Sun
StorEdge
™
™
PCI FC-100 Host Adapter
Installation Manual
Sun Microsystems Computer Company
A Sun Microsystems, Inc. Business
901 San Antonio Road
Palo Alto, CA 94303-4900 USA
650 960-1300
fax 650 969-9131
Part No.: 805-3682-10
Revision A, February 1998
Send comments about this document to: smcc-docs@sun.com
Advertisement
Table of Contents
Related Manuals for Sun Microsystems Sun StorEdge PCI FC-100
Summary of Contents for Sun Microsystems Sun StorEdge PCI FC-100
- Page 1 StorEdge ™ ™ PCI FC-100 Host Adapter Installation Manual Sun Microsystems Computer Company A Sun Microsystems, Inc. Business 901 San Antonio Road Palo Alto, CA 94303-4900 USA 650 960-1300 fax 650 969-9131 Part No.: 805-3682-10 Revision A, February 1998 Send comments about this document to: smcc-docs@sun.com...
- Page 2 Sun, Sun Microsystems, the Sun logo, AnswerBook, SunDocs, SunVTS, Sun Enterprise Network Array, StorEdge, and Solaris are trademarks, registered trademarks, or service marks of Sun Microsystems, Inc. in the U.S. and other countries. All SPARC trademarks are used under license and are trademarks or registered trademarks of SPARC International, Inc.
-
Page 3: Regulatory Compliance Statements
FCC radio frequency emission limits. Networking connections can be made using unshielded twisted-pair (UTP) cables. Modifications: Any modifications made to this device that are not approved by Sun Microsystems, Inc. may void the authority granted to the user by the FCC to operate this equipment. - Page 4 This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Sun StorEdge PCI FC-100 Host Adapter Installation Manual • February 1998...
-
Page 5: Safety Agency Compliance Statements
You must remove the cover of your Sun computer system Do not make mechanical or electrical modifications to the equipment. Sun Microsystems is not responsible for unit in order to add cards, memory, or internal storage devices. Be sure to replace the top cover before powering up regulatory compliance of a modified Sun product. - Page 6 Achtung – Gefährliche Spannungen. Anweisungen die Gefahr eines Stromschlags zu reduzieren, befolgen, um Stromschläge und Verletzungen zu schließen Sie das Kabel nur an eine fachgerecht vermeiden. verlegte, geerdete Steckdose an. Sun StorEdge PCI FC-100 Host Adapter Installation Manual • February 1998...
- Page 7 Ce texte traite des mesures de sécurité qu’il convient de Ne pas apporter de modification mécanique ou électrique au prendre pour l’installation d’un produit Sun Microsystems. matériel. Sun Microsystems n’est pas responsable de la Mesures de sécurité conformité réglementaire d’un produit Sun qui a été modifié.
- Page 8 Sun sans le couvercle en place. Si l’on néglige Encendido – Aplica la alimentación de CA al sistema. cette précaution, on encourt des risques de blessures corporelles et de dégâts matériels. viii Sun StorEdge PCI FC-100 Host Adapter Installation Manual • February 1998...
- Page 9 No realice modificaciones de tipo mecánico o eléctrico en el fuente de alimentación está diseñado para ser el equipo. Sun Microsystems no se hace responsable del elemento primario de desconexión del equipo. El cumplimiento de las normativas de seguridad en los equipos equipo debe instalarse cerca del enchufe de forma Sun modificados.
- Page 10 Sun StorEdge PCI FC-100 Host Adapter Installation Manual • February 1998...
-
Page 11: Declaration Of Conformity
Declaration of Conformity Marketing Part Numbers: 6729A, X6729A Product Name: Sun StorEdge PCI FC-100 Host Adapter This product has been tested and complies with: USA—FCC Class B This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. - Page 12 Sun StorEdge PCI FC-100 Host Adapter Installation Manual • February 1998...
-
Page 13: Table Of Contents
Contents Preface Installation Tools and Equipment Needed Preparing for Installation Installing the Host Adapter Testing the Installation With SunVTS A. Specifications A.1 PCI Card A.2 Fibre Channel Interface Specifications A.3 Performance Specifications A.4 Power Requirements A.5 Physical Dimensions A.6 Regulatory Compliance A.7 PCI Edge Connector Pin Definitions Contents xiii... - Page 14 Sun StorEdge PCI FC-100 Host Adapter Installation Manual • February 1998...
-
Page 15: Preface
Preface The Sun StorEdge PCI FC-100 Host Adapter Installation Manual describes how to install Sun™ StorEdge™ PCI FC-AL 33-MHz, 100 Mbytes/sec Host Adapters. These instructions are designed for an experienced system administrator or trained service provider. Using UNIX Commands ®... -
Page 16: Typographic Conventions
To delete a file, type rm filename. Shell Prompts Shell Prompts TABLE P-2 Shell Prompt C shell machine_name% C shell superuser machine_name# Bourne shell and Korn shell Bourne shell and Korn shell superuser Sun StorEdge PCI FC-100 Host Adapter Installation Manual • February 1998... -
Page 17: Related Documentation
Number 805-1903, for a list of related documentation Ordering Sun Documents SunDocs is a distribution program for Sun Microsystems technical documentation. Contact SunExpress for easy ordering and quick delivery. You can find a listing of available Sun documentation on the World Wide Web. - Page 18 We are interested in improving our documentation and welcome your comments and suggestions. You can email your comments to us at smcc-docs@sun.com. Please include the part number of your document in the subject line of your email. xviii Sun StorEdge PCI FC-100 Host Adapter Installation Manual • February 1998...
