Page 1: Instruction Manual
Color Video Camera Instruction Manual Models : LC703 LC702 LC701 Before installing, operating or adjusting this product, please read this instruction booklet carefully and completely. - Page 2 instruction manual. The user could lose the authority CAUTION to operate this equipment if an unauthorized change or RISK OF ELECTRIC SHOCK modification is made. DO NOT OPEN REGULATORY INFORMATION: FCC Part 15 This equipment has been tested and found to comply CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK with the limits for a Class A digital device, pursuant to DO NOT REMOVE COVER (OR BACK)
- Page 3 • Holes in metal, through which insulated wires pass, Disposal of your old appliance shall have smooth well rounded surfaces or shall 1. When this crossed-out wheeled bin symbol is be provided with brushings. attached to a product it means the product is Warning: Do not install this equipment in a confined covered by the European Directive 00/96/ space such as a bookcase or similar unit.
-
Page 4: Important Safety Instructions
Important Safety Instructions 1. Read these instructions. 11. Only use attachments/accessories specified by 2. Keep these instructions. the manufacturer. 3. Heed all warnings. 12. Use only with the cart, stand, tripod, bracket, or 4. Follow all instructions. table specified by the manufacturer, or sold with 5. -
Page 5: Table Of Contents
Contents Features ......6 Privacy Mask setting ....0 Cautions for Safe Operation. -
Page 6: Features
Features This color video camera is designed for use in monitoring system. • High resolution and high sensitivity with a 1/ 4 inch EX-View CCD (Charge Coupled Device). • High magnitude of zoom lens with optical x7, Digital x1 (MAX x4) •... -
Page 7: Cautions For Safe Operation
Cautions for Safe Operation Power Supply Operating and storage location This camera must be operated DC 1V Certified/Listed, Avoid viewing a very bright object (such as light fittings) class power supply only. during an extended period. Avoid operating or storing the unit in the following locations. -
Page 8: Part Names And Functions
Part Names and Functions a Lens mount cap The cap is installed to protect the lens mount section. Remove the lens mount cap before install the camera. (sold separately) . b Camera installation bracket The bracket can be fixed at the top or bot- tom of the camera. - Page 9 Part Names and Functions Control buttons • T(TELE) button When push, picture is telephoto. • N(NEAR) button In a manual situation, focus get near. • M(MENU) button. If you want to set up a diverse function, you can push this button. •...
- Page 10 Part Names and Functions External Device Connectors • TRX -/+ Connect to an external controller of RS-485 format. • Common GND. • Alarm Output Terminal (ALARM) Connect to the alarm input of an external device. • COM (Common) • OSD/D&N OSD: Connect the external controller to control the OSD function manually.
-
Page 11: Connections
Connections Power connection Connecting Monitor Remove the insulation on the power cable as illus- The video signal connection between the camera and trated. the monitor or DVR. Attach the terminal tips. Connect to the 1V DC UL Listed, Class Power Supply only on the camera. - Page 12 Connections Connecting RS-485 Controller Connect to an external controller of RS-485 format. TRX - RS-485 Controller TRX + 5~7 mm Contact Ratings • Maximum load current is ±10mA. • Do not connect any system or device that has over 40 Vp-p (DC 0 V) bias voltage on the contact ter- minal.
- Page 13 Connections Day&Night function settings OSD function settings If you set the DAY/NIGHT option to EXT on the When you connect the "-5V" signal to the OSD/D&N [CAMERA SET] menu, you can set the D&N function terminal, the menu is displayed or the sub menu is dis- manually.
- Page 14 COMMON FOCUS (+: Near, -: Far) Connections FOCUS and ZOOM Function Settings ZOOM function You can set the FOCUS and ZOOM function manually. Using the external controller or receiver unit to control the FOCUS and ZOOM functions. COMMON FOCUS function ZOOM (+: Tele, -: Wide) COMMON FOCUS (+: Near, -: Far)
-
Page 15: Installation Of Camera
Installation of Camera The bracket can be installed to either the top of the camera as desired. When changing the position of the camera mounting bracket, you should always reuse the screws that have been removed. Note: If using a camera mounting bracket, select a location that is strong enough to bear the full weight of the camera and the mounting bracket for long periods, and install the camera and mounting bracket securely. -
Page 16: Menu Operation
Menu Operation The following table shows the list of menu items and Main Menu Sub Menu Contents options. You can adapt the camera to your require- ments by setting up the respective items in these AUTO menus. ONE PUSH INDOOR, Main Menu Sub Menu Contents... - Page 17 Menu Operation Main Menu Sub Menu Contents Main Menu Sub Menu Contents ZONE ZONE1 ~ D-DNR NUMBER ZONE4 MIDDLE ZONE STATE OFF, ON HIGH WIDTH CAMERA ID 0~55 HEIGHT D-EFFECT OFF/ V-FLIP/ MIRROR/ ROTATE MOTION DET MOVE X COLOR MOVE Y COLOR LEVEL SENSITIVITY FREEZE...
