Quick Start Guide – Synexis
Synexis RP Beltpack Receiver
Headphone socket, mini jack (3.5 mm)
LED to display operation or charging status (refer to the Synexis charger manuals)
On/off and volume control
Set button
Charging contacts
Lid of the battery compartment
Belt clip
Channel selector buttons
OLED display
Mounting for strap
Battery compartment for two 1.5 V batteries or rechargeable NiMH-batteries
Operating instructions for Synexis RP beltpack receiver
1. Connect a beyerdynamic headphone with mono or stereo mini jack plug to
the headphone socket .
2. Switch on the beltpack receiver by turning the control
right.
3. The LED will illuminate:
blue, when a transmitter is turned on and reception available.
red, when there is no transmitter turned on or no reception available.
4. Use the control to set the requested volume by turning it more clockwise.
Important: Do not set the volume too high, because listening at a high
volume can damage your hearing.
5. The selected channel and the battery status are displayed
the receiver is operated on the same channel as the transmitter. To select a
different channel use one of the two channel selector buttons
release the channel selector button
stored after approx. 3 seconds. If you would like to lock the selected channel
to avoid accidental shifting, hold down the Set button
A key symbol will be displayed
unlock a locked channel, hold down the Set button
The key symbol in the display
6. After use, switch off the receiver by turning the control
LED will go out.
7. If the battery status displays only one bar
or replace the alkaline batteries as soon as possible. If the receiver is equipped
with rechargeable NiMH batteries, turn it off and put it into the appropriate
charger (e.g. Synexis C8 or C10). The LED
LED is flashing blue . . . . . . . . . . . . . . The batteries are being charged
LED illuminates blue . . . . . . . . . . . . . The batteries are fully charged
LED is flashing red . . . . . . . . . . . . . . . Error
beyerdynamic GmbH & Co. KG | Theresienstr. 8 | 74072 Heilbronn – Germany | Tel. +49 (0)7131 / 617-400 | conference@beyerdynamic.de | www.beyerdynamic.com | For further distributors worldwide, please go to www.beyerdynamic.com
clockwise to the
. Make sure that
, the channel will automatically be
for about 3 seconds.
. The channel is locked. If you would like to
for about 3 seconds.
will disappear.
anti-clockwise. The
, you should recharge the receiver
indicates the charging status:
E1/PI Synexis Quick Start Guide (07.12)/634.840 • Non-contractual illustrations. Contents subject to change without notice.
Accessories for Synexis RP Beltpack Receiver
DT 1 (Order # 724.521)
• Particularly suitable for the frequent
use in factory tours, tourism, museums
and whenever it is important to hear
acoustic warning signals.
• With elastic ear piece for different
ear sizes.
• Can be worn on the left or right ear.
• 32 ohms.
• Cable length 90 cm [35.43"].
• With mini stereo jack plug (3.5 mm).
DT 2 (Order # 484.679)
• Particularly suitable for the use in
interpretation applications, factory
tours, with loud environmental noise
and whenever binaural listening is
requested.
• With adjustable headband.
• 32 ohms.
• Cable length 80 cm [31.5"].
• With mini stereo jack plug (3.5 mm).
DT 3 (Order # 484.571)
• Suitable for the same applications as
DT 2, but due to neckband especially
for applications where it is required
to wear a helmet.
• 32 ohms.
• Cable length 80 cm [31.5"].
• With mini stereo jack plug (3.5 mm).
DT 4 (Order # 724.548)
• Minimum-cost disposable earphones
for all applications regarding guided
tours; especially when taking back
and cleaning are to be avoided; can
be kept as a souvenir.
• 32 ohms.
• Cable length 90 cm [35.43"].
• With mini stereo jack plug (3.5 mm).
. If you
Synexis IL 100 (Order # 722.944)
• Induction loop for Synexis RP
beltpack receiver
• For people who are wearing
hearing aids.
• Cable length 100 cm [39.37"].
• With mini stereo jack plug (3.5 mm).
