- Page 1 PCI UltraSCSI Host Adapter Installation Guide Single-Ended and Differential Dual-Channel Models Sun Microsystems Computer Company A Sun Microsystems, Inc. Business 2550 Garcia Avenue Mountain View, CA 94043 USA 415 960-1300 fax 415 969-9131 Part No.: 805-1271-10 Revision A, June 1997...
- Page 2 Sun. Sun, Sun Microsystems, le logo Sun, SunOS, et Solaris sont des marques déposées ou enregistrées de Sun Microsystems, Inc. aux Etats-Unis et dans d’autres pays. Toutes les marques SPARC, utilisées sous licence, sont des marques déposées ou enregistrées de SPARC International, Inc.
- Page 3 FCC radio frequency emission limits. Networking connections can be made using unshielded twisted-pair (UTP) cables. Modifications: Any modifications made to this device that are not approved by Sun Microsystems, Inc. may void the authority granted to the user by the FCC to operate this equipment.
- Page 4 DOC Class A Notice - Avis DOC, Classe A This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. DOC Class B Notice - Avis DOC, Classe B This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
-
Page 5: Safety Precautions
Do not make mechanical or electrical modifications to the unit in order to add cards, memory, or internal storage equipment. Sun Microsystems is not responsible for devices. Be sure to replace the top cover before powering up regulatory compliance of a modified Sun product. - Page 6 Installation von Sun-Produkten zu beachten sind. Sicherheitsvorkehrungen Nehmen Sie keine mechanischen oder elektrischen Änderungen an den Geräten vor. Sun Microsystems, Treffen Sie zu Ihrem eigenen Schutz die folgenden übernimmt bei einem Sun-Produkt, das geändert wurde, Sicherheitsvorkehrungen, wenn Sie Ihr Gerät installieren: keine Verantwortung für die Einhaltung behördlicher...
- Page 7 Conformité aux normes de sécurité Ne pas apporter de modification mécanique ou électrique au matériel. Sun Microsystems n’est pas responsable de la Ce texte traite des mesures de sécurité qu’il convient de conformité réglementaire d’un produit Sun qui a été modifié.
- Page 8 Modificaciones en el equipo corporelles et de dégâts matériels. No realice modificaciones de tipo mecánico o eléctrico en el equipo. Sun Microsystems no se hace responsable del cumplimiento de las normativas de seguridad en los equipos Normativas de seguridad Sun modificados.
- Page 9 Conexión del cable de alimentación eléctrica Precaución – Los productos Sun están diseñados para trabajar en una red eléctrica monofásica con toma de tierra. Para reducir el riesgo de descarga eléctrica, no conecte los productos Sun a otro tipo de sistema de alimentación eléctrica.
- Page 10 PCI UltraSCSI Host Adapter Installation Guide • June 1997...
-
Page 11: Declaration Of Conformity
X6540A, X6541A, and X6600A Product Names: Dual-Channel UltraSCSI PCI Host Adapters and associated kits, Single-Ended and Differential. USA – FCC Class B This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. - Page 12 PCI UltraSCSI Host Adapter Installation Guide • June 1997...
-
Page 13: Table Of Contents
To Test the Installation With SunVTS 5 A. Understanding UltraSCSI 7 Target Devices 7 Bus Length 8 Cabling and Termination 9 B. Specifications (Single-Ended) 11 Physical Dimensions 11 Power Requirements 12 Performance Specifications 12 PCI Edge Connector Pin Definitions 13... - Page 14 C. Specifications (Differential) 17 Physical Dimensions 17 Power Requirements 18 Performance Specifications 18 PCI Edge Connector Pin Definitions 19 SCSI Connector Pin Definitions 21 PCI UltraSCSI Host Adapter Installation Guide • June 1997...
- Page 15 Tables Bus Restrictions 8 TABLE A-1 Physical Dimensions 11 TABLE B-1 Power Requirements 12 TABLE B-2 Performance Specifications 12 TABLE B-3 PCI Edge Connector Pin Definitions J1B (Top) 13 TABLE B-4 PCI Edge Connector Pin Definitions J1A (Bottom) 14 TABLE B-5 SCSI Connector Pin Definitions 15 TABLE B-6 Physical Dimensions 17...
- Page 16 PCI UltraSCSI Host Adapter Installation Guide • June 1997...
-
Page 17: Preface
Preface The PCI UltraSCSI Host Adapter Installation Guide provides information about PCI single-ended and differential dual-channel UltraSCSI host adapter cards. Using UNIX Commands ® This document does not contain information on basic UNIX commands and procedures such as shutting down the system, booting the system, and configuring devices. - Page 18 Typographic Conventions Typographic Conventions TABLE P-1 Typeface or Symbol Meaning Examples The names of commands, files, Edit your .login file. AaBbCc123 and directories; on-screen Use ls -a to list all files. computer output. % You have mail. What you type, when AaBbCc123 contrasted with on-screen Password:...
