• When connecting power cable terminals to the GP unit, be sure the cable has
been unplugged from the power outlet, to prevent an electric shock.
• When replacing the backlight, be sure to turn the GP power OFF and wear
gloves to avoid burns or electric shock.
• High voltage runs through the GP unit, so if the unit is disassembled there is a
danger of an electric shock. Do NOT take the unit apart.
• Do not use power beyond the specified voltage range. If you do, it may cause a
fire or an electric shock.
• Do not modify the GP unit. It may cause a fire or an electric shock.
• Do not use the GP in an environment with flammable gas in the surrounding
atmosphere. It may cause explosion.
• The GP uses a lithium battery for backing up its internal clock data. If the battery
is incorrectly replaced, the battery may explode. To avoid the danger, do not
replace the battery yourself. When the battery needs a replacement, please
consult with your local GP distributor.
• Do not use touch panel switches in life-related or important disaster prevention
situations. For safety related switches, such as an emergency switch. use a
separate mechanical switch.
• Please design your system so that the machine will not malfunction by a commu-
nication fault between the GP and its host controller. If not, there could be a
danger of personal injury or equipment damage.

To Prevent Damage:

• Do not hit the touch panel with a hard or heavy object, or press the touch panel
with too much force, for it may cause irreparable damage.
• Do not use GP in an environment where the surrounding temperature exceeds
the specification range, for it may damage the unit.
• Please ensure that liquids or metal do not enter the GP unit, for it may cause
malfunction or a short.
• Please avoid using the unit in areas where sudden, large changes in tempera-
ture may occur. These changes can cause condensation to form inside the
unit, possibly causing an accident.
• To prevent heat building up inside the GP, please do not install GP where its
ventilation holes may be blocked, or where heat cannot escape. Also, please
avoid using or storing the GP in an extremely hot place.
• Do not operate the GP in areas with temperatures and humidity in express of
those levels specified to prevent the GP's touch panel from becoming warped or
bent.
• Please avoid using or storing the GP under direct sunlight or in a dusty environ-
ment.
• The GP is a high accuracy electronic device, so please avoid using or storing it
where it can receive strong impact or vibration.
• Avoid either using or storing GP where vaporized chemicals or chemicals are
present in the atmosphere.
• Do NOT use paint thinner or organic solvents to clean the GP unit or display.
• Be sure to back up all GP screen data regularly.
• After turning this unit OFF, be sure to wait a few seconds before turning ON
again. If the unit is started within a few seconds, it may not start up correctly.
WARNING

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP577R-TC11 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pro-face GP577R-TC11

  • Page 1: To Prevent Damage

    WARNING • When connecting power cable terminals to the GP unit, be sure the cable has been unplugged from the power outlet, to prevent an electric shock. • When replacing the backlight, be sure to turn the GP power OFF and wear gloves to avoid burns or electric shock.
  • Page 2: Package Contents

    Package Contents The following items are included in the package. Before using, please en- sure everything is there. GP unit (GP577R-TC11/GP577R-SC11) Installation fasteners (4 pcs) Handling guide 1 sheet (this sheet) Handling Guide This unit has been carefully packed, with special attention to quality. How- ever, should you find anything damaged or missing, please contact your local GP distributor immediately.
  • Page 3 Host. G:Printer Interface Connect the printer here. H:Tool Connector Connect the Downloading Cable, or a Bar Code Reader here. Dimensions The drawings below illustrate the dimensions of the GP577R-TC11 and GP577R-SC11 unit. Top View unit:mm Front View Side View 77.5...
  • Page 4: Serial Interface

    Serial Interface This is GP’s serial port for RS-232C and RS-422 interface. Connect GP’s host here. Signal Signal Condition Condition Name Name 5V±5% output Frame ground 0.25A Send data Send data B (RS-232C) (RS-422) Receive data Receive data B (RS-232C) (RS-422) Request send No connection...
  • Page 5: Printer Interface

    Printer Interface This is the printer interface port in the rear side of GP unit. Pin Connection Pin # Signal Name PSTB PDB0 PDB1 PDB2 PDB3 PDB4 PDB5 PDB6 PDB7 INIT BUSY *1 When not using the INIT signal, the 10 pin connection becomes unnecessary.
  • Page 6 AUX Interface (Input/Output) An auxiliary interface for touch switch output, system alarm output, RUN output, and remote reset input. Signal Pin Connection Pin # Contents Name TSW0 TSW1 TSW2 TSW3 Touch Switch Output (8 bit) TSW4 TSW5 TSW6 TSW7 Output: On in RUN mode; Off in standby mode or when the power is off.
  • Page 7: Installation

    Installation Confirm the Installation Gasket’s Seating It is strongly recommended that you use the gasket. Place the GP on a level surface with the display panel facing downward. Check that the GP’s installation gasket is seated securely into the gasket’s groove, which runs around the perimeter of the panel’s frame.
  • Page 8 • To avoid electric shock, be sure the Power Cable is unplugged from the power outlet when connecting the cable to the GP unit. • GP577R-TC11 and GP577R-SC11 can only take AC100V input. If you supply power other than AC100V, you will damage its power supply and the GP unit.
  • Page 9 Connect the power cable following the steps below. 1. Check to make sure the Power is Off. 2. With a plus screwdriver, remove the cover on the Power Input Termi- nal Block. 3. Disconnect the screws from the 3 terminals to be used, align the wire rings and re-insert the screws.
  • Page 10: Replacing The Backlight

    577R Series User’s Manual (sold separately) or the instruction manual which comes with replacement backlights (sold separately). Applicable backlight models GP unit Backlight model GP577R-TC11 GP577RT-BL00-MS GP577R-SC11 GP577RS-BL00-MS • Using any backlight other than the applicable models shown above may cause an accident or breakdown.
