Sun StorEdge
SBus Dual Fibre
™
Channel Host Adapter

Installation Guide

Sun Microsystems, Inc.
4150 Network Circle
Santa Clara, CA 95054 U.S.A.
650-960-1300
Part No. 816-2489-12
October
2002, Revision
A
Send comments about this document to: docfeedback@sun.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sun StorEdge and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sun Microsystems Sun StorEdge

Summary of Contents for Sun Microsystems Sun StorEdge

  • Page 1: Installation Guide

    Sun StorEdge SBus Dual Fibre ™ Channel Host Adapter Installation Guide Sun Microsystems, Inc. 4150 Network Circle Santa Clara, CA 95054 U.S.A. 650-960-1300 Part No. 816-2489-12 October 2002, Revision Send comments about this document to: docfeedback@sun.com...
  • Page 2 Sun, Sun Microsystems, the Sun logo, AnswerBook2, docs.sun.com, OpenBoot, SunVTS, Netra, Solaris, Sun StorEdge, Ultra, Sun Blade, Sun Enterprise, et Sun Fire sont des marques de fabrique ou des marques déposées, ou marques de service, de Sun Microsystems, Inc. aux Etats-Unis et dans d’autres pays.

  • Page 3: Table Of Contents

    Contents Preface xv How This Book Is Organized xv How to Use This Book xv Using UNIX Commands xvi Typographic Conventions xvi Shell Prompts xvii Related Documentation xvii Accessing Sun Documentation Online xvii Installing the Software Components 1 Required Software 1 Device Tree Entries 2 Patch and Package Download Sites 3 Installing the Hardware 5...
  • Page 4 Installing Solaris OE From the Installation CD 13 Who Should Use This Software 13 About the CD 0s That Shipped With Your System 14 When to Use the CD 0 14 Installing the Solaris OE With the CD 0s 15 Installing the Solaris 8 4/01, Solaris 8 7/01, or Solaris 8 10/01 Release With the Accompanying CD 0 15 To Install the Solaris Operating Environment With the CD 0 16...
  • Page 5 To Set Up the Client 6 The Dump and Restore Method 8 Overview Of the Dump and Restore Method 8 Partitioning the New Boot Disk the Same As the Temporary Boot Disk 9 To Prepare To Partition the New Disk 9 To Record the Partition Layout 9 To Change to the New Boot Disk 12 To Specify Slices on the New Boot Disk 14...
  • Page 6 Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...

  • Page 7: Declaration Of Conformity

    Declaration of Conformity Compliance Model Number: IVORY Product Family Name: Sun StorEdge SBUS Dual Fiber Channel Host Adapter. European Union This equipment complies with the following requirements of the EMC Directive 89/336/EEC: EN55022:1998 / CISPR22:1997 Class A EN55024:1998 Required Limits (as applicable):...
  • Page 8 Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...

  • Page 9: Regulatory Compliance Statements

    FCC radio frequency emission limits. Networking connections can be made using unshielded twisted-pair (UTP) cables. Modifications: Any modifications made to this device that are not approved by Sun Microsystems, Inc. may void the authority granted to the user by the FCC to operate this equipment.
  • Page 10 Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. BSMI Class A Notice The following statement is applicable to products shipped to Taiwan and marked as Class A on the product compliance label. Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...
  • Page 11 Regulatory Compliance Statements...
  • Page 12 Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...

  • Page 13: Safety Agency Compliance Statements

    Follow all cautions and instructions marked on the Do not make mechanical or electrical modifications to the equipment. equipment. Sun Microsystems is not responsible for regulatory compliance of a modified Sun product. Ensure that the voltage and frequency of your power source match the voltage and frequency inscribed on the equipment’s electrical rating label.

