  • Page 1 PCI-8213/8214 4-Port / 2-Port PCI Ethernet Controller User’s Guide Recycled Paper...
  • Page 3 ©Copyright 2002 ADLINK Technology Inc. All Rights Reserved. Manual Rev. 1.0: June 2002 Part No : 50-13028-110 The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer.
  • Page 4 Getting service from ADLINK Customer Satisfaction is always the most important thing for ADLINK Tech Inc. If you need any help or service, please contact us and get it. ADLINK Technology Inc. http://www.adlinktech.com Web Site Sales & service@adlinktech.com Service NuDAQ nudaq@adlinktech.com...

  • Page 5: Table Of Contents

    Fast Ethernet..................1 1.1.2 Connect the Network Cable............2 1.1.3 Pin-definition of RJ45 Connector............2 Drivers on ADLINK CD............3 Chapter 2 PCI-8213 .............. 4 Introduction ..............4 Specifications ..............4 Installation................ 6 Jumper Setting ..............6 PCI-8213 Front Panel ............7 Extra Display Connector............ 8 PXE Function ..............
  • Page 6 5.1.2 Communication States..............22 5.1.3 WDT Test Utilities ................22 5.1.4 WDT and State Change..............22 WDT control ..............25 5.2.1 WDT control..................25 5.2.2 WDT Time-out Value..............25 5.2.3 Programming information of the WDT........26 DOS Test Utility.............. 28 WDT DLL for Windows NT &...

  • Page 7: How To Use This Guide

    Chapter 1, Introduction gives an overview of the Ethernet. The detail information of each product is list in Chapter 2 to Chapter 4. Chapter 2, PCI-8213 gives detail information of this product. Chapter 3, PCI-8214 gives detail information of this product.

  • Page 9: Chapter 1 Introduction

    Introduction This users manual is used for PCI-8213 and PCI-8214 products based on standard universal PCI short card. The products include: PCI-8213: 4 ports of 10 Base-T / 100 Base-TX Fast Ethernet PCI-8214: 2 ports of 10 Base-T / 100 Base-TX Fast Ethernet Please refer the Chapter 2 and Chapter 3 for detail information of those products.

  • Page 10: Connect The Network Cable

    Hub is 100 meters. The cable must be straight (not a crossover cable) with an RJ-45 plug at each end. Make the network connection by plugging one end of the cable into the RJ-45 jack of the PCI-8213/8214, and the other end into a port of the supporting Hub.

  • Page 11: Drivers On Adlink Cd

    1.2 Drivers on ADLINK CD To install the drivers and utility for the PCI-8213 / 8214 product, please refer the detail installation information from the Chapter 4. We provide the basic information in this manual, however, for more detail installation information, such as non-Windows OS installation, please refer the extensive explanation inside the ADLINK CD.

  • Page 12: Chapter 2 Pci-8213

    PCI-8213 2.1 Introduction PCI-8213 is the high performance 4-port Ethernet card which complies with the PCI standards. It integrates 4 Intel 82559 single chip Ethernet controllers and 1 Intel 21154 single chip PCI-to-PCI bridge. 2.2 Specifications Bus architecture: • Standard PCI Universal bus •...
  • Page 13 Test in Compliance with CISPR PUB. 22 and FCC Part 15 Environment: • Operating Temperature: 0 to 60 • Storage Temperature: -20 to 80 • Humidity: 10%~90% non condensing Dimension: • Standard PCI half-sized card form factor PCI-8213 • 5...

  • Page 14: Installation

    The PCI-8213 supports remote boot via PREBOOT EXECUTION ENVIRONMENT (PXE) function by installing a boot ROM. The boot ROM is default installation but disable. The only jumper on the PCI-8213 is used to enable or disable the boot ROM. JP2: Boot Rom enable & disable setting...

  • Page 15: Pci-8213 Front Panel

    2.5 PCI-8213 Front Panel CN4: ACT/LINK CN4: 10/100 CN3: ACT/LINL CN3: 10/100 CN2: ACT/LINK CN2: 10/100 CN1: ACT/LINK CN1: 10/100 Figure 2.5.1 PCI-8213 Front Panel CN1~4: RJ45 Connector ACT: LAN active LINK: LAN Link 10/100: 10/100 Mbps PCI-8213 • 7...

  • Page 16: Extra Display Connector

    2.6 Extra Display Connector GROUND SPEED LED ACT LED RESERVE RESERVE Figure 2.6.1 Extra Display Connector Pin Assignment 8 • PCI-8213...

