Page 1: User Manual
Indoor Vandal Resistant 10x IP PTZ Dome User Manual NY: 55 Mall Drive • Commack, NY 11725 (800) 422-6707 CA: 20521 Earl Street • Torrance, CA 90503 (800) 888-0131 www.computarganz.com... - Page 2 Warning: Do not open the case and disassemble the product. No user serviceable parts included. Please contact authorized service agent. This lightning flash with arrowhead symbol is intended to alert the user to the presence of un-insulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
- Page 3 Avoid installing in places where radiation is present. Avoid installing in places where there are strong magnetic fields and electric signals. Avoid installing in places where the camera would be subject to strong vibrations. Never expose the camera to rain and water. PT110-IP Instruction Manual...
-
Page 4: Table Of Contents
Installation using Wall Mount Bracket Installation using Flush Mount Bracket Cabling Operation Check Points before Operation Preset and Pattern Function Pre-Check Starting OSD Menu Reserved Preset Preset Swing Pattern Group Other Functions OSD Display of Main Screen PT110-IP Instruction Manual... - Page 5 Pattern Setup Group Setup System Initialize Remote Video Monitoring Remote Video Monitoring Initialize IP address IP finder in remote client IP Finder Configuration Use Internet Explorer System Video Audio Network Serial Event Preset User Specifications Specifications Dimension PT110-IP Instruction Manual...
- Page 6 CHAPTER PT110-IP Instruction Manual...
-
Page 7: Introduction
Privacy Masks are assignable, so as not to intrude on other’s privacy. (4 Privacy Zones) ‰ PTZ (Pan/Tilt/Zoom) Control With RS-485 communication, max. of 255 cameras can be controlled at the same time. Pelco-D or Pelco-P protocol can be selected as a control protocol in the current firmware version. PT110-IP Instruction Manual... - Page 8 One to One Connection and One to Multiple Connection Multi-Casting Automatic Transmission Rate Control by Network Condition ‰ User Interface System Status Display with OSD(On Screen Display) System Configuration via Internet Explorer ‰ Reliability Reliable Embedded System System Recovery with Dual Watch-Dog Function PT110-IP Instruction Manual...
-
Page 9: Product & Accessories
‰ Product & Accessories z Main Body z Surface Mount Bracket z Screws & Terminal Block z Wrench z Audio Cable & Video Cable Lan Cable ‰ Options z Flush Mount Bracket z Pendant Mount Bracket z Wall Mount Bracket PT110-IP Instruction Manual... -
Page 10: Parts Name & Functions
Fixes main unit to surface mount bracket. z Cabling Terminal Block During installation, Power, Video, Communication, Alarm Input cables are connected on to this cabling terminal block. Pull out from Surface Mount Bracket and connect to Main Body hook. z Fall-Proof Spring PT110-IP Instruction Manual... - Page 11 Reboot the network function when it is NOT working properly. z Power LED Illuminates in bright red when the power is supplied to the unit. z Audio Connection Connect to a speaker, MIC, and Ground Wire with an appropriate wire. PT110-IP Instruction Manual...
- Page 12 CHAPTER PT110-IP Instruction Manual...
-
Page 13: Installation
The range of ID is 1~255. Do not use 0 as camera ID. Factory default of Camera ID is 1. If you want to control a certain camera, you must match the camera ID with Cam ID setting of DVR or Controller. PT110-IP Instruction Manual... - Page 14 Pin 3 is only for supplier, D O NOT CHANGE THESE ITS ORIGINAL STATE . If you change one of these, proper operation cannot be achieved. ~ Pin 3 PAL / NTSC system selection of Camera. D O NOT CHANGE THIS PIN PT110-IP Instruction Manual...
- Page 15 Due to similar reasons stated in case 1, the terminal resisters of the controller and the last camera must be set to ‘ON’ state. camera with the longest cable length is determined to be the ‘last’ camera. Do not turn on the terminal resistor of all cameras. PT110-IP Instruction Manual...
