Easy! Smooth!
Replacement Guidebook
GP-3600T
-> SP-5600TA
+ SP-5B10
SP-5B00
(Advanced Display)
(Power Box)
(Standard Box)
The 6
th
Edition Jun. 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP-3600T Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pro-face GP-3600T Series

Summary of Contents for Pro-face GP-3600T Series

  • Page 1 Easy! Smooth! Replacement Guidebook GP-3600T -> SP-5600TA (Advanced Display) + SP-5B10 (Power Box) SP-5B00 (Standard Box) The 6 Edition Jun. 2020...
  • Page 2 Preface This guidebook introduces the procedures to replace a unit in GP-3600T series with a SP-5600TA+SP-5B10/SP-5B00. Model in use Model No. Recommended Substitution AGP3600-T1-AF SP-5600TA (Advanced Display) ＋SP-5B00(Standard Box) GP-3600T AGP3600-T1-D24 ->see 1.1 AGP3600-T1-AF-D81C AGP3600-T1-D24-D81C GP-3600T (DIO Type) SP-5600TA (Advanced Display) AGP3600-T1-AF-D81K ＋SP-5B10(Power Box)

  • Page 3: Table Of Contents

    Contents CHAPTER 1 SPECIFICATION COMPARISON 1.1. S GP-3600T (S PECIFICATION OF TANDARD LASS SP-5600TA+SP-5B00 1.2. S GP-3600T (C PECIFICATION OF ONTROL LASS SP-5600TA+SP-5B10 CHAPTER 2 COMPATIBILITY OF HARDWARE 2.1. L OCATIONS OF CONNECTOR 2.2. P OWER SUPPLY 2.3. USB T RANSFER CABLE 2.4.
  • Page 4 3.3. R GP3000 ECEIVE SCREEN DATA FROM SERIES 3.4. C HANGE THE ISPLAY 3.5. T SP5000 RANSFER THE SCREEN DATA TO SERIES 3.6. D IFFERENCES OF SOFTWARE CHAPTER 4 COMMUNICATION WITH DEVICE/PLC 4.1. S HAPES AND OMMUNICATION METHOD OF PORTS 4.2.

  • Page 5: Chapter 1 Specification Comparison

    Chapter 1 Specification Comparison 1.1. Specification of GP-3600T (Standard Class) and SP-5600TA+SP-5B00 GP-3600T SP-5600TA+SP-5B00 Display Type TFT Color LCD 65,536 colors (without blink)/ Display Colors 262,144 colors 16,384 colors (without blink) (with blink) XGA (1,024×768 pixels) Display Resolution SVGA (800×600 pixels) ->see 2.9 Panel Cut Dimensions W301.5×H227.5mm...
  • Page 6 UP！ 1 port 2 ports Ethernet I/F 10BASE-T/100BASE-TX 10BASE-T/100BASE-TX NEW！ CF Card I/F ✔ -> see 2.4.5 NEW！ SD Card I/F ✔ -> see 2.4.5 Type A 2 ports 2 ports NEW！ Type mini B 1 port USB Type A Printer I/F ->...
  • Page 7 *4: No expansion memory but SP5000 series has enough memory to cover GP3000 series + expansion memory. 7 / 34...

  • Page 8: Specification Of Gp-3600T

    1.2. Specification of GP-3600T (Control Class) and SP-5600TA+SP-5B10 GP-3600T SP-5600TA+SP-5B10 Display Type TFT Color LCD 65,536 colors (without blink)/ 262,144 colors （ without blink） Display Colors 16,384 colors /65,536colors（with blink） (with blink) XGA (1,024×768 pixels) Display Resolution SVGA (800×600 pixels) ->see 2.9 Panel Cut Dimensions W301.5×H227.5mm...
  • Page 9 UP！ 1 port 2 ports Ethernet I/F 10BASE-T/100BASE-TX 10BASE-T/100BASE-TX/ 1000BASE-T NEW！ CF Card I/F ✔ -> see 2.4.5 NEW！ SD Card I/F ✔ -> see 2.4.5 Type A 2 ports 2 ports NEW！ Type mini B 1 port USB Type A Printer I/F ->...
  • Page 10 (Image Unit) -> see 2.7 Expansion Memory ✔ Software GP-Pro EX 2.00 or later GP-Pro EX 4.08.200 or later Size for the time when SP-5600TA (Advanced display) is combined with SP-5B10 (Power box). For further use of the below expansion unit, please refer to below FAQ.

