Summary of Contents for Concept Pro CBP4304
- Page 1 CBP4304 CBP4324 CVP9304 Colour Dome Camera USER MANUAL...
- Page 2 CAUTION This installation should be made by a qualified service person and should abide to all local codes. Avoid installation on a surface subjected to frequent vibration or shocks. Do not operate the camera beyond its temperature range or power source ratings. Should any damage or suspected damage occur, shutdown the power source, unplug and contact your service provider.
- Page 3 Replace the dome cover by pushing firmly in place onto the base Carefully clean the dome surface with a soft lint free cloth CBP4304 / 4324 PACKING CONTENTS Wall Plugs Fitting Screws Mounting Template...
- Page 4 VANDAL RESISTANT DOME INSTALLATION CVP9304 Important: Ensure all cautionary procedures are observed during installation. FIXING TO A WALL It is recommended the camera is tested during the most demanding environmental conditions such as low light or bright sunlight to ensure continuity of effective CCTV Ceiling monitoring.
- Page 5 CONNECTION Connect the video out port to your video cable running to the monitor / recorder Check the power supply is of the correct level and connect your power supply into the power port on the Camera. View the picture on a monitoring device to ...
- Page 6 CBP4304 / 4324 CVP9304 94.64 94.64 147.97 148.39 86.00 46.00...
-
Page 7: Specification
SPECIFICATION MODEL CBP4304 CBP4324 Sony Super HAD Image Sensor PAL: 500(H) x 582(V) ; NTSC: 510(H) x 494(V) Effective Pixels 420TVL Horizontal Resolution 0.3Lux/F1.2 Min. Illumination Auto Iris Vari-focal Lens Fixed Lens f=4mm lens F=4-9mm Colour Only Day & Night... - Page 8 SPECIFICATION MODEL CVP9304 Sony Super HAD Image Sensor PAL: 500(H) x 582(V) ; NTSC: 510(H) x 494(V) Effective Pixels 420TVL Horizontal Resolution 0.3Lux/F1.2 Min. Illumination Fixed Lens f=4mm Lens Colour Only Day & Night more than 48dB S/N Ratio AUTO White Balance AUTO AUTO...
- Page 9 CONCEPT PRO DOME CAMERA RANGE INTERNAL DOME CAMERAS CBP3212 480TVL, 0.3 Lux, 3.6mm Lens. 90(ø)x62mm CBP5112 420TVL, 0.3 Lux, 3.6mm Lens, 128(ø)x93mm CBP5212 480TVL, 0.3 Lux, 3.6mm Lens, 128(ø)x93mm CBP4304 420TVL, 0.3 Lux, 4mm Lens, 148(ø)x106mm CBP5314 650TVL, 0.03Lux, 4mm Lens, 148(ø)x106mm CBP4324 420TVL, 0.3 Lux, 4-9mm Lens,148(ø)x106mm...
