PN: 53040:A
ECN 07-072
Deluge • Preaction Control
MRP-2001 & MRP-2001E
Installation, Operation and Programming Manual
Document
#53040
A
4/16/07
Revision:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MRP-2001E and is the answer not in the manual?

Questions and answers

Summary of Contents for Fire-Lite Alarms MRP-2001E

  • Page 1 PN: 53040:A ECN 07-072 Deluge • Preaction Control MRP-2001 & MRP-2001E Installation, Operation and Programming Manual Document #53040 4/16/07 Revision:...

  • Page 2: Fire Alarm System Limitations

    While a fire alarm system may lower insurance Fire Alarm System Limitations rates, it is not a substitute for fire insurance! An automatic fire alarm system–typically made up of age of flammable materials, etc.). smoke detectors, heat detectors, manual pull stations, Heat detectors do not sense particles of combustion and audible warning devices, and a fire alarm control panel with alarm only when heat on their sensors increases at a...

  • Page 3: Installation Precautions

    Adherence to the following will aid in problem-free Installation Precautions installation with long-term reliability: WARNING - Several different sources of power can be Like all solid state electronic devices, this system may connected to the fire alarm control panel. Disconnect all operate erratically or can be damaged when subjected to sources of power before servicing.

  • Page 4: Table Of Contents

    2.7.8.4 ANN-LED Connection to FACP ....................43 2.7.9: ANN-RLY Relay Module........................44 2.7.9.1 ANN-RLY Board Layout ......................44 2.7.9.2 Specifications ..........................44 2.7.9.3 Mounting/Installation ......................44 2.7.9.4 ANN-RLY Connection to FACP ....................45 SECTION 3: Programming ..........................46 3.1: User Programming............................46 MRP-2001 & MRP-2001E P/N: 53040:A 4/16/07...
  • Page 5 3.6: Maintenance Programming Level .......................81 3.6.1: Input Zones - Enable/Disable......................82 3.6.2: History...............................82 3.6.3: Walktest.............................83 3.6.4: Time-Date............................84 SECTION 4: Operating Instructions ........................85 4.1: Panel Control Buttons ..........................85 4.1.1: Acknowledge/Step ..........................85 4.1.2: Alarm Silenced..........................85 4.1.3: Drill/Hold 2 Sec ..........................85 MRP-2001 & MRP-2001E P/N: 53040:A 4/16/07...
  • Page 6 B.2: Template 8: Single Hazard - Cross-Zone With Manual Release ..............110 B.3: Template 9: Dual Hazard - Combined Release ..................111 B.4: Template 10: Dual Hazard - Split Release ....................112 B.5: Template 11: Single Hazard - 3 Zones and Low Pressure ................113 MRP-2001 & MRP-2001E P/N: 53040:A 4/16/07...
  • Page 7 Connection to FACP Dry Contacts ......................122 APPENDIX D: FACP with Keltron ........................123 APPENDIX E: Testing & Maintenance ......................124 E.1: Testing ...............................124 E.1.1: Inspection ............................124 E.1.2: Alarm Test ............................124 5.4.3: Detector Testing ..........................124 E.2: Maintenance ...............................125 MRP-2001 & MRP-2001E P/N: 53040:A 4/16/07...
  • Page 8 Notes MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 9 Alarm Systems, UL 864, 9th Edition. Operation of this product with products not tested for UL 864, 9th Edition has not been evaluated. Such operation requires the approval of the local Authority Having Jurisdiction (AHJ). MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 10 Main Circuit Board MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 11: Section 1: Product Description

    The MRP-2001E offers the same features as the MRP-2001 but allows connection to 220/240 VAC. Unless otherwise specified, the information in this manual applies to both the 110/120 VAC and 220/240 VAC versions of the panels.
  • Page 12 Optional Trim Ring TR-CE (red) for semi-flush mounting the cabinet • Optional CAC-5X Class A Converter Module for Outputs and IDCs • Optional 4XTMF Municipal Box Transmitter Module • Optional Digital Alarm Communicators (411, 411UD, 411UDAC) MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 13: Specifications

    Product Description 1.2 Specifications AC Power MRP-2001: 120 VAC, 60 Hz, 3.66 amps MRP-2001E: 240 VAC, 50 Hz, 2.085 amps Wire size: minimum #14 AWG (2.0 mm ) with 600V insulation Supervised, nonpower-limited Battery (sealed lead acid only) - J12 Maximum Charging Circuit - Normal Flat Charge: 27.6 VDC @ 1.4 amp...