  • Page 14: Lithium Battery

    Do not connect the power cord when the power supply has been removed from the system chassis. Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...
  • Page 15 Observez tous les avertissements et consignes N'apportez aucune modification mécanique ou électrique à indiqués sur l'équipement. l'équipement. Sun Microsystems décline toute Assurez-vous que la tension et la fréquence de votre responsabilité quant à la non-conformité éventuelle d'un source d'alimentation électrique correspondent à la produit Sun modifié.
  • Page 16 être utilisés avec des ordinateurs. N'utilisez jamais de cordon d'alimentation à usage domestique avec les produits Sun. Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...
  • Page 17 Bloc-batterie CD-ROM Attention – Les unités Sun StorEdge SBus Attention – .L'utilisation de contrôles et de Dual Fibre Channel Host Adapter contiennent réglages ou l'application de procédures autres une batterie étanche au plomb. Produits que ceux spécifiés dans le présent document énergétiques portatifs nº...
  • Page 18 Sun-Produkten nicht haftbar. besitzen die gleiche Stromleitung. Normale Verlängerungskabel besitzen keinen Überspannungsschutz und sind nicht für den Gebrauch mit Computersystemen geeignet. Benutzen Sie keine Haushaltverlängerungskabel für Sun-Geräte. Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...
  • Page 19 Batterien Achtung – Ihr Sun-Gerät wurde mit einem geerdeten (dreiadrigen) Netzanschlußkabel Achtung – Die Geräte Sun StorEdge SBus geliefert. Stecken Sie dieses Kabel immer nur Dual Fibre Channel Host Adapter enthalten in eine geerdete Netzsteckdose, um auslaufsichere Bleiakkumulatoren, Produkt- Kurzschlüsse zu vermeiden.
  • Page 20 Precaución – El nivel de ruido en el lugar de equipo. Siga las instrucciones. trabajo, definido en el apartado 1000 de DIN 45 635, debe ser 70 Db (A) o inferior. Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...
  • Page 21 Sustitúyalo sólo por el mismo tipo espera: de paquete de baterías de Sun Microsystems. No lo desmote o intente recargarlo fuera del sistema. No arroje la batería al fuego. Deshágase de las baterías correctamente siguiendo las normas locales vigentes.
  • Page 22 Hävitä käytetty paristo valmistajan ohjeiden mukaisesti. Certificación GOST-R Gráfico que muestra el símbolo del certificado GOST-R xviii Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...
  • Page 23 Figures Removing the Adapter Plate 7 FIGURE 2-1 Inserting the Host Adapter in an I/O Board 7 FIGURE 2-2 Securing the Adapter With the I/O Board Locking Pins 8 FIGURE 2-3...
  • Page 24 Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...
  • Page 25 Tables Patch and Package Download Sites 3 TABLE 1-1 Fibre Channel Interface Specifications 1 TABLE A-1 Fibre Channel Performance Specifications 2 TABLE A-2 Power Specifications 3 TABLE A-3 Physical Dimensions 4 TABLE A-4 Regulatory Compliance Requirements Met or Exceeded by the Adapter 4 TABLE A-5 SBus Connector Pin Definitions 5 TABLE A-6...
  • Page 26 Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...

  • Page 27: Preface

    Preface This Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide describes how to install and use the dual Fibre Channel (FC) adapter. The procedures in this manual are for system or network administrators who have experience installing hardware in a Solaris™ operating environment.

  • Page 28: Using Unix Commands

    These are called class options. You must be superuser to do this. Command-line variable; replace To delete a file, type rm filename. with a real name or value xvi Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...

  • Page 29: Shell Prompts

    Product Notes Accessing Sun Documentation Online The www.sun.com web site enables you to access Sun™ technical documentation on the Web. To access the Sun StorEdge SBus Dual Fibre Channel Host Adapter product documentation, go to the following Sun web site: http://www.sun.com/products-n- solutions/hardware/docs/Network_Storage_Solutions/Adapters/index .html...
  • Page 30 Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...

  • Page 31: Installing The Software Components

    C H A P T E R Installing the Software Components Before you can use the Sun StorEdge™ SBus dual Fibre Channel host adapter, you must first install the patches and packages for this product. You can download from the web or get them from the CD provided with the adapter. The instructions in this chapter cover downloading the patches and packages from the web.

