parking space. The system will accelerator during the semi-automatic parking maneuver.
Page 280 278 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When the vehicle has reached the end of its backward when instructed to, or when driver intervention is re- movement, the system will instruct the driver to check quired. their surroundings and stop the vehicle’s movement. Once the vehicle is in a standstill condition, the driver will be instructed to place the shift lever into the DRIVE position.
Page 281 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 279 When the driver places the shift lever into the DRIVE The system will then instruct the driver to check their position, the system may instruct the driver to wait for surroundings and move forward. steering to complete.
Page 282 280 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When the vehicle has reached the end of its forward when instructed to, or when driver intervention is re- movement, the system will instruct the driver to check quired. their surroundings and stop the vehicle’s movement. Once the vehicle is in a standstill condition, the driver will be instructed to place the shift lever into the RE- VERSE position.
Page 283 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 281 When the driver places the shift lever into the REVERSE The system will then instruct the driver to check their position, the system may instruct the driver to wait for surroundings and move backward. steering to complete.
Page 284 282 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Your vehicle is now in the perpendicular park position. CAUTION! When the maneuver is complete, the driver will be in- • The ParkSense® Active Park Assist system is only structed to check the vehicle’s parking position. If the driver is satisfied with the vehicle position, they should a parking aid and it is unable to recognize every shift to PARK.
Page 285 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 283 WARNING! WARNING! (Continued) • Before using the ParkSense® Active Park Assist • Drivers must be careful when performing parallel system, it is strongly recommended that the ball or perpendicular parking maneuvers even when mount and hitch ball assembly is disconnected using the ParkSense®...
Page 286: Parkview® Rear Back Up Camera - If Equipped
284 UNDERSTANDING THE FEATURES OF YOUR VEHICLE PARKVIEW® REAR BACK UP CAMERA — When the vehicle is shifted out of REVERSE (with camera IF EQUIPPED delay turned OFF), the rear camera mode is exited and the navigation or audio screen appears again. When the Your vehicle may be equipped with the ParkView®...
Page 287 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 285 Different colored zones indicate the distance to the rear of The following table shows the approximate distances for the vehicle. each zone: Zone Distance to the rear of the vehicle 0 - 1 ft (0 - 30 cm) Yellow 1 ft - 3 ft (30 cm - 1 m) Green...
Page 288: Garage Door Opener - If Equipped
286 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The HomeLink® buttons that are located in the headliner CAUTION! (Continued) or sun visor designate the three different HomeLink® • To avoid vehicle damage, the vehicle must be channels. driven slowly when using ParkView® to be able to stop in time when an obstacle is seen.
Page 289: Before You Begin Programming Homelink
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 287 Before You Begin Programming HomeLink® NOTE: • Erasing all channels should only be performed when Be sure that your vehicle is parked outside of the garage before you begin programming. programming HomeLink® for the first time. Do not erase channels when programming additional buttons.
Page 290 288 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 1. Cycle the ignition to the ON/RUN position. 2. Place the hand-held transmitter 1 to 3 in (3 to 8 cm) away from the HomeLink® button you wish to program while keeping the HomeLink® indicator light in view. 3.
Page 291 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 289 5. At the garage door opener motor (in the garage), To program the remaining two HomeLink® buttons, locate the “LEARN” or “TRAINING” button. This can repeat each step for each remaining button. DO NOT usually be found where the hanging antenna wire is erase the channels.
Page 292: Programming A Non-Rolling Code
290 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Programming A Non-Rolling Code 5. Press and hold the programmed HomeLink® button and observe the indicator light. For programming Garage Door Openers manufactured • If the indicator light stays on constantly, program- before 1995. ming is complete and the garage door/device should 1.
Page 293: Canadian/Gate Operator Programming
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 291 3. Without releasing the button proceed with “Program- 1. Cycle the ignition to the ON/RUN position. ming A Non-Rolling Code” step 2 and follow all 2. Place the hand-held transmitter 1 to 3 in (3 to 8 cm) remaining steps.
Page 294: Using Homelink
292 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 5. Press and hold the programmed HomeLink® button 3. Without releasing button proceed with and observe the indicator light. “Canadian/Gate Operator Programming” step 2 and • If the indicator light stays on constantly, program- follow all remaining steps.
Page 295: Troubleshooting Tips
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 293 The HomeLink® Universal Transceiver is disabled when WARNING! the Vehicle Security Alarm is active. Vehicle exhaust contains carbon monoxide, a danger- Troubleshooting Tips ous gas. Do not run your vehicle in the garage while If you are having trouble programming HomeLink®, programming the transceiver.
Page 296: General Information
294 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: WARNING! (Continued) • The transmitter has been tested and it complies with use a garage door opener without these safety fea- FCC and IC rules. Changes or modifications not ex- tures. Call toll-free 1–800–355–3515 or, on the Internet pressly approved by the party responsible for compli- at www.HomeLink.com for safety information or ance could void the user’s authority to operate the...
Page 297: Power Sunroof With Power Shade - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 295 POWER SUNROOF WITH POWER SHADE — The power shade switches are located to the right be- IF EQUIPPED tween the sun visors on the overhead console. The power sunroof switches are located to the left between the sun visors on the overhead console.
Page 298: Opening Sunroof - Express
296 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! WARNING! (Continued) • Do not allow small children to operate the sunroof. • Never leave children unattended in a vehicle, or Never allow your fingers, other body parts, or any with access to an unlocked vehicle. Never leave the object, to project through the sunroof opening.
Page 299: Opening Sunroof - Manual Mode
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 297 and automatically stop. This is called “Express Open”. Closing Sunroof — Express During Express Open operation, any movement of the Press the switch forward and release it within one-half sunroof switch will stop the sunroof. second and the sunroof will close automatically from any position.
Page 300: Opening Power Shade - Express
298 UNDERSTANDING THE FEATURES OF YOUR VEHICLE sunroof position. During Express Vent operation, any Opening Power Shade — Manual Mode movement of the switch will stop the sunroof. To open the shade, press and hold the switch rearward. The shade will open and stop automatically at the NOTE: If the sunshade is in the closed position when the half-open position.
Page 301: Closing Power Shade - Manual Mode
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 299 NOTE: If the sunroof is open, the shade will close to the NOTE: If three consecutive sunroof close attempts result half-open position. Pressing the shade close button again in Pinch Protect reversals, the fourth close attempt will be will automatically close both the sunroof and shade a Manual Close movement with Pinch Protect disabled.
Page 302: Ignition Off Operation
300 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Ignition OFF Operation the ignition switch is in the ON or ACC position, while the outlets labeled with a “battery” are connected directly The power sunroof switch will remain active for up to to the battery and powered at all times.
Page 303 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 301 The front power outlet is located inside the storage area The rear power outlet is located in the right rear cargo on the center stack of the instrument panel. area. Front Power Outlet Rear Power Outlet In addition to the front power outlet, there is also a power outlet located in the storage area of the center console.
Page 304 302 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The rear power outlet can be switched to “bat- tery” powered all the time by switching the rear power outlet fuse in the fuse panel. Power Outlet Fuse Locations 1 — F75 Fuse 20 A Yellow Front Power Outlet/Cigar Lighter Console Bin 2 —...
Page 305 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 303 WARNING! CAUTION! • Many accessories that can be plugged in draw To avoid serious injury or death: • Only devices designed for use in this type of outlet power from the vehicle’s battery, even when not in should be inserted into any 12 Volt outlet.
Page 306: Power Inverter - If Equipped
304 UNDERSTANDING THE FEATURES OF YOUR VEHICLE POWER INVERTER — IF EQUIPPED electronics and other low power devices requiring power up to 150 Watts. Certain high-end video games, such as Playstation3 and XBox360 will exceed this power limit, as will most power tools. To turn on the power inverter outlet, simply plug in the device.
Page 307: Wireless Charging Pad - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 305 WIRELESS CHARGING PAD — IF EQUIPPED WARNING! To avoid serious injury or death: • Do not insert any objects into the receptacles. • Do not touch with wet hands. • Close the lid when not in use. •...
Page 308: Wireless Charging Pad Operation
306 UNDERSTANDING THE FEATURES OF YOUR VEHICLE your Qi enabled mobile phone. Qi is a standard that uses Wireless Charging Pad Operation magnetic induction to transfer power to your mobile To use the wireless charging pad, the coil in your mobile device.
Page 309 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 307 4. Adjust the wireless charging pad mobile phone cradle to hold the mobile phone in position. The cradle moves by pushing down on the finger tabs and adjusting the cradle in or out. Mobile Phone Alignment NOTE: The mobile phone must be aligned around the Qi logo for the LED to transition from red to flashing green.
Page 310 308 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The initial adjustment will only need to be done WARNING! once as long as only one mobile phone is used. If a different mobile phone is used, the cradle will need to be Do not place metal object(s) between the mobile readjusted.
Page 311: Cupholders
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 309 CUPHOLDERS There are two cupholders for the rear seat passengers, located in the center armrest. There are two cupholders for the front seat passengers, located in the center console. Rear Cupholders Front Cupholders...
Page 312: Storage
310 UNDERSTANDING THE FEATURES OF YOUR VEHICLE STORAGE Glove Compartment The glove compartment is located on the passengers side of the instrument panel. Pull outward on the latch to open the glove compartment. There is also an additional storage bin located above the instrument panel in the center of the dash.
Page 313 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 311 Upper Console Charging Pad Center Console To open, pull up on the latch and lift the cover. The center console has a storage area which can hold cell phones, PDAs, and other small items.
Page 314: Flip 'N Stow™ Front Passenger Seat Storage - If Equipped
312 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Flip ’n Stow™ Front Passenger Seat Storage — If Equipped Some models may be equipped with storage under the front passenger seat cushion. Pull upward on the seat cushion loop to open the storage compartment. Center Console Storage WARNING! Do not operate this vehicle with a console compart-...
Page 315: Cargo Area Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 313 WARNING! Be certain that the seat cushion is locked securely into position before using the seat. Otherwise, the seat will not provide the proper stability for passen- gers. An improperly latched seat cushion could cause serious injury.
Page 316: Cargo Extension Panels
314 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Cargo Extension Panels WARNING! Cargo extension panels can be folded and unfolded. • Cargo tie-downs are not safe anchors for a child When the rear seats are moved to the more forward seat tether strap. In a sudden stop or accident, a positions and the rear seat backs are folded down, the tie-down could pull loose and allow the child seat extension panels can be unfolded manually by hand (2 of...
Page 317: Retractable Cargo Area Cover - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 315 Retractable Cargo Area Cover — If Equipped WARNING! NOTE: The purpose of this cover is for privacy, not to The weight and position of cargo and passengers can secure loads. It will not prevent cargo from shifting or change the vehicle center of gravity and vehicle protect passengers from loose cargo.
Page 318 316 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The removable retractable cargo area cover mounts in the Next, grab the cover handle and pull the cover toward cargo area behind the top of the rear seats. you. As the cover nears the liftgate opening, guide the rear attachment posts (on both ends of the cover) into the The cover, when extended, covers the cargo area to keep notches in the trim panels.
Page 319: Rear Storage Bins
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 317 Rear Storage Bins REAR WINDOW FEATURES Rear Window Wiper/Washer The rear storage bins are located in the rear of the vehicle on the sides of the load floor. The rear wiper/washer controls are located on the wind- shield wiper/washer lever on the right side of the steering column.
Page 320: Rear Window Defroster
318 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rotate the center portion of the lever upward to Rear Window Defroster the first detent for intermittent operation and to the second detent for continuous rear wiper operation. The rear window defroster button is located on the switch bank by the manual climate controls.
Page 321: Roof Luggage Rack - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 319 ROOF LUGGAGE RACK — IF EQUIPPED CAUTION! NOTE: Roof rack and crossbars cannot be used on Failure to follow these cautions can cause damage to vehicles equipped with Skyslider®. the heating elements: • Use care when washing the inside of the rear The load carried on the roof, when equipped with a luggage rack, must not exceed 150 lbs (68 kg), and it window.
Page 322 320 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! WARNING! • To avoid damage to the roof rack and vehicle, do Cargo must be securely tied down before driving not exceed the maximum roof rack load capacity. your vehicle. Improperly secured loads can fly off the Always distribute heavy loads as evenly as pos- vehicle, particularly at high speeds, resulting in per- sible and secure the load appropriately.
Page 323 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS ▫ Electronic Vehicle Information Center (EVIC) INSTRUMENT PANEL FEATURES ..323 Messages ......361 INSTRUMENT CLUSTER —...
Page 324 322 UNDERSTANDING YOUR INSTRUMENT PANEL ▫ Manual Climate Controls Without Touchscreen — iPod®/USB/MP3 CONTROL — IF EQUIPPED. . .389 If Equipped ......393 STEERING WHEEL AUDIO CONTROLS —...
Page 325: Instrument Panel Features
UNDERSTANDING YOUR INSTRUMENT PANEL 323 INSTRUMENT PANEL FEATURES 1 — Air Demister Outlet 5 — Instrument Cluster 9 — Passenger Air Bag 13 — Stop/Start Ignition Button 2 — Air Outlet 6 — Electronic Speed Control 10 — Glove Compartment 14 —...
Page 326: Instrument Cluster - Base
324 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER — BASE...
Page 327: Instrument Cluster - Premium
UNDERSTANDING YOUR INSTRUMENT PANEL 325 INSTRUMENT CLUSTER — PREMIUM...
Page 328: Instrument Cluster Descriptions
326 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS 5. Electronic Vehicle Information Center (EVIC) Display/ Odometer Display 1. Tachometer The odometer display shows the total distance the ve- Indicates the engine speed in revolutions per minute hicle has been driven. (RPM x 1000).
Page 329 UNDERSTANDING YOUR INSTRUMENT PANEL 327 When the appropriate conditions exist, this display shows In this case, the light will remain on until the condition the Electronic Vehicle Information Center (EVIC) messages. has been corrected. If the problem is related to the brake Refer to “Electronic Vehicle Information Center”.
Page 330 328 UNDERSTANDING YOUR INSTRUMENT PANEL The light also will turn on when the parking brake is WARNING! applied with the ignition switch in the ON/RUN position. Driving a vehicle with the red brake light on is NOTE: This light shows only that the parking brake is dangerous.
Page 331 UNDERSTANDING YOUR INSTRUMENT PANEL 329 If the ABS light is on, the brake system should be serviced (kilometers) at speeds greater than 30 mph (48 km/h), see as soon as possible to restore the benefits of Anti-Lock your authorized dealer as soon as possible to have the brakes.
Page 332 330 UNDERSTANDING YOUR INSTRUMENT PANEL 9. Electronic Stability Control (ESC) OFF Indicator 12. Turn Signal Indicator Light — If Equipped The arrows will flash with the exterior turn sig- This light indicates the Electronic Stability Con- nals when the turn signal lever is operated. A tone trol (ESC) is off.
Page 333 UNDERSTANDING YOUR INSTRUMENT PANEL 331 As an added safety feature, your vehicle has been Your vehicle has also been equipped with a TPMS equipped with a Tire Pressure Monitoring System malfunction indicator to indicate when the system is not (TPMS) that illuminates a low tire pressure telltale when operating properly.
Page 334 332 UNDERSTANDING YOUR INSTRUMENT PANEL 15. Temperature Gauge CAUTION! The temperature gauge shows engine coolant tempera- The TPMS has been optimized for the original ture. Any reading within the normal range indicates that equipment tires and wheels. TPMS pressures and the engine cooling system is operating satisfactorily.