  • Page 14: Controls And Indicators

    # key Figure 1.1 Membrane/Display Panel • 0 (recall) key • 1st Event key • Clear key • Escape key • Mode key • Four cursor keys (up, down, left and right) • Enter key MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 15: Components

    (TR-CE [red]). Batteries The cabinet provides space for two 18 Amp Hour batteries (larger batteries require use of a UL listed battery box such as the BB-26 or BB-55). Batteries must be ordered separately. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 16: Optional Modules And Accessories

    The BB-26 or BB-55 battery box may be used to house two batteries greater than 18 Amp Hour. The battery box mounts directly below the control panel cabinet, centered to the main circuit board. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 17: Section 2: Installation

    Board on Chassis mounting holes mounting slots mounting studs mounting tabs grounding stud: attach solid earth ground wire (refer to Figure 2.4 on page 20) mounting slots Backbox Figure 2.1 Chassis Mounting in Backbox MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 18 3.875” into wall to avoid covering venting Hinge Slot for holes on top of box. optional Dress Panel Mounting slots for optional Trim Ring Semi-Flush mounting hole Hinge Slot for optional Dress Panel Figure 2.2 Cabinet Dimensions MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 19 Backbox Mounting Installation Figure 2.3 Backbox MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 20: Operating Power

    120 VAC, 60 Hz, 3.66 amps for the MRP-2001 or 240 VAC, 50 HZ, 2.085 amps for the MRP-2001E. Run a pair of wires (with ground conductor) from the protected premises main breaker box to the AC terminal block TB1 on the main power supply. As per the National Electrical Code, use 14 AWG (2.00 mm...

  • Page 21: Input Circuits

    Waterflow 4-wire smoke release Devices or detector power heat detectors Pressure Switches (500 mA maximum) Dummy load all unused Ω circuits - 4.7 K , ½ watt resistor (P/N: 71245) Figure 2.5 IDC Connections MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 22 Supervisory Switch activation causes the panel to latch the supervisory condition if the Combo type code is selected or track (the panel will clear when the supervisory condition is cleared) if the Combo Autoresettable Supervisory type code is selected MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 23: Output Circuits

    Large gauge wire should be looped through bead at least once as illustrated. Smaller gauge wire can be looped more often. Ferrite Bead in open position Ferrite Bead in closed position Figure 2.7 NAC/Output Connections MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 24: 2: Special Application Dc Power Output Connections

    Note: Relay contacts are shown with power applied to the panel and no active troubles, alarms or supervisories. The Trouble Relay is a fail-safe relay which will transfer on any trouble or total power failure. Figure 2.9 Relay Terminals MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 25: Power-Limited Wiring Requirements

    AC Power 120 VAC Hot (L1) Ground Neutral (L2) 4XTMF Nonpower- earth limited ground Circuit Nonpower- limited Circuit Power-limited Circuit (Class 2) Deluge - Preaction Control FACP Figure 2.10 Typical UL Power-limited Wiring Requirements MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 26: Installation Of Optional Modules

    CAC-5X to the metal standoff with the screw that was just removed. Installation on J7 Connector Installation on J2 Connector CAC-5X Module CAC-5X Module Metal Metal Metal Plastic Standoff Standoff Standoff Standoff Main Circuit Board Figure 2.11 CAC-5X Module Installation MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 27: Wiring Nacs And Idcs For Class A

    Smaller gauge wire can be looped more often. Ferrite Bead in open position Ferrite Bead in closed position Figure 2.12 Wiring NACs and IDCs for Class A Operation MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 28: 2: 4Xtmf Municipal Box Transmitter Option Module

    5. Secure the option module to the standoff on the main circuit board with the supplied screws 6. When the installation has been completed, connect the wiring to the modules as indicated in the following sections 7. Test system for proper operation Standoffs Figure 2.13 4XTMF Option Module Connection MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 29: 4Xtmf Transmitter Module Installation

    Dummy load terminals 6 and 7 (4.7kΩ, ¼ watt resistor) if Disconnect Municipal Box is not connected. Switch shown in disconnect position Disconnect LED Connect to FACP Connectors J4 & J5 Figure 2.14 4XTMF Transmitter Module MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 30: Ann-Bus Devices

    ANN-S/PG Serial/Parallel Printer Interface Module 0.040 amps ANN-I/O LED Driver Module 0.200 amps ANN-(R)LED Annunciator Module 0.068 amps ANN-RLY Relay Module 0.075 amps Note: Total worst case current draw on a single ANN-BUS cannot exceed 0.5 amp. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 31 Exception: When using the ANN-RLY module, the installer must ensure that the maximum 24VDC power line drop does not exceed 0.3 volts. This results in the following wiring limitations: Wire Gauge Maximum Wire Length 312 feet 497 feet 787 feet 1,250 feet MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 32: Wiring Configuration

    2,953 feet maximum using 14 Gauge wire 2.7.1.2 Wiring Configuration Figure 2.15 illustrates the wiring between the FACP and ANN-BUS devices. FACP ANN-BUS and power wiring are supervised and power-limited ANN-80 Figure 2.15 FACP wiring to ANN-BUS Device MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 33: Powering Ann-Bus Devices From Auxiliary Power Supply