- Page 19 Ordering Sun Documents SunDocs is a distribution program for Sun Microsystems technical documentation. Contact SunExpress for easy ordering and quick delivery. You can find a listing of available Sun documentation on the World Wide Web. SunExpress Contact Information TABLE P-3...
- Page 20 PCI UltraSCSI Host Adapter Installation Guide • June 1997...
-
Page 21: Installing The Host Adapter
Overview The single-ended and differential host adapters are UltraSCSI devices that enable you to increase the available number of SCSI ports for adding external devices. The host adapters are designed to be installed in SPARC™ systems running at least Solaris 2.5.1 Hardware:4/97 operating system. -
Page 22: Installing The Host Adapter
Installing the Host Adapter Read these instructions and the installation instructions in your system documentation before installing the host adapter. To Prepare for Installation 1. Determine which version of the operating system you are running. Look at the /etc/release file and make sure the operating system installed is at least Solaris 2.5.1 Hardware: 4/97. -
Page 23: To Install The Host Adapter
Note – A single-ended host adapter is shown in . There are slight FIGURE 1-1 variations in components between the single-ended and differential host adapters. To Install the Host Adapter 1. Open the system. Refer to your system documentation for information about filler panels for your system. - Page 24 6. Make sure that the switches and jumpers are correctly set. For the single-ended host adapter, confirm the following settings: Make sure that all elements of switches U1 and U2 are off. Make sure that jumper TP9 is open. For the differential host adapter, confirm the following settings: Make sure that all jumpers (TP1, TP2, TP3, TP5, TP6) are open.
-
Page 25: To Test The Installation With Sunvts
14. Reboot your system using the boot -r command. For more information on the boot -r command, refer to the System Administrator’s Guide for your operating system. To Test the Installation With SunVTS SunVTS is a diagnostic program that exercises your system to verify the functionality, reliability, and configuration of your host adapter card. - Page 26 PCI UltraSCSI Host Adapter Installation Guide • June 1997...
-
Page 27: Understanding Ultrascsi
A P P E N D I X Understanding UltraSCSI This chapter provides general information about UltraSCSI configuration rules. Target Devices For UltraSCSI performance of 40 Mbytes/sec, there can be a maximum of seven devices connected to each port on the host adapter card. Up to 15 devices can be connected to each port on the host adapter card at 20 Mbytes/sec. -
Page 28: Bus Length
Differential Host Adapter The differential host adapter can support up to 15 devices per port on a SCSI bus length of 24 meters (78.74 feet). Single-Ended Host Adapter For UltraSCSI performance, you must adhere to the following cable length restrictions: For 1 to 3 devices, the maximum bus length per port is 3 meters (9.84 feet) -
Page 29: Cabling And Termination
Cabling and Termination Use the following cabling guidelines to ensure proper device cabling and termination: In order to maintain UltraSCSI performance, all cables used must be UltraSCSI compliant. The SCSI bus must be correctly terminated. Most Sun devices use autotermination. See the documentation that came with the device. If external mass storage devices consist of 68-pin devices and 50-pin devices, connect the 68-pin devices to the system first and terminate the chain with a 50-pin device and its terminator. - Page 30 PCI UltraSCSI Host Adapter Installation Guide • June 1997...
-
Page 31: Specifications (Single-Ended)
A P P E N D I X Specifications (Single-Ended) The chapter contains the specifications for the single-ended host adapter. Physical Dimensions Physical Dimensions TABLE B-1 Dimension Measurement Board With Bracket Board Without Bracket Length 8 inches (203.2 mm) 7.5 inches (190.5 mm) Width 4.81 inches (122.17 mm) -
Page 32: Power Requirements
Capacitance per PCI signal line <= 10 pF, except for CLK between 5 to 12 pF and IDSEL <= 8 pF SCSI interface Single-ended SCSI bus parity SCSI 8-bit bus devices SCSI 16-bit bus devices PCI UltraSCSI Host Adapter Installation Guide • June 1997... -
Page 33: Pci Edge Connector Pin Definitions
AD10 INTB INTD AD21 KEYWAY GND (PRSNT1) AD19 KEYWAY RESERVED +3.3V AD08 GND (PRSNT2) AD17 AD07 KEYWAY C_BE2 +3.3V KEYWAY AD05 RESERVED IRDY AD03 +3.3V DEVSEL AD01 3V/5V LOCK ACK64 3V/5V PERR AD31 +3.3V AD29 SERR Appendix B Specifications (Single-Ended) - Page 34 PCI Edge Connector Pin Definitions J1A (Bottom) TABLE B-5 Description Description Description TRST AD28 +12V AD26 AD15 +3.3V AD24 AD13 IDSEL AD11 INTA +3.3V INTC AD22 AD09 AD20 KEYWAY RESERVED KEYWAY 3V/5V AD18 C_BE0 AD16 RESERVED +3.3V KEYWAY +3.3V AD06 KEYWAY FRAME AD04...