- Page 18 Menu Operation General Operation • RET: Return to the previous. • TOP: Return to the CAMERA SETTING menu Press [M] button on the rear of the camera. screen. The setup menu screen appears on the monitor. • END: Exit the setup menu. Notes: •...
-
Page 19: Focus Settings
Focus settings Focus Mode setting Automatically and then the focus mode is automati- cally changed to manual mode. • MANUAL: Focus is activated only when the N (NEAR) or F (FAR) keys on the camera is pressed. Focus Distance setting The camera adjusts the focus automatically by sensing the center of the picture. - Page 20 Focus settings Zoom Start setting Zoom End setting You can set the zoom start position of the camera. You can set the zoom end position of the camera. If When the zoom function is operated, the zoom always you set the zoom end position, the zoom is operated up will start at the selected zoom start position.
- Page 21 Focus settings Zoom Speed setting Zoom Tracking Mode setting Selects a zoom speed. Selects a zoom tracking mode. Zoom tracking means Select [ZOOM SPEED] option on the [FOCUS] menu, focused zooming state. then select a zoom speed (SLOW, MIDDLE or QUICK). Select [ZTRK MODE] option on the [FOCUS] menu, then select a zoom tracking mode (AUTO or MANUAL).
-
Page 22: Exposure Settings
Exposure settings Iris setting AGC (Automatic Gain Control) setting If the images are too dark, change the maximum [AGC] value to make the images lighter. Select [AGC] option on the [EXPOSURE] menu. Select the desired lens iris value for camera exposure. Select [IRIS] option on the [EXPOSURE] menu, then select a value. -
Page 23: Bright-
Exposure settings WDR/BLC setting • HSBLC: Use for adjusting brightness the specific area of picture. The HSBLC mode is Use WDR/BLC option to set the options for BLC or automatically activated only in low illuminance WDR camera. scene. Select [WDR/BLC] option on the [EXPOSURE] AREA SETTING: Use [N] or [F] button to menu. - Page 24 Exposure settings BRIGHTNESS setting SHUTTER (Shutter Speed) setting You can increase the brightness of the darkened video. Select the desired shutter speed for camera exposure. If you set the brightness to lower value, the image is You can change the shutter speed to higher speed darkened.
- Page 25 Exposure settings SENS-UP setting If pictures are not clear due to darkness, use for increase the sensitivity of picture. Select [SENS-UP] option on the [EXPOSURE] menu. . Use [N] or [F] button to set the SENS-UP limit (OFF, AUTO x ~ AUTO x18). To setting the SENS-UP function, select the [AUTO] on the [SHUTTER].
-
Page 26: White Balance Setting
White Balance setting Select the method by which the camera shifts its output When the scene contains mostly high color colors to compensate for the color of a light source. temperature objects, such as a blue sky or sunset. Select [WHITE BALANCE] option on the [CAMERA When the scene is dim. - Page 27 White Balance setting • MANUAL: You can set the white balance options manually. COLOR TEMP: Use [N] or [F] button to select a function. > INDOOR: The color temperature range for the proper white balance is approximately ,00°K. > OUTDOOR: The color temperature range for the proper white balance is approximately 5,100°K.
-
Page 28: Day/Night Setting
Day/Night setting Select [DAY/NIGHT] option on the [CAMERA SET] menu. D/N LEVEL: Use [N] or [F] button to select a level. Use [N] or [F] button to select mode for day/night (LOW MIDDLE HIGH) function. DWELL TIME: Use [N] or [F] button to •... -
Page 29: Motion Detection Setting
Motion Detection setting Use [T] or [W] to select an option then use [N] or The motion detection detects the moving objects in the scene by monitoring changes in brightness level. You [F] button to adjust the option can select the level of sensitivity for motion detection •... -
Page 30: Privacy Mask Setting
Privacy Mask setting Select [RESET MASK] and press [M]. If you regis- This function is aiming at the protection of personal pri- vacy, selecting a screen part black not to be displayed ter the mask zone for the first time, the mask zone in the screen. - Page 31 Privacy Mask setting • The parts with the registered mask numbers from MASK1 to MASK4 have the same color. (So do the parts with the numbers from MASK5 to MASK8). If you change the mask color, the registered mask color will be changed automatically with the same color for each of group (MASK1~4, MASK5~8).