  • Page 11: Chapter 2 Compatibility Of Hardware

    Chapter 2 Compatibility of Hardware 2.1. Locations of connector Connector locations of GP-3600T and SP-5600TA+SP-5B10/SP-5B00 GP-3600T SP-5600TA (Advanced display) SP-5B10 (Power box) SP-5B00 (Standard box) 11 / 34...

  • Page 12: Power Supply

    SP5000 series SP5000 series GP-3600T SP-5B10(Power box) SP-5B00(Standard box) Power Input Terminal Block (AC) / Power Connector (DC) Power Connector (DC) Power Connector (DC) Serial I/F (COM1) Serial I/F (COM2) Ethernet I/F USB I/F (Type A) USB I/F (Type mini B) Storage Card Cover (There’s a SD card I/F for storage under the cover.) CF card I/F...

  • Page 13: Interface

    2.4. Interface 2.4.1. Serial Interface The SP5000 series has a COM port on the side of box module. The pin array and the shapes of the plug and the socket differ between GP-3600T COM2 port and SP-5B10 (Power box)/SP-5B00 (Standard box) COM port. The PLC connection cable that used to be connected to GP3000 Series via its COM2 port cannot be used as it is.

  • Page 14: Cf Card Interface

    2.4.5. CF Card Interface SP5000 series is not equipped with a CF card slot. But a SD card slot and a USB interfaces are installed. In order to use the GP-3600T data saved in the CF card and the functions using the CF card, use a SD card or a USB flash drive instead. SP-5B10 (Power box) has 2 SD card interfaces, one for the system and the other for backup.

  • Page 15: Peripheral Units And Option Units

    2.5. Peripheral units and option units 2.5.1. Barcode/ 2D [two-dimensional] code reader connection Like GP3000 series, SP5000 series allows you to connect a barcode reader to its USB interface (Type A) or its serial interface. In replacing GP3000 series with SP5000 series, verify proper operation of the barcode/2D code reader before use.

  • Page 16: Isolation Unit

    2.5.4. Isolation Unit RS-485 isolation unit for GP3000 Series (CA3-ISO485-01) cannot be used for SP-5B10 (Power box)/ SP-5B00 (Standard box). You can use the RS-232C isolation unit (CA3-ISO232-01) for SP-5B10 (Power box)/ SP-5B00 (Standard box) instead. (The communication method is switched with this unit’s DIP switch.) Note for using RS-232C isolation unit (CA3-ISO232-01) ・...

  • Page 17: Supported Features

    2.7. Supported features SP5000 Series does not support the following features. • Recording/Playing a video • Features using Image Unit (VM/DVI/RGB input) • Camera-Viewer EX • • PLC Ladder Monitor 2.8. Power Consumption The power consumption of GP3000 series is different from that of SP5000 series. GP-3600T ST-5600TA+ ST-5600TA+...

  • Page 18: About Pro-Server Ex

    2.10. About Pro-Server EX Use Pro-Server EX Ver.1.33 or later. For more detail, please refer to the following. (http://www.proface.co.jp/otasuke/qa/server_ex/replace/) If using SP-5B00(Standard BOX), use Pro-Server EX Ver.1.36 or later. 2.11. Other Notes • Do not expose SP5000 series to direct sunlight. •...