Page 335 UNDERSTANDING YOUR INSTRUMENT PANEL 333 17. Malfunction Indicator Light (MIL) WARNING! The Malfunction Indicator Light (MIL) is part of A hot engine cooling system is dangerous. You or an Onboard Diagnostic system called OBD II that others could be badly burned by steam or boiling monitors engine and automatic transmission con- coolant.
Page 336 334 UNDERSTANDING YOUR INSTRUMENT PANEL 18. Vehicle Security Light CAUTION! This light will flash rapidly for approximately Prolonged driving with the Malfunction Indicator 15 – seconds when the vehicle security alarm is Light (MIL) on could cause damage to the engine arming.
Page 337: Electronic Vehicle Information
UNDERSTANDING YOUR INSTRUMENT PANEL 335 ELECTRONIC VEHICLE INFORMATION CENTER The EVIC Menu items consist of the following: (EVIC) • Speedometer The Electronic Vehicle Information Center (EVIC) fea- • Vehicle Info tures a driver-interactive display that is located in the • Driver Assist instrument cluster.
Page 338 336 UNDERSTANDING YOUR INSTRUMENT PANEL • UP Arrow Button The system allows the driver to select information by pressing the following buttons mounted on the steering Press and release the UP arrow button to scroll wheel: upward through the main menu and submenus. •...
Page 339: Electronic Vehicle Information Center (Evic) Displays - 3.5" Display
UNDERSTANDING YOUR INSTRUMENT PANEL 337 • BACK/LEFT Arrow Button Electronic Vehicle Information Center (EVIC) Displays — 3.5” Display Press and release the LEFT arrow button to The EVIC displays are located in the center portion of the access the information screens or sub-menu cluster and consists of eight sections: screens of a main menu item.
Page 340 338 UNDERSTANDING YOUR INSTRUMENT PANEL 1. Electronic Park Brake Failure — If Equipped In this case, the light will remain on until the condition has been corrected. If the problem is related to the brake This telltale indicates that there is an Electronic booster, the ABS pump will run when applying the brake Park Brake Fault.
Page 341 UNDERSTANDING YOUR INSTRUMENT PANEL 339 The light also will turn on when the parking brake is WARNING! applied with the ignition switch in the ON/RUN posi- tion. Driving a vehicle with the red brake light on is dangerous. Part of the brake system may have failed. NOTE: This light shows only that the parking brake is It will take longer to stop the vehicle.
Page 342 340 UNDERSTANDING YOUR INSTRUMENT PANEL • Unstored Messages 4. Main Display Area This message type is displayed indefinitely or until The main display area will normally display the main the condition that activated the message is cleared. menu or the screens of a selected feature of the main Examples of this message type are “Turn Signal On”...
Page 343 UNDERSTANDING YOUR INSTRUMENT PANEL 341 5. Lane Departure Warning (LDW) — If Equipped 6. Fuel Gauge The Lane Departure Warning (LDW) system Fuel Gauge displays the level of fuel in the fuel tank provides the driver with visual and steering when the ignition switch is in the ON/RUN position.
Page 344 342 UNDERSTANDING YOUR INSTRUMENT PANEL torque converter slip condition, such as 4-wheel drive • Low Coolant Level Indicator operation (e.g., snow plowing, off- road operation). If this This telltale will turn on to indicate the vehicle light comes on, stop the vehicle and run the engine at idle coolant level is low.
Page 345 UNDERSTANDING YOUR INSTRUMENT PANEL 343 11. Speed For Electronic Cruise Control Setting • LaneSense Service — If Equipped This telltale will turn on to indicate that the This displays the set speed of the Electronic Lane Sense Departure has detected a failure. Speed Control.
Page 346 344 UNDERSTANDING YOUR INSTRUMENT PANEL • Electronic Speed Control ON caused an over temperature condition in the power This light will turn on when the electronic steering system. You will lose power steering assis- speed control is ON. For further information, tance momentarily until the over temperature condi- refer to “Electronic Speed Control”...
Page 347 UNDERSTANDING YOUR INSTRUMENT PANEL 345 • Door Ajar • Charging System Light This light will turn on to indicate that one or This light shows the status of the electrical charg- more doors may be ajar. ing system. If the light stays on or comes on while driving, turn off some of the vehicle’s non-essential electrical devices or increase engine speed (if at idle).
Page 348 346 UNDERSTANDING YOUR INSTRUMENT PANEL • Secondary Air Bag Warning Light If a problem is detected, the light will come on while the engine is running. Cycle the ignition key when This telltale indicates the Passenger the vehicle has completely stopped and the shift lever Air Bag Disabled (PAD) [if equipped] is placed in the PARK position.
Page 349 UNDERSTANDING YOUR INSTRUMENT PANEL 347 15. SERV 4WD Indicator Light — If Equipped CAUTION! (Continued) This light alerts the driver that the 4WD is in need of “H” pull over and stop the vehicle. Idle the vehicle service. If this light is illuminated, see your authorized with the air conditioner turned off until the pointer dealer as soon as possible.
Page 350: Electronic Vehicle Information Center (Evic) Displays - 7" Display
348 UNDERSTANDING YOUR INSTRUMENT PANEL Electronic Vehicle Information Center (EVIC) 1. Lane Departure Warning (LDW) — If Equipped Displays — 7” Display The Lane Departure Warning (LDW) system The EVIC displays are located in the center portion of the provides the driver with visual and steering cluster and consists of eight sections: torque warnings when the vehicle starts to drift out of its lane unintentionally without the use...
Page 351 UNDERSTANDING YOUR INSTRUMENT PANEL 349 2. EVIC Selectable Display Area If the light remains on when the parking brake has been disengaged, and the fluid level is at the full mark on the This area displays selectable information (Compass, master cylinder reservoir, it indicates a possible brake Temp, Range to Empty, Trip, Average MPG or L/100 km).
Page 352 350 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: The light may flash momentarily during sharp Operation of the Brake Warning Light can be checked by cornering maneuvers, which change fluid level condi- turning the ignition switch from the OFF position to the tions.
Page 353 UNDERSTANDING YOUR INSTRUMENT PANEL 351 messages that consist of approximately 60 possible warn- Examples of this message type are “Turn Signal On” ing or information messages. These pop up messages fall (if a turn signal is left on) and “Lights On” (if driver into several categories: leaves the vehicle).
Page 354 352 UNDERSTANDING YOUR INSTRUMENT PANEL 6. Manual Speed Assist (MSA) Speed Warning Telltale — be driven several minutes before the updated tempera- If Equipped ture is displayed. Engine temperature can also affect the displayed temperature; therefor, temperature readings This area displays the Manual Speed Assist are not updated when the vehicle is not moving.
Page 355 UNDERSTANDING YOUR INSTRUMENT PANEL 353 • Electronic Speed Control ON 10. Shift Lever Status (PRNDL) This light will turn on when the electronic The shift lever status “P,R,N,D,L,9,8,7,6,5,4,3,2,1” are dis- speed control is ON. For further information, played indicating the shift lever position. Refer to “Start- refer to “Electronic Speed Control”...
Page 356 354 UNDERSTANDING YOUR INSTRUMENT PANEL • Rear Axle Lock Indicator — If Equipped CAUTION! This light indicates when the rear axle lock has been activated. Continuous driving with the Transmission Tempera- ture Warning Light illuminated will eventually cause severe transmission damage or transmission failure. •...
Page 357 UNDERSTANDING YOUR INSTRUMENT PANEL 355 • LaneSense Service — If Equipped Low range provides a greater gear reduction ratio to provide increased torque at the wheels. This telltale will turn on to indicate that the Lane Sense Departure has detected a failure. For further information on four-wheel drive operation and proper use, refer to “Four-Wheel Drive Opera- tion —...
Page 358 356 UNDERSTANDING YOUR INSTRUMENT PANEL • Temperature Gauge If your odometer needs to be repaired or serviced, the repair technician should leave the odometer reading The temperature gauge shows engine coolant tem- the same as it was before the repair or service. If s/he perature.
Page 359 UNDERSTANDING YOUR INSTRUMENT PANEL 357 14. Red Reconfigurable Telltale Display CAUTION! (Continued) • Engine Temperature Warning Light remains on the “H” and you hear continuous chimes, This light warns of an overheated engine turn the engine off immediately and call an autho- condition.
Page 360 358 UNDERSTANDING YOUR INSTRUMENT PANEL • Power Steering System Over Temperature — NOTE: If Equipped • Even if power steering assistance is no longer opera- If the “POWER STEERING SYSTEM OVER tional, it is still possible to steer the vehicle. Under TEMP”...
Page 361 UNDERSTANDING YOUR INSTRUMENT PANEL 359 • Oil Pressure Warning Light on, it means that the vehicle is experiencing a prob- This light indicates low engine oil pressure. The lem with the charging system. Obtain SERVICE IM- light should turn on momentarily when the MEDIATELY.
Page 362: Engine Oil Change Indicator System
360 UNDERSTANDING YOUR INSTRUMENT PANEL If the light remains lit with the engine running, your possible. Refer to “Occupant Restraints” in “Things vehicle will usually be drivable. However, see an To Know Before Starting Your Vehicle” for further authorized dealer for service as soon as possible. If information.
Page 363: Electronic Vehicle Information Center (Evic) Messages
UNDERSTANDING YOUR INSTRUMENT PANEL 361 To reset the oil change indicator system (after performing Electronic Vehicle Information Center (EVIC) the scheduled maintenance) refer to the following proce- Messages dure. • Front Seatbelts Unbuckled Vehicles Equipped With Keyless Enter-N-Go™ • Driver Seatbelt Unbuckled 1.
Page 364 362 UNDERSTANDING YOUR INSTRUMENT PANEL • Service Power Steering • Service Electronic Throttle Control • Cruise Off • Lights On • Cruise Ready • Right Turn Signal Light Out • Cruise Set To XXX MPH • Left Turn Signal Light Out •...
Page 365 UNDERSTANDING YOUR INSTRUMENT PANEL 363 • Remote Start Aborted Hood Open • Automatic Unavailable Use Autostick Service Req. • Remote Start Aborted Tailgate Open • Transmission Getting Hot Press Brake • Remote Start Aborted Time Expired • Trans. Hot Stop Safely Shift to Park Wait to Cool •...
Page 366: Evic Selectable Menu Items
364 UNDERSTANDING YOUR INSTRUMENT PANEL EVIC Selectable Menu Items button to select or reset the following resettable sub- menus: Press and release the UP or DOWN arrow buttons until the Transmission Temperature – Automatic Transmission desired Selectable Menu icon is highlighted in the EVIC. Only Speedometer Oil Temp...
Page 367 UNDERSTANDING YOUR INSTRUMENT PANEL 365 If one or more tires have low pressure, “Inflate Tire To Press the ADAPTIVE CRUISE CONTROL (ACC) ON/ XX” is displayed with the vehicle ICON and the tire OFF button (located on the steering wheel) until one of pressure values in each corner of the ICON with the the following displays in the EVIC: pressure value of the low tire displayed in a different...
Page 368 366 UNDERSTANDING YOUR INSTRUMENT PANEL The ACC screen may display once again if any ACC LaneSense Menu activity occurs, which may include any of the following: The EVIC displays the current LaneSense system set- • Distance Setting Change tings. The information displayed depends on LaneSense system status and the conditions that need to be met.
Page 369 UNDERSTANDING YOUR INSTRUMENT PANEL 367 Trip Info Stored Messages Press and release the UP or DOWN arrow button until Press and release the UP or DOWN arrow the Trip icon is highlighted in the EVIC (Toggle left or button until the Messages display icon is high- right to select Trip A or Trip B).
Page 370: Screen Setup Driver Selectable Items
368 UNDERSTANDING YOUR INSTRUMENT PANEL • Current MPG or L/100 km Screen Setup Driver Selectable Items • Trip A Gear Display • Standard (PRND) Gear Indicator • Trip B • Single Character (D) Gear Indicator Upper Right • None Upper Left •...
Page 371 UNDERSTANDING YOUR INSTRUMENT PANEL 369 • Trip A • Range To Empty • Trip B • Average MPG or L/100 km • Current MPG or L/100 km Restore To Defaults (Restores All Settings To Default Settings) • Trip A • Cancel •...
Page 372: Uconnect® Settings
370 UNDERSTANDING YOUR INSTRUMENT PANEL Uconnect® SETTINGS The Uconnect® system uses a combination of soft and hard keys located on the center of the instrument panel that allows you to access and change the customer programmable features. Uconnect® 5.0 Soft-Keys And Hard-Keys 1 —...
Page 373: Hard-Keys
UNDERSTANDING YOUR INSTRUMENT PANEL 371 Hard-Keys Hard-Keys are located below the Uconnect® system in the center of the instrument panel. In addition, there is a Scroll/Enter control knob located on the right side of the Climate Controls in the center of the instrument panel. Turn the control knob to scroll through menus and change settings (i.e., 30, 60, 90), press the center of the control knob one or more times to select or change a...
Page 374: Soft-Keys
372 UNDERSTANDING YOUR INSTRUMENT PANEL Soft-Keys When making a selection, touch the soft-key to enter the desired mode. Once in the desired mode, touch and Soft-Keys are accessible on the Uconnect® display. release the preferred setting until a check-mark appears Customer Programmable Features —...
Page 375 UNDERSTANDING YOUR INSTRUMENT PANEL 373 • Display Brightness With Headlights ON soft-key, then touch the desired language soft-key until a check-mark appears next to the language, showing that When in this display, you may select the brightness with setting has been selected. Touch the back arrow soft-key the headlights on.
Page 376 374 UNDERSTANDING YOUR INSTRUMENT PANEL • Touchscreen Beep Clock After pressing the “Clock” soft-key the following settings When in this display, you may turn on or shut off the will be available: sound heard when a touchscreen button (soft-key) is pressed.
Page 377 UNDERSTANDING YOUR INSTRUMENT PANEL 375 • Set Time Minutes Safety/Assistance After touching the “Safety/Assistance” soft-key the fol- When in this display, you may adjust the minutes. The lowing settings will be available: “Sync with GPS Time” soft-key must be unchecked. To make your selection, touch the “+”...
Page 378 376 UNDERSTANDING YOUR INSTRUMENT PANEL • Forward Collision Warning (FCW) Active Braking — For further information, refer to “Lane Departure Warn- ing (LDW)” in “Understanding The Features Of Your If Equipped Vehicle”. The FCW system includes Advanced Brake Assist (ABA). •...
Page 379 UNDERSTANDING YOUR INSTRUMENT PANEL 377 • ParkSense® Rear Park Assist Chime Volume — (18 km/h). The system can be enabled with Sound Only, or Sound and Display. To change the Park Assist status, If Equipped touch and release the “Sound Only” or “Sounds and Rear Park Assist chime volume settings can be selected Display”...
Page 380 378 UNDERSTANDING YOUR INSTRUMENT PANEL • Tilt Mirrors In Reverse — If Equipped visual alert in the outside mirrors as well as an audible alert when the turn signal is on. When Off is selected, the When this feature is selected, the outside sideview mir- Blind Spot Monitor (BSM) system is deactivated.
Page 381 UNDERSTANDING YOUR INSTRUMENT PANEL 379 • Fixed ParkView® Rear Backup Camera Guide Lines — caution note to “check entire surroundings” across the top of the screen. After five seconds, this note will If Equipped disappear. The ParkView® camera is located on the rear When this feature is enabled, fixed (static) grid lines are of the vehicle above the rear License plate.
Page 382 380 UNDERSTANDING YOUR INSTRUMENT PANEL • Electric Park Brake Service Mode and choose either 0 sec, 30 sec, 60 sec or 90 seconds. A check-mark appears next to setting indicating that the This feature provides a means for a technician or vehicle setting has been selected.
