Monitor Mode

Table 18 - Monitor Mode Commands

Command Command Name
VS x.x.x.x Version
GC x.x.x.x Get Configuration
SC x.x.x.x Send Configuration
(CAUTION)
PI x.x.x.x Ping
AT ARP Table
TT TCP Connection
Table
NC Network Connection
RS Reset
QU Quit
G0, G1,...,Ge, Get configuration
Gf from memory page
S0, S1,...,Se, Set configuration to
Sf memory page
GM Get MAC address
SS Set Security record
Responses to some of the commands are given in Intel Hex format.
Note: Entering any of the commands listed above will generate one of the following command response codes:

Table 19 -Command Response Codes

Response Meaning
0> OK; no error
1> No answer from remote device
2> Cannot reach remote device or no
answer
8> Wrong parameter(s)
9> Invalid command
6-2
Function
Query software header record (16 bytes) of unit with (opt) IP
address x.x.x.x
Get configuration of unit with (opt) IP address x.x.x.x as hex
records (120 bytes)
Set configuration of unit with (opt) IP address x.x.x.x from
hex records
Pings unit with IP address x.x.x.x to check device status
Show the unit's ARP table entries
Shows all incoming and outgoing TCP connections
Shows the unit's IP configuration
Resets the unit's power
Exit diagnostics mode
Gets a memory page of configuration information from the
device.
Sets a memory page of configuration information on the
device.
Shows the unit's 6-byte MAC address.
Sets the Security record without the encryption key and
length parameters. The entire record must still be written,
but the encryption-specific bytes do not need to be provided
(they can be null since they are not overwritten).