  • Page 17: Pxe Function

    2.7 PXE Function The PCI-8213 supports one channel (CN1) remote boot via PREBOOT EXECUTION ENVIRONMENT (PXE) function. The user should enable the system BIOS’s Boot From LAN First item. When POST (power-on self-test) of the system BIOS finished, press Ctrl+S Into INTEL Boot Agent Setup Program.

  • Page 18: Chapter 3 Pci-8214

    PCI-8214 3.1 Introduction PCI-8214 is the high performance 2-port Ethernet card, which complies with the PCI standards. It integrates 2 Intel 82559 single chip Ethernet controllers and one Intel 21154 single chip PCI-to-PCI bridge. PCI-8214 has the ability of connecting two channels while the system is halted or software is down when WDT function is active.
  • Page 19 Power: • Power Requirement: 5V or 3.3V @ 1.2A (maximum) Compliant Standards: • CE Test According to: EMI Test: European Standard EN 55022 Class B Harmonic Test: European Standard EN 61 000-3-2 Voltage fluctuations Test: European Standard EN 61 000-3-3 EMS Test: European Standard EN 50 082-1:1997 •...

  • Page 20: Installation

    3.3 Installation After unpacking the box, please check if the package contains the following items. If you discover any damage or any item missing, please contact with your dealer. PCI-8214 card ADLINK CD This manual You may follow the following steps to install this card into your system. 1.

  • Page 21: Jumper Setting

    3.4 Jumper Setting The PCI-8214 supports remote boot via PREBOOT EXECUTION ENVIRONMENT (PXE) function by installing a boot ROM. The boot ROM is default installation but disable. The only jumper on the PCI-8214 is used to enable or disable the boot ROM. JP2: Boot Rom enable &...

  • Page 22: Extra Display Connector

    3.6 Extra Display Connector CH2 Speed Ground CH2 Active Ground CH1 Speed Ground CH1 Active Ground Power On LED Ground WDT time out LED Ground GROUND SPEED LED ACT LED Power On LED WDT time out LED Fig 3.6.1 Extra Display Connector Pin Assignment Pins Signal Level Meaning...

  • Page 23: Pxe Function

    3.7 PXE Function The PCI-8214 supports one channel (CN1) remote boot via PREBOOT EXECUTION ENVIRONMENT (PXE) function. The user should enable the system BIOS’s Boot From LAN First item. When POST (power-on self-test) of the system BIOS finished, press Ctrl+S Into INTEL Boot Agent Setup Program.

  • Page 24: Chapter 4 82559 Driver Installation

    82559 Driver Installation This chapter describes LAN driver installation for the onboard Ethernet controller Intel 82559. The relative drivers are under the following ADLINK CD directory: X:\CHIPDRV\LAN\100pdisk, where X: is the location of the CD-ROM drive. 4.1 Software and Drivers Support The 82559 drivers support the following OS or platforms: Windows 95, Windows 98, Windows 2000, Windows NT Novell Netware, DOS Setup for Novell NetWare DOS...

  • Page 25: Driver Installation On Windows 2000

    4.2 Driver Installation on Windows 2000 The Windows 2000 will install LAN driver automatically. We recommend you to manually install the most updating LAN driver from ADLINK CD to ensure the compatibility. After installing the Windows 2000, please update the driver by the following steps. 1.

  • Page 26: Driver Installation On Windows 98 (Se & Me)

    4.3 Driver Installation on Windows 98 (SE & ME) The Windows 98 will install the LAN driver automatically. We recommend you to manually update the LAN driver from ADLINK CD to ensure the compatibility. After setuping Windows 98, please update the driver through the following steps.

  • Page 27: Driver Installation On Windows Nt

    4.4 Driver Installation on Windows NT Before installing LAN driver on Windows NT, please copy the files of LAN driver in the CD to your hard disk. You may copy the relative NT drivers in the directory below. X:\CHIPDRV\LAN\100pdisk where X is the CD-ROM drive. After booting, Windows NT may detect the hardware of the LAN card and ask to install a LAN driver from its own library of drivers.

  • Page 28: Driver Installation On Red Hat Linux

    4.5 Driver Installation on Red Hat Linux The 82559 source code has been included in Red Hat 6.2, 7.0, 7.1 and 7.2 Linux kernel. So what you need to do is plug your card in and boot Red Hat, then the driver will be automatically installed. 20 •...