-
Page 16: Direct Installation On The Ceiling
2~2.5 inch (50~60mm) hole on the screws. ceiling panel. Wire cables to terminal block and connect the Fasten main unit to surface mount bracket with terminal blocks to main unit. 4 lock-up screws. Remove protective vinyl from dome cover PT110-IP Instruction Manual... -
Page 17: Installation Using Pendant Mount Bracket
Fasten pendant mount bracket to ceiling with 3 Wire cables to terminals and connect the screws. terminals to main unit. Do not use surface mount bracket! Fasten main unit to pendant mount bracket with Remove protective vinyl from dome cover 4 screws. PT110-IP Instruction Manual... -
Page 18: Installation Using Wall Mount Bracket
Wire cables to terminals and connect the Fasten wall mount bracket to ceiling with 3 terminals to main unit. Do not use surface screws. mount bracket! Fasten main unit to wall mount bracket with 4 Remove protective vinyl from dome cover screws. PT110-IP Instruction Manual... -
Page 19: Installation Using Flush Mount Bracket
Put main body and bracket assembly into hook. Assemble and fasten with screws. main hole. Secure flush mount bracket to the ceiling Cover assembly with bracket with screws through the 3 holes on the cover and turn it clockwise. bracket. PT110-IP Instruction Manual... -
Page 20: Cabling
DC 11V ~ 18V 1.3 A ‰ RS-485 Communication For PTZ control, connect this line to keyboard and DVR. To control multiple cameras at the same time, RS-485 communication lines to cameras are connected in parallel as shown below. PT110-IP Instruction Manual... - Page 21 Normal Open and Normal Close. If the sensor type is not selected properly, alarm activation will occur opposite of what is desired. ~ Normal Open Output Voltage is high state when sensor is activated ~ Normal Close Output Voltage is high state when sensor is not activated PT110-IP Instruction Manual...
- Page 22 CHAPTER PT110-IP Instruction Manual...
-
Page 23: Check Points Before Operation
Input [Pattern Number] and press [Pattern] button for more than 2 seconds. If controller or DVR has no pattern button or function, use shortcut keys with preset numbers. For more information, refer to “Reserved Preset” in this manual. PT110-IP Instruction Manual... -
Page 24: Starting Osd Menu
: Sets OSD Display Mode to OFF (Except Privacy Mask) Go Preset [192] : Setting OSD Display Mode to ON (Except Privacy Mask) Go Preset [193] : Sets all Privacy Mask Display to OFF Go Preset [194] : Sets all Privacy Mask Display to ON PT110-IP Instruction Manual... -
Page 25: Preset
Method 1) <Run Pattern> [Swing NO.+10] ex) Run Swing 3 : <Run Pattern> [13] Method 2) <Go Preset> [Swing NO.+140] ex) Run Swing 3 : <Go Preset> [143] z Delete Swing To delete Swing, use OSD menu. PT110-IP Instruction Manual... -
Page 26: Pattern
Method 1) <Run Pattern> [Pattern NO.] ex) Run Pattern 2 : <Run Pattern> [2] Method 2) <Go Preset> [Pattern NO.+130] ex) Run Pattern 2: <Go Preset> [132] z Delete Pattern Use OSD menu to delete a Pattern. PT110-IP Instruction Manual... -
Page 27: Group
Run Group Method 1) <Run Pattern> [Group NO.+20] ex) Run Group 7 : <Run Pattern> [27] Method 2) <Go Preset> [Group NO.++150] ex) Run Group 7 : <Go Preset> [157] z Delete Group Use OSD Menu to delete. PT110-IP Instruction Manual... -
Page 28: Other Functions
This method shortens focus times. Focus mode changes to Auto Focus mode automatically when jog operation starts. PT110-IP Instruction Manual... -
Page 29: Osd Display Of Main Screen
If an Input point is OFF, will be displayed. Example - if points 2 & 3 of inputs are ON, the OSD will show as below: I:-23- z Image Flip Indicates that images are currently reversed by Auto Flip Function. PT110-IP Instruction Manual... - Page 30 CHAPTER PT110-IP Instruction Manual...
