ATC Labs Perceptual SoundMax Q24 Operation Manual page 33

• OP TUNE
Operating Points: These thresholds are the levels defined in dB for each band. It's
the master threshold and rests of the thresholds are derived from it. Operating points
are set for each genre in such a way that it will apply desired gain on particular
frequency. So ideally operating points must be different for different genres. As in
broadcast scenario audio content is not always mapped with right genre, we are
providing floating option which will automatically the adjust operating points
according to input stream. The Operating Points can be used to boost or lower the
prominence of a particular frequency region and control audio consistency in the
corresponding band.
Master Floating and Floating: If MASTER FLOTING option is checked then
every band is in floating mode i.e. their operating points are calculated according to
input stream. With Individual floating check, above mentioned floating operating
point calculation will happen on particular band.
Figure 4.5: DRC OPTUNE Screen
