- Page 1 Click on the desired topic in the “Bookmarks” column or “Table of Contents” to select page.
- Page 2 Unless you are an Authorized Service Technician! © 1998 BY ELITE ACCESS SYSTEMS, INC. All rights reserved. No part of this manual may be reproduced in any means without the expressed written permission of the publisher. Materials, components and specifications are subject to change without notice.
-
Page 3: U L L I S T I N G S
L I S T I N G S L I S T I N G S L I S T I N G S A N D A N D A N D I N S T R U C T I O N S I N S T R U C T I O N S I N S T R U C T I O N S Installation Instructions Regarding the Gate Operator... - Page 4 L I S T I N G S L I S T I N G S L I S T I N G S A N D A N D A N D I N S T R U C T I O N S I N S T R U C T I O N S I N S T R U C T I O N S For a gate operator utilizing a non-contact sensor such as a photo beam:...
-
Page 5: Important Safety Instructions
L I S T I N G S L I S T I N G S L I S T I N G S A N D A N D A N D I N S T R U C T I O N S I N S T R U C T I O N S I N S T R U C T I O N S Important Safety Instructions... - Page 6 L I S T I N G S L I S T I N G S L I S T I N G S A N D A N D A N D I N S T R U C T I O N S I N S T R U C T I O N S I N S T R U C T I O N S Gate –...
- Page 7 W A R N I N G S W A R N I N G S W A R N I N G S A N D A N D A N D P R E C A U T I O N S P R E C A U T I O N S P R E C A U T I O N S Warning -...
-
Page 8: F O R I N S T A L L A T I O N
P R O C E D U R E F O R I N S T A L L A T I O N O p e n T h e I n s i d e Important: Weld Re-Bar Gate Hinge Gate Hinge Behind Gate... - Page 9 P R O C E D U R E F O R I N S T A L L A T I O N O p e n T h e O u t s i d e Important: Weld Re-Bar Gate Hinge Gate Hinge Behind Gate...
- Page 10 P R O C E D U R E F O R I N S T A L L A T I O N M o u n t i n g I n s t r u c t i o n s Step 1: Step 2: Remove the 4 screws and lift the...
- Page 11 P R O C E D U R E F O R I N S T A L L A T I O N M o u n t i n g I n s t r u c t i o n s Step 4 (con't): The gate must be in the closed position.
- Page 12 P R O C E D U R E F O R I N S T A L L A T I O N M o u n t i n g I n s t r u c t i o n s Step 8: Make sure that the operator is level or it will not function properly.
- Page 13 P R O C E D U R E F O R I N S T A L L A T I O N A d j u s t i n g t h e L i m i t S w i t c h e s Step 11: Adjust the travel distance of the gate with the limit switches.
- Page 14 R E M O V I N G T H E C O N T R O L B O A R D Unscrew the 4 Phillips head screws from the plastic cover and remove. MAGLOCK ALARM SYSTEM REVERSE SENSOR ALARM SENSOR OPEN...
-
Page 15: Wire Gauge
W I R I N G 1 O P E R A T O R T O C O N T R O L B O A R D Caution: Do Not over-bend the cord from the operator. Doing this will cause the wires to eventually break. Wire Gauge: 16 AWG / 200 Ft. - Page 16 W I R I N G O P E R A T O R S M A S T E R S L A V E Field 6 Wires from Operator in Conduit Wiring Wire Gauge: Operator 1 (Master) 16 AWG / 200 Ft. Operator 2 (Slave) Caution:...
- Page 17 C H O O S I N G G A T E M O V E M E N T D I R E C T I O N Switch the “Open Inside / Open Outside” switch on the control board to the corresponding position for the proper direction.
-
Page 18: Power Supply
C O N N E C T I N G P O W E R S U P P L Y Connect the two yellow wires from the J3 plug connector to low voltage, direct burial landscape lighting cable, 14 gauge/300 watt not exceeding 500 ft, 10 AWG up to 1000 ft. - Page 19 W I R I N G A D D I T I O N A L I N P U T S Important: Wiring at 7 and 12 will be recognized as an Open Only command, and Will Not close the gate. To Close the gate with this wiring configuration, the control board timer must be turned ON.
