BEDIENUNGSANLEITUNG
OPERATING INSTRUCTIONS
NOTICE D'UTILISATION
Opus 500
Drahtloses UHF-System
Wireless UHF System
Système sans fil UHF

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Opus 500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Beyerdynamic Opus 500

Summary of Contents for Beyerdynamic Opus 500

  • Page 1 BEDIENUNGSANLEITUNG OPERATING INSTRUCTIONS NOTICE D’UTILISATION Opus 500 Drahtloses UHF-System Wireless UHF System Système sans fil UHF...

  • Page 2: Table Of Contents

    Konformitätserklärung ....Seite 75 OPERATING INSTRUCTIONS Opus 500 NE 500 Diversity Receiver ....Page 27 ZAS 500 Antenna Splitter .

  • Page 3: Operating Instructions Opus 500

    OPERATING INSTRUCTIONS OPUS 500 Thank you for selecting the Opus 500 wireless system in PLL synthesised technology. Please take some time to read carefully through this manual before setting up the equipment. Important: • When you unpack the devices, inspect them for transport damage. If you do find transport damage, notify the transportation company without delay.
  • Page 4 6. Adjust the output level (8) of the receiver depending on the connected mixing console or amplifier. Rule of thumb: Microphone level - fully anti-clockwise Line level - fully clockwise 7. Switch the NE 500 on (1). The following indications will appear: beyerdynamic NE 500 V x.xx 806.900 MHz [06] Squelch 8µV (example) You can display this indication (2.) any time by pressing the left button (3).
  • Page 5 If there is a transmitter switched on and somebody speaks into the microphone, the following default screen appears on the display (2): CH06 IIIIIIIIIIII IIIIIIIIIIIIIII 1.3.1 Diversity Indication of the Receiving Channel The NE 500 has two separate receiving circuits for each of the antennae. The signal with the better S/N ratio is switched to the output.
  • Page 6 1.3.5 Choosing another frequency Press the left and right button simultaneously: SELECT MENU FREQ MORE Press the left button once again. The following indication appears: FREQUENCY SELECT 806.900 MHz [06] Choose the new frequency by pressing the left (descending) or the right (ascending) button. To store the new frequency press the two buttons simultaneously.
  • Page 7 1.3.7 RF-indication (RF-meter) With this function you can check the receiving antennae and find out the optimum antenna positions. Press the left and right button simultaneously: SELECT MENU FREQ MORE Press the right button two times. The following indication appears: SELECT MENU RF-METER MORE...
  • Page 8 Press the right button three times. The following indication appears: SELECT MENU LOCK MORE Press the left button. The following indication appears: FREQ. UNLOCKED LOCK MORE For locking the frequency selection press the left button. The following indication appears: FREQ. LOCKED UNLOCK MORE Locking the Squelch Function...
  • Page 9 For locking the audio mute function press the left button. The following indication appears: MUTE LOCKED UNLOCK MORE For storing all lock functions press the left and right button simultaneously. If one of these locked functions is called, the following indication appears: FUNCTION LOCKED Release of the locked functions...
  • Page 10 Connecting and Positioning of remote Antennae In multichannel systems we recommend the use of the GPA 700 groundplane antennae in conjunction with the ZAF 500 N antenna connection panel and low attenuation antenna cables such as AVK N(HF)-N(HF) (LA). For mounting the antenna use the AMK 700 mounting device (on top 3/8"...

  • Page 11: Zas 500 Antenna Splitter

    4. If the operating range of the transmitters is greater than the stage, the antennae can be mounted vertically on the ceiling. The distance between the two GPA 700 receiving antennae should be approximately half the total operating range. Operating range Stage Please note: 1.
  • Page 12 The ZAS 500 antenna splitter can be cascaded. With two ZAS 500 you can operate 7 receivers, with three ZAS 500 then 10 receivers. For operation of more than 10 channels please contact beyerdynamic. 19" Rack Mounting One NE 500 receiver and ZAF 500 N antenna connecting panel:...
  • Page 13 One NE 500 receiver and one ZBP blank panel: ZTE 500 AF -40 +6 dB N E 5 0 0 U H F R e c e i v e r Z B P 5 0 0 M e n u P o w e r RF 10 1000 µV...