    Note: address (ID Number) DIP switches on some devices may have more than 5 switch positions. Unless otherwise specified in the documentation supplied with each device, switch positions 6 and above must be set to OFF. Address Switch 5 Switch 4 Switch 3 Switch 2 Switch 1 not valid MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 34: 3: Ann-80 Remote Lcd Annunciator

    4. Turn the key switch to the OFF (Locked) position by turning clockwise and remove the key Annunciator cover with LCD display Annunciator backplate Press in latch and pull annunciator cover open Key switch shown in ON position MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 35: Wiring Ann-80 To Facp

    1 (-) & 2 (+). Make certain to observe proper polarity 7. After all connections are made, remove extra wire from inside of annunciator by dressing it neatly through wire channel, with any excess wire pushed back through hole into electrical MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 36 Following installation and wiring of the ANN-80 LCD annunciator to the FACP, the annunciator must be added to the system via FACP programming. Refer to the programming section titled "ANN-BUS" on page 71 in this manual for detailed programming information. Select the LCD option for programming. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 37: 6: Ann-S/Pg Serial/Parallel Printer Interface Installation

    It provides 80 columns of data on standard 9” x 11” tractor-feed paper. This section contains information on connecting a printer to the control panel and setting the printer options. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 38: Connecting Prn-6 Printer

    7 Bit, Even, 1 Stop Formien Protocol XON/XOFF Lines 6LPI=60 Character Set Standard Standard Exec 10.5 SI.Zero Auto LF PAPER BIN 1 12/72” BIN 2 12/72” SINGLE 12/72” PUSH TRA 12/72” PULL TRA 12/72” PAP ROLL 12/72” MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 39: 7: Ann-I/O Led Driver Module

    • Max. Current: Alarm: 200 mA Standby: 35 mA Each LED: 10 mA • Operating Temperature: 32 F to 120 F (0 C to 49 • For indoor use in a dry location only MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 40: Ann-I/O Connection To Facp

    The ANN-I/O connects to the FACP via the ANN-BUS as illustrated in Figure 2.20. After the ANN-I/O is connected to the panel, it must be added to the system via FACP programming. ANN-I/O Module FACP ANN-BUS and power wiring are supervised and power-limited Figure 2.20 ANN-I/O Connection to FACP MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 41: Ann-I/O Module Led Wiring

    The ANN-LED annunciator modules provide LED annunciation of general system faults and input zones when used with a compatible FACP. The ANN-LED module provides alarm (red), trouble (yellow) and supervisory (yellow) indication for up to ten input zones. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 42: Ann-Led Board Layout

    Operating Temperature: 32 F to 120 F (0 C to 49 • For indoor use in a dry location only 2.7.8.3 Mounting/Installation Install the ANN-LED Module as described in the documentation supplied with the annunciator. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 43: Ann-Led Connection To Facp

    Figure 2.23 illustrates the ANN-LED board showing locations of screw terminals for connection to the FACP and the DIP switches for selecting the ANN-BUS ID number. FACP ANN-LED -24 VDC +24 VDC ANN-BUS Figure 2.23 ANN-LED Connection to FACP MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 44: 9: Ann-Rly Relay Module

    Operating Temperature: 32 F to 120 F (0 C to 49 • For indoor use in a dry location only 2.7.9.3 Mounting/Installation The ANN-RLY relay module can be mounted inside the FACP main circuit board chassis. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 45: Ann-Rly Connection To Facp

    Figure 2.23 illustrates the ANN-RLY board showing locations of screw terminals for connection to the FACP and the DIP switches for selecting the ANN-BUS ID number. FACP ANN-RLY -24 VDC +24 VDC ANN-BUS Figure 2.25 ANN-RLY Connection to FACP MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 46: Section 3: Programming

    Status Mode which allows the user to view the programmed features and status of the control panel The Read Status feature is not password protected. Refer to "Read Status" on page 92 for a detailed description of this feature. See Page MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 47: Initial Power-Up

    Note that subscreens may also have multiple options which require viewing more than one screen. The same process, as detailed in the previous paragraphs, is followed to view all option choices. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 48: Programming And Passwords

    If the Maintenance level password (default 11111) is entered, the following screen will appear: PROGRAMMING 1=INPUT ZONES 2=HISTORY 3=WALKTEST Note that in the two preceding screens, an arrow appears to inform the programmer that additional options can be viewed by pressing the keypad down arrow key. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 49: Master Programming Level

    ‘up’ arrow key will display the previous screen. PROGRAMMING 1=CROSS INPUT ZONES 2=ON-BOARD RELAYS 3=SYSTEM SETUP Programming Screen #2 PROGRAMMING 1=ANN-BUS 2=HISTORY 256 EVENTS 3=WALKTEST Programming Screen #3 PROGRAMMING 1=CLEAR PROGRAM 2=PASSWORD CHANGE Programming Screen #4 MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 50: 1: Facp Config (Application Templates)