Page 383 UNDERSTANDING YOUR INSTRUMENT PANEL 381 • Daytime Running Lights — If Equipped The headlights will also turn off when the wipers are turned off if they were turned on by this feature. To make When this feature is selected, the headlights will turn on your selection, touch the “Headlights With Wipers”...
Page 384 382 UNDERSTANDING YOUR INSTRUMENT PANEL Doors & Locks Lock” soft-key, until a check-mark appears next to set- ting, indicating that the setting has been selected. Touch After pressing the “Doors & Locks” soft-key the follow- the back arrow soft-key to return to the previous menu. ing settings will be available: •...
Page 385 UNDERSTANDING YOUR INSTRUMENT PANEL 383 • 1st Press Of Key Fob Unlocks lock/unlock switch can be used to unlock all doors (or use RKE transmitter). When 1st Press Of Key Fob Unlocks is selected, only the • Passive Entry driver’s door will unlock on the first press of the Remote Keyless Entry (RKE) transmitter UNLOCK button.
Page 386 384 UNDERSTANDING YOUR INSTRUMENT PANEL • Auto-On Driver Heated/Ventilated Seat & Steering NOTE: The seat will return to the memorized seat location (if Recall Memory with Remote Key Unlock is set Wheel With Vehicle Start — If Equipped to ON) when the Remote Keyless Entry (RKE) transmitter When this feature is selected the driver’s heated seat and is used to unlock the door.
Page 387 UNDERSTANDING YOUR INSTRUMENT PANEL 385 To make your selection, touch the Easy Exit Seats soft- when exiting the vehicle. To change the Headlight Off key, until a check-mark appears next to setting, showing Delay status, touch the “+” or “–” soft-key to select your that setting has been selected.
Page 388 386 UNDERSTANDING YOUR INSTRUMENT PANEL • Perform Compass Calibration NOTE: Keep magnetic materials away from the top of the instrument panel, such as iPod’s, Mobile Phones, Laptop Push the “Calibration” button on the touchscreen to Computers and Radar Detectors. This is where the com- change this setting.
Page 389 UNDERSTANDING YOUR INSTRUMENT PANEL 387 • Equalizer • Surround Sound — If Equipped When in this display you may adjust the Bass, Mid and This feature provides simulated surround sound mode. Treble settings. Adjust the settings with the + and – To make your selection, touch the “Surround Sound”...
Page 390: Uconnect® Radios - If Equipped
388 UNDERSTANDING YOUR INSTRUMENT PANEL Radio Setup — If Equipped soft-key. A check mark will appear in the box when selected. Then touch the back arrow soft-key. After touching the “Radio Setup” soft-key the following settings will be available. Clear Personal Data •...
Page 391: Ipod®/Usb/Mp3 Control - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 389 iPod®/USB/MP3 CONTROL — IF EQUIPPED Located in the front storage area, this feature allows an iPod® or external USB device to be plugged into the USB port. iPod® control supports Mini, 4G, Photo, Nano, 5G iPod® and iPhone®...
Page 392: Steering Wheel Audio Controls - If Equipped
390 UNDERSTANDING YOUR INSTRUMENT PANEL STEERING WHEEL AUDIO CONTROLS — The right-hand control is a rocker-type switch with a IF EQUIPPED pushbutton in the center and controls the volume and mode of the sound system. Pressing the top of the rocker The remote sound system controls are located on the rear switch will increase the volume, and pressing the bottom surface of the steering wheel.
Page 393: Cd Player
UNDERSTANDING YOUR INSTRUMENT PANEL 391 The button located in the center of the left-hand control CD/DVD DISC MAINTENANCE will tune to the next preset station that you have pro- To keep a CD/DVD in good condition, take the following grammed in the radio preset button. precautions: CD Player 1.
Page 394: Radio Operation And Mobile Phones
392 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: If you experience difficulty in playing a particular General Information disc, it may be damaged (e.g., scratched, reflective coat- This device complies with Part 15 of the FCC rules and ing removed, a hair, moisture or dew on the disc) RSS 210 of Industry Canada.
Page 395: Climate Controls
UNDERSTANDING YOUR INSTRUMENT PANEL 393 CLIMATE CONTROLS The air conditioning and heating system is designed to make you comfortable in all types of weather. This system can be operated through either the controls on the instrument panel or through the Uconnect® system dis- play.
Page 396 394 UNDERSTANDING YOUR INSTRUMENT PANEL Front Blower Control Temperature Control There are seven blower speeds. Use Use this control to regulate the tem- this control to regulate the amount of perature of the air inside the passenger air forced through the system in any compartment.
Page 397 UNDERSTANDING YOUR INSTRUMENT PANEL 395 MAX A/C Mode Control (Air Direction) For maximum cooling, when MAX A/C is selected the A/C is turned on automatically and the air is Mode control allows you to choose recirculated. from several patterns of air distribu- tion.
Page 398 396 UNDERSTANDING YOUR INSTRUMENT PANEL Bi-Level Mode Defrost Mode Air is directed through the panel and floor outlets. Air is directed through the windshield and side window demist outlets. Use the DEFROST mode with maximum blower and warm temperature settings NOTE: There is a difference in temperature (in any for best windshield and side window defrosting.
Page 399 UNDERSTANDING YOUR INSTRUMENT PANEL 397 NOTE: Air Outlets • If the RECIRCULATION button is pressed when the The airflow from each of the instrument panel outlets can be adjusted for direction, and turned on or off to control system is in Defrost mode the Recirculation LED airflow.
Page 400: Manual Climate Controls With Touchscreen
398 UNDERSTANDING YOUR INSTRUMENT PANEL Manual Climate Controls With Touchscreen — Soft-Keys If Equipped Soft-keys are accessible on the Uconnect® system screen. Hard-Keys The hard-keys are located below the Uconnect® screen. Uconnect® 5.0 Manual Temperature Controls — Soft-Keys Uconnect® Manual Climate Controls — Hard-Keys...
Page 401 UNDERSTANDING YOUR INSTRUMENT PANEL 399 Button Descriptions (Applies To Both Hard-Keys And Soft-Keys) 1. MAX A/C Button Press and release to change the current setting, the indicator illuminates when MAX A/C is ON. Performing this function again will cause the MAX A/C operation to switch into manual mode and the MAX A/C indicator will turn off.
Page 402 400 UNDERSTANDING YOUR INSTRUMENT PANEL 4. Front Defrost Button CAUTION! Press and release to change the current airflow setting to Failure to follow these cautions can cause damage to Defrost mode. The indicator illuminates when this fea- the heating elements: ture is ON.
Page 403 UNDERSTANDING YOUR INSTRUMENT PANEL 401 6. Blower Control 7. Modes Blower control is used to regulate the amount of air The airflow distribution mode can be adjusted so air forced through the climate system. There are seven comes from the instrument panel outlets, floor outlets, blower speeds available.
Page 404 402 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: BI-LEVEL mode is designed under comfort con- 9. Temperature Control Down Button (Uconnect® 8.4) ditions to provide cooler air out of the panel outlets and Provides temperature control. Push the hard-key button warmer air from the floor outlets. for cooler temperature settings or on the touchscreen, •...
Page 405: Automatic Climate Controls With Touchscreen - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 403 Automatic Climate Controls With Touchscreen — Soft-Keys If Equipped Soft-keys are accessible on the Uconnect® system screen. Hard-Keys The hard-keys are located below the Uconnect® screen. Uconnect® 8.4 Automatic Temperature Controls — Soft-Keys Uconnect® Automatic Climate Controls — Hard-Keys...
Page 406 404 UNDERSTANDING YOUR INSTRUMENT PANEL Button Descriptions (Applies To Both Hard-Keys And 4. AUTO Operation Button Soft-Keys) Automatically controls the interior cabin temperature by 1. MAX A/C Button adjusting airflow distribution and amount. Performing this function will cause the ATC to switch between Press and release to change the current setting, the manual mode and automatic modes.
Page 407 UNDERSTANDING YOUR INSTRUMENT PANEL 405 6. Rear Defrost Button CAUTION! (Continued) Press and release this button to turn on the rear window • Do not use scrapers, sharp instruments, or abrasive defroster and the heated outside mirrors (if equipped). window cleaners on the interior surface of the An indicator will illuminate when the rear window window.
Page 408 406 UNDERSTANDING YOUR INSTRUMENT PANEL 8. Passenger Temperature Control Down Button 10. Blower Control Provides the passenger with independent temperature Blower control is used to regulate the amount of air control. Push the hard-key button for cooler temperature forced through the climate system. There are seven settings or on the touchscreen, touch and slide the blower speeds available.
Page 409 UNDERSTANDING YOUR INSTRUMENT PANEL 407 11. Modes NOTE: BI-LEVEL mode is designed under comfort con- ditions to provide cooler air out of the panel outlets and The airflow distribution mode can be adjusted so air warmer air from the floor outlets. comes from the instrument panel outlets, floor outlets, •...
Page 410: Climate Control Functions
408 UNDERSTANDING YOUR INSTRUMENT PANEL 13. Driver Temperature Control Down Button Climate Control Functions Provides the driver with independent temperature con- A/C (Air Conditioning) trol. Push the hard-key button for cooler temperature The Air Conditioning (A/C) button allows the operator settings or on the touchscreen, touch and slide the to manually activate or deactivate the air conditioning soft-key temperature bar towards the blue arrow soft-key...
Page 411 UNDERSTANDING YOUR INSTRUMENT PANEL 409 • If your air conditioning performance seems lower than Recirculation expected, check the front of the A/C condenser (lo- When outside air contains smoke, odors, or cated in front of the radiator), for an accumulation of high humidity, or if rapid cooling is desired, dirt or insects.
Page 412: Automatic Temperature Control (Atc)
410 UNDERSTANDING YOUR INSTRUMENT PANEL Automatic Temperature Control (ATC) NOTE: • It is not necessary to move the temperature settings for Automatic Operation cold or hot vehicles. The system automatically adjusts 1. Press the AUTO hard-key or soft-key button on the the temperature, mode, and blower speed to provide Automatic Temperature Control (ATC) Panel.
Page 413: Operating Tips
UNDERSTANDING YOUR INSTRUMENT PANEL 411 The blower fan speed can be set to any fixed speed by A solution of 50% OAT (Organic Additive Technology) adjusting the blower control. The fan will now operate at coolant that meets the requirements of Chrysler Material a fixed speed until additional speeds are selected.
Page 414 412 UNDERSTANDING YOUR INSTRUMENT PANEL Window Fogging Outside Air Intake Interior fogging on the windshield can be quickly re- Make sure the air intake, located directly in front of the moved by turning the mode selector to Defrost. The windshield, is free of obstructions such as leaves. Leaves Defrost/Floor mode can be used to maintain a clear collected in the air intake may reduce airflow, and if they windshield and provide sufficient heating.
Page 415 UNDERSTANDING YOUR INSTRUMENT PANEL 413 Control Setting Suggestions For Various Weather Conditions...
Page 417 STARTING AND OPERATING CONTENTS ▫ Brake/Transmission Shift Interlock System . . .426 STARTING PROCEDURES ....420 ▫ Normal Starting..... . .420 ▫...
Page 418 416 STARTING AND OPERATING ▫ Rear Electronic Locker (E-Locker) System — ELECTRIC PARKING BRAKE (EPB) ..451 If Equipped......442 ▫...
Page 419 STARTING AND OPERATING 417 ▫ Selec Speed Control (SSC) — If Equipped ..470 TIRES — GENERAL INFORMATION ..492 ▫ Tire Pressure ......492 ▫...
Page 420 418 STARTING AND OPERATING TIRE ROTATION RECOMMENDATIONS ..506 ADDING FUEL ......525 ▫ Emergency Fuel Filler Door Release..527 TIRE PRESSURE MONITOR SYSTEM (TPMS) .
Page 421 STARTING AND OPERATING 419 ▫ Recreational Towing — 4WD Models With RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) ... .543 1-Speed Power Transfer Unit ... . .545 ▫...
Page 422: Starting Procedures
420 STARTING AND OPERATING STARTING PROCEDURES Start the engine with the shift lever in the NEUTRAL or PARK position. Apply the brake before shifting to any Before starting your vehicle, adjust your seat, adjust both driving range. inside and outside mirrors, and fasten your seat belts. Normal Starting WARNING! NOTE: Normal starting of either a cold or a warm engine...
Page 423: Extreme Cold Weather (Below -20°F Or −29°C)
STARTING AND OPERATING 421 starter will disengage automatically in 10 seconds. If this 3. If the engine fails to start within 10 seconds, place the occurs, turn the ignition switch to the LOCK position, ignition to the STOP (OFF/LOCK) position, wait five wait 10 to 15 seconds, then repeat the “Normal Starting”...
Page 424: After Starting
422 STARTING AND OPERATING clear any excess fuel, press the accelerator pedal all the WARNING! (Continued) way to the floor and hold it. Then, cycle the ignition • Do not attempt to push or tow your vehicle to get it switch to the START position and release it as soon as the started.
Page 425: Engine Block Heater - If Equipped
STARTING AND OPERATING 423 ENGINE BLOCK HEATER — IF EQUIPPED 4. After the vehicle is running, reattach the cord to the Velcro strap and properly stow away behind the The engine block heater warms the engine and permits driver’s side headlamp. quicker starts in cold weather.
Page 426: Automatic Transmission
424 STARTING AND OPERATING AUTOMATIC TRANSMISSION WARNING! (Continued) • Unintended movement of a vehicle could injure WARNING! those in or near the vehicle. As with all vehicles, • It is dangerous to shift out of PARK or NEUTRAL you should never exit a vehicle while the engine is if the engine speed is higher than idle speed.
Page 427 STARTING AND OPERATING 425 WARNING! (Continued) CAUTION! • Never leave children alone in a vehicle, or with Damage to the transmission may occur if the follow- access to an unlocked vehicle. Allowing children to ing precautions are not observed: be in a vehicle unattended is dangerous for a •...
Page 428: Key Ignition Park Interlock
426 STARTING AND OPERATING Key Ignition Park Interlock Nine-Speed Automatic Transmission This vehicle is equipped with a Key Ignition Park Inter- Your vehicle is equipped with a state of the art, fuel lock which requires the transmission to be in PARK efficient nine-speed transmission.
Page 429 STARTING AND OPERATING 427 Only shift from DRIVE to PARK or REVERSE when the accelerator pedal is released and the vehicle is stopped. Be sure to keep your foot on the brake pedal when shifting between these gears. The transmission shift lever has PARK, REVERSE, NEU- TRAL, DRIVE, and Electronic Range Select (ERS) shift positions.
Page 430: Gear Ranges
428 STARTING AND OPERATING Gear Ranges When parking on a hill, apply the parking brake before shifting the transmission to PARK, otherwise the load on DO NOT race the engine when shifting from PARK or the transmission locking mechanism may make it diffi- NEUTRAL into another gear range.
Page 431 STARTING AND OPERATING 429 WARNING! (Continued) WARNING! (Continued) • Your vehicle could move and injure you and others • Unintended movement of a vehicle could injure if it is not completely in PARK. Check by trying to those in or near the vehicle. As with all vehicles, move the shift lever out of PARK with the brake you should never exit a vehicle while the engine is pedal released.
Page 432 430 STARTING AND OPERATING WARNING! (Continued) CAUTION! • Never leave children alone in a vehicle, or with • Before moving the shift lever out of PARK, you access to an unlocked vehicle. Allowing children to must turn the ignition switch from the LOCK/OFF be in a vehicle unattended is dangerous for a position to the ON/RUN position, and also press number of reasons.
