NOTE: User can also upgrade the software from PC to Q24 interface (refer section 5).
• SET PASSWORD: Security key setting screen shown below will come after
pressing SET PASSWORD soft key.
A valid Password should consist of more than 5 characters.
After entering the password press SAVE soft key.
• RUN DIAGNOSTICS: Run diagnostics feature will help you to determine whether
your unit is malfunctioning. When the RUN DIAGNOSTICS BUTTON is pressed a
diagnosis screen as shown below is displayed and diagnostics can be run for each of
the 3 paths (analog/digital/composite) as described below.
A T C L a b s C o p y r i g h t ( 2 0 1 2 ) A l l R i g h t s R e s e r v e d .
Figure 3.8: Set Password Screen
