Extension
Own name
Presence
Apps
innovaphone AG | Böblinger Str. 76 | 71065 Sindelfingen | Tel +49 7031 73009-0 | www.innovaphone.com
Original: Bedienungsanleitung_IP2x2_IP11X_EN.docx | Date: April 2016
Subject to availability and technical modifications without notice. Errors excepted.
Display setup using the
innovaphone IP222 VoIP phone
as an example
Copyright © 2016 innovaphone AG
i n n o v a p h o n e I P 1 1 1 / 1 1 2
i n n o v a p h o n e I P 2 2 2 / 2 3 2
Operating manual
Status
Date, time
Turn page key
Information
Advertisement
Table of Contents
Related Manuals for Innovaphone IP111
Summary of Contents for Innovaphone IP111
- Page 1 Display setup using the innovaphone IP222 VoIP phone as an example innovaphone AG | Böblinger Str. 76 | 71065 Sindelfingen | Tel +49 7031 73009-0 | www.innovaphone.com Original: Bedienungsanleitung_IP2x2_IP11X_EN.docx | Date: April 2016 Subject to availability and technical modifications without notice. Errors excepted.
-
Page 2: Table Of Contents
While the IP111, IP112 and IP222 phones have 12 dynamically assigned function keys on the edge of the display, the IP232 phone has a touch display. Touching the display of the IP232 triggers the same function as the function key on the edge of the IP111´s, IP112´s and IP222’s display. -
Page 3: Overview
Operating manual: innovaphone IP111, IP112, IP222 and IP232 IP phones Overview The user interfaces of the IP111, IP112, IP222 and IP232 IP phones are divided into applications that are shown and can be selected at the bottom of the display. -
Page 4: Key Configuration
Operating manual: innovaphone IP111, IP112, IP222 and IP232 IP phones Key configuration The functions of the keys on the numeric keypad are commonly used and correspond to their labelling. They are not described in more detail here. Home: One step back in the menu. On the top level of an app, the key switches to the Home app. -
Page 5: The Phone Status Icons
Operating manual: innovaphone IP111, IP112, IP222 and IP232 IP phones The phone status icons The status of the phone is shown as an icon in the middle of the top line of the screen. A maximum of three icons can be shown at the same time. In the case of icons that rule each other out, only the icon that is currently active will be shown. -
Page 6: Phone Calls
Operating manual: innovaphone IP111, IP112, IP222 and IP232 IP phones Phone calls Making calls is possible in any mode, as expected: You pick up the handset, dial a number and hear the ring tone until someone has answered the call. - Page 7 Operating manual: innovaphone IP111, IP112, IP222 and IP232 IP phones An inbound call will be shown on the information display - as well as further information such as “name and “phone number” of the caller, if available. The handset or the handset icon is used to pick up an inbound call. If you accept a call by pressing the green handset, the call is picked up in hands-free mode or via a connected headset.
- Page 8 IP111, IP112 and IP222: You can enable a three-party conference between you and the other two parties on the call on hold – to do so, please press the left softkey on the call on hold.
- Page 9 An internal diverted call is shown with additional information. An angled arrow on the display of the IP111, IP112 and IP222 indicates who forwarded the call to you. Thus you can inform the caller that you are not actually the person the caller was trying to reach.
-
Page 10: Headset Operation
Operating manual: innovaphone IP111, IP112, IP222 and IP232 IP phones In addition, information about the call that is parked there is listed. By pressing on the favourite, a detailed view is offered, which contains a pickup function. This enables the call to be retrieved to your own phone and accepted. -
Page 11: Extension Module
The list can be found on the wiki.innovaphone.com and is also accessible via the web page for IP111, IP112, IP222 and IP232 phones. -
Page 12: Applications
Operating manual: innovaphone IP111, IP112, IP222 and IP232 IP phones Applications Home Your Presence is shown at the top left. Press the icon to see a selection of various possibilities. You can change your activity and add a note here. The option "Do not disturb"... - Page 13 Press the key at the bottom right-hand side next to the space bar for the keyboard to disappear. When using the IP111, IP112 and IP222 phones, a shift key is at the top left to enter numbers and switch between capital/small letters. The backspace key on the right of the input box deletes the last character before the cursor.
- Page 14 Operating manual: innovaphone IP111, IP112, IP222 and IP232 IP phones The following screen shows all the information available on the subscriber you have selected. You may call the person directly, send a message or to add the person as a personal favorite.
-
Page 15: Call Lists
Operating manual: innovaphone IP111, IP112, IP222 and IP232 IP phones Call lists There are the following versions on the call list: "All calls", "Inbound calls" and "Outbound calls" as well as a list of active "recalls" and “automatic redials”. Use the arrow keys at the top to switch between lists. -
Page 16: Favourites
Operating manual: innovaphone IP111, IP112, IP222 and IP232 IP phones Favourites The favourites are provided in parallel on the phone and in the myPBX UC application on the computer. The most frequently used contacts are added to the Favourites list. Favourites are displayed with Presence information enabling the user to see whether, how and when the other subscriber can be reached. -
Page 17: Settings
Operating manual: innovaphone IP111, IP112, IP222 and IP232 IP phones Settings Up to 6 users can be registered to a phone. Accounts correspond to all users who are registered on this phone. Selecting an account makes it possible to make this user the active user. -
Page 18: Contacts
The local entries can be recorded manually to transfered from the call lists. About this document This document refers to the IP111,IP112, IP222 and IP232 phones with the firmware: Version 12 R1 [12.0.626] Brand names are used with no guarantee that they may be freely employed. Almost all hardware and software designations in this manual are registered trademarks or should be treated as such.
