Easy! Smooth!
GP-3300 Series->GP4000 Series
Replacement Guidebook
1
Fifth Edition Jul. 2012
Copyright © 2012.7 Digital Electronics Corporation. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP-3300T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pro-face GP-3300T

Summary of Contents for Pro-face GP-3300T

  • Page 1 Easy! Smooth! GP-3300 Series->GP4000 Series Replacement Guidebook Fifth Edition Jul. 2012 Copyright © 2012.7 Digital Electronics Corporation. All Rights Reserved.
  • Page 2 Preface This guidebook introduces the procedures to replace a unit in GP-3300 series with a GP-4301T/TW unit. Model in use Model No. Recommended Substitution GP-3300T AGP3300-T1-D24 GP-4301T GP-3300S AGP3300-S1-D24 GP-3300L AGP3300-L1-D24 GP-3301S*1 AGP3301-S1-D24 GP-4301TW GP-3301L*1 AGP3301-L1-D24 GP-3302B*1 AGP3302-B1-D24 It is also possible to replace GP-3301S/L with GP-4301TM (modular type). For details, please refer to “GP/ST3000 Series ->...

  • Page 3: Safety Information

    Safety Information HAZARD OF OPERATOR INJURY, OR UNINTENDED EQUIPMENT DAMAGE Before operating any of these products, be sure to read all related manuals thoroughly. Failure to follow these instructions can result in death, serious injury or unintended equipment damage.
  • Page 4 GP4000 Series Model Number GP4000 series model number partly differs depending on a specification. Before placing an order, please make sure of the model number. GP-4200 series (3.5”) GP-4300 series (5.7”) GP-4400 series (7.5”/7.0”W) GP-4500 series (10.4”) GP-4600 series (12.1”) RS-232C/422/485 RS-485 (isolation) TFT color LCD...

  • Page 5: Table Of Contents

    Contents PREFACE SAFETY INFORMATION HAZARD OF OPERATOR INJURY, OR UNINTENDED EQUIPMENT DAMAGE GP4000 SERIES MODEL NUMBER CONTENTS CHAPTER 1 SPECIFICATION COMPARISON 1.1 S GP-3300T GP-4301T PECIFICATIONS OF 1.2 S GP-3300S/L GP-4301TW PECIFICATIONS OF 1.3 S GP-3301S/L GP-4301TW PECIFICATIONS OF 1.4 S...
  • Page 6 2.6 B GP-4301T) ACKUP ATTERY ONLY WHEN REPLACING WITH 2.7 P OWER ONSUMPTION 2.8 M ATERIALS OLORS OF THE BODY 2.9 B (SRAM) ( GP-4301TW) ACKUP EMORY ONLY WHEN REPLACING WITH CHAPTER 3 REPLACEMENT PROCEDURE 3.1 W 3.2 P REPARATION 3.3 R GP-3300 ECEIVE SCREEN DATA FROM...

  • Page 7: Chapter 1 Specification Comparison

    Chapter 1 Specification Comparison 1.1 Specifications of GP-3300T and GP-4301T GP-3300T GP-4301T Display Type TFT color LCD Display Colors, Levels 65,536 colors (without blink)/16,384 colors (with blink) Display Resolution QVGA (320x240 pixels) Panel Cutout 156(W)×123.5(H) Dimensions (mm) External Dimensions 167.5(W)x135(H)x59.5(D) 169.5(W)x137(H)x59.5(D)
  • Page 8 D-Sub 9 pin (plug) D-Sub 9 pin (socket) COM2 RS-422/485 RS-422/485 ->See 2.4.1 and Chapter4 Ethernet I/F 10BASE-T/100BASE-TX CF Card I/F ✔ ->See 2.4.2 NEW! SD Card I/F ✔ Type A ✔ ✔ Type mini B ->See 2.3 Expansion Unit I/F ->See 2.5.3 ✔...
  • Page 9 1.2 Specifications of GP-3300S/L and GP-4301TW GP-3300S/L GP-4301TW Display GP-3300S STN color LCD TFT color LCD Type GP-3300L Monochrome LCD GP-3300S 4,096 colors Display 65,536 colors (without blink)/ Colors, 16,384 colors (with blink) GP-3300L Monochrome, 16 levels Levels ->See 2.2 Display Resolution QVGA (320x240 pixels) Panel Cutout...
  • Page 10 D-Sub 9 pin (plug) D-Sub 9 pin (socket) COM2 RS-422/485 RS-422/485 ->See 2.4.1 and Chapter4 Ethernet I/F 10BASE-T/100BASE-TX CF Card I/F ->See 2.4.2 ✔ Type A ✔ ✔ ->See 2.3 Type mini B Expansion Unit I/F ->See 2.5.3 ✔...
  • Page 11 1.3 Specifications of GP-3301S/L and GP-4301TW GP-3301S/L GP-4301TW Display GP-3301S STN color LCD TFT color LCD Type GP-3301L Monochrome LCD GP-3301S 4,096 colors Display 65,536 colors (without blink)/ Colors, 16,384 colors (with blink) GP-3301L Monochrome, 16 levels Levels ->See 2.2 Display Resolution QVGA (320x240 pixels) Panel Cutout...
  • Page 12 D-Sub 9 pin (plug) D-Sub 9 pin (socket) COM2 RS-422/485 RS-422/485 ->See 2.4.1 and Chapter4 NEW! Ethernet I/F 10BASE-T/100BASE-TX ->See 2.4.2 CF Card I/F ✔ Type A ✔ ✔ ->See 2.3 Type mini B Expansion Unit I/F ->See 2.5.3 ✔...

  • Page 13: Specifications Of Gp-3302B

    1.4 Specifications of GP-3302B and GP-4301TW GP-3302B GP-4301TW Monochrome Blue Mode Display Type TFT color LCD Display Colors, 65,536 colors (without blink)/ Monochrome, 8 levels Levels 16,384 colors (with blink) ->See 2.2 Display Resolution QVGA (320x240 pixels) Panel Cutout 156(W)x123.5(H) Dimensions (mm) External Dimensions 167.5(W)x135(H)x59.5(D)

  • Page 14: L Ocations Of Connector

    Type A ✔ ✔ Type mini B ->See 2.3 Expansion Unit ->See 2.5.3 ✔ Chapter 2 Compatibility of Hardware 2.1 Locations of connector Connector locations on GP-3300 series and GP-4301T/TW are as follows: Connector locations on GP-3300T and GP-4301T GP-3300T GP-4301T...
  • Page 15 Interface names GP-3300T GP-4301T Power Connector Serial Interface (COM1) Serial Interface (COM2) Ethernet Interface USB Interface (Type A) USB Interface (Type mini B) SD Card Interface CF Card Interface Expansion Unit Interface...
  • Page 16 Connector locations on GP-3300S/L, GP-3301S/L, GP-3302B and GP-4301TW GP-3300S/L GP-3301S/L...
  • Page 17 GP-3302B GP-4301TW Interface names...
  • Page 18 GP-3300S/L GP-3301S/L GP-3302B GP-4301TW Power Connector Serial Interface (COM1) Serial Interface (COM2) Ethernet Interface Ethernet Interface USB Interface (Type A) USB Interface (Type mini B) CF Card Interface Expansion Unit Interface 2.2 Display Colors (only when replacing GP-3300L/3301L/3302B) The display color of GP-3300L/3301L/3302B is monochrome, but GP-4301TW has a TFT color LCD.

  • Page 19: Transfer Cable

    (2) Open the [Display Settings] tab. (3) Change [Color] setting to “16 Levels Monochrome, 3-Speed Blink”. * [Reverse Display] setting is for displaying the screen with black/white reversed. Check on this setting if needed. * Please confirm the display colors of the drawing or the parts on the screens after changing the [Color] setting.

  • Page 20: Interface

    Using a USB/RS-422/485 Conversion Adapter (PFXZCBCBCVUSR41) allows you to use GP4000 series’ USB interface as RS-422/485 serial interface for connection. For more information, please refer to USB/RS-422/485 Conversion Adapter Installation Guide. (http://www.pro-face.com/otasuke/download/manual/cgi/manual.cgi?mode=33 &cat=3) IMPORTANT When using USB/RS-422/485 Conversion Adapter (PFXZCBCBCVUSR41) with a display unit, the device/PLCs you can connect to its serial interface (RS-422/485) are limited.

  • Page 21: Cf Card Interface

    (PFXZCBCBCVUSR41) for your connection, please contact our sales office in your region. (http://www.pro-face.com/customer/contact.html) 2.4.2 CF Card Interface (except GP-3302B) GP-4301T/TW is not equipped with a CF card slot. But a SD card slot (for GP-4301T only) and a USB interface are installed. In order to use the GP-3300 series functions using the CF card, use a SD card or USB flash drive for GP-4301T/USB flash drive for GP-4301TW instead.

  • Page 22: Expansion Unit

    For the models GP-4301T/TW supports, see [OtasukePro!] (http://www.pro-face.com/otasuke/qa/3000/0056_connect_e.html). 2.5.3 Expansion Unit GP-4301T/TW is not equipped with an expansion unit interface. The expansion units (each kind of unit like CC-LINK Unit) for GP-3300 series cannot be used. 2.5.4 Isolation Unit RS-485 isolation unit for GP-3300 series (CA3-ISO485-01) cannot be used for GP-4301T/TW.