-
Page 35: Scsi Connector Pin Definitions
VHDCI and Internal SCSI Connectors FIGURE B-1 SCSI Connector Pin Definitions TABLE B-6 Description Description Description SD(7)- SDP- Cable Sense (GND) TERMPWR TERMPWR OPEN ATN- Cable Sense (GND) BSY- SD(12)- ACK- SD(13)- RST- SD(14)- MSG- SP(15)- SEL- SDP(1)- C/D- Appendix B Specifications (Single-Ended) -
Page 36: Table
SCSI Connector Pin Definitions (Continued) TABLE B-6 Description Description Description TERMPWR SD(0)- REQ- TERMPWR SD(1)- I/O- OPEN SD(2)- SD(8)- SD(3)- SD(9)- SD(4)- SD(10)- SD(5)- SD(11)- SD(6)- PCI UltraSCSI Host Adapter Installation Guide • June 1997... - Page 37 A P P E N D I X Specifications (Differential) The chapter contains the specifications for the wide differential host adapter. Physical Dimensions Physical Dimensions TABLE B-1 Dimension Measurement Board With Bracket Board Without Bracket Length 8 inches (203.2 mm) 7.5 inches (190.5 mm) Width 4.81 inches (122.17 mm)
-
Page 38: Table B-2 Power Requirements
Power Requirements Power Requirements TABLE B-2 Voltage Maximum Current 5V ±5% 3.3V ±9% 130 ma 12V ±5% 0.05A Performance Specifications Performance Specifications TABLE B-3 Feature Specification PCI clock 33 MHz maximum PCI data burst transfer rate 132 Mbytes/sec burst rate SCSI synchronous transfer rate 40 Mbytes/sec (wide) SCSI asynchronous transfer rate... -
Page 39: Table B-4 Pci Edge Connector Pin Definitions J1B (Top)
PCI Edge Connector Pin Definitions PCI Edge Connector Pin Definitions J1B (Top) TABLE B-4 Description Description Description -12V +3.3V AD27 C_BE1 AD25 AD14 +3.3V C_BE3 AD12 AD23 AD10 INTB INTD AD21 KEYWAY GND (PRSNT1) AD19 KEYWAY RESERVED +3.3V AD08 AD17 GND (PRSNT2) AD07 KEYWAY... -
Page 40: Table B-5 Pci Edge Connector Pin Definitions J1A (Bottom)
PCI Edge Connector Pin Definitions J1A (Bottom) TABLE B-5 Description Description Description TRST AD28 +12V AD26 AD15 +3.3V AD24 AD13 IDSEL AD11 INTA +3.3V INTC AD22 AD09 AD20 KEYWAY RESERVED KEYWAY 3V/5V AD18 C_BE0 AD16 RESERVED +3.3V KEYWAY +3.3V AD06 KEYWAY FRAME AD04... -
Page 41: Table B-6 Scsi Connector Pin Definitions
SCSI Connector Pin Definitions VHDCI Connector Internal SCSI Connector VHDCI and Internal SCSI Connectors FIGURE B-1 SCSI Connector Pin Definitions TABLE B-6 Description Description Description +SD(12) +RST SD(6)- +SD(13) +MSG SD(7)- +SD(14) +SEL SDP- +SD(15) +C/D Cable Sense (GND) +SDP(1) +REQ TERMPWR +I/O... - Page 42 SCSI Connector Pin Definitions TABLE B-6 Description Description Description TERMPWR SD(0)- OPEN SD(1)- SD(8)- +ATN SD(2)- SD(9)- SD(3)- SD(10)- +BSY SD(4)- SD(11)- +ACK SD(5)- PCI UltraSCSI Host Adapter Installation Guide • June 1997...
-
Page 43: Table C-1 Physical Dimensions
Ordering Sun Documents SunDocs is a distribution program for technical documentation and is available from SunExpress. To order or for more information: Country Phone Country Phone Belgium 02-72-09-09 02-72-88-50 Luxembourg 32-2-72-09-09 32-2-725-88-50 Canada 1-80-873-7869 1-80-944-0661 Sweden 020-79-57-26 020-79-57-27 France 0800-90-61-57 080-90-61-58 Switzerland 0800-55-19-26... -
Page 44: Table C-2 Power Requirements
IF MAILED TO THE UNITED STATES INTERNATIONAL BUSINESS REPLY MAIL/RESPONSE PAYEE PERMIT NO. 808 MOUNTAIN VIEW CA POSTAGE WILL BE PAID BY ADDRESSEE INFORMATION PRODUCTS M/S MPK14-108 SUN MICROSYSTEMS INC 2550 GARCIA AVE MOUNTAIN VIEW CA 94043-9551 UNITED STATES OF AMERICA...