    To program Input Zone 1, press the 1 key while viewing Input Zone Screen #1. The following screens will be displayed: INPUT ZONE 1 Normal PULL STATION PRESS TO EDIT Edit Input Zone Screen #1 MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 51 Screen #2. This will cause the control panel to display the following Zone Type Screen: 3=OUTPUT CIRCUIT MAP Edit Input Zone Screen #2 ZONE 1 TYPE 1=PULL STATION 2=N/A 3=MANUAL RELEASE Zone Type Screen #1 MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 52 While viewing any Zone Type screen, select the type of zone being programmed by pressing the corresponding keyboard number key. The display will return to Edit Input Zone Screen #2 and indicate the selection next to the Type option. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 53 2=DESCRIPTION ***************** detector currently being programmed. Pressing 1 while viewing Edit Input Zone Screen #3 will cause the following screen to be displayed: Edit Input Zone Screen #3 1=STANDARD ADJECTIVE 2=STANDARD NOUN Noun/Adjective Screen MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 54 ********************** 1=FLOOR1 1=WEST 2=FLOOR2 2=FRONT 3=FLOOR3 3=CENTER Adjective Screen #6 Adjective Screen #2 ********************** ********************** 1=REAR 1=FLOOR4 2=UPPER 2=FLOOR5 3=LOWER 3=ROOM Adjective Screen #3 Adjective Screen #7 ********************* 1=MAIN 2=FIRST 3=2ND Adjective Screen #4 MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 55 A flashing cursor will appear at the first asterisk to the left. The programmer can enter additional descriptive information about the device being programmed. This information will appear on the display along with the standard device label information. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 56 Noun field 3. With the cursor on the last letter of the Noun field, press the zero key again to increment the room number to 305 4. Press the Enter key to store the information MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 57: 3=Output Circuits

    The following screens will be displayed for each selection: OUTPUT # 1=ENABLED 2=TYPE ALARM NAC Output Screen #1 OUTPUT # 1=SILENCE NON-SIL 2=AUTO SILENCE 3=SIL INHIBIT Output Screen #2 OUTPUT # 1=CODING STEADY Output Screen #3 MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 58: Enabled

    Note: Release circuits may be directly activated by a single input zone or may be activated using cross-zoned inputs. Refer to "Circuit Mapping and Cross-Zoning" on page 103 for a description of cross-zoning and input to output circuit mapping. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 59: Release Stage Nac

    Important: When an Output Circuit with a mix of audible and visual devices is programmed for Sync Mute, only the audible devices will be turned off if the Silence key is pressed or if the Autosilence feature is enabled. The visual devices (strobes, etc.) will continue to operate. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 60: Auto Silence

    Output Screen #2 will cause a screen to be displayed with the options 1=No Silence Inhibit and 2=1 Min. Silence Inhibit. Pressing 1 will disable the Silence Inhibit feature while pressing 2 will enable a 1 minute Silence Inhibit for the selected Output. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 61: Coding

    Coding Screen #1 Output Screen #3 CODING 1=TEMPORAL 2=FUTURE USE 3=FUTURE USE Coding Screen #2 CODING 1=CROSS ZONE 2=SYNC SYSTEM SENSOR 3=SYNC WHEELOCK Coding Screen #3 CODING 1=SYNC GENTEX 2=SYNC FARADAY 3=SYNC AMSECO Coding Screen #4 MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 62: Synchronized Nac Operation

    FACP and the maximum number that can be connected to each NAC. Make sure that the NAC maximum current is not exceeded: System Sensor: 46 Strobes Wheelock: 50 Strobes Gentex: 39 Strobes Faraday: 33 Strobes Amseco: 34 Strobes MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 63: 4: Cross Input Zones

    Screens similar to the following will be displayed: REL 1 CROSS GROUP 1 1=ZONE 1 2=ZONE 2 3=ZONE 3 Select Cross Zone Screen #1 REL 1 CROSS GROUP 1 1=ZONE 4 2=ZONE 5 3=ZONE 6 Select Cross Zone Screen #2 MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 64: 5: On-Board Relays

    Abnormal 24 hour Test message via the optional communicator. • Charger Disable: This option allows the programmer to disable the onboard battery charger in the event an external battery charger is being used. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 65: Timers

    System Setup Screen #1. The following screen will be displayed: 3=BANNER System Setup Screen #1 TIMERS 1=SOAK 1 MIN 2=SOAK 2 MIN 3=WATERFLOW DELAY Timer Screen #1 TIMERS 1=AC LOSS DELAY 2 HR Timer Screen #2 MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 66: Soak 1 Or Soak 2