Page 433 STARTING AND OPERATING 431 • With brake pedal released, verify that the shift lever CAUTION! will not move out of PARK. Towing the vehicle, coasting, or driving for any other REVERSE (R) reason with the transmission in NEUTRAL can cause This range is for moving the vehicle backward.
Page 434 432 STARTING AND OPERATING When frequent transmission shifting occurs (such as If the transmission becomes extremely hot, the “Trans- when operating the vehicle under heavy loading condi- mission Temperature Warning Light” may illuminate and tions, in hilly terrain, traveling into strong head winds, or the transmission may operate differently until the trans- while towing heavy trailers), use the Electronic Range mission cools down.
Page 435 STARTING AND OPERATING 433 SPORT — IF EQUIPPED illuminated. Limp Home Mode allows the vehicle to be driven to an authorized dealer for service without dam- This mode alters the transmission’s automatic shift aging the transmission. schedule for sportier driving. Upshift speeds are in- creased to make full use of available engine power.
Page 436 434 STARTING AND OPERATING NOTE: Even if the transmission can be reset, we recom- Moving the shift lever to the ERS position (beside mend that you visit your authorized dealer at your DRIVE) will activate ERS mode, display the current gear earliest possible convenience.
Page 437: Four-Wheel Drive Operation
STARTING AND OPERATING 435 NOTE: To select the proper gear position for maximum deceleration (engine braking), simply press and hold the shift lever forward (-). The transmission will shift to the range from which the vehicle can best be slowed down. FOUR-WHEEL DRIVE OPERATION 1-Speed Four-Wheel Drive (4WD) —...
Page 438: 2-Speed Four-Wheel Drive (4Wd) - If Equipped
436 STARTING AND OPERATING CAUTION! All wheels must have the same size and type tires. Unequal tire sizes must not be used. Unequal tire size may cause failure of the power transfer unit. 2-Speed Four-Wheel Drive (4WD) — If Equipped Selec-Terrain Switch The Four-Wheel Drive is fully automatic in the normal driving mode.
Page 439: Shift Positions
STARTING AND OPERATING 437 When additional traction is required, the 4WD LOW Because four-wheel drive provides improved traction, range position can be used to provide an additional gear there is a tendency to exceed safe turning and stopping reduction which allows for increased torque to be deliv- speeds.
Page 440: Shifting Procedures
438 STARTING AND OPERATING NOTE: Refer to “Selec-Terrain® – If Equipped” for fur- WARNING! ther information on the various positions and their intended usages. You or others could be seriously or fatally injured if you leave the vehicle unattended with the power Shifting Procedures transfer unit in the NEUTRAL (N) position without Shifting Into 4WD LOW...
Page 441 STARTING AND OPERATING 439 Shifting Out Of 4WD LOW With the vehicle at speeds of 0 to 3 mph (0 to 5 km/h), the ignition switch in the ON position or the engine running, shift the transmission into NEUTRAL, and press the “4WD LOW”...
Page 442 440 STARTING AND OPERATING • Shifting into or out of 4WD LOW is possible with the WARNING! (Continued) vehicle completely stopped; however, difficulty may drive shafts from the powertrain and will allow the occur due to the mating clutch teeth not being prop- vehicle to move regardless of the transmission posi- erly aligned.
Page 443 STARTING AND OPERATING 441 The light behind the NEUTRAL (N) symbol will blink, 7. After the shift is completed and the NEUTRAL light indicating shift in progress. The light will stop blink- stays on, release the NEUTRAL (N) button. ing (stay on solid) when the shift to NEUTRAL (N) is 8.
Page 444: Starting And Operating Rear Electronic Locker (E-Locker) System - If Equipped
442 STARTING AND OPERATING Rear Electronic Locker (E-Locker) System — Deactivating The Rear E-Locker System If Equipped To deactivate the Rear E-Locker System, the following The Rear E-Locker System features a mechanical locking conditions must be met: rear differential to provide better traction in the 4WD 1.
Page 445: Selec-Terrain
STARTING AND OPERATING 443 • When engaging Rear E-Locker, the indicator lights in • The Rear E-Locker System must be disengaged prior to the instrument cluster and on the REAR LOCK button taking the vehicle out of 4WD LOW range. If 4WD will begin to flash.
Page 446 444 STARTING AND OPERATING • Snow — Tuning set for additional stability in inclem- ent weather. Use on and off road on loose traction surfaces such as snow. When in SNOW mode (depend- ing on certain operating conditions), the transmission may use second gear (rather than first gear) during launches, to minimize wheel slippage.
Page 447: On-Road Driving Tips
STARTING AND OPERATING 445 • Rock — Off-road calibration only available in 4WD ON-ROAD DRIVING TIPS LOW range. Traction based tuning with improved Utility vehicles have higher ground clearance and a steer-ability for use on high traction off-road surfaces. narrower track to make them capable of performing in a Use for low speed obstacles such as large rocks, deep wide variety of off-road applications.
Page 448: Off-Road Driving Tips
446 STARTING AND OPERATING OFF-ROAD DRIVING TIPS Driving Through Water Although your vehicle is capable of driving through When To Use 4WD LOW Range water, there are a number of precautions that must be When off-road driving, shift to 4WD LOW for additional considered before entering the water: traction and control on slippery or difficult terrain, ascending or descending steep hills, and to increase...
Page 449: Driving In Snow, Mud And Sand
STARTING AND OPERATING 447 entering. Proceed with caution and maintain a steady Maintenance controlled speed less than 5 mph (8 km/h) in deep water After driving through deep water, inspect your vehicle to minimize wave effects. fluids and lubricants (engine, transmission, Power Trans- fer Unit and Rear Drive Module) to assure they have not Flowing Water been contaminated.
Page 450: Hill Climbing
448 STARTING AND OPERATING Avoid abrupt downshifts on icy or slippery roads be- WARNING! cause engine braking may cause skidding and loss of control. If the engine stalls or you lose headway or cannot make it to the top of a steep hill or grade, never Hill Climbing attempt to turn around.
Page 451: Traction Downhill
STARTING AND OPERATING 449 Traction Downhill can get any problems taken care of right away and have your vehicle ready when you need it. Shift the transmission into a low gear and the 4WD • Completely inspect the underbody of your vehicle. System to 4WD LOW range or Select Hill Descent Control if equipped (refer to Electronic Brake Control Check tires, body structure, steering, suspension, and...
Page 452: Power Steering
450 STARTING AND OPERATING • After extended operation in mud, sand, water, or POWER STEERING similar dirty conditions, have the radiator, fan, brake The electric power steering system will give you good rotors, wheels, brake linings, and axle yokes inspected vehicle response and increased ease of maneuverability and cleaned as soon as possible.
Page 453: Electric Parking Brake (Epb)
STARTING AND OPERATING 451 If the “SERVICE POWER STEERING” message ELECTRIC PARKING BRAKE (EPB) and a steering wheel icon are displayed on the Your vehicle is equipped with an Electric Parking Brake EVIC screen, it indicates that the vehicle needs System (EPB) that offers simple operation, and some to be taken to the dealer for service.
Page 454 452 STARTING AND OPERATING The parking brake switch is located in the center console. an indicator on the switch will illuminate. If your foot is on the brake pedal while you apply the parking brake, you may notice a small amount of brake pedal move- ment.
Page 455 STARTING AND OPERATING 453 will illuminate. If your foot is on the brake pedal, you NOTE: When parking on a hill, it is important to turn the may notice a small amount of brake pedal movement front wheels toward the curb on a downhill grade and while the parking brake is engaging.
Page 456 454 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • Never leave children alone in a vehicle, or with • Always fully apply the parking brake when leav- access to an unlocked vehicle. Allowing children to ing your vehicle, or it may roll and cause damage or be in a vehicle unattended is dangerous for a injury.
Page 457: Auto Park Brake
STARTING AND OPERATING 455 will sound. The rear stop lamps will also be illuminated This may be accompanied by the Brake warning lamp automatically while the vehicle remains in motion. flashing. In this event, urgent service of the electric park brake system is required.
Page 458: Safehold
456 STARTING AND OPERATING Safehold For manual transmissions, the park brake will automati- cally engage if all of the following conditions are met: Safehold is a safety feature of the Electric Park Brake • The vehicle is at a standstill System that will engage the park brake automatically if the vehicle is left unsecured while the ignition switch is •...
Page 459: Brake Service Mode
STARTING AND OPERATING 457 Brake Service Mode Service Mode has requirements that must be met in order to be activated: We recommend having your brakes serviced by your • The vehicle must be at a standstill. authorized dealer. You should only make repairs for which you have the knowledge and the right equipment.
Page 460: Brake System
458 STARTING AND OPERATING In addition, if the malfunction is caused by a leak in the WARNING! hydraulic system, the “Brake Warning Light” will turn on as the brake fluid level drops in the master cylinder. You can be badly injured working on or around a motor vehicle.
Page 461: Electronic Brake Control System
STARTING AND OPERATING 459 Your vehicle is also equipped with Trailer Sway Control WARNING! (Continued) (TSC), Ready Alert Braking (RAB), Rain Brake Support • Driving a vehicle with the “Brake Warning Light” (RBS), and Dynamic Steering Torque (DST). Further, all on is dangerous.
Page 462 460 STARTING AND OPERATING WARNING! WARNING! • Pumping of the Anti-Lock Brakes will diminish Significant over or under-inflation of tires or mixing sizes of tires or wheels on the vehicle can lead to loss their effectiveness and may lead to a collision. of braking effectiveness.
Page 463 STARTING AND OPERATING 461 • Engines may idle at higher speeds during warm-up, CAUTION! which could cause rear wheels to spin and result in loss of vehicle control. Be especially careful while The ABS is subject to possible detrimental effects of driving on slippery roads, in close-quarter maneuver- electronic interference caused by improperly in- ing, parking, or stopping.
Page 464: Traction Control System (Tcs)
462 STARTING AND OPERATING Traction Control System (TCS) Brake Assist System (BAS) This system monitors the amount of wheel spin of each of The BAS is designed to optimize the vehicle’s braking the driven wheels. If wheel spin is detected, brake capability during emergency braking maneuvers.
Page 465: Electronic Roll Mitigation (Erm)
STARTING AND OPERATING 463 applies the appropriate brake and may also reduce WARNING! engine power to lessen the chance that wheel lift will The Brake Assist System (BAS) cannot prevent the occur. ERM will only intervene during very severe or natural laws of physics from acting on the vehicle, evasive driving maneuvers.
Page 466: Hill Start Assist (Hsa)
464 STARTING AND OPERATING The following conditions must be met in order for HSA to WARNING! (Continued) activate: rollovers, especially those that involve leaving the • The vehicle must be stopped. roadway or striking objects or other vehicles. The capabilities of an ERM-equipped vehicle must never •...
Page 467 STARTING AND OPERATING 465 Towing With HSA WARNING! HSA will provide assistance during acceleration on an There may be situations where the Hill Start Assist incline while towing a trailer. (HSA) will not activate and slight rolling may occur, such as on minor hills or with a loaded vehicle, or WARNING! while pulling a trailer.
Page 468: Hill Descent Control (Hdc) - If Equipped
466 STARTING AND OPERATING Hill Descent Control (HDC) — If Equipped WARNING! (Continued) • HSA is not a parking brake. Always apply the parking brake fully when leaving your vehicle. Also, be certain to leave the transmission in PARK. • Failure to follow these warnings can result in a collision or serious personal injury.
Page 469 STARTING AND OPERATING 467 HDC has three states: Activating HDC Once HDC is enabled it will activate automatically if 1. Off (feature is not enabled and will not activate) driven down a grade of sufficient magnitude (greater 2. Enabled (feature is enabled and ready but activation than approximately 8%).
Page 470 468 STARTING AND OPERATING • 4th = 2.5 mph (4 km/h) Deactivating HDC • 5th = 3.1 mph (5 km/h) HDC will be deactivated but remain available if any of the following conditions occur: • 6th = 3.7 mph (6 km/h) •...
Page 471 STARTING AND OPERATING 469 • The parking brake is applied. • The cluster icon and switch lamp will flash for several seconds then extinguish when HDC deactivates due to • Driver door opens. excess speed. • The vehicle is driven greater than 20 mph (32 km/h) •...
Page 472: Selec Speed Control (Ssc) - If Equipped
470 STARTING AND OPERATING Selec Speed Control (SSC) — If Equipped SSC has three states: 1. Off (feature is not enabled and will not activate) 2. Enabled (feature is enabled and ready but activation conditions are not met, or driver is actively overriding with brake or throttle application) 3.
Page 473 STARTING AND OPERATING 471 Activating SSC 4WD Low Range Set Speeds • 1st = .6 mph (1 km/h) Once SSC is enabled it will activate automatically once the following conditions are met: • 2nd = 1.2 mph (2 km/h) • Driver releases throttle •...
Page 474 472 STARTING AND OPERATING NOTE: Deactivating SSC • These SSC default set speeds are dependent on hill SSC will be deactivated but remain available if any of the grade. That is the steeper the grade of the hill the following conditions occur: vehicle travels on the lower the values of the set speed •...
Page 475 STARTING AND OPERATING 473 • Driver door opens. • The cluster icon and switch lamp will flash for several seconds then extinguish when SSC deactivates due to • The vehicle is driven greater than 20 mph (32 km/h) excess speed. for greater than 70 seconds.
Page 476: Electronic Stability Control (Esc)
474 STARTING AND OPERATING Electronic Stability Control (ESC) The “ESC Activation/Malfunction Indicator Light” lo- cated in the instrument cluster will start to flash as soon This system enhances directional control and stability of as the tires lose traction and the ESC system becomes the vehicle under various driving conditions.
Page 477 STARTING AND OPERATING 475 ESC On — Two-Wheel Drive Vehicles And Four-Wheel WARNING! (Continued) Drive Vehicles In 2WD And 4WD High Range speed in turns, driving on very slippery surfaces, or This is the normal operating mode for ESC when oper- hydroplaning.
Page 478 476 STARTING AND OPERATING The “ESC Off” button is located in the lower switch bank WARNING! (Continued) above the climate control. To enter the “Partial Off” • Trailer Sway Control (TSC) is disabled when the mode, momentarily press the “ESC Off” button and the ESC system is in the Partial Off mode.
Page 479 STARTING AND OPERATING 477 The “ESC Off” button is located in the lower switch bank WARNING! above the climate control panel. To enter “Full Off” mode, press and hold the “ESC Off” button for five With the ESC switched off, the enhanced vehicle seconds while the vehicle is stopped with the engine stability offered by ESC is unavailable.
Page 480: Esc Activation/Malfunction Indicator Light And Esc Off Indicator Light
478 STARTING AND OPERATING ESC Activation/Malfunction Indicator Light And The “ESC Activation/Malfunction Indicator Light” also ESC OFF Indicator Light flashes when TCS is active. If the “ESC Activation/ Malfunction Indicator Light” begins to flash during ac- The “ESC Activation/Malfunction Indicator celeration, ease up on the accelerator and apply as little Light”...
Page 481: Trailer Sway Control (Tsc)
STARTING AND OPERATING 479 The ESC OFF Indicator Light indicates the you may feel the brakes being applied to individual Electronic Stability Control (ESC) is partially wheels to attempt to stop the trailer from swaying. TSC is off or full off. only active in the default “ESC On”...