-
Page 31: How To Use Osd Menu
<DOME CAMERA SETUP> Enable/Disable of OSD display on Main Screen. <SYSTEM INITIALIZE> z Dome Camera Setup Configure various functions of this camera. EXIT z System Initialize Initializes system configuration and sets all data to factory default configuration. PT110-IP Instruction Manual... -
Page 32: Display Setup
Preset Label [ON/OFF/AUTO] z Alarm Input [ON/OFF/AUTO] ‰ Compass Direction Setup Set North to assign compass direction as criteria. Move camera and SET NORTH DIRECTION ------------------------ press NEAR button to save. MOVE TO TARGET POSITION [NEAR:SAVE /FAR:CANCEL PT110-IP Instruction Manual... -
Page 33: Privacy Zone Mask Setup
‰ Privacy Zone Size Adjustment Adjust mask size. Use joystick or arrow buttons to adjust mask size. EDIT MASK 1 ------------------------ z (Left/Right) z (Left/Right) z (Up/Down) z (Up/Down) :ADJUST MASK WIDTH] :ADJUST MASK HEIGHT] [NEAR:SAVE /FAR:CANCEL] PT110-IP Instruction Manual... -
Page 34: Camera Setup
WB SETUP - GLOBAL z WB Mode [AUTO/MANUAL] ------------------------ WB MODE AUTO In Manual mode, Red and Blue level can be ADJUST BLUE ADJUST set up manually z Red Adjust [10~60] z Blue Adjust [10~60] BACK EXIT PT110-IP Instruction Manual... - Page 35 SENS-UP [AUTO(2~128)/OFF] Activates Slow Shutter function when luminance of image (signal) is too dark. It is possible to set up the maximum number of frames stacked on one another by Slow Shutter function. PT110-IP Instruction Manual...
-
Page 36: Motion Setup
As soon as camera stops at preset end point, camera will display live images received at the preset end point. Availability of this function will vary by model. PT110-IP Instruction Manual... - Page 37 ALARM1 ACT NOT USED ALARM2 ACT NOT USED ALARM3 ACT NOT USED Sets sensor input type. ALARM4 ACT NOT USED BACK z Alarm u Action [NOT USED/PRESET 1~128] EXIT Assign counteraction Preset position to each Alarm input. PT110-IP Instruction Manual...
-
Page 38: Preset Setup
PTZ). ‰ Edit Preset Scene Using Joystick, move camera to desired position. EDIT SCENE - PRESET 1 ------------------------ By pressing NEAR key, save current PTZ data. Press FAR key to cancel. MOVE TO TARGET POSITION [NEAR:SAVE /FAR:CANCEL] PT110-IP Instruction Manual... -
Page 39: Swing Setup
2nd point, the camera will turn 360q in CW direction and then turn 360q in CCW direction. z Swing Speed [1q/sec ~180q/sec] Sets Swing speed from 1q/sec to 180q/sec. z Clear Swing [CANCEL/OK] Deletes current Swing data. PT110-IP Instruction Manual... -
Page 40: Pattern Setup
Maximum 1200 communication commands can be stored in a pattern. To save data and exit, press NEAR key. To cancel recording and [NEAR:SAVE /FAR:DELETE] 0/0/x1/N delete record data, press FAR key. PT110-IP Instruction Manual... -
Page 41: Group Setup
Sets Dwell Time between functions 5 NONE ------------------------ z OPT Option. Displays the preset speed when SAVE :MOVE CURSOR] CANCEL [ :CHANGE VAL.] preset is set in Action. Displays the number of repeats when Pattern or Swing is selected in Action PT110-IP Instruction Manual... - Page 42 EDIT GROUP 1 ------------------------ cursor should be moved to “SAVE”. Press Near key to save data. NO ACTION ### DWELL OPT ------------------------ 1 PRESET 1 00:03 360 2 NONE 3 NONE 4 NONE 5 NONE ------------------------ SAVE CANCEL PT110-IP Instruction Manual...
-
Page 43: System Initialize
Power Up Action SENS-UP AUTO Auto Flip z User Edit Data Jog Max Speed 120q/sec Jog Direction INVERSE Preset 1~128 Undefined Freeze In Preset Swing 1~8 Undefined Park Action Pattern 1~4 Undefined Alarm Action Group 1~8 Undefined PT110-IP Instruction Manual... - Page 44 CHAPTER PT110-IP Instruction Manual...
-
Page 45: Remote Video Monitoring
If an encoder’s IP address is entered on the Internet Explorer, the system will ask for confirmation to install Active-X control. Once authorized, the Internet Explorer will start to display video images from the encoder as shown below. http://192.168.10.100 PT110-IP Instruction Manual... - Page 46 Snapshot : snapshot on current live image as still cut. Talk : voice talk over connected devices. * Camera only can send sound to client. To hear the sound from camera, you should connect microphone on camera and speaker on Remote. PT110-IP Instruction Manual...