-
Page 20: Safety Loop
S A F E T Y A N D C E N T E R L O O P I N S T A L L A T I O N Center Loop Even with Open End of Gate Twisted Wires From Loop Cuts... -
Page 21: Installation
P H O T O C E L L I N S T A L L A T I O N To reduce the risk of injury, You must install a photocell sensor when the gate opens to less than 18” from a wall or any other object or potential entrapment installation. -
Page 22: Board Description
C O N T R O L B O A R D D E S C R I P T I O N 24 23 22 21 20 19 18 Open or Close Relay LED Board Fuse Control Relay LED Replace Charging Power Fuse LED Motor Fuse Replace Board Power Fuse LED... - Page 23 C O N T R O L B O A R D D E S C R I P T I O N M a s t e r / S l a v e Open or Close Relay LED Board Fuse Control Relay LED Replace Charging Power Fuse LED...
-
Page 24: Relay Contact Rating
A L A R M & M A G L O C K C O N N E C T I O N S Relay Contact Rating 0.5 A - 125 VAC 1 A - 24 VDC Use the harness provided with the unit to make your connections to these alarm outputs. Maglock Connection Alarm Connection UL Audio Alarm... - Page 25 A U D I O A L A R M This UL alarm is required per UL-325. It will go off after 2 consecutive events on reverse sensor. The UL alarm will sound for a period of 5 minutes or until a new command is received by one of the commands in column A but NOT column B.
- Page 26 G A T E O P E N I N G “ I N S I D E ” I N S T A L L A T I O N O F . . . MAGLOCK ALARM SYSTEM REVERSE SENSOR ALARM SENSOR...
- Page 27 G A T E O P E N I N G “ O U T S I D E ” I N S T A L L A T I O N O F . . . MAGLOCK ALARM SYSTEM REVERSE SENSOR ALARM...
- Page 28 E M E R G E N C Y K E Y R E L E A S E Step 1: To move the gate during an emergency or power failure, insert key and turn counterclockwise to Unlock the Miracle 1 from the gate. Unlock Unlock Key Provided...
- Page 29 C L O S E D E L A Y O P T I O N M a s t e r / S l a v e O n l y This option is to be used when there is a master/slave installation with overlapping gates. MASTER SLAVE SYSTEM ON...
- Page 30 C L O S E D E L A Y O P T I O N M a s t e r / S l a v e O n l y This option is to be used when there is a master/slave installation with overlapping gates. MASTER SLAVE SYSTEM ON...
-
Page 31: Troubleshooting
T R O U B L E S H O O T I N G Check the Fuses If the gate is not moving in any direction be sure to check all of the LED displays on the control board. If the board power or charging power LEDs are on, change the corresponding fuse on the right side of the board. - Page 32 T R O U B L E S H O O T I N G The Gate Will Not Close! Symptom: The radio receiver LED on the control board remains “ON” when using the remote control. Possible Solutions: Stuck remote Control Board LED control button.
-
Page 33: Incorrect Installation
T R O U B L E S H O O T I N G You will SEE the alarm LED “ON” when... MAGLOCK ALARM SYSTEM REVERSE SENSOR ALARM SENSOR OPEN OPEN INSIDE OUTSIDE REPLACE FUSE STOP BY WHEN LED IS ON POSITIVE STOP TIMER... - Page 34 CENTER OPEN LOOP LOOP ACCESS SYSTEMS INC ACCESS SYSTEMS INC MADE IN USA DC Power Adapter fits inside the Miracle-One electronic box Solar Panel Wires DC Power Adapter Elite Part # A SOLAR ADP Battery Connector from Miracle-One Connector from...
- Page 35 M I R A C L E P A R T S A BT 12 Q006 A BT MIR Q227P Q222 Q223 Q162 Q258 Q404 A POW3 Q243 Q162 Q260 Q226 Q231 Q259 Q233 Q224 Q231 Q230 Q301 Q234 Q302 Q262 Q303 Q303...
-
Page 36: Maintenance
M I R A C L E P A R T S L I S T A BT 12 - Backup Battery Q233 - Bolt, Bushing, Nut (Fits Rear Mount of Operator) A BT MIR - Plastic Rack and 2 Batteries Q234 - Bracket/Rod A POW3 - Transformer (24 VAC) Q239 - Limit Switch Harness (Wires and 4... - Page 37 M I R A C L E A C C E S S O R I E S 24V DC Radio Receiver Intercom System (Elite Part # A RM 201K) (Elite Part # 1099) Transmitters 24V Photo Electric Eye (Elite Part # 3089) (Elite Part # 3060)
-
Page 38: Mechanical Specifications
F E A T U R E S F E A T U R E S F E A T U R E S A N D A N D A N D S P E C I F I C A T I O N S S P E C I F I C A T I O N S S P E C I F I C A T I O N S Mechanical Specifications...