  • Page 29: Chapter 5 Bypass And Wdt

    Bypass and WDT The bypass function on PCI-8214 in used to link (or short) two independent Ethernet ports when user’s application software halt or when power is off. 5.1 Bypass Operation 5.1.1 Block Diagram The following diagram shows the operation of bypass on PCI-8214: Bypass Relays 82559...

  • Page 30: Communication States

    5.1.2 Communication States There are two communications states for the bypass function: (1) Normal State, (2) Bypass State. A watch-dog-timer (WDT) is used to control and switch the communication between the two states. A relay array is controlled by the WDT for physically routing of the two Ethernet ports.
  • Page 31 Default State Setting The JP4~7 set the Default State of communication as following: Default Normal State Default Bypass State After the system power on or PCI reset, the communication will be in the Default State, which can be either Bypass State or Normal State. The factory default setting is the Bypass State.
  • Page 32 When power on default setting is Normal State Power State Note Utility(DOS) Relay physical Disable Bypass character Default Power on Disable Normal State Enable WDT and Enable Normal LANWDT.EXE keep reload WDT Enable WDT but will Enable Bypass ENWDT.EXE timeout if no reload Disable WDT and set Disable Normal DISWDT.EXT...

  • Page 33: Wdt Control

    5.2 WDT control 5.2.1 WDT control Four signals, which are the GPIO pins of the PCI-to-PCI chip, control the WDT. The function names are listed as the following table: Functions Default Action command GPIO0 Enable WDT GPIO1 Disable WDT GPIO2 Reload WDT GPIO3 Force to Normal State...

  • Page 34: Programming Information Of The Wdt

    5.2.3 Programming information of the WDT Search Intel 21154 PCI-to-PCI bridge The first step of programming the WDT is to use the 21554 chip information (Vendor ID=1011h, Device ID=0026h, Class Code = 0604h) to search the PCI-8214 card. If the card does exist, then record the bridge’s location (Bus number, Device number and function number) for the further programming.
  • Page 35 Reset value: 0 (all pins are input only) The gpio<3:0> pin output enable control write-1-to-set. Writing 1 to any of these bits configures corresponding gpio<3:0> pin as bi-directional, that is, GPIO output enables the output driver and drives the enable R/W1TS value set in the output data register Write-1-to-set...

  • Page 36: Dos Test Utility

    5.3 DOS Test Utility The following four test utilities can be used for testing whether if the bypass relays work, before integrating the WDT control into user applications. You can find these 4 utilities in the directory below. X:\NuPRO\PCI8214\WDTutility\DOS where X is the CD-ROM drive. ENWDT.EXE: Enable WDT.

  • Page 37: Wdt Library For Linux

    2. Run P8213reg.reg in X:\NuPRO\PCI8214\WDTutility\NT&2K\NTDRV to register WDT DLL to system. 3. Copy X:\NuPRO\PCI8214\WDTutility\NT&2K\Lib\LanWDT.dll to C:\WINT\System32 4. Run X:\NuPRO\PCI8214\WDTutility\NT&2K\Sample \SdkLanWDT\LanWDT.exe Select index card number, enter OK. 5.5 WDT Library for Linux 5.5.1 WDT Installation for Linux The Linux Module of WDT had been tested under Linux kernel 2.2.12 and ready for 2.4.2.
  • Page 38 ex. If you have 2 PCI-8214 cards, and install the PCI-8214 package in /usr/local/8213_wdt. install the cards with the command : wdt_inst.pl 2 /usr/local/8213_wdt 4. INSTALL LIBRARY The library is provided as a shared library. To install the library, type the following command: Cp <InstallDir>/8213_wdt/lib/libLanWDT.so /usr/lib In addition, wdt_inst.pl also involves the installation for the library.

  • Page 39: Warranty Policy

    Warranty Policy Thank you for choosing ADLINK. To understand your rights and enjoy all the after-sales services we offer, please read the following carefully. Before using ADLINK’s products, please read the user manual and follow the instructions exactly. When sending in damaged products for repair, please attach an RMA application form.
  • Page 40 To ensure the speed and quality of product repair, please download an RMA application form from our company website www.adlinktech.com . Damaged products with RMA forms attached receive priority. For further questions, please contact our FAE staff. ADLINK: service@adlinktech.com Test & Measurement Product Segment: NuDAQ@adlinktech.com Automation Product Segment: Automation@adlinktech.com Computer &...