  • Page 23: Power Consumption

    Replaceable Battery Model PFXZCBBT1 2.7 Power Consumption The power consumption of GP-3300 series is different from that of GP-4301T/TW. GP3300T/S/L 26W or less GP-3301S/L GP-3302B 18W or less GP-4301T/TW 10.5W or less For the detailed electric specifications, see the hardware manual. 2.8 Materials/Colors of the body The materials and the colors of GP-3300 series and GP-4301T/TW are as follows: GP-3300 series...

  • Page 24: Chapter 3 Replacement Procedure

    (2) Change the Display Unit type of your project file to “GP-4301TW”. To know how to do it, see [3.4 Change the Display Unit Type]. (3) Click [Project]->[Information]->[Project Information]. The Project Information window appears. (4) Click [SRAM Information] to see SRAM size. Chapter 3 Replacement Procedure 3.1 Work Flow Installation...

  • Page 25: Preparation

    USB Transfer Cable (model: CA3-USBCB-01) from GP-3300 series * Possible to send/receive a screen with a CF card, an USB storage device, or via Ethernet (for GP-3300T/S/L only). Requirements for PC in which GP-Pro EX Ver.3.00 or later is installed.

  • Page 26: Receive Screen Data From Gp-3300 Series

    You can transfer data to GP-3300 series via; ・ An USB transfer cable (model: CA3-USBCB-01) ・ A CF card/USB storage device ・ Ethernet (for GP-3300T/S/L only) But this section explains, as an example, how to receive screen data from GP-3300...
  • Page 27 series using a USB transfer cable (model: CA3-USBCB-01). If you have backed up screen data, this step is unnecessary, skip to the next section [3.4 Change the Display Unit Type]. (1) Connect your PC and GP-3300 series with an USB transfer cable. If the driver of the cable has not been installed on your PC yet, a dialog box will appear.
  • Page 28 ・ If the following symptoms appear on Microsoft Windows® 7, go to updating “USB Data Transfer Driver” on [OtasukePro!] for download (http://www.pro-face.com/otasuke/download/freesoft/gpproex_transfer.ht - An error occurs when GP-Pro EX or Transfer Tool is installed - An error occurs when data is transferred via a USB transfer cable (model: CA3-USBCB-01).
  • Page 29 (3) Make sure that the [Device] in the “Transfer Settings Information” is set to [USB]. If not, click the [Transfer Setting] button to open the “Transfer Setting” dialog box. Select [USB] in the Communication Port Settings field and click [OK]. (4) Start GP-Pro EX Transfer Tool and click the [Receive Project] button.
  • Page 30 (5) Click [Receive Project], and the following dialog box will appear. Specify a place to save the received data in and a project file name, and then click [Save] to start transfer.
  • Page 31 NOTE When a file exists, the window that confirms whether or not to overwrite the file is displayed. (6) The following dialog box appears during transfer and you can check the communication status. (The display unit enters the Transferring mode and communication with the device such as a PLC is terminated.) Display Screen...
  • Page 32 NOTE If you receive the project files that use CF card data such as Recipe Function ・ (CSV data), the following dialog box will appear during transfer. Specify a place to save the CF card data in. Click [OK], and the [Receive Project] dialog box will return and transfer will be completed.

  • Page 33: Change The Display Unit Type

    (8) Close the Transfer Tool. 3.4 Change the Display Unit Type Open the received project file (*.prx) of GP-3300 series on GP-Pro EX and change the display unit type to GP-4301T/TW. (1) Open the received project file (*.prx) on GP-Pro EX. (2) Click [System Settings]->[Display]->[Change Display] in [Project] menu and change the Display Unit type to the replacement model.

  • Page 34: Transfer Screen Data To Gp-4301T/Tw

    3.5 Transfer screen data to GP-4301T/TW Transfer the project file after display unit type change to GP-4301T/TW. You can transfer data to GP-4301T/TW via; ・ An USB transfer cable (model: CA3-USBCB-01) ・ An USB data transfer cable (model: ZC9USCBMB1) ・ A commercial USB cable (USB Type A/mini B) ・...
  • Page 35 ・ If the following symptoms appear on Microsoft Windows® 7, go to updating “USB Data Transfer Driver” on [OtasukePro!] for download (http://www.pro-face.com/otasuke/download/freesoft/gpproex_transfer.ht - An error occurs when GP-Pro EX or Transfer Tool is installed - An error occurs when data is transferred via a USB transfer cable...
  • Page 36 (2) Turn on the power of GP-4301T/TW. The “Initial Start Mode” screen will appear on the display unit. After transferring a project file once, this screen will not appear again. (3) On the GP-Pro EX’s State Toolbar, click the [Transfer Project] icon to open the Transfer Tool.
  • Page 37 (4) Make sure that the [Device] in the “Transfer Settings Information” is set to [USB]. If not, click the [Transfer Setting] button to open the “Transfer Setting” dialog box. Select [USB] in the Communication Port Settings field and click [OK]. (5) Click [Send Project] to start transfer.