-
Page 19: Installation
C H A P T E R Installation This chapter describes how to install the Sun StorEdge PCI FC-100 Host Adapter in a system. Tools and Equipment Needed You may need to order fiber optic cables. You can order them in the following... -
Page 20: Preparing For Installation
Look at the /etc/release file and make sure the operating system installed is at least Solaris 2.6. If you don’t have an /etc/release file, you probably need to upgrade your operating system to at least Solaris 2.6. Sun StorEdge PCI FC-100 Host Adapter Installation Manual • February 1998... - Page 21 3. Get the required patches, if any. a. Go to the http://docs.sun.com web site. b. Go to the Storage & Peripherals section and read the Sun StorEdge A5000 Installation Supplement. c. Download the patches from: http://sunsolve.sun.com/sunsolve/pubpatches/patches.html Contact your support service provider if you cannot access these web sites. Note –...
- Page 22 For systems that have more than one system board, you must also select and remove a system board that has an available PCI slot. Refer to your system documentation for specific instructions. Sun StorEdge PCI FC-100 Host Adapter Installation Manual • February 1998...
-
Page 23: Installing The Host Adapter
1. Pull the two dust covers out of the gigabit interface converter (GBIC) connectors FIGURE 1-2 Dust covers GBIC connectors Sun StorEdge PCI FC-100 Host Adapter FIGURE 1-2 2. Install the host adapter in the PCI slot you have chosen. Installation details vary for each system. Refer to your system documentation for specific instructions. - Page 24 Note – If your system starts to reboot, interrupt the reboot process by pressing the Stop-A keys. The system should now be at the ok prompt. If a > prompt is showing, type switch to the ok prompt. Sun StorEdge PCI FC-100 Host Adapter Installation Manual • February 1998...
- Page 25 SEAGATE ST19171FCSUN9.0G10789735E83803 2100002037075302 SEAGATE ST19171FCSUN9.0G10789735E83720 In the example, is the Sun StorEdge PCI FC-100 Host pci@4,4000/SUNW,ifp@4 Adapter and the disks shown by using the show-children command are in a Sun StorEdge A5000 array (SENA). 9. Reboot your system using the boot -r command.
-
Page 26: Testing The Installation With Sunvts
5. Verify that no errors have occurred by checking the SunVTS status window. 6. If no problems occur, stop SunVTS. Your host adapter card is ready to run applications. Sun StorEdge PCI FC-100 Host Adapter Installation Manual • February 1998... -
Page 27: Specifications
A P P E N D I X Specifications PCI Card The Sun StorEdge PCI FC-100 Host Adapter is a single-loop Fibre Channel PCI card with an onboard gigabit interface converter (GBIC). This host adapter is PCI Version 2.1 compliant. -
Page 28: Performance Specifications
IDSEL ≤ 8pF FC-AL lnterface 1 Gbit optical (1.026 bits/sec) Power Requirements Power Requirements TABLE A-3 Specification Rating Power Requirements 5V ±5% 3.3V ±9% 130 mA Ripple 100 mV Sun StorEdge PCI FC-100 Host Adapter Installation Manual • February 1998... -
Page 29: Physical Dimensions
Physical Dimensions Physical Dimensions TABLE A-4 Height Width Depth Weight 4.2 inches 6.875 inches 3.6 oz .6 inches 15 mm 106.68 mm 174.63 mm 109g Regulatory Compliance Requirements Met or Exceeded by the Host Adapter TABLE A-5 Category Rating Safety UL 1950 CSA 950 TUV EN 60950... -
Page 30: Pci Edge Connector Pin Definitions
LOCK Reserved AD[37] PERR Ground +3.3V C/BE#[6] AD[35] SERR C/BE#[4] AD[33] +3.3V Ground Ground AD31 C_BE1 AD[63] Reserved AD29 AD14 AD[61] Reserved Ground AD27 AD12 AD[59] AD25 AD10 AD[57] Sun StorEdge PCI FC-100 Host Adapter Installation Manual • February 1998... - Page 31 PCI Edge Connector Pin Definitions (Bottom) TABLE A-7 Description Description Description Description TRST AD24 AD09 AD[56] +12V IDSEL KEYWAY AD[54] +3.3V KEYWAY AD22 C_BE0 AD[52] AD20 +3.3V AD[50] INTA AD06 Ground INTC AD18 AD04 AD[48] AD16 AD[46] RESERVED +3.3V AD02 Ground FRAME AD00...
- Page 32 Sun StorEdge PCI FC-100 Host Adapter Installation Manual • February 1998...