-
Page 47: Initialize Ip Address
Once the system reboots, IP address will be set to the system default as below. x IP mode x IP address Fixed IP 192.168.10.100 x Subnet mask x Gateway 255.255.255.0 192.168.10.1 x Base port x HTTP port 2222 PT110-IP Instruction Manual... -
Page 48: Ip Finder In Remote Client
-Time zone : change time zone -import setup import setup configuration files -Web connection : Connect through I.explorer. After Searching, select a device and change IP address according to your network information and connect through ‘Web Connect’. PT110-IP Instruction Manual... -
Page 49: Ip Finder Configuration
- Use DDNS : check this option when you use DDNS service. - Port : shows port numbers which required in communication. ‰ Web connect Access directly to camera with Internet Explorer and user can do remote setup. See more details on next page. PT110-IP Instruction Manual... -
Page 50: Use Internet Explorer
The configurations are grouped into 8 categories: System, Video, Audio, Network, Serial, Event, Preset and User. Any configuration changes are not applied until Apply is pressed. Leaving the page without pressing Apply button, changes in the page will be discarded. PT110-IP Instruction Manual... -
Page 51: System
Name of the NTP server should be registered on NTP server Name. synchronize with NTP server ‰ Reboot Server Pressing Reboot Server button will cause the system to reboot. Do not press the Reboot button unless the server needs a reboot. ‰ Factory Reset Back to default(factory default) PT110-IP Instruction Manual... -
Page 52: Video
Therefore, ‘Bitrate’ and ‘Quality’ corresponds to CBR and VBR respectively ‰ Resolution Selectable video compression resolution: NTSC: 720u480, 720u240, 352u480, 352u240 PAL: 720u576, 720u288, 352u576, 352u288 PT110-IP Instruction Manual... - Page 53 Controls input video saturation by selecting values between 0 and 100. ‰ Burn-in OSD Inserts system ID and date/time in the compressed video. Separately System ID and Time can be turned On or Off in the video. Position specifies the position of such data PT110-IP Instruction Manual...
-
Page 54: Audio
REMOTE VIDEO MONITORING Audio ‰ Mode Select audio operation mode Mode Action No operation Tx-Only Transmit only Rx-Only Receive only Tx & Rx Transmit and Receive ‰ Input Gain Set audio input gain PT110-IP Instruction Manual... -
Page 55: Network
REMOTE VIDEO MONITORING Network PT110-IP Instruction Manual... - Page 56 In case the server is registered with DDNS server, the registered Domain domain name is displayed Display the MAC address of the server. In case the server is Address registered with DDNS server, the MAC address is used in DDNS registration PT110-IP Instruction Manual...
-
Page 57: Serial
Set connection type with each connection information. To get detail of RS-485 connection, refer to PTZ camera’s instructions. ‰ PTZ Set PTZ type and ID according to configured setup. Serial communication information should be synchronized to Analog camera communication setup. PT110-IP Instruction Manual... -
Page 58: Event
Set mail server information to send out e-mail to specified user. Check if you will Notification include Video Clip or not. ‰ FTP upload Set FTP server to upload event triggered image data. ‰ Event Record Set PRE & POST Recording time and POST Event type. PT110-IP Instruction Manual... -
Page 59: Preset
Press Set button. Once all the presets are set, press Save List button. ‰ Move to Preset Position Select a preset from the Preset and press Go To button, then, the camera will move to the selected preset position. PT110-IP Instruction Manual... -
Page 60: User
Admin All operations User ID = admin Manager All operations except for user configuration User Live viewing and PTZ control Guest Live viewing only ‰ Add User Page for adding a user comes on pressing Add button. PT110-IP Instruction Manual... - Page 61 Skip Login is provided for convenient access to the server when authentication is not required. When Skip Login is set to Enable, login step is skipped. The privilege level after login in this way is determined by the setting of Privilege Level After Login Skipped. PT110-IP Instruction Manual...
- Page 62 CHAPTER PT110-IP Instruction Manual...
-
Page 63: Specifications
HTTPS encryption, IEEE 802.1u authentication Max 36 Channel Monitoring simultaneously PTZ Control Live Monitoring Event Monitoring Bi-directional Audio communication Time/Camera-Base/Event-Base Search/Playback Multi-channel viewing of recorded status on timeline Export to AVI file Backup Snapshot to BMP file PT110-IP Instruction Manual... -
Page 64: Specifications
‡154.5 u 158.5(H) mm Housing : Weight about 1.3 Kg Operating 0qC ~ 40qC Temp. * Specifications of this product are subject to change without notice. Flush Mount ** Check the voltage and current capacity of rated power carefully. PT110-IP Instruction Manual... -
Page 65: Dimension
SPECIFICATIONS Dimension z Main Unit & Surface Mount Bracket z Pendant Mount Bracket z Wall Mount Bracket measurement (mm) PT110-IP Instruction Manual...