  • Page 32: Device Tree Entries

    Install this patch on the latest revision of the Sun StorEdge Network Foundation Software. cfgadm plug-in This component is delivered with the Solaris upgrades for the Sun StorEdge SAN 4.0 Release. It discovers SAN-attached devices in addition to creating and deleting Fabric devices.

  • Page 33: Patch And Package Download Sites

    Patch and Package Download Sites You can download the required software components from the web sites listed in TABLE 1-1 Patch and Package Download Sites TABLE 1-1 Software Downloading Web Site Packages http://www.sun.com/storage/san/ Patches http://sunsolve.sun.com Chapter 1 Installing the Software Components...
  • Page 34 Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...

  • Page 35: Installing The Hardware

    C H A P T E R Installing the Hardware The minimum hardware requirement for the Sun StorEdge SBus Dual Fibre Channel Host Adapter is an SBus-based system. This chapter describes how to install the adapter in a system and contains the following topics: “Tools and Equipment Needed”...

  • Page 36: To Prepare For The Installation

    Refer to your system documentation for specific instructions. Caution – If you need to remove a system board for installation, place the board on a padded antistatic mat to prevent damage. Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...
  • Page 37 2. If necessary, remove the adapter plate by removing the two Phillips screws. Refer to the documentation for your system to see if you need to remove this part. Adapter plate Fibre Channel optical adapters SBus Connector Rubber plugs Removing the Adapter Plate FIGURE 2-1 3.
  • Page 38 8. Connect the other end of the fiber optic cable to a device such as a disk array, hub, or switch. Refer to the documentation that came with the device for specific instructions. Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...

  • Page 39: To Confirm The Installation

    To Confirm the Installation 1. Power on your peripherals and then your system. Note – If your system starts to reboot, interrupt the reboot process by pressing the Stop-A keys. The system should now be at the ok prompt. 2. Detect devices from the OpenBoot PROM. Detecting OpenBoot PROM Level Devices CODE EXAMPLE 2-1 ok probe-fcal-all...
  • Page 40 /counter-timer@3,3c00 /sbus@3,0 /counter-timer@2,3c00 /fhc@2,f8800000 /sbus@2,0 /SUNW,UltraSPARC-II@7,0 /SUNW,UltraSPARC-II@6,0 /fhc@6,f8800000 /central@1f,0 /virtual-memory /memory@0,0 /aliases /options /openprom /chosen /packages /sbus@3,0/SUNW,qlc@0,30400 /sbus@3,0/SUNW,qlc@0,30000 /sbus@3,0/SUNW,fas@3,8800000 /sbus@3,0/SUNW,hme@3,8c00000 /sbus@3,0/SUNW,qlc@0,30400/fp@0,0 /sbus@3,0/SUNW,qlc@0,30400/fp@0,0/disk /sbus@3,0/SUNW,qlc@0,30000/fp@0,0 /sbus@3,0/SUNW,qlc@0,30000/fp@0,0/disk /sbus@3,0/SUNW,fas@3,8800000/st /sbus@3,0/SUNW,fas@3,8800000/sd Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...
  • Page 41 Displaying the Entire Device Tree (Continued) CODE EXAMPLE 2-2 /fhc@2,f8800000/sbus-speed@0,500000 /fhc@2,f8800000/eeprom@0,300000 /fhc@2,f8800000/flashprom@0,0 /fhc@2,f8800000/environment@0,400000 /fhc@2,f8800000/ac@0,1000000 /sbus@2,0/SUNW,socal@d,10000 /sbus@2,0/SUNW,socal@d,10000/sf@1,0 /sbus@2,0/SUNW,socal@d,10000/sf@0,0 /sbus@2,0/SUNW,socal@d,10000/sf@1,0/ssd /sbus@2,0/SUNW,socal@d,10000/sf@0,0/ssd /fhc@6,f8800000/flashprom@0,0 /fhc@6,f8800000/sram@0,200000 /fhc@6,f8800000/environment@0,400000 /fhc@6,f8800000/simm-status@0,600000 /fhc@6,f8800000/ac@0,1000000 /central@1f,0/fhc@0,f8800000 /central@1f,0/fhc@0,f8800000/clock-board@0,900000 /central@1f,0/fhc@0,f8800000/zs@0,904000 /central@1f,0/fhc@0,f8800000/zs@0,902000 /central@1f,0/fhc@0,f8800000/eeprom@0,908000 /openprom/client-services /packages/ufs-file-system /packages/disk-label /packages/obp-tftp /packages/deblocker /packages/terminal-emulator b. Use the apply show-children command with the port path of the adapter to display the devices attached to the port.
  • Page 42 1 on the Sun StorEdge CODE EXAMPLE 2-3 /sbus@3,0/SUNW,qlc@0,30000 SBus dual Fibre Channel host adapter and the disks are in a Sun StorEdge A5x00 array (SENA). Note – The probe-fcal-all command does not function identically on all platforms, and it does not always probe for Fibre Channel devices.

