3) Numeric DHCP name. You are able to change the DHCP name by specifying the last octet of the IP
address. When you use this method, the DHCP name will be LTXYY where YY is what you chose for the
last octet of the IP address. If the IP address you specify is 0.0.0.12, then the DHCP name will be LTX12.
This method will only work with 2 digit numbers (0-99).

3.6.7 Enable DHCP FQDN option

FQDN is the fully qualified domain name of the remote host
Dynamic update enables a DHCP server to register address (A) and pointer (PTR) resource records on
behalf of a DHCP client by using DHCP Client FQDN option 81. Option 81 enables the DHCP client to
provide its FQDN to the DHCP server. The DHCP client also provides instructions to the DHCP server
describing how to process DNS dynamic updates on behalf of the DHCP client.

3.7 Channel 1 Configuration (Serial Port Parameters)

This section describes how to setup the serial port. The following parameters are displayed when you select
Channel 1 (Option 1).

Baudrate (9600)

I/F Mode (4C)
Flow (00)
Port No (10001)
ConnectMode (C0)
Send '+++' in Modem Mode
Show IP addr after 'RING'
Auto increment source port (N) ?
Remote IP Address : (000).(000).(000).(000)
Remote Port (00000)
DisConnMode (00)
FlushMode
DisConnTime (00:00) :
SendChar 1
SendChar 2
3.7.1 Baudrate
The unit and attached serial device, such as a modem, must agree on a speed or baud rate to use for the
serial connection. Valid baud rates are 300, 600, 1200, 2400, 4800, 9600 (default), 19200, 38400, 57600,
115200, and 230400 bits per second. XPort-03 and greater units also support high-performance baud rates
of 460800 and 921600 bps.
NET485 User Guide
(Y) ?
(Y) ?
(00)
(00)
(00)
Device Installer
3-11
