3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.

3.6.4 Connection Settings - TCP

To configure a channel's TCP settings:
1. On the main menu, click Connection. The Connection Settings window for the channel displays.
2. In the available fields, enter or modify the following information:
Connect Protocol
Protocol
Connect Mode: Active Connection
Active Connect
Endpoint Configuration
Local Port
Remote Port
Remote Host
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.
3-10
From the drop-down menu, select TCP.
- With Any Character: Attempts to connect when any character is
received from the serial port.
- Auto Start: Automatically connects to the remote IP address and port
after booting up.
Enter the local port number. The default setting is 10001. This works for
most applications.
Enter the remote port number. If you are connecting two NET232
devices in Tunnel Mode, enter the remote port of the other device here.
The other device can also use port 10001.
Enter the IP address of the remote device. If you are connecting two
NET232 devices in Tunnel Mode, enter the remote IP address of the
other device here.