  • Page 38: Differences Of Software

    (9) Click the [X] mark on top right of the screen or [Project]->[Exit] to close GP-Pro 3.6 Differences of software Some functions supported by GP-3300 series are not supported by GP-4301T/TW. For details of the supported parts and functions, refer to [Supported Featuers] of GP-Pro EX Reference Manual. (http://www.pro-face.com/otasuke/files/manual/gpproex/new/refer/gpproex.htm).

  • Page 39: Chapter 4 Communication With Device/Plc

    Chapter 4 Communication with Device/PLC 4.1 Drivers More connectable drivers will be added. For the devices/PLC each driver supports, see [Connectable Devices] (http://www.pro-face.com/product/soft/gpproex/driver/driver.html). 4.2 Shapes of COM ports GP-3300T/S/L GP-3302B GP-4301T/TW GP-3301S/L D-Sub 9 pin (plug) D-Sub 9 pin (plug)

  • Page 40: Signals Of Com Ports

    4.3 Signals of COM ports 4.3.1 Signals of COM1 For GP-3300T/S/L and GP-3301S/L RS-232C (plug) *1: RI and VICC of Pin 9 are switched on the software. VCC Output is not protected from overcurrent. Please follow the current rating to avoid false operation or breakdown.
  • Page 41 For GP-3302B RS-232C (plug) *1: RI and VICC of Pin 9 are switched on the software. VCC Output is not protected from overcurrent. Please follow the current rating to avoid false operation or breakdown.
  • Page 42 For GP-4301T/TW RS-232C (plug) *1: RI and VICC of Pin 9 are switched on the software. VCC Output is not protected from overcurrent. Please follow the current rating to avoid false operation or breakdown.

  • Page 43: Signals Of Com2

    4.3.2 Signals of COM2 For GP-3300T/S/L and GP-3301S/L RS-422/485 (socket) *1: VCC Output is not protected from overcurrent. Please follow the current rating to avoid false operation or breakdown. For GP-3302B RS-422 (plug)

  • Page 44: Multilink Connection

    For GP-4301T/TW RS-422/485 (plug) 4.4 Multilink Connection For the communication drivers that support serial multi-link, see [Which drivers support serial multilink communication?] (http://www.pro-face.com/otasuke/files/manual/gpproex/new/device/com_mlnk.ht...

  • Page 45: Cable Diagram At The Time Of Replacement

    GP-3300T/S/L and GP-3301S/L. ・ When a RS-422/485 device is connected via the COM1 port, if GP-3300T/S/L or GP-3301S/L is replaced with GP-4301T/TW, it will be connected via the COM2 port of GP-4301T/TW. (The cable diagram can be still used.) Before GP-4301T/TW is connected, be sure to change the port setting to COM2 on the Device/PLC setting.
  • Page 46 ・ The cable used for connection to GP-3300T/S/L or GP-3301S/L via COM2 can be used for GP-4301T/TW with a COM Port Conversion Adapter (CA3-ADPCOM-01) added in the following cases; In all other cases, the operation is not guaranteed and it's recommended to prepare a new connection cable.

  • Page 47: Chapter 5 Appendix

    Chapter 5 Appendix 5.1 Changing the setting of the external media to use If a CF card is used for GP-3300 series, after the display unit type of the project file is changed to GP-4301T/TW, “a CF card” is automatically replaced with “a SD card” for the external media setting.
  • Page 48 [Solution] 1. Change the SD card setting to the USB storage setting following the steps below. <Procedure> i. Click [Project]->[Information]->[Destination Folder]. ii. Uncheck “Enable SD Card” and check “Enable USB Storage. iii. Click the [Browse] button and specify a destination folder. iv.
  • Page 49 NOTE To check each function setting of GP-Pro EX, refer to GP-Pro EX Reference Manual. 2. Check and change the destination folder setting following the steps below. i. Click [Project]->[Information]->[Destination Folder]. ii. The current setting is displayed. iii. After changing it, click [OK] to confirm the setting. iv.
