First Degree Fitness Neptune Challenge AR Owner's Manual page 16

Neptune Challenge AR Rower Exploded Diagram
Upper and Lower Frame Assembly
P/N
10041 Nut Nylock M10
10082 Washer M10
60135 Bolt M10x95
60149 Spring Washer M10 5x7x2
60803 Rubber Bump Stop - Seat Rail
60804 Seat Rail End Cap 75x50
60806 Frame Tensioning Bolt M10x180
60807 Bolt M6x10
60809 Plastic Dome Cap 10mm
Main shaft Rear Bracket Bolt
71025
M10x25mm
90400 Rear Leg for Neptune
16
60809
90901
90907
10082
10041
Refer to Seat
Assembly
Description
90803
90801
QTY P/N
2 90801 Rail for Neptune
2 90803 Sensor With Lead
Seat Rail Internal Support
1 91022
Bracket - NEPAR
2 90901 Plastic Footplate
1 90902 Footplate Axle 12mmx388
Footplate Spacer Nylon
1 90903
D25xD17x19L
Internal Footplate Spacer
1 90904
17mmx1.5Tx110L
2 90905 Footplate Bolt M8x15
1 90906 Spring Washer M8x10
1 90907 Velcro Foot Strap for Neptune
1
Description
91022
QTY
1
1
1
2
1
2
1
2
2
2
