Door Status Indicators; Buttons And Functions; Supplier/Installer Information - Automatic Technology GDO-8V2 EasyRoller II Installation Instructions Manual

Parameters

Door Status Indicators

Door Opener State
Open
Close
Opening
Closing
Door travel stopped
Door obstructed when
opening
Door obstructed when closed
Opener overloaded
Mains power interupted
Buttons
Operate
Door code
Force Margin Set + plus (+)
Force Margin Set + Minus (-)
Force Margin Set (then) Set
Close for 6 seconds
Set (then power on) & hold until all LEDs are off
Door Code (then power on) & hold until all LEDs
are off
Set for 2 seconds
Purchased from:
Installed by:
Serial No:
GDO-8V2 EasyRoller® II
18
Open LED Close LED
Green Red
On
On
Flashing
Flashing
Flashing
Flashing
Flashing
Alternating fl ashes Alternating fl ashes
Rapid fl ashes
Function
Opens/Stops/Closes the door
Codes a transmitter button for OPERATE function
Increases the obstruction force margin setting
Decreases the obstruction force margin setting
Reloads the factory set default obstruction force
margin setting
Clears the door limits set positions. Limits then need
to be reset
Deletes control parameters excluding transmitter
storage memory
Deletes all transmitter stored in memory.
Re-initialises the Opener to re-calculate force margins
Owner Installation Instructions
Door Status Beeper
LED yellow
Beeps
while door
is moving
Phone:
Date:
