- Page 1 CVP9328DNIR-IP2M-Z CVP9328DNIRLL-IP2M-Z CVP9328DNIR-IP4M-Z CVP9328DNIR-IP4M-G-Z CVP9328DNIR-IP8M-Z IP External Eyeball Camera QUICK START GUIDE QUICK START GUIDE QUICK START GUIDE Technical Documents IP CAMERA QUICK START GUIDE...
- Page 2 IP Camera x1 Allen Key x1 Quick Start Guide x1 RJ45 Waterproofing Cap x1 Fitting Screws x4 Analogue SVO Cable x1 (Except CVP9328DNIR-IP2M-Z) Wall Plugs x4 Terminal Blocks x2 (Except CVP9328DNIR-IP2M-Z) 2. INSTALLATION 1. Open Packaging FIXING TO A WALL Open packaging, remove camera, and set aside the included accessories.
- Page 3 3. CONFIGURING THE CAMERA Outer Camera Connections RJ45 10M/100M Base-T Ethernet (PoE/Video) Audio Input (except CVP9328DNIR-IP2M-Z) Audio Output (except CVP9328DNIR-IP2M-Z) DC1V Power Connector Alarm Input (except CVP9328DNIR-IP2M-Z) Alarm Output (except CVP9328DNIR-IP2M-Z) Analogue SVO (for CVP9328DNIR-IP2M-Z) DC12V Output (except CVP9328DNIR-IP2M-Z) - If using DC12V/AC24V to power the camera, ensure the power supply matches the camera power supply requirements specified and connect to the camera DC12V/AC24V power input.
- Page 4 This is highly recommended for all users to ensure proper device security. Using the Concept Pro Test Monitor (VLEDTM-TS7) Turn on the VLEDTM-TS7 test monitor and enter the IP Camera menu, then select ONVIF. ONVIF will open and automatically scan the connected network for ONVIF devices.
- Page 5 5. Troubleshooting Common Issues Answered Can’t find the camera IP address using Concept Pro Lite or other software: • Make sure Ethernet and/or DC power cables are correctly connected to the camera. • Make sure the PoE switch or DC power source meets the camera power requirements.
- Page 6 6. Caution Safety Precautions 1. This installation should be made by qualified service personnel and should adhere to all local codes. 2. Avoid installation on a surface subjected to frequent vibration or shocks. 3. Do not operate the camera beyond its specified temperature range or power source ratings.
- Page 7 7. H.265 Selecting the H.265 codec can help reduce camera bit rates while maintaining an acceptable video quality level. These compression options can result in lower network bandwidth usage and reduced storage space requirements compared to normal H.264 usage. Note: bandwidth/storage savings depend upon the stream settings and CCTV monitoring environment and results may vary.
