Overview

2.11 Technical Specifications

Table 4 - Technical Specs

Category
CPU
Firmware
Reset Circuit
Serial Interface
USB
Serial Line Formats
Modem Control
Flow Control
Network Interface
Compatibility
Protocols Supported
LEDs
Management
Security
Internal Web Server
Weight
Material
Temperature
Relative Humidity
Warranty
Included Software
EMI Compliance
2-8
Description
DSTni-EX 186 CPU
Upgradeable via TFTP and serial port
200msec power up/down reset pulse. Reset triggered at 3.08V
RS232. Baudrate software selectable (300 to 230400bps in standard mode, 460800 and
921600 in high performance mode)
USB Type A Male connector. USB Specification 2.0 Compliant, Full Speed (12Mbps).
Baud rates: 300bps to 921.6Kbps.
512 Byte Receive Buffer, 512 Byte Transmit Buffer.
Virtual COM Port Device Drivers for Win 98/2000/XP, Win CE, Linux 2.40
7 or 8 data bits, 1-2 Stop bits, Parity: odd, even, none
CTS, RTS
XON/XOFF (software), CTS/RTS (hardware), None
RJ45 Ethernet 10Base-T or 100Base-TX (Auto-sensing)
Ethernet: Version 2.0/IEEE 802.3
ARP, UDP/IP, TCP/IP, Telnet, ICMP, SNMP, DHCP, BOOTP, TFTP, Auto IP, SMTP,
and HTTP
10Base-T & 100Base-TX Activity, Full/half duplex.
Internal web server, SNMP (read only)
Serial login, Telnet login
Password protection, Locking features, optional Rijndael 128-bit encryption
Serves static web pages and Java applets
2.2oz
Case: Flame Retardant
Operating range: -40°C to +85°C (-40°F to 185°F) High performance mode has an
upper temperature limit of 75°C.
Operating: 5% to 95% non-condensing
1-year limited warranty
Windows™ 98/NT/2000/XP based Device Installer configuration software, Windows™
based Comm Port Redirector and USB device drivers.
Radiated & conducted emissions - complies with Class B limits of EN 55022:1998
Direct & Indirect ESD - complies with EN55024:1998
RF Electromagnetic Field Immunity - complies with EN55024:1998
Electrical Fast Transient/Burst Immunity - complies with EN55024:1998
Power Frequency Magnetic Field Immunity - complies with EN55024:1998
RF Common Mode Conducted Susceptibility - complies with EN55024:1998
NET232/NETUSB User Guide
