Configure
3) Numeric DHCP name. You are able to change the DHCP name by specifying the last octet of the IP
address. When you use this method, the DHCP name will be LTXYY where YY is what you chose for the
last octet of the IP address. If the IP address you specify is 0.0.0.12, then the DHCP name will be LTX12.
This method will only work with 2 digit numbers (0-99).

3.13 Channel 1 Configuration (Serial Port Parameters)

This section describes how to setup the serial port. The following parameters are displayed when you select
Channel 1 (Option 1).

Baudrate (9600)

I/F Mode (4C)
Flow (00)
Port No (10001)
ConnectMode (C0)
Send '+++' in Modem Mode
Auto increment source port (N) ?
Show IP addr after 'RING' enabled
Remote IP Address : (000).(000).(000).(000)
Remote Port (00000)
DisConnMode (00)
FlushMode
DisConnTime (00:00) :
SendChar 1
SendChar 2
3.13.1 Baudrate
The unit and attached serial device, such as a modem, must agree on a speed or baud rate to use for the
serial connection. Valid baud rates are 300, 600, 1200, 2400, 4800, 9600 (default), 19200, 38400, 57600,
115200, and 230400 bits per second. XPort-03 and greater units also support high-performance baud rates
of 460800 and 921600 bps. See Expert Settings on page 3-33.

3.13.2 I/F (Interface) Mode

The Interface (I/F) Mode is a bit-coded byte that you enter in hexadecimal notation.

Table 7 - Interface Mode Options

I/F Mode Option
(1)
RS-232C
RS-422/485
RS-485 2-wire
7 Bit
8 Bit
No Parity
Even Parity
Odd Parity
1 Stop bit
(1)
2 Stop bit
(1) 2 stop bits are implemented by software. This might have influence on performance.
Note: RS-422/485 I/F Modes are supported on XPort-03 with firmware 6.1.0.0 and above.
3-20
(Y) ?
(00)
(00)
(00)
7 6 5 4 3
1
1
0 0
1 1
0 1
0 1
1 1
2 1 0
0 0
0 1
1 1
0
1
NET232/NETUSB User Guide