Page 482: Ready Alert Braking (Rab)
480 STARTING AND OPERATING Ready Alert Braking (RAB) Dynamic Steering Torque (DST) Ready Alert Braking may reduce the time required to Dynamic Steering Torque is a feature of the ESC and EPS reach full braking during emergency braking situations. modules that provide a torque at the steering wheel for It anticipates when an emergency braking situation may certain driving conditions in which the ESC module is occur by monitoring how fast the throttle is released by...
Page 483: Tire Safety Information
STARTING AND OPERATING 481 TIRE SAFETY INFORMATION NOTE: • P (Passenger) — Metric tire sizing is based on U.S. Tire Markings design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. •...
Page 484 482 STARTING AND OPERATING • Temporary spare tires are designed for temporary • High flotation tire sizing is based on U.S. design emergency use only. Temporary high pressure com- standards and it begins with the tire diameter molded pact spare tires have the letter “T” or “S” molded into into the sidewall.
Page 485 STARTING AND OPERATING 483 EXAMPLE: 65 = Aspect ratio in percent (%) – Ratio of section height to section width of tire 10.5 = Section width in inches (in) R = Construction code – R means radial construction – D means diagonal or bias construction 15 = Rim diameter in inches (in) Service Description: 95 = Load Index...
Page 486 484 STARTING AND OPERATING EXAMPLE: H = Speed Symbol – A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions – The maximum speed corresponding to the speed symbol should only be achieved under specified operating conditions (i.e., tire pressure, vehicle loading, road conditions, and posted speed limits) Load Identification:...
Page 487: Tire Identification Number (Tin)
STARTING AND OPERATING 485 Tire Identification Number (TIN) Look for the TIN on the outboard side of black sidewall tires as mounted on the vehicle. If the TIN is not found on The TIN may be found on one or both sides of the tire, the outboard side, then you will find it on the inboard however, the date code may only be on one side.
Page 488: Tire Terminology And Definitions
486 STARTING AND OPERATING EXAMPLE: DOT MA L9 ABCD 0301 01 = Number representing the year in which the tire was manufactured (two digits) — 01 means the year 2001 — Prior to July 2000, tire manufacturers were only required to have one number to represent the year in which the tire was manufactured.
Page 489 STARTING AND OPERATING 487 Term Definition Maximum Inflation Pressure The maximum inflation pressure is the maximum permissible cold tire inflation pressure for this tire. The maximum inflation pressure is molded into the sidewall. Recommended Cold Tire Inflation Vehicle manufacturer’s recommended cold tire inflation pressure Pressure as shown on the tire placard.
Page 490: Tire Loading And Tire Pressure
488 STARTING AND OPERATING Tire Loading And Tire Pressure Tire And Loading Information Placard Tire And Loading Information Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver’s side door.
Page 491 STARTING AND OPERATING 489 3. Tire size designed for your vehicle. To determine the maximum loading conditions of your vehicle, locate the statement “The combined weight of 4. Cold tire inflation pressures for the front, rear, and occupants and cargo should never exceed XXX lbs or spare tires.
Page 492 490 STARTING AND OPERATING 4. The resulting figure equals the available amount of NOTE: cargo and luggage load capacity. For example, if • If your vehicle will be towing a trailer, load from your “XXX” amount equals 1,400 lbs (635 kg) and there will trailer will be transferred to your vehicle.
Page 493 STARTING AND OPERATING 491...
Page 494: Tires - General Information
492 STARTING AND OPERATING Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause collisions. recommended load capacity for your vehicle.
Page 495 STARTING AND OPERATING 493 Ride Comfort And Vehicle Stability WARNING! (Continued) Proper tire inflation contributes to a comfortable ride. • Unequal tire pressures from one side of the vehicle Over-inflation produces a jarring and uncomfortable to the other can cause the vehicle to drift to the ride.
Page 496: Tire Inflation Pressures
494 STARTING AND OPERATING Tire Inflation Pressures Inflation pressures specified on the placard are always “cold tire inflation pressure.” Cold tire inflation pressure The proper cold tire inflation pressure is listed on the is defined as the tire pressure after the vehicle has not driver’s side B-Pillar or rear edge of the driver’s side door.
Page 497: Tire Pressures For High Speed Operation
STARTING AND OPERATING 495 Example: If garage temperature = 68°F (20°C) and the WARNING! outside temperature = 32°F (0°C) then the cold tire inflation pressure should be increased by 3 psi (21 kPa), High speed driving with your vehicle under maxi- which equals 1 psi (7 kPa) for every 12°F (7°C) for this mum load is dangerous.
Page 498: Tire Types
496 STARTING AND OPERATING Tire Repair Tire Types If your tire becomes damaged, it may be repaired if it All Season Tires — If Equipped meets the following criteria: All Season tires provide traction for all seasons (spring, • The tire has not been driven on when flat. summer, fall and winter).
Page 499: Run Flat Tires - If Equipped
STARTING AND OPERATING 497 Use summer tires only in sets of four; failure to do so may While studded tires improve performance on ice, skid and traction capability on wet or dry surfaces may be adversely affect the safety and handling of your vehicle. poorer than that of non-studded tires.
Page 500: Spare Tires - If Equipped
498 STARTING AND OPERATING Spare Tires — If Equipped rotation for your vehicle. If your vehicle has this option, refer to an authorized tire dealer for the recommended NOTE: For vehicles equipped with TIREFIT instead of a tire rotation pattern. spare tire, please refer to “TIREFIT KIT”...
Page 501 STARTING AND OPERATING 499 Do not install a wheel cover or attempt to mount a Full Size Spare — If Equipped conventional tire on the compact spare wheel, since the The full size spare is for temporary emergency use only. wheel is designed specifically for the compact spare tire.
Page 502: Tire Spinning
500 STARTING AND OPERATING tire affects vehicle handling. Since it is not the same as Tire Spinning your original equipment tire, replace (or repair) the When stuck in mud, sand, snow, or ice conditions, do not original equipment tire and reinstall on the vehicle at the spin your vehicle’s wheels above 30 mph (48 km/h) or for first opportunity.
Page 503: Tread Wear Indicators
STARTING AND OPERATING 501 Tread Wear Indicators These indicators are molded into the bottom of the tread grooves. They will appear as bands when the tread depth Tread wear indicators are in the original equipment tires becomes 1/16 in (2 mm). When the tread is worn to the to help you in determining when your tires should be tread wear indicators, the tire should be replaced.
Page 504: Replacement Tires
502 STARTING AND OPERATING “Tread Wear Indicator.” Refer to the Tire and Loading WARNING! Information placard or the Vehicle Certification Label for the size designation of your tire. The Load Index and Tires and the spare tire should be replaced after six Speed Symbol for your tire will be found on the original years, regardless of the remaining tread.
Page 505 STARTING AND OPERATING 503 WARNING! WARNING! (Continued) • Failure to equip your vehicle with tires having • Do not use a tire, wheel size or rating other than adequate speed capability can result in sudden tire that specified for your vehicle. Some combinations failure and loss of vehicle control.
Page 506: Tire Chains (Traction Devices)
504 STARTING AND OPERATING TIRE CHAINS (TRACTION DEVICES) Four Wheel Drive (4WD) Non-Trailhawk Models with- out a Two-Speed Power Takeoff Unit Use of traction devices require sufficient tire-to-body • Original equipment 225/65R17 and 225/60R18 tire clearance. Follow these recommendations to guard against damage.
Page 507 STARTING AND OPERATING 505 CAUTION! CAUTION! • Use on Front Tires Only To avoid damage to your vehicle or tires, observe the • Damage to Front Wheel Drive (FWD) Models may following precautions: result if tire chains or traction devices are used with •...
Page 508: Tire Rotation Recommendations
506 STARTING AND OPERATING These effects can be reduced by timely rotation of tires. CAUTION! (Continued) The benefits of rotation are especially worthwhile with • Observe the traction device manufacturer’s instruc- aggressive tread designs such as those on On/Off Road tions on the method of installation, operating type tires.
Page 509 STARTING AND OPERATING 507 Front Wheel Drive (FWD) Tire Rotation Four Wheel Drive (4WD) Tire Rotation The suggested Four Wheel Drive (4WD) Tire rotation CAUTION! method is the “forward-cross” shown in the following diagram. Proper operation of four-wheel drive vehicles de- pends on tires of equal size, type and circumference on each wheel.
Page 510: Tire Pressure Monitor System (Tpms)
508 STARTING AND OPERATING the tire sidewall. Refer to “Tires – General Information” CAUTION! (Continued) in “Starting and Operating” for information on how to damage to the power transfer unit. Tire rotation properly inflate the vehicle’s tires. The tire pressure will schedule should be followed to balance tire wear.
Page 511 STARTING AND OPERATING 509 NOTE: When filling warm tires, the tire pressure may pressure is low enough to turn ON the “Tire Pressure need to be increased up to an additional 4 psi (30 kPa) Monitoring Telltale Light.” Driving the vehicle may cause above the recommended cold placard pressure in order the tire pressure to rise to approximately 28 psi (193 kPa), to turn the Tire Pressure Monitoring Telltale Light off.
Page 512 510 STARTING AND OPERATING CAUTION! CAUTION! (Continued) • After inspecting or adjusting the tire pressure, • The TPMS has been optimized for the original always reinstall the valve stem cap. This will equipment tires and wheels. TPMS pressures and prevent moisture and dirt from entering the valve warning have been established for the tire size stem, which could damage the Tire Pressure Moni- equipped on your vehicle.
Page 513: Base System
STARTING AND OPERATING 511 • Driving on a significantly underinflated tire causes the Base System tire to overheat and can lead to tire failure. Underin- The Tire Pressure Monitor System (TPMS) uses wireless flation also reduces fuel efficiency and tire tread life, technology with wheel rim mounted electronic sensors to and may affect the vehicle’s handling and stopping monitor tire pressure levels.
Page 514 512 STARTING AND OPERATING Tire Pressure Monitoring Low Pressure Warnings Service TPMS Warning When a system fault is detected, the “Tire Pressure The “Tire Pressure Monitoring Telltale Light” will Monitoring Telltale Light” will flash on and off for illuminate in the instrument cluster, a “LOW TIRE 75 seconds and then remain on solid.
Page 515 STARTING AND OPERATING 513 4. Using tire chains on the vehicle. Vehicles With Compact Spare 5. Using wheels/tires not equipped with TPMS sensors. 1. The compact spare tire does not have a tire pressure monitoring sensor. Therefore, the TPMS will not moni- Vehicles With Full-Size Spare tor the pressure in the compact spare tire.
Page 516: Premium System - If Equipped
514 STARTING AND OPERATING 5. Once you repair or replace the original road tire and The TPMS consists of the following components: reinstall it on the vehicle in place of the compact spare, • Receiver Module the TPMS will update automatically and the “TPMS •...
Page 517 STARTING AND OPERATING 515 Tire Pressure Monitoring Low Pressure Warnings The “Tire Pressure Monitoring Telltale Light” will illuminate in the instrument cluster and a chime will sound when tire pressure is low in one or more of the four active road tires. In addition, the Electronic Vehicle Information Center (EVIC)/Driver information Display (DID) will display a Tire Low message for a minimum of five seconds, an Inflate to XX message and a graphic...
Page 518 516 STARTING AND OPERATING update, the pressure values in the graphic display in the EVIC/DID will return to their original color, and the “Tire Pressure Monitoring Telltale Light” will turn off. The vehicle may need to be driven for up to 20 minutes above 15.5 mph (25 km/h) in order for the TPMS to receive this information.
Page 519 STARTING AND OPERATING 517 SYSTEM” message will no longer display, and a pressure Vehicles With Matching Full-Size Spare value will display in place of the dashes. A system fault 1. The matching full size spare wheel and tire assembly can occur due to any of the following: has a tire pressure monitoring sensor that can be 1.
Page 520 518 STARTING AND OPERATING 4. The EVIC/DID will display a graphic showing the tire graphic in the EVIC/DID will still display a different pressure value in the same color as the other pressure color pressure value and an Inflate to XX message. values in place of the different color low tire pressure 3.
Page 521: General Information
STARTING AND OPERATING 519 automatically. In addition, the “TPMS Telltale Light” The TPM sensors are regulated under one of the follow- will turn off and the graphic in the EVIC will display ing licenses: a new pressure value instead of dashes (- -), as long as United States GQ4-61T no tire pressure is below the low-pressure warning...
Page 522 520 STARTING AND OPERATING Light spark knock at low engine speeds is not harmful to 3.2L Engine your engine. However, continued heavy spark knock at These engines are designed to meet all high speeds can cause damage and immediate service is emissions regulations and provide satisfac- required.
Page 523: Reformulated Gasoline
STARTING AND OPERATING 521 Reformulated Gasoline CAUTION! Many areas of the country require the use of cleaner DO NOT use gasoline containing Methanol or gaso- burning gasoline referred to as “Reformulated Gasoline.” line containing more than 10% Ethanol. Use of these Reformulated gasoline contain oxygenates and are spe- blends may result in starting and drivability prob- cifically blended to reduce vehicle emissions and im-...
Page 524: E-85 Usage In Non-Flex Fuel Vehicles
522 STARTING AND OPERATING E-85 Usage In Non-Flex Fuel Vehicles To fix a Non-FFV vehicle inadvertently fueled once with E-85 perform the following: Non-Flex Fuel Vehicles (FFV) are compatible with gaso- • Drain the fuel tank (see your authorized dealer). line containing 10% ethanol (E10).
Page 525: Materials Added To Fuel
STARTING AND OPERATING 523 MMT. Gasoline blended with MMT reduces spark plug Fuel System Cautions life and reduces emissions system performance in some vehicles. The manufacturer recommends that gasoline CAUTION! without MMT be used in your vehicle. The MMT content Follow these guidelines to maintain your vehicle’s of gasoline may not be indicated on the gasoline pump, performance:...
Page 526: Carbon Monoxide Warnings
524 STARTING AND OPERATING Carbon Monoxide Warnings CAUTION! (Continued) • The use of fuel additives, which are now being WARNING! sold as octane enhancers, is not recommended. Carbon monoxide (CO) in exhaust gases is deadly. Most of these products contain high concentrations Follow the precautions below to prevent carbon of methanol.
Page 527: Adding Fuel
STARTING AND OPERATING 525 WARNING! (Continued) • Guard against carbon monoxide with proper main- tenance. Have the exhaust system inspected every time the vehicle is raised. Have any abnormal conditions repaired promptly. Until repaired, drive with all side windows fully open. ADDING FUEL The gas cap is located behind the fuel filler door, on the passenger side of the vehicle.
Page 528 526 STARTING AND OPERATING • Tighten the gas cap about one quarter turn until you NOTE: When removing the fuel filler cap, lay the cap tether in the hook, located on the fuel filler door rein- hear one click. This is an indication that the cap is forcement.
Page 529: Emergency Fuel Filler Door Release
STARTING AND OPERATING 527 Emergency Fuel Filler Door Release CAUTION! (Continued) If you are unable to open the fuel filler door, use the fuel • To avoid fuel spillage and overfilling, do not “top filler door emergency release. off” the fuel tank after filling. 1.
Page 530: Vehicle Loading
528 STARTING AND OPERATING Tighten the fuel filler cap until a “clicking” sound is heard. Gross Vehicle Weight Rating (GVWR) This is an indication that the fuel filler cap is properly The GVWR is the total permissible weight of your vehicle tightened.
Page 531 STARTING AND OPERATING 529 Each axle GAWR is determined by the components in the Curb Weight system with the lowest load carrying capacity (axle, The curb weight of a vehicle is defined as the total weight springs, tires or wheels). Heavier axles or suspension of the vehicle with all fluids, including vehicle fuel, at full components sometimes specified by purchasers for in- capacity conditions, and with no occupants or cargo...