    25 for twenty-five seconds. Upon entering the second digit, the time delay will be stored in the control panel memory and the display will return to the Delay Screen which will indicate the new delay time. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 67: Ac Loss Delay

    This screen allows the user to select the factory default Banner which will be displayed when the system is in Normal Mode of operation. Press the Enter key to accept this as the default display. Press the Escape key to cancel and return to the Select Banner Screen. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 68: Time-Date

    Screen #2. The following screen will be displayed: TIME AND DATE 1=TIME 10:00A SYSTEM SETUP 2=DATE 04072006 1=TIME-DATE 3=CLOCK FORMAT 12HR 2=TROUBLE REMIND 3=CHARGR DISABLE System Setup Screen #2 Time-Date Screen #1 TIME AND DATE 1=DAYLIGHT SAVINGS Time-Date Screen #2 MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 69: Time

    24HR. Select 12HR for 12 hour display or 24HR for 24 hour display. Note: If the clock is changed to 24 hour (military) format, the date will change to the European standard of Day-Month-Year (for display purposes only). MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 70: Daylight Savings Time

    If an external battery charger is being used, the onboard battery charger must be disabled. Each press of the 3 key will toggle between Chargr Disable No and Chargr Disable Yes. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 71: 7: Ann-Bus

    ANN-BUS, press 1 while viewing ANN-BUS screen #1 so that the display reads ANN-BUS Enabled Yes. Each press of the 1 key will cause the display to toggle between ANN- BUS Enabled Yes and ANN-BUS Enabled No. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 72: Ann-Bus Modules

    Module Type Screen #1 ANN-BUS MODULE TYPE 1=ANN-S/PG 2=ANN-RLY 3=ANN-LED Module Type Screen #2 Press the number corresponding to the module type, if any, that is installed with the selected address. This will enable the module. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 73: Auto-Configure

    Parallel and Serial Port for printer connection. Each press of the 1 key will cause the display to toggle between Port PAR (parallel) and Port SER (serial). It is important to note that the interface selected determines which options are available to the user. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 74 No Parity, Even Parity or Odd Parity. Pressing 1 for Stop Bits while viewing Printer Options screen #3 will cause a screen to appear which allows the user to select between 0.5, 1.0 or 2.0 Stop Bits. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 75: Ann-I/O Led Zone Assignments

    Not Used Not Used Not Used Not Used Zone 1 Supervisory Zone 2 Supervisory Zone 3 Supervisory Zone 4 Supervisory Zone 5 Supervisory Zone 6 Supervisory Not Used Not Used Not Used Not Used MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 76: Options

    Drill button on any installed ANN-80 LCD annunciator will function normally or always be ignored. Pressing 3 while viewing the ANN-80 Options Screen #2 causes the display to toggle between Drl Btn Enable Yes (Drill button functions normally) and Drl Btn Enable No (Drill button never functions). MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 77: Ann-Rly Options

    • 2nd Shot Release 1 • 2nd Shot Release 2 • Input Zone 1 • Input Zone 2 • Input Zone 3 • Input Zone 4 • Input Zone 5 • Input Zone 6 MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 78: 8: History

    Pressing 1 while viewing the Erase History Screen will erase all events from the History file. During this process, the display will read as follows: ERASING HISTORY PLEASE WAIT Erase History Wait Screen After the History file has been erased, the display will return to the History Screen. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 79: 9: Walktest

    Note that the Walktest log is stored in RAM. If all power (AC and DC) is removed from the FACP, the Walktest log information will be lost. This information is also overwritten when subsequent walktests are performed. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 80: 10: Clear Program

    10101 for the Master Level). After the fifth digit is entered, the following screen will be displayed: VERIFY NEW PASSWORD Password Change Screen The new five digit password must be re-entered to accept the change. The display will then return to the initial Password Change Screen. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 81: Maintenance Programming Level

    Note that in the preceding screens, an arrow appears to inform the programmer that additional options can be viewed by pressing the keypad down arrow key, as shown in the following screen. PROGRAMMING 1=TIME-DATE MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 82: 1: Input Zones - Enable/Disable

    1=VIEW EVENTS 2=ERASE HISTORY History Screen The History feature allows the operator to view control panel events which have been stored in a history file in memory and erase the contents of the history file MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 83: 3=Walktest

    UNIT IN WALKTEST. To end the Walktest, press the Esc (Escape) key. Pressing 3 after the walktest has been completed, will allow the operator to view the results of the walktest. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 84: 4: Time-Date

    To change between 12 hour and 24 hour format, press 3 for Clock Format while viewing the Time and Date screen. Each press of the 3 key will toggle the display between 12 HR and 24 HR format. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 85: Section 4: Operating Instructions

    LCD display segments after the Reset key is released. Any alarm or trouble that exists after a reset will resound the system. Note that if Silence Inhibit has been enabled, the FACP cannot be reset for one minute following initiation of an alarm. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 86: Indicators

    (temperature of F or less) on initial entry into Normal mode. Thereafter, each device will be polled every hour for freeze and every four hours for maintenance conditions MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 87: Trouble Operation

    Time; the current time in this example is 10:00A which represents 10:00 AM Date; the current month, day and year in this example is 03 for March, 08 for the 8th day of the month and 06 for the year 2006 MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 88: Alarm Operation

    <NOUN>; refers to the user programmed noun descriptor from library list resident in the control panel or custom entry via PC. • Third line in display: Zone 1 indicates the zone programmed to this device which, in this example, is Input Zone 1. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 89: Supervisory Operation

    Note that disabled Releasing Circuits are treated as supervisory events. 4.8 Waterflow Circuits Operation If an alarm exists from a zone that is a waterflow non-silenceable type, the Alarm Silence key will not function. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 90: 2Nd-Shot Water Switch

    Circuit to perform a water release and the programmed NAC output to turn on steady • Synchronized output for System Sensor, Wheelock, Gentex, Faraday or Amseco - Refer to "Synchronized NAC Operation" on page 62 for additional information. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 91: Release Stages

    Disabled NAC devices will not activate during walktest. In addition, i smoke detectors will enter their own test mode causing their LEDs to flash twice every five seconds (refer to i specification document). MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 92: Read Status

    2=INPUT ZONES 3=HISTORY 3=OUTPUT CIRCUITS Read Status Screen #1 Read Status Screen #3 READ STATUS READ STATUS 1=CROSS INPUT ZONES 1=PRINT 2=ON-BOARD RELAYS 2=ANN-BUS 3=SYSTEM SETTINGS Read Status Screen #2 Read Status Screen #4 MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 93: 1: Facp Configuration

    Pressing the down arrow key, while viewing the screen shown above, will allow the operator to view additional programming information about the selected device, such as: • Enable/Disable Status • Device Type • Output Circuit MAP • Adjective/Noun descriptor MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 94: 3=Output Circuits

    CROSS ZONE REL 1 X 1 4 NONE NONE Cross Input Zone Screen The Cross Zone Release screen displays the zones that have been cross-zoned. In this example, Zone 1 is cross-zoned with Zone 4. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 95: 5: On-Board Relays

    Pressing 3 while viewing Read Status Screen #2 will display the following screens: SYSTEM SETTINGS FUTURE USE TROUBLE REMIND CHARGER DISABLE SYSTEM SETTINGS FACTORY BANNER The operator can view the system settings options that have been programmed into the FACP. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 96: 7: Timers

    Pressing 2 while Read Status Screen #3 will cause the following screens to be displayed: DAYLIGHT SAVINGS ENABLED START MONTH START WEEK WK 2 DAYLIGHT SAVINGS END MONTH END WEEK WK 1 These screens allow the operator to view settings that have been programmed for Daylight Savings Time. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 97: 9: History

    Pressing 2 allows the user to print the Walktest log which will detail all of the system activations during walktest since the log was last cleared. Refer to "Walktest" on page 79 for additional information on the display. Pressing 3 will exit the Print operation. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 98: 11: Ann-Bus

    Pressing 1 while viewing ANN-BUS Screen #2 will display the programmed options for the ANN- 80 LCD annunciators connected to the ANN-BUS. Pressing 2 while viewing ANN-BUS Screen #2 will display the programmed options for the ANN- RLY devices connected to the ANN-BUS. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 99: Section 5: Power Supply Calculations

    Use Table 5-1 , to determine the total amount of current, in AC amperes (A), that must be supplied to the system. TABLE 5-1:120 VAC Branch Circuit Requirements Number of Current Draw Total Current per Device Type Devices (AC amps) Device MRP-2001 3.66 MRP-2001E 2.085 Sum Column for AC Branch Current Required MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 100: Calculating The System Current Draw

    Calculation Column 2 - The primary supply current load that the control panel must support during a fire alarm condition, with AC power applied. Calculation Column 3 - The standby current drawn from the batteries in a non-fire alarm condition during a loss of AC power. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 101 Current limitations of TB9, Terminals 1 & 2 = 0.500 amps, filtered, 24 VDC +/-5%, 120 Hz ripple @ 10 mV nonresettable power and TB9, Terminals 3 & 4 = 0.500 amps, filtered, 24 VDC +/-5%, 120 Hz ripple @ 10mV , resettable power. 6. Total current draw listed above cannot exceed 7.0 amps MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 102: Calculating The Battery Size

    7 AH to 26 AH range. The control panel cabinet is capable of housing batteries up to 18 AH. Batteries larger than 18 AH require the BB-26, BB-55 or other UL listed external battery cabinet. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 103: Appendix A Circuit Mapping And Cross-Zoning