  • Page 43: Installing Solaris Oe From The Installation Cd

    Installing Solaris OE From the Installation CD Note – If you installed the software as directed in Chapter 1 and the Sun StorEdge SBus Dual Fibre Channel Host Adapter Product Notes, skip this chapter and continue with Chapter 4. For the latest patch and package information, see the product notes.

  • Page 44: About The Cd 0S That Shipped With Your System

    When to Use the CD 0 The CD 0s must be used to initiate installation of systems with the Sun StorEdge SBus Dual Fibre Channel adapter. Do not use the Solaris 8 Installation CD that shipped with the Solaris 8 4/01, Solaris 7/01, or Solaris 10/01 release.

  • Page 45: Installing The Solaris Oe With The Cd 0S

    By initiating installation with CD 0, the Solaris operating environment is installed along with the required adapter patches. Installing the Solaris OE With the CD 0s There are two ways to install the Solaris software: Install the Solaris OE directly on the system from the appropriate CD 0. Install an image from the Media Kit of the Solaris OE on an installation server, patch the image using the binary images from the CD 0, and then use the patched image to install the Solaris OE on the systems.

  • Page 46: To Install The Solaris Operating Environment With The

    Type the appropriate number for your choice of language. Note – For a command line installation, the installation process is in English only. 5. Answer the installation questions when prompted. Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...
  • Page 47 The installation CD 0 loads installation mini-os software (mini-root) temporarily on one of the disk partitions (usually the swap partition). In the first part of the installation process, specify how the mini-root is loaded by answering the following questions through a series of menus: a.

  • Page 48: To Use The Solaris Web Start Interface

    This could take an hour or more, depending on the software you are installing and the speed of your system 6. When the installation is complete, click Next in the Installation Summary panel. Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...

  • Page 49: Patching A Network Installation Image For The Solaris 8 4/01, Solaris 8 7/01, Or Solaris 8 10/01 Release

    The system reboots and then the CD is ejected. Web Start is displayed. 7. Load any dditional Solaris software from the CDs as required. Refer to the Solaris 8 4/01, Solaris 8 7/01, or Solaris 8 10/01 documentation for further information on optional software. 8.
  • Page 50 For more information, see the “Preparing to Install Solaris Software Over the Network” chapter in the Solaris Advanced Installation Guide that is in your media kit. Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...

  • Page 51: Testing The Installation

    C H A P T E R Testing the Installation This chapter describes how to test the Sun StorEdge™ SBus dual Fibre Channel host adapter in a system. Testing the Installation Using the SunVTS Software The SunVTS™ diagnostic program exercises your system to verify the functionality, reliability, and configuration of your host adapter.
  • Page 52 This is a good way to test your Fibre Channel loop if you leave the qlc port attached to storage devices. Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...

  • Page 53: Specifications

    A P P E N D I X Specifications Fibre Channel Interface Specifications Fibre Channel Interface Specifications TABLE A-1 Specification Value ANSI standards Fibre Channel FC-PH X3.230-1995 SCSI Fibre Channel Protocol X3.269-1996 Optical transceiver 100 Mbytes/sec. (1 Gbits/sec.) full duplex Shortwave laser, Module Definition 5 Fibre cable type 50 micrometer multimode...