Page 532: Trailer Towing
530 STARTING AND OPERATING front or rear axles has been exceeded but the total load is TRAILER TOWING within the specified GVWR. If so, weight must be shifted In this section you will find safety tips and information from front to rear or rear to front as appropriate until the on limits to the type of towing you can reasonably do specified weight limitations are met.
Page 533 STARTING AND OPERATING 531 exceed the GVWR. Refer to “Vehicle Loading/Vehicle WARNING! (Continued) Certification Label” in “Starting and Operating” for use a standard weight-carrying hitch, you could lose further information. control of your vehicle and cause a collision. Gross Trailer Weight (GTW) Gross Combination Weight Rating (GCWR) The GTW is the weight of the trailer plus the weight of all cargo, consumables, and equipment (permanent or tem-...
Page 534 532 STARTING AND OPERATING Trailer Sway Control — Mechanical WARNING! The trailer sway control is a telescoping link that can be It is important that you do not exceed the maximum installed between the hitch receiver and the trailer tongue front or rear GAWR.
Page 535 STARTING AND OPERATING 533 Weight-Distributing Hitch WARNING! A weight-distributing system works by applying lever- • An improperly adjusted Weight Distributing Hitch age through spring (load) bars. They are typically used system may reduce handling, stability, braking for heavier loads to distribute trailer tongue weight to the performance, and could result in a collision.
Page 536: Trailer Hitch Classification
534 STARTING AND OPERATING Trailer Hitch Classification Trailer Hitch Classification Definitions The following chart provides the industry standard for Class Max. Trailer Hitch the maximum trailer weight a given trailer hitch class can Industry Standards tow and should be used to assist you in selecting the Class IV - 10,000 lbs (4 540 kg) correct trailer hitch for your intended towing condition.
Page 537: Trailer Towing Weights (Maximum Trailer Weight Ratings)
STARTING AND OPERATING 535 Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. Engine/ Maximum GTW Maximum Tongue Model Frontal Area Transmission (Gross Trailer Wt.) Wt. (See Note) 2.4L/Automatic FWD or 4WD 32 sq ft (2.97 sq m)
Page 538: Trailer And Tongue Weight
536 STARTING AND OPERATING NOTE: The trailer tongue weight must be considered as Never exceed the maximum tongue weight stamped on part of the combined weight of occupants and cargo (ie. your bumper or trailer hitch. the GVWR), and the GVWR should never exceed the weight referenced on the Tire and Loading Information placard.
Page 539: Towing Requirements
STARTING AND OPERATING 537 Consider the following items when computing the Towing Requirements weight on the rear axle of the vehicle: To promote proper break-in of your new vehicle drive- • The tongue weight of the trailer. train components, the following guidelines are recom- mended: •...
Page 540 538 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • When hauling cargo, or towing a trailer, do not • Total weight must be distributed between the tow overload your vehicle or trailer. Overloading can vehicle and the trailer such that the following four cause a loss of control, poor performance, or dam- ratings are not exceeded: age to brakes, axle, engine, transmission, steering,...
Page 541 STARTING AND OPERATING 539 • Check for signs of tire wear or visible tire damage CAUTION! (Continued) before towing a trailer. Refer to “Tires – General • Then, during the first 500 miles (805 km) that a Information” in “Starting And Operating” for the trailer is towed, do not drive over 50 mph (80 km/h) proper inspection procedure.
Page 542 540 STARTING AND OPERATING actuated brakes. When towing a trailer equipped with CAUTION! a hydraulic surge actuated brake system, an electronic brake controller is not required. If the trailer weighs more than 1,000 lbs (454 kg) loaded, it should have its own brakes and they •...
Page 543 STARTING AND OPERATING 541 The electrical connections are all complete to the vehicle but you must mate the harness to a trailer connector. Refer to the following illustrations. Seven-Pin Connector 1 — Battery 5 — Ground 2 — Backup Lamps 6 —...
Page 544: Towing Tips
542 STARTING AND OPERATING • When using the speed control, if you experience speed Towing Tips drops greater than 10 mph (16 km/h), disengage until Before setting out on a trip, practice turning, stopping, you can get back to cruising speed. and backing the trailer in an area located away from •...
Page 545: Recreational Towing (Behind Motorhome, Etc.)
STARTING AND OPERATING 543 RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle 4WD Models Towing Wheel OFF Front-Wheel Drive 1-Speed Power 2-Speed Power Condition the Ground (FWD) Models Transfer Unit Transfer Unit Flat Tow NONE NOT ALLOWED NOT ALLOWED See Instructions: •...
Page 546: Recreational Towing - Front-Wheel Drive (Fwd) Models
544 STARTING AND OPERATING Recreational Towing — Front-Wheel Drive (FWD) 4. Properly secure the front wheels to the dolly, following Models the dolly manufacturer’s instructions. DO NOT flat tow this vehicle. Damage to the drivetrain 5. Release the parking brake. will result.
Page 547: Recreational Towing - 4Wd Models With
STARTING AND OPERATING 545 Recreational Towing — 4WD Models With Recreational Towing — 4WD Models With 1-Speed Power Transfer Unit 2-Speed Power Transfer Unit The power transfer unit must be shifted into NEUTRAL Recreational towing is not allowed. These models do (N) and the transmission must be in PARK for recre- not have a NEUTRAL (N) position in the power transfer unit.
Page 548 546 STARTING AND OPERATING Shifting Into NEUTRAL (N) CAUTION! (Continued) • The transmission must be in PARK for recreational WARNING! towing. • Before recreational towing, perform the procedure You or others could be seriously or fatally injured if you leave the vehicle unattended with the power outlined under “Shifting into NEUTRAL (N)”...
Page 549 STARTING AND OPERATING 547 NEUTRAL (N) symbol will blink, indicating shift in CAUTION! progress. The light will stop blinking (stay on solid) when the shift to NEUTRAL (N) is complete. It is necessary to follow these steps to be certain that the power transfer unit is fully in NEUTRAL (N) before recreational towing to prevent damage to internal parts.
Page 550 548 STARTING AND OPERATING 8. Start the engine. NOTE: • Steps 1 through 5 are requirements that must be met 9. Shift the transmission into REVERSE. prior to pressing the NEUTRAL (N) button, and must 10. Release the brake pedal for five seconds and ensure continue to be met until the shift has been completed.
Page 551 STARTING AND OPERATING 549 Shifting Out Of NEUTRAL (N) Use the following procedure to prepare your vehicle for normal usage. 1. Bring the vehicle to a complete stop, leaving it con- nected to the tow vehicle. 2. Apply the parking brake. 3.
Page 552 550 STARTING AND OPERATING 8. After the NEUTRAL (N) button has been released, the NOTE: power transfer unit will shift to the position indicated • Steps 1 through 5 are requirements that must be met by the selector switch. prior to pressing the NEUTRAL (N) button, and must NOTE: When shifting the power transfer unit out of continue to be met until the shift has been completed.
Page 553: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS HAZARD WARNING FLASHERS ...553 JACKING AND TIRE CHANGING ..566 ▫ Jack Location/Spare Tire Stowage ..567 IF YOUR ENGINE OVERHEATS .
Page 554 552 WHAT TO DO IN EMERGENCIES ▫ Four-Wheel Drive (4WD) Models With 1–Speed SHIFT LEVER OVERRIDE ....585 Power Transfer Unit....588 TOWING A DISABLED VEHICLE .
Page 555: Hazard Warning Flashers
WHAT TO DO IN EMERGENCIES 553 HAZARD WARNING FLASHERS IF YOUR ENGINE OVERHEATS The Hazard Warning flasher switch is located in the In any of the following situations, you can reduce the switch bank below the radio screen. potential for overheating your engine by taking the appropriate action.
Page 556: Wheel And Tire Torque Specifications
554 WHAT TO DO IN EMERGENCIES NOTE: There are steps that you can take to slow down WHEEL AND TIRE TORQUE SPECIFICATIONS an impending overheat condition: Proper lug nut/bolt torque is very important to ensure • If your air conditioner (A/C) is on, turn it off. The A/C that the wheel is properly mounted to the vehicle.
Page 557 WHAT TO DO IN EMERGENCIES 555 Inspect the wheel mounting surface prior to mounting the tire and remove any corrosion or loose particles. Torque Patterns After 25 miles (40 km) check the lug nut/bolt torque to be sure that all the lug nuts/bolts are properly seated Wheel Mounting Surface against the wheel.
Page 558: Tirefit Kit - If Equipped
556 WHAT TO DO IN EMERGENCIES TIREFIT Storage WARNING! The TIREFIT kit is stowed under the load floor behind To avoid the risk of forcing the vehicle off the jack, the rear seat. do not tighten the lug nuts fully until the vehicle has 1.
Page 559: Tirefit Kit Components And Operation
WHAT TO DO IN EMERGENCIES 557 TIREFIT Kit Components And Operation Using The Mode Select Knob And Hoses Your TIREFIT kit is equipped with the following symbols to indicate the air or sealant mode. Selecting Air Mode Push in the Mode Select Knob (5) and turn to this position for air pump operation only.
Page 560: Tirefit Usage Precautions
558 WHAT TO DO IN EMERGENCIES Using The Power Button Push and release the Power Button (4) once to turn On the TIREFIT kit. Push and release the Power Button (4) again to turn Off the TIREFIT kit. Using The Deflation Button Press the Deflation Button (2) to reduce the air pressure in the tire if it becomes over-inflated.
Page 561 WHAT TO DO IN EMERGENCIES 559 the vehicle or tire and wheel components. Once the WARNING! sealant dries, it can easily be peeled off and properly • Do not attempt to seal a tire on the side of the discarded. vehicle closest to traffic.
Page 562: Sealing A Tire With Tirefit
560 WHAT TO DO IN EMERGENCIES WARNING! (Continued) WARNING! (Continued) • Keep TIREFIT away from open flames or heat • TIREFIT Sealant solution contains latex. In case of source. an allergic reaction or rash, consult a physician • A loose TIREFIT kit thrown forward in a collision immediately.
Page 563 WHAT TO DO IN EMERGENCIES 561 kit when injecting the sealant into the deflated tire and 4. Remove the cap from the valve stem and then screw running the air pump. Move the vehicle as necessary the fitting at the end of the Sealant Hose (6) onto the to place the valve stem in this position before proceed- valve stem.
Page 564 562 WHAT TO DO IN EMERGENCIES NOTE: Sealant may leak out through the puncture in NOTE: If the Mode Select Knob (5) is on Air Mode and the tire. the pump is operating, air will dispense from the Air Pump Hose (7) only, not the Sealant Hose (6). If the sealant (white fluid) does not flow within 0 –...
Page 565 WHAT TO DO IN EMERGENCIES 563 latch pillar (recommended pressure). Check the tire 3. Immediately disconnect the Sealant Hose (6) from the pressure by looking at the Pressure Gauge (3). valve stem, reinstall the cap on the fitting at the end of the hose, and place the TIREFIT kit in the vehicle If the tire does not inflate to at least 26 psi (1.8 Bar) storage location.
Page 566 564 WHAT TO DO IN EMERGENCIES (D) Drive Vehicle: (E) After Driving: Immediately after injecting sealant and inflating the tire, Pull over to a safe location. Refer to “Whenever You Stop drive the vehicle 5 miles (8 km) or 10 minutes to ensure to Use TIREFIT”...
Page 567 WHAT TO DO IN EMERGENCIES 565 If the tire pressure is 19 psi (1.3 Bar) or higher: 5. Replace the Sealant Bottle (1) and Sealant Hose (6) assembly at your authorized dealer as soon as pos- 1. Press the Power Button (4) to turn on TIREFIT and sible.
Page 568: Jacking And Tire Changing
566 WHAT TO DO IN EMERGENCIES 4. Clean any remaining sealant from the TIREFIT housing. JACKING AND TIRE CHANGING 5. Position the new Sealant Bottle (1) in the housing so WARNING! that the Sealant Hose (6) aligns with the hose slot in the front of the housing.
Page 569: Jack Location/Spare Tire Stowage
WHAT TO DO IN EMERGENCIES 567 WARNING! (Continued) • The jack is designed to be used as a tool for changing tires only. The jack should not be used to lift the vehicle for service purposes. The vehicle should be jacked on a firm level surface only. Avoid ice or slippery areas.
Page 570 568 WHAT TO DO IN EMERGENCIES 3. Remove the fastener securing the jack and spare tire. Jack And Tool Assembly NOTE: The jack handle attaches to the side of the jack Jack And Spare Tire Fastener with two attachment points. When the jack is partially 4.
Page 571: Preparations For Jacking
WHAT TO DO IN EMERGENCIES 569 2. Turn on the Hazard Warning flasher. WARNING! 3. Set the parking brake. A loose tire or jack thrown forward in a collision or 4. Place the shift lever into PARK (automatic transmis- hard stop could endanger the occupants of the ve- sion) or REVERSE (manual transmission).
Page 572: Jacking Instructions
570 WHAT TO DO IN EMERGENCIES Jacking Instructions WARNING! (Continued) • Do not let anyone sit in the vehicle when it is on a WARNING! jack. • Do not get under the vehicle when it is on a jack. If Carefully follow these tire changing warnings to help prevent personal injury or damage to your you need to get under a raised vehicle, take it to a...
Page 573 WHAT TO DO IN EMERGENCIES 571 4. Place the jack underneath the lift area that is closest to CAUTION! the flat tire. Turn the jack screw clockwise to firmly engage the jack saddle with the lift area of the sill Do not attempt to raise the vehicle by jacking on flange, centering the jack saddle inside the cutout in locations other than those indicated in the Jacking...
Page 574 572 WHAT TO DO IN EMERGENCIES Rear Jacking Location Rear Jacking Engagement Point...
Page 575 WHAT TO DO IN EMERGENCIES 573 Front Jacking Location Front Jacking Engagement Point...
Page 576 574 WHAT TO DO IN EMERGENCIES 5. Raise the vehicle just enough to remove the flat tire. CAUTION! WARNING! Be sure to mount the spare tire with the valve stem facing outward. The vehicle could be damaged if the Raising the vehicle higher than necessary can make spare tire is mounted incorrectly.
Page 577 WHAT TO DO IN EMERGENCIES 575 NOTE: 10. Lower the vehicle to the ground by turning the jack handle counterclockwise. • For vehicles so equipped, do not attempt to install a center cap or wheel cover on the compact spare. 11.
Page 578 576 WHAT TO DO IN EMERGENCIES Assembled Jack Stowed Tire, Jack And Chock 12. Securely stow the jack, tools, chocks and flat tire. WARNING! A loose tire or jack thrown forward in a collision or hard stop could endanger the occupants of the ve- hicle.
Page 579: Road Tire Installation
WHAT TO DO IN EMERGENCIES 577 3. Lower the vehicle to the ground by turning the jack WARNING! (Continued) handle counterclockwise. the places provided. Have the deflated (flat) tire 4. Finish tightening the wheel bolts. Push down on the repaired or replaced immediately. wrench while at the end of the handle for increased leverage.
Page 580: Jump-Starting Procedures
578 WHAT TO DO IN EMERGENCIES JUMP-STARTING PROCEDURES WARNING! If your vehicle has a discharged battery it can be jump- Do not attempt jump-starting if the battery is frozen. started using a set of jumper cables and a battery in It could rupture or explode and cause personal injury.