  • Page 19: Chapter 3 Replacement Procedure

    Chapter 3 Replacement Procedure 3.1. Work Flow Installation Screen Communication Receive screen data from Check the connection Check the compatibility of GP3000 Series. hardware in Chapter 2. between SP5000 series and a PLC in the GP-Pro EX Device/PLC Connection Manual. Change the received data Remove GP3000 Series.
  • Page 20 GP3000 Series. If you don’t know the version, we recommend you to use the newest version. For the newest version, you can download the transfer tool from our web site called [OtasukePro!] (http://www.pro-face.com/otasuke/download/freesoft/gpproex_transfer.htm). PROFIBUS DP slave/MPI unit (Model number:PFXZCDEUPF1) of SP5000 series is supported at GP-Pro EX V4.07.000 or later.
  • Page 21 3.3. Receive screen data from GP3000 series You can transfer data to GP3000 Series via; A USB transfer cable (model: CA3-USBCB-01) • A CF card/USB storage device • Ethernet • If you have backed up screen data, this step is unnecessary, skip to the next section [3.4 Change the Display Unit Type].
  • Page 22 (2) Start the Transfer Tool of GP-Pro EX (3) Make sure that the [Device] in the “Transfer Settings Information” is set to [USB]. If not, click the [Transfer Setting] button to open the “Transfer Setting” dialog box. Select [USB] in the Communication Port Settings field and click [OK]. 22 / 34...
  • Page 23 (4) Start GP-Pro EX Transfer Tool and click the [Receive Project] button (5) Click [Receive Project], and the following dialog box will appear. Specify a place to save the received data in and a project file name, and then click [Save] to start transfer.
  • Page 24 (6) The following dialog box appears during transfer and you can check the communication status. (The display unit enters the Transferring mode and communication with the device such as a PLC is terminated.) Display Screen NOTE (1) If you receive the project files that use CF card data such as Recipe Function (CSV data), the following dialog box will appear during transfer.
  • Page 25 (7) When transfer is completed, the status displayed in the dialog box will change from [Transferring] to [Complete Transfer]. Click [Close] to close the dialog box. (8) Close the Transfer Tool. 25 / 34...
  • Page 26 3.4. Change the Display Unit Type Open the received project file (*.prx) of GP3000 Series on GP-Pro EX and change the display unit type to SP5000 series. (-> 2.9) (1) Open the received project file (*.prx) on GP-Pro EX. (2) Click [System Settings]->[Display]->[Change Display] in [Project] menu and change the Display Unit type to the replacement model.
  • Page 27 (1) Connect your PC and the GP unit of SP5000 series with a USB transfer cable. If the driver of the cable has not been installed on you PC, a dialog box will appear. Please follow the instructions. NOTE ・ The “Hardware Installation” dialog box as shown below may appear during installing the USB driver depending on the security ®...
  • Page 28 (3) On the GP-Pro EX’s State Toolbar, click the [Transfer Project] icon to open the Transfer Tool. To transfer a different project file, click the [Select Project] button and select a project file. (4) Make sure that the [Device] in the “Transfer Settings Information” is set to [USB].
  • Page 29 (5) Click [Send Project] to start transfer. When the following dialog box appears, click [Yes]. This dialog box doesn’t appear when the same project file is sent again. (6) The following dialog box appears during transfer and you can check the communication status.

  • Page 30: Differences Of Software

    3.6. Differences of software Some functions supported by GP3000 Series are not supported by SP5000 series. For details of the details of the supported parts and functions, refer to [Supported Features] of GP-Pro EX Reference Manual (http://www.pro-face.com/otasuke/files/manual/gpproex/new/refer/gpproex.ht 30 / 34...

  • Page 31: Chapter 4 Communication With Device/Plc

    Chapter 4 Communication with Device/PLC 4.1. Shapes and Communication method of COM ports GP-3600T SP-5B10 SP-5B00 (Power box) (Standard box) D-Sub9 pin (plug) D-Sub9 pin (plug) COM1 RS-232C/422/485 RS-232C D-Sub9 pin (socket) D-Sub9 pin (plug) D-Sub9 pin (plug) COM2 RS-422/485 RS-232C/422/485 RS-422/485 When both the COM1 port and the COM2 port have the RS-422/485 setting,...

  • Page 32: Cable Diagram At The Time Of Replacement

    COM2 on the Device/PLC setting. Also, please check the communication settings with GP-Pro EX Device/PLC Connection Manual just in case. (http://www.pro-face.com/otasuke/files/manual/gpproex/new/device/index.ht ◆GP-3600T’s COM2 cable For the following case only, it can be used for the COM1/COM2 on SP-5B10 (Power box), COM2 on SP-5B00(Standard box) if the ”COM Port Conversion Adapter...

  • Page 33: Chapter 5 Appendix

    Chapter 5 Appendix 5.1. Changing the setting of the external media to use If a CF card is used for GP3000 series, after the display unit type of the project file is changed to SP5000 series, “a CF card” is automatically replaced with “a SD card”...
  • Page 34 Click [OK] to confirm the setting. Click [Project]->[Save] to save changes. Check each function that uses the CF card and replace the setting of [SD Card] with the one of [USB Storage]. NOTE To check each function setting of GP-Pro EX, refer to GP-Pro EX Reference Manual.
