Summary of Contents for Concept Pro CBP360-HD
- Page 1 CBP360-HD CBP360-HD High Definition 360º Panoramic High Definition 360º Panoramic Camera Camera USER MANUAL USER MANUAL...
- Page 2 CAUTION This installation should be made by a qualified service person and should abide to all local codes. Avoid installation on a surface subjected to frequent vibration or shocks. Do not operate the camera beyond its temperature range or power source ratings. Should any damage or suspected damage occur, shutdown the power source, unplug and contact your service provider.
-
Page 3: Installation
INSTALLATION SURFACE MOUNT FLUSH MOUNT Ceiling Screws Ceiling Ceiling Wall plugs Fitting Screw Ceiling Cover Ceiling Screw PACKING CONTENTS Body Camera Ceiling Cover Ceiling Screws Ceiling Screws Wall Plugs Fitting Screws... - Page 4 CONNECTIONS Label1 Camera 1 CVBS(BNC) output Label2 Camera 2 CVBS(BNC) output Label3 Camera 3 CVBS(BNC) output Label4 Camera 4 CVBS(BNC) output RS485 cable Purple + / white - (Pelco D, 9600) RCA cable Audio output to speaker or DVR audio input Power cable DC12V SDI cable...
- Page 5 CONFIGURATIONS This 360° camera can be installed in many different configuration. Without DVR RS485 HDMI CABLE KEYBOARD CBP360-HD 16:9 1080p Monitor HD-SDI DVR RS485 HD-SDI HDMI / VGA KEYBOARD CBP360-HD HD-SDI DVR 16:9 1080p Monitor Analogue to HD-SDI VHD-SD4-CONV RS485...
- Page 6 DIMENSIONS...
- Page 7 OSD (On Screen Display) AE (Auto Exposure) 50Hz: PAL /60Hz:NTSC SHUTTER SPEED X3; X2; X1; AUTO; 1/100; 1/120; 1/250 Return AWB (Auto White Balance) AUTO, OFF AWC SET Return BRIGHTNESS BRIGHTNESS 1 ~ 9 SATURATION SATURATION 1 ~ 9 MD (Motion Detection) AREA ACTION ON/OFF...
-
Page 8: Noise Reduction
MASK (Privacy Zone) MASK MODE OFF/ON MASK AREA XPOS 0001~1943 YPOS 0001~1943 WIDTH 0000~1943 HEIGHT 0000~1943 RETURN COLOR TRANSP RETURN DAY/NIGHT DAY/NIGHT AUTO, DAY, NIGHT NOISE REDUCTION NOISE REDUCTION 00~99 SHOW MODE SHOW MODE WALL 0/ WALL 90/ WALL 180/ WALL 270/ DESK/ CEILING... - Page 9 PATTERN (Display Mode Option) PATTERN MODE 1~13 When you change the pattern mode, you have to wait 20 sec until the change is displayed on the monitor. SYSTEM SYSTEM CAMERA1 ON/OFF CAMERA2 ON/OFF CAMERA3 ON/OFF CAMERA4 ON/OFF AUTOFLIP ON/OFF SETID If user plans to have more than 1 device in the installation LOAD DEFAULT...
- Page 10 PATTERNS When you change the pattern mode, you have to wait 20 sec until the change is displayed on the monitor. PRESET PRESET MOTION PATTERN TOUR SEQUENCE TRACKING CAMERA 1 MODE Camera 360º 1~4 + 360º CAMERA 1 CAMERA 2 Quad + MODE 5 360º...
-
Page 11: Display Mode
PRESET PRESET MOTION PATTERN TOUR SEQUENCE TRACKING MODE 9 360º Flat 360º FLAT 180º 180º + MODE 10 CAMERA 3 CAMERA 4 Camera 3 + Camera 4 180º (0 >180º) MODE 11 180º + 180º 180º (181º >360º) CAMERA 1 CAMERA 2 Quad Display... -
Page 12: Command List
Press "SET" + "1" + "ENTER" on the keyboard (the camera OSD will display POINT1) Preset set-up may differ depending on RS485 control device. Concept Pro VA-KBDPRO+ - settings as above. Menu navigation selected by up/down - left/right joystick control. PRESET... -
Page 13: Specification
SPECIFICATION Model 360º Panoramic camera Signal System NTSC or PAL Pick up device 1/3.2” Color CMOS QSXGA(5Mega Pixel : 2592x1944) image sensor Synchronizing Internal Scanning System 2:1 Interlace S/N Ratio More than 51dB Electronic Shutter X3; X2; X1; AUTO; 1/100; 1/120; 1/250 White Balance Auto Angle of view Diagonal...