  • Page 54: Performance Specifications

    Specification SBus clock frequency 25 MHz SBus transfer rate 32-bit: 80 Mbytes/second burst rate 64-bit: 160 Mbytes/second burst rate Fibre Channel transfer rate 100 Mbytes/second per port Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...

  • Page 55: Power Specifications

    Power Specifications The following specifications must be verified. Power Specifications TABLE A-3 Specification Value Power dissipation 15.0W Max. Current requirement A Max. @ 5V Input voltage requirement V +/- 5% Power supply voltage ripple requirement < 100mv p-p Appendix A Specifications...

  • Page 56: Physical Dimensions

    EMC Directive (89/336/EEC), EN55022 Immunity EMC Directive (89/336/EEC), EN55082-1 SBus Connector Pin Definitions The SBus slot uses a high density 96-pin SBus connector. The Sun StorEdge SBus Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...

  • Page 57: Table A-6 Sbus Connector Pin Definitions

    Dual Fibre Channel Host Adapter cards use a male SBus card connector mounted on the solder side of the board. SBus Connector Pin Definitions TABLE A-6 Description Description Description Description D[31] D[30] SIZ[0] SIZ[1] SEL* SIZ[2] PPRD INT[1]* INT[7]* D[00] PA[00] D[01] PA[01]...
  • Page 58 Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...

  • Page 59: Booting From The Network Adapter

    A P P E N D I X Booting From the Network Adapter Note – Use the procedures in this appendix if you are not using a CD 0. This appendix contains two procedures for booting from the network adapter to enable detection of the installation devices.

  • Page 60: Determining Which Boot Method To Use

    Installing a client from a boot or install server uses two images of the Solaris OE: 1. For the distinction between these two types of server, see the Solaris system administration documentation. Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...
  • Page 61 A boot mini-root (which is referred to from here on as the boot image) A separate install image that gets copied onto the boot disk This procedure assumes you know how to install Solaris software over the network as described in the Solaris installation manuals. For more information, see the man(1) pages for the commands that are used in this procedure.

  • Page 62: To Set Up The Boot Or Install Server

    4. Download the required patch(es) and the accompanying README file(s) from sunsolve.sun.com into the /export_public directory on the boot or install server. Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...

  • Page 63: To Modify The Boot Image

    a. See the release notes for a list of required patches. b. Go to the URL specified in the instructions on how to download the network adapter driver in the product notes. c. Download the README file. d. Remove any previously installed related patches that are specified in the README.

  • Page 64: To Set Up The Client

    3. Respond to the prompts according to your configuration as instructed in the Solaris installation guide. Ensure that to specify the new boot disk as the destination for the operating environment installation. Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...
  • Page 65 4. When prompted to choose between automatic reboot or manual reboot, click the Manual Reboot button, complete the remaining question, and then start the installation. This question offering a choice between automatic and manual reboot is the last question before the installation starts. If you are using the suninstall program, choose boot manual.

  • Page 66: The Dump And Restore Method

    Note – The examples in this section show disk 0 as the directly connected boot disk, and disk 2 as the designated new boot disk that is connected through the host adapter. Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...

  • Page 67: Partitioning The New Boot Disk The Same As The Temporary Boot Disk

    B.3.2 Partitioning the New Boot Disk the Same As the Temporary Boot Disk This section contains several subprocedures you must perform to complete the first phase of enabling bootability from a temporarily connected boot disk. These sub procedures include: “To Prepare To Partition the New Disk” on page B-9 “To Record the Partition Layout”...
  • Page 68 3. Specify the disk where the operating system is installed on the temporary boot disk. The following screen example specifies disk 0. Specify disk (enter its number): 0 B-10 Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...
  • Page 69 4. Use the partition command to display the PARTITION MENU. format> partition PARTITION MENU: - change ‘0’ partition - change ‘1’ partition - change ‘2’ partition - change ‘3’ partition - change ‘4’ partition - change ‘5’ partition - change ‘6’ partition - change ‘7’...

  • Page 70: To Change To The New Boot Disk

    The FORMAT MENU is displayed. To Change to the New Boot Disk After you record the partition layout, change to the new boot disk. B-12 Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...
  • Page 71 1. At the format> prompt, type disk to change the current disk to the new boot disk: # format Searching for disks...done AVAILABLE DISK SELECTIONS: 0. c0t1d0 <SUN18G cyl 7506 alt 2 hd 19 sec 248> /pci@8,600000/SUNW,qlc@4/fp@0,0/ssd@w2100002037e43542,0 1. c0t2d0 <SUN36G cyl 24620 alt 2 hd 27 sec 107> /pci@8,600000/SUNW,qlc@4/fp@0,0/ssd@w21000020374205a1,0 2.

  • Page 72: To Specify Slices On The New Boot Disk

    The following examples specify the root slice 0 on the new boot disk to match slice 0 on the temporary boot disk. B-14 Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...
  • Page 73 1. Use the partition command to display the PARTITION MENU. format> p PARTITION MENU: - change ‘0’ partition - change ‘1’ partition - change ‘2’ partition - change ‘3’ partition - change ‘4’ partition - change ‘5’ partition - change ‘6’ partition - change ‘7’...
  • Page 74 Enter partition size[262899b, 91c, 128.37mb, 0.13gb]: 6. Type the partition size. The following example shows the partition size of 2.00gb entered. Enter partition size[262899b, 91c, 128.37mb, 0.13gb]: 2.00gb partition> B-16 Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...
  • Page 75 7. Use the print command to display the updated partition table. The following example shows that the root tag, the wm permissions flag, and the partition size of 2.00GB are assigned to slice 0. partition> print Current partition table (unnamed): Total disk cylinders available: 24620 + 2 (reserved cylinders) Part Flag...

  • Page 76: To Label The New Boot Disk

    2. Type y to continue labeling the disk. Ready to label disk, continue? y 3. When the labeling is complete, type q to quit the format program. format> q B-18 Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...

  • Page 77: To Create File Systems On The New Boot Disk

    To Create File Systems on the New Boot Disk Use this procedure to create a file system on the new boot disk for every slice on the temporary boot disk. When you are finished, go to “To Copy the Contents of Non- Root File Systems Onto the New Boot Disk”...

  • Page 78: To Copy The Boot Block And Root File System Contents To The New Boot Disk

    (on the /mnt mount point). Make sure you use the original root slice in the command. In the following example, the root slice is /dev/rdsk/c0t1d0s0. B-20 Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...

  • Page 79: To Update The Vfstab File

    # ufsdump 0f - /dev/rdsk/c0t1d0s0 | ( cd /mnt; ufsrestore rf -) DUMP: Writing 32 Kilobyte records DUMP: Date of this level 0 dump: Tue 19 Feb 2002 02:44:35 PM PST DUMP: Date of last level 0 dump: the epoch DUMP: Dumping /dev/rdsk/c7t16d0s0 (hba2-81:/) to standard output.

  • Page 80: To Copy The Contents Of Non-Root File Systems Onto The New Boot Disk

    1. Mount the file system onto the /mnt mount point. This example shows the copying of the /home file system from slice 7 to the new boot disk. # mount /dev/dsk/c7t16d0s7 /mnt B-22 Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...

  • Page 81: To Specify The New Boot Disk As The Boot Device

    2. Use the ufsdump(1M) and ufsrestore(1M) commands to copy the contents of the file system from the temporary boot disk to the new boot disk. # ufsdump 0f - /dev/rdsk/c0t1d0s7 | ( cd /mnt; ufsrestore rf -) DUMP: Writing 32 Kilobyte records DUMP: Date of this level 0 dump: Tue 19 Feb 2002 02:44:35 PM PST DUMP: Date of last level 0 dump: the epoch DUMP: Dumping /dev/rdsk/c7t16d0s0 (hba2-81:/) to standard...
  • Page 82 5. Reboot the system using the boot command with the -r option so that the Solaris operating environment can recognize the adapter. ok boot -r B-24 Sun StorEdge SBus Dual Fibre Channel Host Adapter Installation Guide • October 2002...
