Short user guide
innovaphone IP240
Display
Symbol
Description
Loudspeaker
Microphone
Call diversion
Telephone locked
Handset active
Headset active
Connection to gatekeeper down
Connection to gatekeeper OK
Voice encryption enabled
Keys
Key
Enter main menu, leave menu and save changes
Enter menu, confirm selection, enter
Arrow keys for orientation in menu
Delete left character
Leave menu without saving changes
Enter to complete entries or confirm selection
Exit menu
Do not disturb, ring tone off
Displays in-bound call list
Displays out-bound call list
Starts hands-free calling
...in idle state
Name
Symbols
Date
...during connection
Setup a conference
Adjust volume of speaker
Left and right arrow to adjust volume
Terminate active call
Terminate active call
Mute, microphone off
Consultation call
Forward active call
Speaker on, change to hands-free mode
Number
Time
Symbols

Advertisement

loading
Need help?

Need help?

Do you have a question about the IP240 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Innovaphone IP240

Summary of Contents for Innovaphone IP240

  • Page 1 Short user guide innovaphone IP240 Display Symbol Description Name Number Loudspeaker Microphone Call diversion Telephone locked Handset active Headset active Connection to gatekeeper down Connection to gatekeeper OK Voice encryption enabled Symbols Date Time Symbols Keys ...in idle state ...during connection...
  • Page 2 Actions Action Status Key combination Description Accept call pick up The display shows caller and called party Reject call Caller gets a busy tone Terminate call hang up, The active call is terminated Make call 0...9, then Dialling can also take place after picking up handset Redial then Displays the most recent in-coming calls, use arrow...

  • Page 3: Function Key Configuration

    Function key configuration Function Display Description Dial Immediately dials the configured number Call forward Configuration of automatic call forward Up to 4 different call forwards can be configured. Call forward unconditional, on busy or on no reply. 3: Off shows call forwarding on busy or no reply. The complete number is shown on display for unconditional call forwarding.
  • Page 4 Enter your own configuration here All described functions are related to use of the IP240 telephone connected to an innovaphone PBX. The telephone configuration must take place using the web interface. Use this key...