    3. The programming menus will prevent you from mapping any incompatible input zone and output circuit types together, such as mapping a supervisory input zone to a releasing output circuit. 4. Timers and/or delays are not represented in these examples. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 104: A.1.1: Mapping Input Zones To Output Circuits For Direct Activation

    1) but not output circuits 3 or 4. ZONE 1 TYPE 1=COMBO 2=COMBO W/AR. SUPERV 3=2-WIRE SMOKE OUTPUT MAP ZONE 1 1=ALARM NAC 2=RELEASE 1 3=WATERFLOW NAC OUTPUT MAP ZONE 1 1=SUPV BELL NAC MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 105: A.1.2: Mapping Input Zones To Release Circuits For Cross Zone

    1=ALARM NAC 2=RELEASE 1 2=RELEASE 1 3=ALARM NAC 3=ALARM NAC OUTPUT MAP ZONE 1 OUTPUT MAP ZONE 2 1=SUPV BELL NAC 1=SUPV BELL NAC REL 1 CROSS GROUP 1 1=ZONE 1 2=ZONE 2 3=ZONE 3 MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 106 1=SUPV BELL NAC REL 1 CROSS GROUP 1 REL 2 CROSS GROUP 1 1=ZONE 1 1=ZONE 1 2=ZONE 2 2=ZONE 2 3=ZONE 3 3=ZONE 3 REL 2 CROSS GROUP 1 1=ZONE 4 2=ZONE 5 3=ZONE 6 MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 107: Release Circuits

    INPUT ZONES menus. Example 8: Release Circuit 1 activates if Input Zone 1 activates followed in time by Input Zone 2 activating. • This kind of sequential reaction is not possible at this time. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 108: Appendix Bfacp Configuration Templates

    Circuit Types. If the FACP is configured with one of the preprogrammed Templates, the user must ensure that the devices connected to each Input Zone and Output Circuit are compatible with the programmed types. (The user can reprogram the circuit types if desired). MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 109: B.1: Template 7: Single Hazard - 3 Zone

    (Waterflow - with Waterflow Delay time) or Zone 4 (Manual Release) or Zone 5 (Pull Station) will operate Alarm Relay • Trouble Relay - any system trouble will activate the Trouble Relay • Supervisory - activation of Zone 6 (Supervisory) will operate the Supervisory Relay MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 110: B.2: Template 8: Single Hazard - Cross-Zone With Manual Release

    (Waterflow - with Waterflow Delay time) or Zone 4 (Manual Release) or Zone 5 (Pull Station) will operate Alarm Relay • Trouble Relay - any system trouble will activate the Trouble Relay • Supervisory - activation of Zone 6 (Supervisory) will operate the Supervisory Relay MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 111: B.3: Template 9: Dual Hazard - Combined Release

    (Waterflow - with Waterflow Delay time) or Zone 4 (Manual Release) or Zone 5 (Pull Station) will operate Alarm Relay • Trouble Relay - any system trouble will activate the Trouble Relay • Supervisory - activation of Zone 6 (Supervisory) will operate the Supervisory Relay MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 112: B.4: Template 10: Dual Hazard - Split Release

    (Waterflow - with Waterflow Delay time) or Zone 5 (Manual Release) or Zone 6 (Pull Station) will operate Alarm Relay • Trouble Relay - any system trouble will activate the Trouble Relay • Supervisory - activation of Zone 4 (Supervisory) will operate the Supervisory Relay MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 113: B.5: Template 11: Single Hazard - 3 Zones And Low Pressure

    (Waterflow - with Waterflow Delay time) or Zone 4 (Manual Release) or Zone 5 (Pull Station) will operate Alarm Relay • Trouble Relay - any system trouble will activate the Trouble Relay • Supervisory - activation of Zone 6 (Supervisory) will operate the Supervisory Relay MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 114: B.6: Template 12: Single Hazard - 2 Zones Cross-Zoned With All Active

    (Waterflow - with Waterflow Delay time) or Zone 4 (Manual Release) or Zone 5 (Pull Station) will operate Alarm Relay • Trouble Relay - any system trouble will activate the Trouble Relay • Supervisory - activation of Zone 6 (Supervisory) will operate the Supervisory Relay MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 115: B.7: Template 13: Single Hazard - Dual Zone

    (Waterflow - with Waterflow Delay time) or Zone 4 (Manual Release) or Zone 5 (Pull Station) will operate Alarm Relay • Trouble Relay - any system trouble will activate the Trouble Relay • Supervisory - activation of Zone 3 (Low Pressure) will operate the Supervisory Relay MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 116: Appendix Cnfpa Standard-Specific Requirements

    “Proprietary Protective Signaling System,” on page 121, for installation instructions for this unit. The relay contacts of this control panel may be used to trip any dialer that is UL-listed for Central Station/Remote Station services. The illustrations in this appendix provide examples of possible system configurations. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 117 Relay Output (DACT Trouble) from 411UD FACP Supervisory Relay FACP Trouble Relay FACP Alarm Relay 2.2K ELRs P/N 27070 1 2 3 4 5 6 7 8 9 FACP Trouble Input (nonsupervised, power-limited) Figure C.1 FACP Connection to 411UD MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 118 7. The MRP-2001/E must be programmed for AC Loss Reporting Delay This prevents the immediate transmission of a trouble on the loss of AC power. 8. A (-)VDC from the 411UD Trouble Contacts will activate the Trouble Input J6 on the FACP. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 119: C.1: Nfpa 72 Auxiliary Fire Alarm System

    Figure C.2 Municipal Box Connected to 4XTMF Transmitter Module FIRE Municipal Box Circuit Gamewell Model M34-56 Local Energy Municipal Box Polarities shown in alarm condition Nonpower-limited 4XTMF Figure A.2 Municipal Box Connected to 4XTMF Transmitter Module MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 120 Cutting TBL Jumper allows the 4XTMF Transmitter Module reverse polarity circuit to open with a system trouble condition if no alarm condition exists. Figure C.3 Remote Station Connection Using 4XTMF Module MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 121 Notes: 1. Connection between the FACP and the transmitter are supervised by the transmitter. 2. This FACP/Transmitter arrangement can be employed for NFPA 72 Proprietary Protective Signaling System. Figure C.4 Proprietary Protective Signaling System MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 122: Connection To Facp Dry Contacts

    NO and C contacts as indicated in the illustration. Fire Alarm Control Panel Figure C.5 FACP Dry Contacts Connection to Central Station/Remote Station Transmitter MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 123: Appendix D: Facp With Keltron

    Note: Cut TBL jumper on 4XTMF module to send alarm/trouble signal from the same pair or terminals. Fire Alarm Control Panel (terminal blocks are not shown in their actual positions in order to clarify wiring connections) MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 124: Appendix E: Testing & Maintenance

    Ensure proper wiring and power is applied. After power-up, allow 80 seconds for the detectors to stabilize before testing. Refer to System Sensor’s i Installation and Maintenance Instructions document I56-1800-00 for device specifications and testing procedures. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 125: E.2: Maintenance

    A regular schedule of inspection, testing and maintenance is vital to ensure proper and reliable operation of the control panel. The procedures should be performed as required by the local authority having jurisdiction. Refer to NFPA documentation for further details. MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 126 Testing & Maintenance Maintenance MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 127 11 Banner 64 Detector setting 67 adding description 53 battery 15, 20 enable/disable 51 precautions 20 detector functions 90 rating 13 device compatibility 11 battery box 16 dimensions battery calculations 102 backbox 15 MRP-2001 & MRP-2001E PN 53040:A 4/16/07...
  • Page 128 Fire Alarm 12, 15 main circuit board 17 Supervisory 12, 15 mounting System Trouble 15 cabinet 17 Trouble 12 municipal box 29 indicator municipal box transmitter AC Power 86 see also 4XTM 16 Alarm Silenced 86 MRP-2001 & MRP-2001E PN 53040:A 4/16/07...
  • Page 129 58 Recall/Increment Function 56 outputs 12 Relay Form-C 64 Password 48 programming 64 change 80 relay 11, 24 Maintenance Level 2 48, 81 contact rating 13, 24 Master Level 1 48 relay module 16 MRP-2001 & MRP-2001E PN 53040:A 4/16/07...
  • Page 130 Class A IDC 27 synchronization 62 Class A NAC 27 Synchronized 62 combination waterflow/supervisory 22 synchronized 62 IDC 21 synchronized signals 62 NAC 23 and silenceable circuits 59 nonpower-limited 25 system current calculations 100 power-limited 25 MRP-2001 & MRP-2001E PN 53040:A 4/16/07...
  • Page 131 Index UL requirements 25 Zone type 51 Zone Setup Maintenance Level 82 zone type inputs 52 MRP-2001 & MRP-2001E PN 53040:A 4/16/07...
  • Page 132 Testing & Maintenance Maintenance MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 133 Maintenance Testing & Maintenance MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...
  • Page 134 Testing & Maintenance Maintenance MRP-2001 & MRP-2001E PN 53040:A 4/16/2007...

  • Page 135: Limited Warranty

    This warranty is void if the product is altered or repaired by anyone other than Honeywell International Inc. or as expressly authorized by Honeywell International Inc.
  • Page 136 World Headquarters 1 Firelite Place Northford, CT 06472-1653 USA 203-484-7161 fax 203-484-7118 www.firelite.com...

This manual is also suitable for:

Mrp-2001

Table of Contents