  • Page 14: Sem 581 / Sdm 569 Handheld Transmitters

    SDM 569 / SEM 581 Handheld Transmitters Controls and Indicators SEM 581 Microphone head (fixed) Battery compartment (Frequency table) SDM 569 or SEM 581 type description Sensitivity switch (3 stages) Channel selector control (16 frequencies) ON/OFF-switch LED power indicator (green)
  • Page 15 Setting up 1. Open the battery compartment (2) as indicated in the illustration and insert a 9 volt alkaline battery or a suitable rechargeable battery. 2. Switch on the handheld transmitter (6). The LED power indicator (7) is illuminated. 3. To change the frequency, turn the channel selector control (5) with a suitable screwdriver or trim tool until the control points to the desired frequency.

  • Page 16: Ts 500 Beltpack Transmitter

    TS 500 Beltpack Transmitter Controls and Indicators (top view) PEAK HIGH INPUT LEVEL POWER (rear view) (front view) BATTERY ACCESS 798.000 813.775 800.650 10 814.850 801.950 11 815.400 803.050 12 817.925 803.550 13 821.800 806.900 14 825.150 809.100 15 827.700 811.025 16 828.925 1 Lemo socket (4-pin) connection for microphones,...
  • Page 17 Setting up 1. Open the battery compartment (10) as indicated by the arrows and insert a 9 V alkaline battery observing the polarity +/- marks. 2. Instead of alkaline batteries you can also use V 7/8 H type rechargeable batteries. The SLG 44/500 charging unit can be used for charging this type of battery whilst still fitted in the transmitter.

  • Page 18: General Instructions For All Transmitters

    Please note: • Switch the TS 500 beltpack transmitter off before recharging or changing the battery. (ON/OFF switch (5) in position OFF). • Never put the TS 500 beltpack transmitter in the charging unit with a standard battery in it. The battery could explode and destroy the beltpack transmitter. •...

  • Page 19: Trouble Shooting

    Before the Soundcheck 1. Check the transmitter battery and replace or recharge it if necessary. Use fresh alkaline batteries only. 2. Adjust the level of the receiver to the amplifier or mixing console. 3. Check the performance area for dropouts. If you find any dropouts, try to eliminate them by repositioning the antennae or the receiver.
  • Page 20 1.3.8) Indication: • Frequency cannot be used any longer • Choose another frequency or consult „RECEIVER ERROR - • Disturbances due to RF-interference your beyerdynamic dealer CHANGE FREQUENCY“ SDM 569 / SEM 581, TS 500 Transmitters Problem Cause Solution No function •...

  • Page 21: Maintenance

    In most countries around the world, wireless systems must be approved for use by the authorities and it may be necessary to obtain a licence to use it legally. Your local beyerdynamic dealer will be able to give you details on wireless system regulations for your area.

  • Page 22: Optional Accessories

    9. Optional Accessories NE 500 Diversity Receiver Antenna splitter A-NCW/58 BNC True resistance, 50  ......Order # 376.736 ZAS 500 Antenna splitter for 4 NE 500 receivers, incl.

  • Page 23: Technical Specifications

    TS 500 Beltpack Transmitter Microphones HEM 194.16 Headworn microphone (cardioid) ....Order # 450.634 MCE 5.16 Condenser Clip-On-Microphone (omnidirectional) ..Order # 420.662 MCE 7.16 BLK Condenser Clip-On-Microphone (omnidirectional), black .
  • Page 24 ZAS 500 Antenna Splitter Inputs ..... . 2 (BNC) Outputs ....2 x 4 (BNC) Frequency range .
  • Page 25 Nominal deviation ... . 50 kHz Radiated transmitter power..max. 50 mW (output power) Compander system... . LN compander S/N ratio .

  • Page 26: Declaration Of Conformity

    Type of Equipment: Wireless Microphone System Model Numbers: SDM 569, SEM 581, TS 500 I, the undersigned, as an employee of beyerdynamic, hereby declare that the equipment specified conforms to the above Directive and Standards. Manufacturer’s Signature: Date: 1. January, 2001...
  • Page 27 Garantie Dans les pays de la CE (CEE) beyerdynamic garantit les appareils qui y ont été achetés. La prestation de garantie comprend le matéri- al et la main-d’œuvre pendant au moins 12 mois à dater de l’achat. Par ailleurs, les prestations de garantie sont accordées selon les prescriptions légales du pays concerné.