-
Page 32: D-Dnr Setting
3D-DNR setting Select [D-DNR] option. If pictures are not clear due to brightness, use for reduce the noise of picture. Use [N] or [F] button to select a option. (OFF MIDDLE HIGH) Notes: • If you set the AGC to [OFF] on the [EXPOSURE] menu, the [D-DNR] function is not available. -
Page 33: Special Menu Settings
Special menu settings Camera Identification setting D-EFFECT (Digital effect) setting You can use the camera identification (CAMERA ID) to You can select the digital effect. assign a number to the camera. Select [D-EFFECT] option on the [SPECIAL] menu. Select [CAMERA ID] option on the [SPECIAL] menu. - Page 34 Special menu settings Color setting Freeze setting You can switch the displayed picture to grayscale or Select [FREEZE] option on the [SPECIAL] menu. color. Select [COLOR] option on the [SPECIAL] menu. Use [N] or [F] button to set up the ON or OFF. Use [N] or [F] button to change a color effect.
- Page 35 Special menu settings Sharpness setting Stabilizer setting Sharpens the image outline. Select [SHARPNESS] option on the [SPECIAL] menu. The image stabilizer function minimizes the appearance of shaky images caused by low-frequency vibration. This function is useful for outdoor surveillance. Use [N] or [F] button to change a adjust the option. If you set the sharpness value to higher, the image Select [STABILIZER] option and set to ON or OFF.
- Page 36 Special menu settings OSD setting Use [T] or [W] to select an option then use [N] or [F] button to set the option. You can set the Function On-Screen Display options • ON: Displays the Function OSD on the screen. using the [OSD] menu.
- Page 37 Special menu settings User title setting CLR: If you enter the wrong code, select CLR then press [M]. You can use the camera identification to assign a num- POS: Use [N] or [F] button to move position of ber and character to the camera (0 - 9, A-Z, a-z). USER TITLE on the screen.
- Page 38 Special menu settings Language setting Select a language for setup menu and information display.
-
Page 39: Reset Settings
Reset settings Select [RESET] option. Press [M] button and the RESET menu appears. Use [T] or [W] to select option. • FACTORY RESET: Clear certain settings and information and return to factory default set- tings. • S/W VERSION: Displays the software version on the monitor. -
Page 40: On Screen Display
On Screen Display TITLE TITLE Some of these functions will be displayed every time the camera is operated. Function Description Format None Display Zoom Trigger Mode a b c d e f g h i j k l Auto Mode Manual Mode TITLE... - Page 41 TITLE On Screen Display Function Description Function Description Format Format None Display Auto or ATW Mode D-DNR is turned None Display off. White D-DNR Manual Mode Balance D-DNR is turned Mode One Push Mode Text: A~Z, User Title User Title White 0~9, ‘-’, ‘.’, ‘...
- Page 42 On Screen Display Function Description Format None Display Color On Color On/Off Color Off Status None Display Freeze Off Freeze On/Off Freeze On Status Displays when "Set Preset preset" or "Go to + Number Status preset" function is operating. Motion Displays when the Detection motion is detected.
-
Page 43: Rs-485 Protocol
RS-485 Protocol Data Communication Format • Data Length: 1 Byte (8 Bit) • Start/Stop Bit: 1 Bit • Parity Bit: None • Baud rate: 9,600 bps Format Byte 1 Byte Byte Byte 4 Byte 5 Byte 6 Byte 7 0xE5 0x87 Camera ID... - Page 44 RS-485 Protocol Commands Function Command Description OSD On Key Action Key In E5 87 ID 60 00 14 CS Menu When OSD is being displayed, Enter into Key Out E5 87 ID 60 FF 14 CS the submenu or execute the menu item. Menu Defined Speed Tele Key Action Key In E5 87 ID 60 00 08 CS...
-
Page 45: Specification
Specification Model LC701N LC702N LC703N LC701P LC702P LC703P Signal System NTSC Total Pixels No. 811(H) X 508(V) 795(H) X 596(V) Image Device 1/4" EX-View CCD x7 Zoom ( F1.5(Wide End) , F.6(Tele End) Lens ( f = .5mm ~ 88 mm ) IRIS Control DC IRIS Sync. - Page 46 Specification Model LC701N LC702N LC703N LC701P LC702P LC703P Control Method RS485 Auto Gain Control Off / Low / Medium / High Day & Night Day / Night / Auto / Ext Electronic Shutter 1/60 ~1/90,000 1/50 ~1/90,000 White Balance Auto / ATW/ ONE PUSH / Manual Electronic Sensitivity OFF /Auto OFF / BLC /...
- Page 47 P/NO : MFL677...
