User Guide for the Polycom VVX 1500 Phone
1 - 20
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299
Feature
2 Active call window
3 Inactive call group
4 Soft keys
5 Main Menu key
6 Line Keys and
Speed Dial Keys
7 Speed Dial Keys
8 Line Key status indicator
Description
Displays the active call. During a video
call, the active call window can display
the near site or the far site.
Displays calls on hold, as well as
incoming calls that are not
immediately answered.
Keys on the touch screen you can tap
to access phone functions. The keys
are automatically labeled to identify
their context-sensitive functions.
Opens the Main Menu.
See Line Key in this table.
See Speed Dial Keys in this table.
Use these keys to activate up to five
speed dials that can be assigned to
your phone. Use a Speed Dial Key to
quickly dial a contact.
Speed Dial Keys display
For more information on Speed Dial
Keys, see Placing Calls Using Speed
Dial on page 3-10 and Managing
Speed Dial Keys on page 3-38.
A Line Key can have one of the
following status indicators:
• Solid green—A dial-tone is
available, dialing is in progress, or
a call is active.
• Flashing green—An incoming call.
• Solid red—A remote shared line is
active, or the buddy associated
with the Speed Dial Key has a
status that is either Offline or
Do Not Disturb.
• Flashing red—A call (one or more)
is on hold (on a private or shared
line), or the buddy associated with
the Speed Dial Key has a status
that is Busy, Be Right Back, Away,
or Out to Lunch.
.
