ATC Labs Perceptual SoundMax Q24 Operation Manual page 12

SoundMax Manager will auto detect the "Model Q24 rack Mount
processor" as Live Station. By clicking on the station from this list,
you can get a detailed view and options to configure that particular
station. This view provides the ability to configure parameters specific
to a channel such as profile selection, save and remove profiles, tune
profile parameters. A snapshot of this detailed view is shown in the
figure below.
Figure 2.3: Detailed view of Manager
It provides an option to tune the audio quality of any channel based on
the requirement. Clicking on the tune button will change your view to
a tuning screen showing all the tunable modules and an option to save
custom profiles and load saved profiles. For more detailed explanation
on TUNING through manager ref section 4.
If SoundMax Manager is controlling the Processor then front-panel
TFT interface (see below) will be disabled.