Page 581 WHAT TO DO IN EMERGENCIES 579 WARNING! • Take care to avoid the radiator cooling fan when- ever the hood is raised. It can start anytime the ignition switch is ON. You can be injured by moving fan blades. • Remove any metal jewelry such as rings, watch bands and bracelets that could make an inadvertent electrical contact.
Page 582: Jump-Starting Procedure
580 WHAT TO DO IN EMERGENCIES 3. If using another vehicle to jump-start the battery, park CAUTION! the vehicle within the jumper cables reach, set the parking brake and make sure the ignition is OFF. Failure to follow these procedures could result in damage to the charging system of the booster vehicle WARNING! or the discharged vehicle.
Page 583 WHAT TO DO IN EMERGENCIES 581 2. Disconnect the opposite end of the negative (-) jumper WARNING! cable from the negative (-) post of the booster battery. Do not connect the jumper cable to the negative (-) post 3. Disconnect the positive (+) end of the jumper cable of the discharged battery.
Page 584: Freeing A Stuck Vehicle
582 WHAT TO DO IN EMERGENCIES NOTE: For vehicles with automatic transmission: shifts CAUTION! (Continued) between DRIVE and REVERSE can only be achieved at the vehicle’s battery will discharge sufficiently to wheel speeds of 5 mph (8 km/h) or less. Whenever the degrade battery life and/or prevent the engine from transmission remains in NEUTRAL for more than two starting.
Page 585: Recovery Strap - If Equipped
WHAT TO DO IN EMERGENCIES 583 CAUTION! WARNING! • Racing the engine or spinning the wheels may lead Fast spinning tires can be dangerous. Forces gener- to transmission overheating and failure. Allow the ated by excessive wheel speeds may cause damage, or engine to idle with the transmission in NEUTRAL even failure, of the axle and tires.
Page 586 584 WHAT TO DO IN EMERGENCIES Using Recovery Strap WARNING! 1. Review all warnings and instructions first. Recovery straps should only be used in emergencies to rescue stranded vehicles. Only use Recovery straps on 2. Position the recovery vehicle. vehicles that fit within the recommended GVW of 3.
Page 587: Shift Lever Override
WHAT TO DO IN EMERGENCIES 585 SHIFT LEVER OVERRIDE 6. Move the shift lever to the NEUTRAL position. If a malfunction occurs and the shift lever cannot be 7. The vehicle may then be started in NEUTRAL. moved out of the PARK position, you can use the 8.
Page 588 586 WHAT TO DO IN EMERGENCIES 4X4 MODELS Towing Wheels OFF FWD MODELS 1–SPEED 2–SPEED Condition the Ground POWER TRANSFER UNIT POWER TRANSFER UNIT Flat Tow NONE NOT ALLOWED See instructions under ALLOWED “Recreational Towing” in “Starting And Operating” • Transmission in PARK •...
Page 589: Front-Wheel Drive (Fwd) Models
WHAT TO DO IN EMERGENCIES 587 Proper towing or lifting equipment is required to prevent CAUTION! damage to your vehicle. Use only tow bars and other • Do not use sling type equipment when towing. equipment designed for this purpose, following equip- ment manufacturer’s instructions.
Page 590: Power Transfer Unit
588 WHAT TO DO IN EMERGENCIES CAUTION! CAUTION! • DO NOT tow this vehicle with ANY of its wheels Towing this vehicle in violation of the above require- ments can cause severe transmission damage. Dam- on the ground. Damage to the drivetrain will result. •...
Page 591: Four-Wheel Drive (4Wd) Models With 2-Speed Power Transfer Unit
WHAT TO DO IN EMERGENCIES 589 Four-Wheel Drive (4WD) Models With 2–Speed Refer to “Recreational Towing” in “Starting and Operat- Power Transfer Unit ing” for detailed instructions. The manufacturer recommends towing with all four CAUTION! wheels OFF the ground. • Front or rear wheel lifts must not be used. Internal Acceptable methods are to tow the vehicle on a flatbed or damage to the transmission or power transfer unit with one end of the vehicle raised and the opposite end...
Page 593: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS ▫ Engine Oil Filter ..... .603 ENGINE COMPARTMENT — 2.4L ..593 ▫...
Page 594 592 MAINTAINING YOUR VEHICLE ▫ Brake System ......619 ▫ Front Turn Signals ....645 ▫...
Page 595: Engine Compartment - 2.4L
MAINTAINING YOUR VEHICLE 593 ENGINE COMPARTMENT — 2.4L 1 — Air Cleaner Filter 5 — Power Distribution Center (Fuses) 2 — Engine Coolant Pressure Cap 6 — Battery 3 — Oil Fill Cap 7 — Washer Fluid Reservoir 4 — Brake Fluid Reservoir 8 —...
Page 596: Engine Compartment - 3.2L
594 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 3.2L 1 — Engine Coolant Reservoir 5 — Washer Fluid Reservoir 2 — Engine Oil Filter Access Cover 6 — Engine Oil Dipstick 3 — Brake Fluid Reservoir 7 — Engine Oil Fill 4 —...
Page 597: Onboard Diagnostic System - Obd Ii
MAINTAINING YOUR VEHICLE 595 ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated onboard • Prolonged driving with the MIL on could cause diagnostic system called OBD II. This system monitors further damage to the emission control system. It the performance of the emissions, engine, and automatic could also affect fuel economy and driveability.
Page 598: Loose Fuel Filler Cap Message
596 MAINTAINING YOUR VEHICLE Loose Fuel Filler Cap Message EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS If the vehicle diagnostic system determines that the fuel filler cap is loose, improperly installed, or damaged, a In some localities, it may be a legal requirement to pass “gASCAP”...
Page 599 MAINTAINING YOUR VEHICLE 597 • The MIL will not flash at all and will remain fully Your vehicle has a simple ignition actuated test, which you can use prior to going to the test station. To check if illuminated until you turn OFF the ignition or start the engine.
Page 600: Replacement Parts
598 MAINTAINING YOUR VEHICLE REPLACEMENT PARTS NOTE: Intentional tampering with emissions control systems may void your warranty and could result in civil Use of genuine MOPAR® parts for normal/scheduled penalties being assessed against you. maintenance and repairs is highly recommended to en- sure the designed performance.
Page 601 MAINTAINING YOUR VEHICLE 599 Besides those maintenance items specified in the fixed CAUTION! (Continued) “Maintenance Schedule”, there are other components • Your vehicle has been built with improved fluids which may require servicing or replacement in the future. that protect the performance and durability of your vehicle and also allow extended maintenance inter- CAUTION! vals.
Page 602: Engine Oil
600 MAINTAINING YOUR VEHICLE Engine Oil CAUTION! Checking Oil Level Overfilling or underfilling the crankcase will cause To assure proper engine lubrication, the engine oil must aeration or loss of oil pressure. This could damage be maintained at the correct level. Check the oil level at your engine.
Page 603 MAINTAINING YOUR VEHICLE 601 Engine Oil Selection CAUTION! For best performance and maximum protection under all Do not use chemical flushes in your engine oil as the types of operating conditions, the manufacturer only chemicals can damage your engine. Such damage is recommends engine oils that are API Certified and meet not covered by the New Vehicle Limited Warranty.
Page 604 602 MAINTAINING YOUR VEHICLE Engine Oil Viscosity (SAE Grade) — 3.2L Engine Materials Added To Engine Oil MOPAR® SAE 5W-20 engine oil or equivalent Pennzoil® The manufacturer strongly recommends against the ad- or Shell Helix® is recommended for all operating tem- dition of any additives (other than leak detection dyes) to peratures.
Page 605: Engine Oil Filter
MAINTAINING YOUR VEHICLE 603 Engine Oil Filter WARNING! The engine oil filter should be replaced with a new filter The air induction system (air cleaner, hoses, etc.) can at every engine oil change. provide a measure of protection in the case of engine NOTE: For best access to the oil filter, a drive on hoist backfire.
Page 606: Maintenance-Free Battery
604 MAINTAINING YOUR VEHICLE Maintenance-Free Battery WARNING! (Continued) Your vehicle is equipped with a maintenance-free battery. • Battery gas is flammable and explosive. Keep You will never have to add water, nor is periodic main- flame or sparks away from the battery. Do not use tenance required.
Page 607: Air Conditioner Maintenance
MAINTAINING YOUR VEHICLE 605 Air Conditioner Maintenance CAUTION! For best possible performance, your air conditioner should • It is essential when replacing the cables on the be checked and serviced by an authorized dealer at the battery that the positive cable is attached to the start of each warm season.
Page 608 606 MAINTAINING YOUR VEHICLE Protection Agency and is an ozone-saving product. How- WARNING! (Continued) ever, the manufacturer recommends that air conditioning • The air conditioning system contains refrigerant service be performed by authorized dealer or other under high pressure. To avoid risk of personal service facilities using recovery and recycling equipment.
Page 609: A/C Air Filter - If Equipped
MAINTAINING YOUR VEHICLE 607 A/C Air Filter — If Equipped Particular attention should also be given to hood latching components to ensure proper function. When performing Refer to the “Maintenance Schedule” for the proper other underhood services, the hood latch, release mecha- maintenance intervals.
Page 610 608 MAINTAINING YOUR VEHICLE Avoid using the wiper blades to remove frost or ice from the windshield. Keep the blade rubber out of contact with petroleum products such as engine oil, gasoline, etc. NOTE: Life expectancy of wiper blades varies depending on geographical area and frequency of use.
Page 611: Adding Washer Fluid
MAINTAINING YOUR VEHICLE 609 3. Grab the bottom of the wiper blade and rotate it 4. Install the wiper blade pivot pin into the wiper blade forward to unsnap the blade pivot pin from the wiper holder at the end of the wiper arm, and firmly press blade holder.
Page 612: Exhaust System
610 MAINTAINING YOUR VEHICLE To prevent freeze-up of your windshield washer system or when the underside or rear of the vehicle is damaged; in cold weather, select a solution or mixture that meets or have an authorized technician inspect the complete ex- exceeds the temperature range of your climate.
Page 613 MAINTAINING YOUR VEHICLE 611 WARNING! (Continued) CAUTION! (Continued) • A hot exhaust system can start a fire if you park • Damage to the catalytic converter can result if your over materials that can burn. Such materials might vehicle is not kept in proper operating condition. be grass or leaves coming into contact with your In the event of engine malfunction, particularly exhaust system.
Page 614: Cooling System
612 MAINTAINING YOUR VEHICLE • Do not idle the engine with any spark plug wires NOTE: Intentional tampering with emissions control systems can result in civil penalties being assessed disconnected or removed, such as when diagnostic against you. testing, or for prolonged periods during very rough idle or malfunctioning operating conditions.
Page 615 MAINTAINING YOUR VEHICLE 613 Engine Coolant Checks If the cap is sealing properly, the engine coolant (anti- freeze) will begin to drain from the coolant recovery Check the engine coolant (antifreeze) protection every bottle. DO NOT REMOVE THE COOLANT PRESSURE 12 months (before the onset of freezing weather, where CAP WHEN THE COOLING SYSTEM IS HOT.
Page 616 614 MAINTAINING YOUR VEHICLE Selection Of Coolant CAUTION! (Continued) Refer to “Fluids, Lubricants, and Genuine Parts” in system in an emergency, the cooling system will “Maintaining Your Vehicle” for further information. need to be drained, flushed, and refilled with fresh OAT coolant (conforming to MS-12106), by an CAUTION! authorized dealer as soon as possible.
Page 617 MAINTAINING YOUR VEHICLE 615 • Mix a minimum solution of 50% OAT engine coolant Adding Coolant that meets the requirements of Chrysler Material Stan- Your vehicle has been built with an improved engine dard MS-12106 and distilled water. Use higher concen- coolant (OAT coolant conforming to MS-12106) that trations (not to exceed 70%) if temperatures below allows extended maintenance intervals.
Page 618 616 MAINTAINING YOUR VEHICLE NOTE: The cap should be inspected and cleaned if there is any accumulation of foreign material on the sealing surfaces. • Some vehicles require special tools to add coolant properly. Failure to fill these systems properly could WARNING! lead to severe internal engine damage.
Page 619 MAINTAINING YOUR VEHICLE 617 Disposal Of Used Engine Coolant The radiator normally remains completely full, so there is no need to remove the radiator/coolant pressure cap Used ethylene glycol-based engine coolant (antifreeze) is unless checking for engine coolant (antifreeze) freeze a regulated substance requiring proper disposal.
Page 620 618 MAINTAINING YOUR VEHICLE • Maintain engine coolant (antifreeze) concentration at humidity accumulating on the radiator and being vapor- ized when the thermostat opens, allowing hot engine a minimum of 50% OAT coolant (conforming to coolant (antifreeze) to enter the radiator. MS-12106) and distilled water for proper corrosion protection of your engine which contains aluminum If an examination of your engine compartment shows no...
Page 621: Brake System
MAINTAINING YOUR VEHICLE 619 Brake System Brake Master Cylinder In order to assure brake system performance, all brake The fluid in the master cylinder should be checked when system components should be inspected periodically. performing under hood services or immediately if the Refer to the “Maintenance Schedule”...
Page 622 620 MAINTAINING YOUR VEHICLE WARNING! WARNING! (Continued) fluid in a open container absorbs moisture from the • Use only manufacturer’s recommended brake air resulting in a lower boiling point. This may fluid. Refer to “Fluids, Lubricants, and Genuine cause it to boil unexpectedly during hard or pro- Parts”...
Page 623: Automatic Transmission
MAINTAINING YOUR VEHICLE 621 Automatic Transmission CAUTION! (Continued) Selection Of Lubricant shudder, and will require more frequent fluid and filter changes. Refer to “Fluids, Lubricants, and It is important to use the proper transmission fluid to Genuine Parts” in this section for fluid specifica- ensure optimum transmission performance and life.
Page 624 622 MAINTAINING YOUR VEHICLE CAUTION! CAUTION! Do not use chemical flushes in your transmission as If a transmission fluid leak occurs, visit your autho- the chemicals can damage your transmission compo- rized dealer immediately. Severe transmission dam- nents. Such damage is not covered by the New age may occur.
Page 625: Appearance Care And Protection From Corrosion
MAINTAINING YOUR VEHICLE 623 Appearance Care And Protection From Corrosion What Causes Corrosion? Corrosion is the result of deterioration or removal of Protection Of Body And Paint From Corrosion paint and protective coatings from your vehicle. Vehicle body care requirements vary according to geo- graphic locations and usage.
Page 626 624 MAINTAINING YOUR VEHICLE • If insects, tar, or other similar deposits have accumu- Special Care lated on your vehicle, use MOPAR® Super Kleen Bug • If you drive on salted or dusty roads or if you drive and Tar Remover to remove. near the ocean, hose off the undercarriage at least once •...
Page 627 MAINTAINING YOUR VEHICLE 625 • If you carry special cargo such as chemicals, fertilizers, NOTE: If your vehicle is equipped with Dark Vapor de-icer salt, etc., be sure that such materials are well Chrome wheels DO NOT USE wheel cleaners, abrasives packaged and sealed.
Page 628 626 MAINTAINING YOUR VEHICLE Stain Repel Fabric Cleaning Procedure — Interior Care If Equipped Instrument Panel Cover Stain Repel seats may be cleaned in the following man- The instrument panel cover has a low glare surface, ner: which minimizes reflections in the windshield. Do not •...
Page 629 MAINTAINING YOUR VEHICLE 627 Your leather upholstery can be best preserved by regular Cleaning Headlights cleaning with a damp soft cloth. Small particles of dirt Your vehicle is equipped with plastic headlights and fog can act as an abrasive and damage the leather upholstery lights that are lighter and less susceptible to stone break- and should be removed promptly with a damp cloth.
