- Page 1 CVP9324DNIR-HDA-3MP CVP9324DNIR-HDA-3MP External Dome Camera USER MANUAL...
- Page 2 CAUTION Installation should be made by a qualified service person and should adhere to all local codes. In order to prevent electric shock and avoid damage to waterproof seals, do not loosen any screws on the camera body. Adjust the sunshield to avoid exposing the lens to direct sunlight. Do not touch the front glass.
-
Page 3: Installation
INSTALLATION FIXING TO A WALL Important: Ensure all precautionary procedures are observed during installation. It is recommended the camera is tested under the most demanding environmental conditions such as low light or bright sunlight to ensure continuity of effective CCTV monitoring. - Page 4 INSTALLATION CONNECTION Connect the video out port to your video cable To assist in installation when using an running to the monitor / recorder analogue test monitor, the camera can Check the power supply is of the correct level be switched to an analogue output by and connect your power supply into the power pushing the joystick fully up for port on the Camera.
-
Page 5: On-Screen Display (Osd)
ON SCREEN DISPLAY (OSD) OSD Controller RIGHT MENU / ENTER DOWN LEFT Press and hold UP for 5 seconds. This will switch to a 960H ready output. Press and hold LEFT for 5 seconds. This will switch to the 1080p AHD output. Remove the dome cover and locate the OSD control buttons on the camera mainboard. -
Page 6: Video Setting
ON SCREEN DISPLAY (OSD) MAIN MENU ⏎ ⏎ DAY-NIGHT ⏎ VIDEO SETTING ⏎ LANGUAGE: ENGLISH, CHINESE, SPANISH, KOREAN, ITALIAN RESET ⏎ SAVE-EXIT ⏎ EXIT EXPOSURE BRIGHTNESS: 1-20 EXPOSURE MODE: GLOBE, CENTER, BLC, FLC LV (EXPOSURE MODE = BLC): GAIN: 1-16 RETURN ⏎... -
Page 7: Specification
SPECIFICATION MODEL CVP9324DNIR-HDA-3MP SENSOR 1/3" CMOS SENSOR RESOLUTION 3MP (2048x1536) SIGNAL SYSTEM PAL/NTSC SCANNING SYSTEM PROGRESSIVE SYNC. MODE Internal FRAME RATE 18fps @ 2048x1536 (TVI) 25fps @ 1920x1080 (AHD/TVI/CVI) 25fps @ 960H (CVBS) LED COUNT/TYPE 21pcs IR LED IR EFFECTIVE DISTANCE... - Page 8 SPECIFICATION MODEL CVP9324DNIR-HDA-3MP UP THE COAX CONTROL SUPPLY VOLTAGE DC12V/AC24V/AC24V POWER CONSUMPTION (MAX) 4.5W OPERATING TEMPERATURE -10°C ~ 55°C OPERATING HUMIDITY 0% ~ 85% RH DIMENSIONS Φ149 x 107mm WEIGHT 950g CERTIFICATIONS IP66/CE/FCC...
- Page 9 DIMENSIONS 46.00...
- Page 10 NOTES...
- Page 11 NOTES...
- Page 12 OCTOBER 17 Design and specification are subject to change without notice.