Page 630 628 MAINTAINING YOUR VEHICLE cleaner. Use caution when cleaning the inside rear win- Seat Belt Maintenance dow equipped with electric defrosters or the right rear Do not bleach, dye or clean the belts with chemical quarter window equipped with the radio antenna. Do solvents or abrasive cleaners.
Page 631: Fuses
MAINTAINING YOUR VEHICLE 629 WARNING! (Continued) WARNING! (Continued) • Before replacing a fuse, make sure that the ignition assemblies must be replaced after a collision if they have been damaged (i.e., bent retractor, torn web- is off and that all the other services are switched off bing, etc.).
Page 632: Power Distribution Center
630 MAINTAINING YOUR VEHICLE Power Distribution Center The Power Distribution Center is located in the engine compartment near the battery. This center contains car- tridge fuses, mini-fuses and relays. A label that identifies each component is printed on the inside of the cover. Power Distribution Center Cavity Blade Fuse...
Page 633 MAINTAINING YOUR VEHICLE 631 Cavity Blade Fuse Cartridge Fuse Description 25 Amp Clear — Engine Control Module (ECM) — — Not Used 20 Amp Yellow — Power Takeoff Unit (PTU) — — Not Used 20 Amp Yellow — Brake Vacuum Pump - If Equipped 10 Amp Red —...
Page 634 632 MAINTAINING YOUR VEHICLE Cavity Blade Fuse Cartridge Fuse Description 10 Amp Red — A/C Compressor Clutch — — Not Used 5 Amp Tan — Radiator Fan 70 Amp Tan — Body Controller Module (BCM) - Feed 1 — — Not Used —...
Page 635 MAINTAINING YOUR VEHICLE 633 Cavity Blade Fuse Cartridge Fuse Description — 30 Amp Pink Driver Door Module (DDM) - If Equipped — 30 Amp Pink Body Controller Module (BCM) - Feed 3 — — Not Used — — Not Used —...
Page 636 634 MAINTAINING YOUR VEHICLE Cavity Blade Fuse Cartridge Fuse Description — 30 Amp Pink Trailer Tow / 7-Way Connector - If Equipped — 30 Amp Pink Passenger Door Module (PDM) - If Equipped — 25 Amp Clear Sunroof - If Equipped —...
Page 637 MAINTAINING YOUR VEHICLE 635 Cavity Blade Fuse Cartridge Fuse Description 15 Amp Blue — Ignition Node Module (IGNM)/KIN/RF Hub/Electric Steering Column Lock (ESL) 20 Amp Yellow — Fuel Pump Motor 10 Amp Red — Occupant Classification Module — — Not Used 20 Amp Yellow —...
Page 638 636 MAINTAINING YOUR VEHICLE Cavity Blade Fuse Cartridge Fuse Description 10 Amp Red — In Car Temperature Sensor / Humidity Sensor / Driver Assist System Module (DASM) / Park Assist (PAM) — — Not Used — — Not Used 10 Amp Red —...
Page 639 MAINTAINING YOUR VEHICLE 637 Cavity Blade Fuse Cartridge Fuse Description — 20 Amp Blue Engine Control Module (ECM) Gasoline Engine - If Equipped 20 Amp Yellow — Cigar Lighter 20 Amp Yellow — Rear Differential Module (RDM) - If Equipped 10 Amp Red —...
Page 640 638 MAINTAINING YOUR VEHICLE Cavity Blade Fuse Cartridge Fuse Description — 30 Amp Pink Headlamp Washer Pump - If Equipped — 40 Amp Green Brake System Module (BSM) - Pump Motor If Equipped With Diesel Engine — 20 Amp Blue Trailer Tow Backup Lights - If Equipped With Gasoline Engine —...
Page 641 MAINTAINING YOUR VEHICLE 639 Cavity Blade Fuse Cartridge Fuse Description — — Not Used 20 Amp Yellow — Rear Power Outlet — 40 Amp Green Brake System Module (BSM) - Pump Motor - If Equipped With Gasoline Engine — 30 Amp Pink Electric Park Brake (EPB) - Right 10 Amp Red —...
Page 642: Interior Fuses
640 MAINTAINING YOUR VEHICLE Interior Fuses The interior fuse panel is located in the passenger com- partment on the left side dash panel under the instru- ment panel. Cavity Blade Fuse Description 15 Amp Blue Low Beam Left 10 Amp Red Interior Lighting 10 Amp Red Intrusion Module/Siren –...
Page 643 MAINTAINING YOUR VEHICLE 641 Cavity Blade Fuse Description 10 Amp Red Driver Window Switch/Power Mirrors – If Equipped 7.5 Amp Brown UCI Port (USB & AUX) 10 Amp Red Door Locks – Driver Unlock 7.5 Amp Brown Fog Lamp Front Left 7.5 Amp Brown Fog Lamp Front Right 10 Amp Red...
Page 644: Vehicle Storage
642 MAINTAINING YOUR VEHICLE VEHICLE STORAGE REPLACEMENT BULBS If you are leaving your vehicle dormant for more than 21 Interior Bulbs days you may want to take steps to protect your battery. Bulb Number You may: Cargo Lamp TL212–2 • Disconnect the negative cable from the battery. Overhead Console Lamp PLW214–2A •...
Page 645: Bulb Replacement
MAINTAINING YOUR VEHICLE 643 BULB REPLACEMENT Bulb Number Front Turn Signal Lamps WY21W NOTE: Lens fogging can occur under certain atmo- spheric conditions. This will usually clear as atmospheric Front Fog Lamps conditions change to allow the condensation to change Front Fog Lamps PSX24W back into a vapor.
Page 646 644 MAINTAINING YOUR VEHICLE NOTE: On vehicles equipped with HID headlamps, 3. Firmly grasp the cap and rotate it counterclockwise to when the headlamps are turned on, there is a blue hue to unlock it. the lights. This diminishes and becomes more white after 4.
Page 647: Front Turn Signals
MAINTAINING YOUR VEHICLE 645 7. Install the bulb cap in the headlamp housing and Front Fog Lamp rotate clockwise to lock it in place. 1. Unlock lower access door in wheel liner. 8. Lock upper door in wheel liner. 2. Reach behind the fog lamp housing to access the bulb. Front Turn Signals 3.
Page 648: Front Fog Lamp (Trailhawk)
646 MAINTAINING YOUR VEHICLE 5. Install the bulb and socket assembly into the into the 5. Reconnect the wiring harness to the new bulb and fog lamp housing, and rotate the connector clockwise reinstall by inserting the new bulb straight into the fog to lock it in place.
Page 649: Back-Up Lamp
MAINTAINING YOUR VEHICLE 647 8. Reconnect the electrical connector. 7. Pull the bulb to remove it from the socket. 9. Reinstall the tail lamp housing and screws. 8. Replace the bulb, reinstall the socket. 10. Close the liftgate. 9. Connect the electrical connector. Back-up Lamp 10.
Page 650: Fluid Capacities
648 MAINTAINING YOUR VEHICLE FLUID CAPACITIES U.S. Metric Fuel (Approximate) 2.4L and 3.2L Engines 15.8 Gallons 60 Liters Engine Oil With Filter 2.4 Liter Engine (SAE 0W-20, API Certified) 5.5 Quarts 5.2 Liters 3.2 Liter Engine (SAE 5W-20, API Certified) 6 Quarts 5.6 Liters Cooling System*...
Page 651: Fluids, Lubricants And Genuine Parts
MAINTAINING YOUR VEHICLE 649 FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant We recommend you use MOPAR® Antifreeze/Coolant 10 Year/ 150,000 Mile Formula OAT (Organic Additive Technology) or equivalent meeting the requirements of Chrysler Material Standard MS-12106. Engine Oil –...
Page 652: Chassis
650 MAINTAINING YOUR VEHICLE Component Fluid, Lubricant, or Genuine Part Spark Plugs – 2.4L Engine We recommend you use MOPAR® Spark Plugs (Gap 0.047 in [1.2 mm]) Spark Plugs – 3.2L Engine We recommend you use MOPAR® Spark Plugs (Gap 0.043 in [1.1 mm]) Fuel Selection –...
Page 653: Maintenance Schedules
MAINTENANCE SCHEDULES CONTENTS ▫ Maintenance Chart.....654 MAINTENANCE SCHEDULE ... . .652...
Page 654 652 MAINTENANCE SCHEDULES MAINTENANCE SCHEDULE Your authorized dealer will reset the oil change indicator message after completing the scheduled oil change. If a Your vehicle is equipped with an automatic oil change scheduled oil change is performed by someone other indicator system.
Page 655 MAINTENANCE SCHEDULES 653 Once A Month Or Before A Long Trip: At Every Oil Change Interval As Indicated By Oil • Check engine oil level. Change Indicator System: • Change oil and filter • Check windshield washer fluid level. • Rotate the tires. Rotate at the first sign of irregu- •...
Page 656 654 MAINTENANCE SCHEDULES Maintenance Chart Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Inspections Inspect the CV joints. Inspect front suspension, boot seals. tie rod ends, and replace if necessary. Inspect the brake linings, parking brake function. Additional Maintenance Replace engine air cleaner filter.
Page 657 MAINTENANCE SCHEDULES 655 Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Replace spark plugs – 2.4L Engine ** Replace spark plugs – 3.2L Engine ** Flush and replace the engine coolant at 10 years or 150,000 miles (240,000 km) whichever comes first. Inspect and replace PCV valve if necessary.
Page 658 656 MAINTENANCE SCHEDULES WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.
Page 659: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS ▫ Customer Assistance For The Hearing Or SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE ....659 Speech Impaired (TDD/TTY) ... . .661 ▫...
Page 660 658 IF YOU NEED CONSUMER ASSISTANCE ▫ Traction Grades ..... . .665 DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES ..665 ▫...
Page 661: Suggestions For Obtaining Service For Your Vehicle
IF YOU NEED CONSUMER ASSISTANCE 659 SUGGESTIONS FOR OBTAINING SERVICE FOR Be Reasonable With Requests YOUR VEHICLE If you list a number of items and you must have your vehicle by the end of the day, discuss the situation with Prepare For The Appointment the service advisor and list the items in order of priority.
Page 662: Chrysler Group Llc Customer Center
660 IF YOU NEED CONSUMER ASSISTANCE • Authorized dealer name facilities, factory-trained technicians, special tools, and the latest information to ensure the vehicle is fixed • Vehicle Identification Number (VIN) correctly and in a timely manner. • Vehicle delivery date and mileage This is why you should always talk to an authorized Chrysler Group LLC Customer Center dealer service manager first.
Page 663: In Mexico Contact
IF YOU NEED CONSUMER ASSISTANCE 661 In Mexico Contact: Canadian residents with hearing difficulties that require assistance can use the special needs relay service offered Av. Prolongacion Paseo de la Reforma, 1240 by Bell Canada. For TTY teletypewriter users, dial 711 Sante Fe C.P.
Page 664: Warranty Information
662 IF YOU NEED CONSUMER ASSISTANCE The manufacturer will not stand behind any service WARNING! contract that is not the manufacturer’s service contract. It is not responsible for any service contract other than the Engine exhaust, some of its constituents, and certain manufacturer’s service contract.
Page 665: Mopar® Parts
IF YOU NEED CONSUMER ASSISTANCE 663 MOPAR® PARTS campaign. However, NHTSA cannot become involved in individual problems between you, your authorized MOPAR® fluids, lubricants, parts, and accessories are dealer, and the manufacturer. available from an authorized dealer. They are recom- mended for your vehicle in order to help keep the vehicle To contact NHTSA, you may either call the Auto Safety Hotline toll free at 1–888–327–4236 (TTY: 1–800–424–9153),...
Page 666: Publication Order Forms
664 IF YOU NEED CONSUMER ASSISTANCE PUBLICATION ORDER FORMS Diagnostic Procedure Manuals To order the following manuals, you may use either the Diagnostic Procedure Manuals are filled with diagrams, website or the phone numbers listed below. Visa, Master- charts and detailed illustrations. These practical manuals card, American Express, and Discover orders are ac- make it easy for students and technicians to find and fix cepted.
Page 667 IF YOU NEED CONSUMER ASSISTANCE 665 Call toll free at: Treadwear • 1–800–890–4038 (U.S.) The Treadwear grade is a comparative rating, based on the wear rate of the tire when tested under controlled • 1–800–387–1143 (Canada) conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half times as well on the government course as a tire graded Visit us on the Worldwide Web at:...
Page 668 666 IF YOU NEED CONSUMER ASSISTANCE The grade C corresponds to a level of performance, WARNING! which all passenger car tires must meet under the Federal Motor Vehicle Safety Standard No. 109. Grades B and A The traction grade assigned to this tire is based on represent higher levels of performance on the laboratory straight-ahead braking traction tests, and does not test wheel, than the minimum required by law.
Page 669 INDEX...
Page 670 668 INDEX About Your Brakes ......458 Air Filter .......603 ABS (Anti-Lock Brake System) .
Page 671 INDEX 669 Automatic Headlights ..... .167 Battery ....... . .604 Automatic High Beams .
Page 672 670 INDEX Camera, Rear ......284 Checks, Safety......115 Capacities, Fluid .
Page 673 INDEX 671 Contract, Service ......661 Data Recorder, Event ..... . .89 Coolant Pressure Cap (Radiator Cap) .
Page 674 672 INDEX Electrical Outlet, Auxiliary (Power Outlet) ..300 Break-In Recommendations ....114 Electric Parking Brake ..... .451 Checking Oil Level .
Page 675 INDEX 673 Enhanced Accident Response Feature ... .85 Flooded Engine Starting ....421 Entry System, Illuminated .
Page 676 674 INDEX Filler Cap (Gas Cap) .....525 Speedometer ......330 Gasoline .
Page 677 INDEX 675 Passing ......173 HomeLink® (Garage Door Opener) ... .286 Replacing .
Page 678 676 INDEX Jacking Instructions ......570 Lap/Shoulder Belts......55 Jack Location .
Page 679 INDEX 677 Daytime Running ..... . .170 Malfunction Indicator (Check Engine) ..333 Dimmer Switch, Headlight .
Page 680 678 INDEX Auto Unlock ......36 Methanol .......521 Child Protection .
Page 681 INDEX 679 Odometer.......326 Operating Precautions ..... .595 Trip .
Page 682 680 INDEX Mirrors ......134 Rear Window Defroster .....318 Outlet (Auxiliary Electrical Outlet) .
Page 683 INDEX 681 Programming Additional Transmitters ..18 Safety Checks Inside Vehicle....117 Remote Sound System (Radio) Controls ..390 Safety Checks Outside Vehicle .
Page 684 682 INDEX Shoulder Belt Anchorage ....60 Service Assistance ......659 Untwisting Procedure .
Page 685 INDEX 683 Starting ....... . .30 Supplemental Restraint System - Airbag ..66 Cold Weather .
Page 686 684 INDEX Chains .......504 Trailer Towing ......539 Changing .
Page 687 INDEX 685 Trailer Weight ......535 Uconnect® Settings ..... . .25 Transaxle .
Page 688 686 INDEX Washers, Windshield ..... . .176 Washing Vehicle ......623 Wheel and Wheel Trim .
Page 689 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into The antenna cable should be as short as practical this vehicle’s electronic system to provide immunity and routed away from the vehicle wiring when pos- to radio frequency signals. Mobile two-way radios sible.
Page 690 Chrysler Group LLC 14KL74-126-AF Sixth Edition Printed in U.S.A.
